Denon AVR-E200 User manual

AVR-E200
AV SURROUND RECEIVER
Owner’s Manual
Basic instructions
Advanced instructions
Information
DVD

I
nSAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION:
To completely disconnect this product from the mains, disconnect the plug
from the wall socket outlet.
The mains plug is used to completely interrupt the power supply to the unit
and must be within easy access by the user.
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer,or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus,the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
15. Batteries shall not be exposed to excessive heat such as sunshine, fire or
the like.
FCC INFORMATION (For US customers)
1. PRODUCT
This product complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this product may not cause harmful
interference, and (2) this product must accept any interference received,
including interference that may cause undesired operation.
2. IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT
This product, when installed as indicated in the instructions contained
in this manual, meets FCC requirements. Modification not expressly
approved by Denon may void your authority, granted by the FCC, to use
the product.
3. NOTE
This product has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This product generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
product does cause harmful interference to radio or television reception,
which can be determined by turning the product OFF and ON, the user
is encouraged to try to correct the interference by one or more of the
following measures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connect the product into an outlet on a circuit different from that to
which the receiver is connected.
•Consultthelocalretailerauthorizedtodistributethistypeofproductor
an experienced radio/TV technician for help.
For Canadian customers:
This Class B digital apparatus complies with Canadian ICES-003.
CAUTION:
HOT SURFACE. DO NOT TOUCH.
The top surface over the internal heat sink may become hot
when operating this product continuously.
Do not touch hot areas, especially around the “Hot surface
mark” and the top panel.
Hot
surface
mark
Basic instructions
Advanced instructions
Information
DVD

II
nNOTES ON USE
WARNINGS
•Avoid high temperatures.
Allow for sufficient heat dispersion when installed in a rack.
•Handle the power cord carefully.
Hold the plug when unplugging the cord.
•Keep the unit free from moisture, water, and dust.
•Unplug the power cord when not using the unit for long periods of time.
•Do not obstruct the ventilation holes.
•Do not let foreign objects into the unit.
•Do not let insecticides, benzene, and thinner come in contact with the unit.
•Never disassemble or modify the unit in any way.
•Ventilation should not be impeded by covering the ventilation openings
with items, such as newspapers, tablecloths or curtains.
•Naked flame sources such as lighted candles should not be placed on
the unit.
•Observe and follow local regulations regarding battery disposal.
•Do not expose the unit to dripping or splashing fluids.
•Do not place objects filled with liquids, such as vases, on the unit.
•Do not handle the mains cord with wet hands.
•When the switch is in the OFF (STANDBY) position, the equipment is not
completely switched off from MAINS.
•The equipment shall be installed near the power supply so that the power
supply is easily accessible.
•Do not keep the battery in a place exposed to direct sunlight or in places
with extremely high temperatures, such as near a heater.
nCAUTIONS ON INSTALLATION
z z
z
Wall
z
zFor proper heat dispersal, do not install this unit in a confined
space, such as a bookcase or similar enclosure.
•More than 12 in. (0.3 m) is recommended.
Basic instructions
Advanced instructions
Information
DVD

1
Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Getting started
Basic instructions··································································3
Connections···················································································4
Important information···································································4
Connecting HDMI devices····························································5
Connecting other devices·····························································9
Connecting the power cord ························································ 14
Playback (Basic operation) ·························································15
Important information·································································15
Playing a Blu-ray Disc player/DVD player ····································16
Playing a portable player·····························································16
Tuning in radio stations·······························································17
Selecting a listening mode (Surround mode) ··························19
Standard playback·······································································20
Multi-channel stereo playback ···················································· 21
Virtual playback···········································································21
Stereo playback ··········································································21
Direct playback ···········································································21
Advanced instructions ·····················································22
Installation/connection/setup of speakers (Advanced) ··········23
Speaker installation·····································································23
Speaker connection ····································································24
Playback (Advanced operation) ·················································27
Adjusting the volume of the speakers········································27
Sleep timer function ···································································28
Quick select function··································································28
Various memory functions··························································28
How to make detailed settings··················································29
Menu map ··················································································29
Examples of menu and front display ··········································30
Inputs··························································································31
Speakers·····················································································34
General ·······················································································37
Adjusting the sound field effects················································39
Information ·················································································43
Information·············································································44
Part names and functions···························································45
Front panel··················································································45
Display ························································································46
Rear panel···················································································47
Remote control unit····································································48
Other information ·······································································50
Trademark information································································50
Surround ·····················································································51
Relationship between video signals and monitor output············53
Explanation of terms···································································54
Troubleshooting··········································································56
Resetting the microprocessor ····················································58
Specifications ··············································································58
Getting started ··············································································1
Accessories ··················································································1
Features························································································2
Cautions on handling ····································································2
Accessories
Check that the following parts are supplied with the product.
qGetting Started ........................................................................ 1
wCD-ROM (Owner’s Manual) .................................................... 1
eSafety Instructions .................................................................. 1
rWarranty (for North America model only)................................ 1
tRemote control unit (RC-1180)................................................ 1
yR03/AAA batteries................................................................... 2
uAM loop antenna ..................................................................... 1
iFM indoor antenna .................................................................. 1
oSpeaker cable label.................................................................. 1
tui
Contents
Basic instructions
Advanced instructions
Information
DVD

2
Features
With discrete circuit technology, the power
amplifier provides identical quality for all 5
channels (110 Watts x 5 channels)
For optimum realism and stunning dynamic range, the power
amplifier section features discrete power devices (not integrated
circuitry).
By using high current, high power discrete power devices, the
amplifier is able to easily drive high quality speakers.
HDMI connections enable quick connection to
various digital AV devices (4 inputs, 1 output)
(vpage5)
The unit is equipped with 4 HDMI input connectors for connecting
devices with HDMI connectors, such as a Blu-ray Disc player,
game console, HD digital camcorder, etc.
Supports HDMI (3D, Deep Color and “x.v.Color”)
(vpage8)
Advanced HDMI features are supported, including 3D passthrough,
Deep Color and “x.v.Color”.
High definition audio support
The unit is equipped with a decoder which supports high-quality
digital audio format for Blu-ray Disc players such as Dolby TrueHD,
DTS-HD Master Audio, etc.
Cautions on handling
•Before turning the power on
Check once again that all connections are correct and that there are
no problems with the connection cables.
•Power is supplied to some of the circuitry even when the unit is
set to the standby mode. When going on vacation or leaving home
for long periods of time, be sure to unplug the power cord from the
power outlet.
•About condensation
If there is a major difference in temperature between the inside of
the unit and the surroundings, condensation (dew) may form on
the operating parts inside the unit, causing the unit not to operate
properly.
If this happens, let the unit sit for an hour or two with the power
turned off and wait until there is little difference in temperature
before using the unit.
•Cautions on using mobile phones
Using a mobile phone near this unit may result in noise. If that
occurs, move the mobile phone away from this unit when it is in use.
•Moving the unit
Turn off the power and unplug the power cord from the power
outlet. Next, disconnect the connection cables to other system units
before moving the unit.
•About care
•Wipe the cabinet and control panel clean with a soft cloth.
•Follow the instructions when using a chemical cleaner.
•Benzene, paint thinner or other organic solvents as well as
insecticide may cause material changes and discoloration if brought
into contact with the unit, and should therefore not be used.
Features an PORTABLE input jack on the front
panel for connecting portable audio player
(vpage13)
Compressed Audio Restorer is Denon technology that restores
compressed music sources to their original pre-compressed quality
to give you a lively sonic ambience with greater detail and depth.
GUI overlay on HD source
You can easily make settings for your home theatre system while
viewing menus on the TV screen. These menu displays can also be
output to the monitor over HDMI.
Easy to use, screen display
Simple settings are enabled with the setting menus displayed on
the TV screen. When you control the sound volume, the volume
level is displayed on the screen, and when you switch the input
source, the name of the input source is displayed.
Basic instructions
Advanced instructions
Information
DVD

Basic instructions
3
FConnections vpage4
FPlayback (Basic operation) vpage15
FSelecting a listening mode (Surround mode) vpage19
For speaker connections, see page24.
Basic instructions
Here we explain the connections and basic operation methods for this unit.
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

4
Important information
Make connections before using this unit.
To create a home theater that can play back higher quality video and audio by fully utilizing the
capabilities of the unit and your video devices, connect the unit to each of your video devices with
HDMI cables.
nHDMI-compatible device
vpage6 vpage7 vpage7
vpage7 vpage7
If your video device does not support HDMI connections, use the following connection.
nHDMI-incompatible device
vpage10 vpage11 vpage12
vpage12
PORTABLE
vpage13 vpage13
This unit can change the source that is assigned to the DIGITAL AUDIO IN connectors.
You can change the source for connectors listed in Input connector setting within pages that
describe connections for devices.
For details on assigning a source to connectors, see “Changing the source assigned to connectors”
(vpage9). For the setting method, see “Input Assign” (vpage32).
NOTE
•The menu screen is only displayed on TV connected to this unit via HDMI. If your TV is connected
to this unit via other video output connectors, perform menu operations while seeing the display
on this unit.
•Do not plug in the power cord until all connections have been completed.
•When making connections, also refer to the operating instructions of the other devices being connected.
•Be sure to connect the left and right channels properly (left with left, right with right).
•Do not bundle power cords together with connection cables. Doing so can result in noise.
Relationship between video signals and monitor output
This unit is equipped with two types of video input connectors (HDMI and composite video) and two types
of video output connectors (HDMI and composite video).
GFlow of video signalsH
HDMI connector
Video connector
HDMI-compatible TV
HDMI connector
Video connector
HDMI connector
Video connector
HDMI connector
Video connector
Video device
This unit
Output
Input
(IN)
Output
(MONITOR OUT) Input
HDMI signal HDMI signal
Video signal Video signal
HDMI-incompatible
TV
NOTE
•The menu screen is only displayed on TV connected to this unit via HDMI. If your TV is connected
to this unit via other video output connectors, perform menu operations while seeing the display
on this unit.
•HDMI signals cannot be converted into analog signals (vpage53).
•Analog signals cannot be converted into HDMI signals (vpage53).
Connections
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

5
Connecting HDMI devices
You can connect up to five HDMI-compatible devices (4-inputs/1-output) to the this unit.
If the device connected to this unit is equipped with an HDMI connector, it is recommended to use HDMI
connections. Connections with an HDMI cable offer the following benefits that can not be achieved with
other connection methods.
•High quality playback by transmitting audio and video via digital signals
HDMI connections can transmit high definition video and high quality audio formats adopted by Blu-
ray disc players (Dolby Digital Plus, Dolby TrueHD, DTS-HD, DTS-HD Master Audio).
HDMI connections also convey information required for playback between devices. This information
is used for copyright protection and TV resolution recognition.
•Transmission of audio and video signals with a single HDMI cable
Previous connections required multiple audio and video cables, but HDMI connections require only a
single HDMI cable to transmit audio and video signals. This allows wires in a home theater system,
which tend to be complicated, to be more easily organized.
•Pass Through (vpage38)
Outputs signals received from the HDMI input connector to the TV connected to the HDMI output
connector even when the unit is in standby mode.
•This unit also supports 3D video playback and other functions related to video and audio
(vpage8).
•There is more than one version of the HDMI standard. The supported functions and the performance
vary according to the version. This unit complies with the HDMI standard that supports the 3D playback
functions. To enjoy these functions, the HDMI device connected to this unit also needs to use the same
version of the standard. For the version of the HDMI standard on the device connected to this unit, see
the device’s manual.
•Some TVs do not support audio input via HDMI connections. For details, see your TV’s manual.
•When “Pass Through” is set to other than “Off”, more power is consumed than in normal standby mode.
nConnecting this unit to a TV via HDMI connections (vpage6)
nConnecting this unit to video devices via HDMI connections (vpage7)
nHDMI function (vpage8)
nSettings related to HDMI connections (vpage8)
Examples of screen display
•Setup Menu screen •Status display screen
When the input source is
switched.
When the volume is adjusted.
Inputs
Speakers
General
Input Assign
Source Level
Input Select
Video Source
Enter Return
Setup Menu
ENTER BACK
SOURCE:CBL/SAT
MODE
:MULTI CH STEREO
[Auto]
Master Volume 29.0
Status display: The operating status appears briefly on the screen
when the input source is switched or the volume is
changed.
NOTE
•The menu screen is only displayed on TV connected to this unit via HDMI. If your TV is connected
to this unit via other video output connectors, perform menu operations while seeing the display
on this unit.
•If you operate the menu while playing back 3D video content or computer’s resolution (e.g. VGA), the
playback video is replaced by the menu screen. The playback video is not displayed behind the menu
screen.
•This unit does not show the status display while playing back 3D video content or computer’s resolution
(e.g. VGA).
Important information
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

6
Connecting HDMI devices
•Video signals are not output if the input video signals do not match the display’s resolution. In this case,
switch the Blu-ray Disc/DVD player’s resolution to a resolution with which the display is compatible.
•When this unit and monitor are connected with an HDMI cable, if the display or monitor is not compatible
with HDMI audio signal playback, only the video signals are sent to the display or monitor. Make audio
connections (vpage10 “Connecting a TV”).
NOTE
•The audio signal from the HDMI output connector (sampling frequency, number of channels, etc.) may be
limited by the HDMI audio specifications of the connected device regarding permissible inputs.
•Only an HDMI signal is output from the HDMI MONITOR OUT connector.
Connecting to a device equipped with a DVI-D connector
The DVI-D (Digital Visual Interface) method is also used for video transmission via digital signals. This is
developed mainly for computers, and some displays such as projectors are equipped with this interface. To
output HDMI video signals to a DVI-D video input compatible device, use an HDMI/DVI conversion cable
or adapter.
The DVI-D connector can transmit high quality digital video signals, but copy guard and other issues may
hinder normal operations for some device combinations.
NOTE
•No sound is output when connected to a device equipped with a DVI-D connector. Make audio
connections as described in “Connecting a TV” (vpage10).
•Signals cannot be output to DVI-D devices that do not support HDCP.
•Depending on the combination of devices, the video signals may not be output.
Connecting this unit to a TV via HDMI connections
Cables used for connections
Audio and video cable (sold separately)
HDMI cable
•This interface allows transfer of digital video signals and digital audio signals over a single HDMI cable.
IN
HDMI
TV
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

7
GFront panelH
OUT
HDMI
Video
camcorder
You can enjoy games by connecting a game machine via the AUX HDMI connector. In this case, select the
input source to “AUX”.
Connecting HDMI devices
Connecting this unit to video devices via HDMI connections
Cables used for connections
Audio and video cable (sold separately)
HDMI cable
OUT
HDMI
OUT
HDMI
OUT
HDMI
Blu-ray Disc
player /
DVD player
Set-top
box
Game
console
GRear panelH
•When this unit is connected to other devices with HDMI cables, connect this unit and TV also with an
HDMI cable.
•When connecting a device that supports Deep Color, please use a “High Speed HDMI cable” or “High
Speed HDMI cable with Ethernet”.
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

8
Settings related to HDMI connections
Set as necessary. For details, see the respective reference pages.
nHDMI (vpage38)
Make settings for HDMI.
•HDMI Audio Out •Pass Through •Pass Source
NOTE
The audio signal input from the HDMI input connector can be output as an output signal from the HDMI
output connector by setting the HDMI audio output destination to TV.
Audio signals input via the Analog/Coaxial/Optical input connectors cannot be output from the HDMI
output connector.
Connecting HDMI devices
HDMI function
This unit supports the following HDMI functions:
nAbout 3D function
This unit supports input and output of 3D (3 dimensional) video signals of HDMI.
To play back 3D video, you need a TV and player that provide support for the HDMI 3D function and a
pair of 3D glasses.
NOTE
•When playing back 3D video, refer to the instructions provided in the manual of your playback device
together with this manual.
•If you operate the menu while playing back 3D video content, the playback video is replaced by the menu
screen. The playback video is not displayed behind the menu screen.
•This unit does not show the status display while playing back 3D video content.
•If 3D video with no 3D information is input, the menu screen and status display on this unit are displayed
over the playback video.
•If 2D video is converted to 3D video on the television, the menu screen and status display on this unit
are not displayed correctly. To view the menu screen and status display on this unit correctly, turn the
television setting that converts 2D video to 3D video off.
nDeep Color (vpage54)
When a device supporting Deep Color is connected (such as an HD camcorder), use a cable compatible
with “High Speed HDMI cable” or “High Speed HDMI cable with Ethernet”.
n“x.v.Color”, sYCC601 color, Adobe RGB color, Adobe YCC601 color
(vpage54, 55)
nHigh definition digital audio format
Copyright protection system
In order to play back digital video and audio such as BD-Video or DVD-Video via HDMI connection, both
this unit and TV or the player need to support the copyright protection system known as HDCP (High-
bandwidth Digital Content Protection System). HDCP is copyright protection technology comprised of
data encryption and authentication of the connected AV devices. This unit supports HDCP.
•If a device that does not support HDCP is connected, video and audio are not output correctly. Read
the owner’s manual of your television or player for more information.
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

9
Connecting other devices
For highest quality video and surround playback, it is recommended to
use an HDMI cable to connect this unit to TV and other video devices
(vpage5 “Connecting HDMI devices”).
This section describes alternate connection methods when your
device does not support HDMI connections.
Connection methods for various devices
vpage10 vpage11
vpage12 vpage12
PORTABLE
vpage13 vpage13
Cables used for connections
Video cable (sold separately)
Video cable
Audio cable (sold separately)
Coaxial digital cable
Optical cable
Audio cable R
L
R
L
Stereo mini plug cable
Changing the source assigned to
connectors
This unit can change the source that is assigned to the DIGITAL
AUDIO IN connectors.
Here, a connection to the DVD player is taken as an example for
explanation. The rear panel digital audio input connectors do not
have the input connector indication for DVD players (DVD). However,
DIGITAL AUDIO IN connectors have the “ASSIGNABLE” indication,
which means that you can change the source assigned to these
connectors. You can assign DVD players to these connectors to use
them for DVD players. If you select “DVD” when you switch the input
source for this unit, you can play back the source connected to these
connectors.
nHow to change the source assigned to
connectors (vpage32)
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

10
a a a
VIDEOAUDIO
IN
VIDEO
OUT
COAXIAL OPTICAL
OUT
TV
or
NOTE
•The menu screen is only displayed on TV connected to this unit via HDMI. If your TV is connected
to this unit via other video output connectors, perform menu operations while seeing the display
on this unit.
•If the VIDEO input connector is to be used, be sure to connect the MONITOR output connector of the
unit and the VIDEO input connector of the TV, using a video cable.
Connecting a TV
•This section describes how to connect when your TV does not support HDMI connections.
For instructions on HDMI connections, see “Connecting HDMI devices” (vpage5).
•To listen to TV audio through this unit, use the optical digital connection.
nAudio connection
The following methods are available for connecting to this unit. Use either of the methods to make
a connection.
The numbers prefixed with connectors indicate the recommendation order. The smaller the number is,
the higher playback quality is achieved.
aDIGITAL AUDIO COAXIAL connector z
DIGITAL AUDIO OPTICAL connector
When a multichannel audio (digital bit stream audio) is input, this unit decodes the audio to play back
surround sound.
zWhen making this type of connection, you must change the settings on this unit.
(vInput connector setting )
nVideo connection
The following methods are available for connecting to this unit.
aVIDEO OUT (MONITOR) connector
This makes an analog video connection.
When making the following connection, you must change the input connector settings.
aDIGITAL AUDIO COAXIAL connector
Change the default “CBL/SAT” to “TV AUDIO”.
For how to change, see “Input Assign” (vpage32).
Input connector setting
Connecting other devices
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

11
Connecting a set-top box (Satellite tuner/Cable TV)
This section describes how to connect when your satellite tuner or cable TV does not support HDMI
connections.
For instructions on HDMI connections, see “Connecting HDMI devices” (vpage5).
nAudio connection
The following methods are available for connecting to this unit. Use either of the methods to make
a connection.
The numbers prefixed with connectors indicate the recommendation order. The smaller the number is,
the higher playback quality is achieved.
aDIGITAL AUDIO COAXIAL connector
DIGITAL AUDIO OPTICAL connector z
When a multichannel audio (digital bit stream audio) is input, this unit decodes the audio to play back
surround sound.
zWhen making this type of connection, you must change the settings on this unit.
(vInput connector setting )
sAUDIO IN (CBL/SAT) connector
This makes an analog audio connection. This type of connection converts digital audio to analog
audio, so the output audio may be degraded compared to connections a.
nVideo connection
The following methods are available for connecting to this unit.
aVIDEO IN (CBL/SAT) connector
This makes an analog video connection.
When making the following connection, you must change the input connector settings.
aDIGITAL AUDIO OPTICAL connector
Change the default “TV AUDIO” to “CBL/SAT”.
For how to change, see “Input Assign” (vpage32).
Input connector setting
Connecting other devices
a as a
R
L
R
L
AUDIO
AUDIO
RL
OUT OUT
COAXIAL OPTICAL
OUT
VIDEO
OUT
VIDEO
Satellite tuner/Cable TV
or or
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

12
a as a
R
L
R
L
AUDIO
AUDIO
RL
OUT OUT
COAXIAL OPTICAL
OUT
VIDEO
OUT
VIDEO
Blu-ray Disc player/DVD player
or or
When you want to play back HD Audio (Dolby TrueHD, DTS-HD, Dolby Digital Plus, DTS Express) and
Multi-channel PCM with this unit, use an HDMI connection (vpage5 “Connecting HDMI devices”).
Connecting a Blu-ray Disc player/DVD player
This section describes how to connect a Blu-ray Disc player and DVD player that does not support HDMI
connections.
For instructions on HDMI connections, see “Connecting HDMI devices” (vpage5).
nAudio connection
The following methods are available for connecting to this unit. Use either of the methods to make
a connection.
The numbers prefixed with connectors indicate the recommendation order. The smaller the number is,
the higher playback quality is achieved.
aDIGITAL AUDIO COAXIAL connector
DIGITAL AUDIO OPTICAL connector
When a multichannel audio (digital bit stream audio) is input, this unit decodes the audio to play back
surround sound. However, digital bit stream audio signals for HD audios from Blu-ray disc players
(such as Dolby Digital Plus and DTS-HD) can not be transmitted.
When making this type of connection, you must change the settings on this unit.
(vInput connector setting )
sAUDIO IN (DVD) connector
This makes an analog audio connection. This type of connection converts digital audio to analog
audio, so the output audio may be degraded compared to connections a.
nVideo connection
The following methods are available for connecting to this unit.
aVIDEO IN (DVD) connector
This makes an analog video connection.
When making the following connection, you must change the input connector settings.
aDIGITAL AUDIO COAXIAL connector
Change the default “CBL/SAT” to “DVD”.
DIGITAL AUDIO OPTICAL connector
Change the default “TV AUDIO” to “DVD”.
For how to change, see “Input Assign” (vpage32).
Input connector setting
Connecting other devices
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

13
Connecting an FM/AM antenna
•Connect the FM antenna or AM loop antenna supplied with the unit
to enjoy listening to radio broadcasts.
•After connecting the antenna and receiving a broadcast signal
(vpage 17 “Listening to FM/AM broadcasts”), fix the antenna
with tape in a position where the background noise level becomes
minimal and the sound quality is most clear.
w eq
FM outdoor
antenna
Direction of broadcasting station
75 Ω/ohms
coaxial cable
Ground
AM outdoor
antenna
AM loop antenna
(supplied)
Black
White
FM indoor
antenna
(supplied)
nAM loop antenna assembly
1Put the stand section
through the bottom of the
loop antenna from the
rear and bend it forward.
Stand
Square
hole
Projecting
part
Loop
antenna
2Insert the projecting part
into the square hole in
the stand.
nUsing the AM loop antenna
Suspending on a wall
Suspend directly on a wall without assembling.
Nail, tack, etc.
Standing alone
Use the procedure shown above to assemble.
NOTE
•Do not connect two FM antennas simultaneously.
•Even if an external AM antenna is used, do not disconnect the AM
loop antenna.
•Make sure the AM loop antenna lead terminals do not touch metal
parts of the panel.
•If the signal has noise interference, connect the ground terminal
(GND) to reduce noise.
•If you are unable to receive a good broadcast signal, we recommend
installing an outdoor antenna. For details, inquire at the retail store
where you purchased the unit.
Connecting a portable player
If a portable player is connected via the PORTABLE input jack of the
unit, music from the portable player can be played.
AUDIO
AUDIO
OUT
Portable
player
Connecting other devices
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

14
Connecting the power cord
After completing all the connections, insert the power plug into the power outlet.
To household power outlet
(AC 120 V, 60 Hz) Power cord
NOTE
Do not bundle power cords together with connection cables. Doing so can result in humming or noise.
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

15
Playback (Basic operation)
nPlaying a Blu-ray Disc player/DVD player
(vpage16)
nPlaying a portable player (vpage16)
nTuning in radio stations (vpage17)
Selecting a listening mode (Surround mode)
(vpage19)
nTurning the power on (vpage15)
nSelecting the input source (vpage15)
nAdjusting the master volume (vpage16)
nTurning off the sound temporarily (vpage16)
nSwitching the brightness of the display
(vpage16)
Playback (Advanced operation) (vpage27)
Important information
Before starting playback, make the connections between the different
devices and the settings on the unit.
NOTE
Also refer to the operating instructions of the connected devices
when playing them.
Turning the power on
Press POWER Xto turn on power to
the this unit.
The power indicator flashes green and the
power turns on.
You can also switch the power to standby by pressing Xon the main
unit.
nWhen power is switched to standby
Press POWER X.
GPower indicator status in standby modeH
•Normal standby : Off
•When “Pass Through” (vpage38) is set to “On” : Red
Selecting the input source
Press the input source select button
(CBL/SAT, DVD, Blu-ray, GAME,
AUX, PORTABLE, TV AUDIO or
TUNER) to be played back.
The desired input source can be selected
directly.
You can also use the following operation to select an input
source.
nSelect the input source using the main unit
Use SOURCE SELECT 01.
•Use SOURCE SELECT 01 switches the input source, as shown
below.
Blu-rayDVD
TUNERTV AUDIO AUX
CBL/SAT GAME
PORTABLE
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

16
Adjusting the master volume
Use VOLUME df to adjust the
volume.
nWhen the “Scale” setting
(vpage37) is “0 – 98”
GAdjustable rangeH 0.0 – 98.0
nWhen the “Scale” setting (vpage37) is “–79.5dB –
18.0dB”
GAdjustable rangeH – – –.– –79.5dB – 18.0dB
•The variable range differs according to the input signal and channel
level setting.
You can also operate via the main unit. In this case, perform the
following operations.
Turn MASTER VOLUME to adjust the volume.
Turning off the sound temporarily
Press MUTE :.
•“MUTE” indicator on the display flashes.
•:appears on the TV screen.
•The sound is reduced to the level set at “Mute Level” (vpage37).
•To cancel, press MUTE :again. Muting can also be cancelled by
adjusting the master volume.
Switching the brightness of the display
Press DIMMER.
•The display brightness of this unit switches
each time the button is pressed.
Bright Dim
DarkOff
Bright Normal display brightness.
Dim Reduced display brightness.
Dark Very low display brightness.
Off Turns the display off.
NOTE
When the brightness of the display is set to “Off”, the display turns
off and appears as if there is no electricity.
Playing a Blu-ray Disc player/DVD
player
The following describes the procedure for playing Blu-ray Disc player/
DVD player.
1Prepare for playback.
qTurn on the power of the TV,
subwoofer and player.
wChange the TV input to the input of
this unit.
eLoad the disc in the player.
2Press POWER Xto turn on power
to the unit.
3Press Blu-ray or DVD to switch an input source for a
player used for playback.
4Play the Blu-ray Disc player or DVD player.
•Make the necessary settings on the player (language setting,
subtitles setting, etc.) beforehand.
Playing a portable player
The following describes the procedure for playing portable player.
1Connect the portable player
to this unit (vpage 13
“Connecting a portable player”).
2Press POWER Xto turn on power
to the unit.
3Press PORTABLE to switch the
input source to “PORTABLE”.
4Play the portable player.
Important information
Basic instructions
Advanced instructions
Information
Basic instructions
DVD

17
Tuning in radio stations
For antenna connections, see “Connecting an FM/AM antenna”
(vpage13).
How to tune in
The modes for receiving FM/AM broadcasts consists of “AUTO”
mode that automatically searches available broadcast stations and
“MANUAL” mode that lets you tune in using buttons to change the
frequency. The default setting is “AUTO”.
In “AUTO” mode, you cannot tune in to radio stations if the reception
is not good. If this is the case, then use the “MANUAL” to tune in.
Listening to FM/AM broadcasts
1Press TUNER to switch the input
source to “TUNER”.
2Press BAND to select “FM” or
“AM”.
FM When listening to an FM broadcast.
AM When listening to an AM broadcast.
GTV ScreenH
TUNER
A1
Tuning
Preset
Band
Memory
Mode
FM 92.1MHz
AUTO
Now Playing
TUNE BAND
CHANNEL
MODE
MEMORY
GDisplay of this unitH
A1 FM 92.1MHz
3Tune in the desired broadcast station.
AUTO Automatically tune to the station.
qPress
MODE to select “AUTO”.
MODE:AUTO
wPress TUNE + or TUNE – to select the station you want to
hear.
•The frequency changes in steps each time the button is
pressed.
MANUAL Manually tune to the station.
qPress
MODE to select “MANUAL”.
MODE:MANUAL
wPress TUNE + or TUNE – to select the station you want to
hear.
•The frequency changes in steps each time the button is
pressed.
When tuning in stations manually, press and hold TUNE + or
TUNE – to change frequencies continuously.
nPresetting radio stations (Manual preset)
Your favorite broadcast stations can be preset so that you can tune
them in easily. Up to 56 stations can be preset.
•Stations can be preset automatically at “Auto Preset”
(vpage32). If “Auto Preset” is performed after performing
“Manual preset”, the “Manual preset” settings will be overwritten.
1Tune in the broadcast station you
want to preset.
2Press MEMORY.
GTV ScreenH
Tuning
Preset
Band
Memory
Mode TUNE
SHIFT
BAND
CHANNEL
CHANNEL
MODE
MEMORY
MEMORY
TUNER
A1
To store preset:
select
A1-G8
GDisplay of this unitH
Storing Station
3Press CHANNEL + or CHANNEL – to select the preset
number.
•Press SHIFT, and then the block (A – G) can be selected.
4Press MEMORY again to complete the setting.
•To preset other stations, repeat steps 1 to 4.
Basic instructions
Advanced instructions
Information
Basic instructions
DVD
