Denon TU-604CI - Multi-Zone Dual AM/FM Tuner User manual

29.May.2008
DENON AVR control protocol
Ver. 5.6.0
Application model : TU-604CI
Application terminal: RS-232C/ Ethernet
Connector specification
Ⅰ. RS-232C
Connector type: DB-9pin female type, slave straight connection (DCE type)
( 1pin : GND , 2pin : TxD , 3pin : RxD , 5pin : Common(GND) , 4,6,7,8,9pin : NC )
Communication format:
Synchronous system : Tone step synchronization
Communication system : A half duplex
Communication speed : 9600bps
Character length : 8 bits
Parity control : None
Start bit : 1 bit
Stop bit : 1 bit
Communication procedure : Non procedural
Communication data length : 135 bytes (maximum)
1/17

29.May.2008
Ⅱ. Ethernet
Connector type ：RJ-45(10BASE-T/100BASE-TX)
Communication format ：
Communication system : A half duplex
Communication speed : 10Mbps/100Mbps
Communication port : TCP port 23 (telnet)
Communication data length : 135bytes (maximum)
2/17

29.May.2008
<
Network Option: Standby Mode Power Saving>
(1)Press SETUP button, then Menu appears on FL-display (and GUI)
(2)Select “Option Setup > Ether Power ” or “Option Setup > RS-232C Power ”
(3)Set parameters described below.
“ON” --- Use this setting when using the TU-604CI connected in a network.
“OFF”--- Use this setting when not using the TU-604CI connected in a network.
This setting is reducing the power consumption in the standby mode.
3/17

29.May.2008
Protocol specification
The following three data forms are defined.
COMMAND : The message sent to a system(AVR) from a controller(Touch Panel etc.)
A command to a system is given from a controller.
EVENT : The message sent to a controller (Touch Panel etc.) from a system (AVR)
The result is sent, when a system is operated directly and a state changes.
*The form of EVENT presupposes that it is the same as that of COMMAND .
**Refer to the following table for the contents of COMMAND and EVENT .
RESPONSE : The message sent to a controller (Touch Panel etc.) from a system (AVR)
if the ‘request command’ (COMMAND+? +CR (0x0D)) has came from a controller.
The RESPONSE should be sent within 200ms of receiving the COMMAND .
*The form of RESPONSE presupposes that it is the same as that of EVENT .
Basic specification: The command by ASCII CODE, parameter expression
*ASCII CODE which can be used is from 0x20 to 0x7F: the alphabet and the number of 0-9, and space (0x20), some signs,
AND carriage return (0x0D) --- It is used only as a pause sign.
Command structure: COMMAND + PARAMETER + CR (0x0D)
COMMAND: ASCII CODE of 2 characters
Ex. SI : Select Input source
MS : surround Mode Setting
MV : Master Volume setting
PW : system PoWer setting
PARAMETER : ASCII CODE (up to 25 characters)
Ex. DVD : function name
SUPER STADIUM : surround mode name
*Special Parameter--- ? : for request command
4/17

29.May.2008
The example of a command * <CR> is the meaning of 0x0D.
SIDVD<CR> : Select Input source DVD
MSSTEREO<CR> : surround Mode Set to STEREO
MVUP<CR> : Master Volume UP
PWON<CR> : system PoWer ON
PWSTANDBY<CR> : system PoWer STANDBY
SI?<CR> : Request command for now playing input source >> Return RESPONSE ‘SI***<CR>’
5/17

29.May.2008
Others
A) COMMAND is receivable also during transmission of EVENT .
B) Since CHANNEL VOLUME changes simultaneously when the SURROUND MODE changes, the value of the channel volume of all channels
returns as EVENT .
C) CHANNEL VOLUME returns the data of ALL channels by the present SURROUND MODE also including an intact channel. In this case,
the data of an intact channel is set to "50".
D) Since SURROUND MODE changes simultaneously when the INPUT source changes, the SURROUND MODE (and also the value of the
channel volume of all channels , It described in B) ) returns as EVENT .
E) When SURROUND MODE is the same in between INPUT source change before and after, EVENT of SURROUND MODE and CHANNEL VOLUME
does NOT return.
F) Although EVENT of SURROUND MODE returns when the present SURROUND MODE is set up again, CHANNEL VOLUME does NOT return.
G) When SURROUND MODE is changed, before returning SURROUND MODE after change as EVENT , the present SURROUND MODE is returned.
H) The RESPONSE should be sent as opposed to the request command by all the commands with which an EVENT exists , not need to
the another request commands(ex. SV command).
I) The PARAMETER (with COMMAND and RESPONSE , EVENT ) of minimum level of MASTER VOLUME defines “99”.
J) If the MASTER VOLUME & CHANNEL VOLUME set with 0.5dB step, the PARAMETER (with COMMAND and RESPONSE , EVENT ) defines three
ASCII characters as bellows.
Ex. MASTER VOLUME = +1.0dB : MV81<CR>
+0.5dB : MV805<CR>
0dB : MV80<CR>
-0.5dB : MV795<CR>
-1.0dB : MV79<CR>
| |
-79.5dB : MV005<CR>
-80.0dB : MV00<CR>
--- : MV99<CR>
* At the **.0dB step, only uses two ASCII characters as PARAMETER , same as usual.
6/17

29.May.2008
COMMAND and PARAMETER list
COMMAND function example NA EU OTHER
PW POWER ON change PWON<CR> ✓✓✓
POWER STANDBY change PWSTANDBY<CR> ✓✓✓
Return PW Status PW?<CR> ✓✓✓
COMMAND function example NA EU OTHER
PW S* ON Each Tuner ON change PWS*ON<CR> ✓✓✓
STANDBY Each Tuner STANDBY change PWS*STANDBY<CR> ✓✓✓
?Return PW Status PWS*?<CR> ✓✓✓
S*:Slot-1=>S1 *mark is Target slot No.
COMMAND function example NA EU OTHER
SI Select source (Change Display) SITU1<CR> ✓✓✓
SITU2<CR> ✓✓✓
SITU3<CR> ✓✓✓
SITU4<CR> ✓✓✓
SITU5<CR> ✓✓✓
SITU6<CR> ✓✓✓
Return SI Status SI?<CR> ✓✓✓
?
PARAMETER
PARAMETER
PARAMETER
TU1
ON
STANDBY
?
TU2
TU3
TU4
TU5
TU6
7/17

29.May.2008
※Cursor/Enter/Menu(Setup)
COMMAND function example NA EU OTHER
MN “Cursor Up” Control MNCUP<CR> ✓✓✓
“Cursor Down” Control MNCDN<CR> ✓✓✓
“Cursor Left” Control MNCLT<CR> ✓✓✓
“Cursor Right” Control MNCRT<CR> ✓✓✓
“Enter” Control MNENT<CR> ✓✓✓
“RETURN” Control MNRTN<CR> ✓✓✓
“GUI Menu ON” Control MNMEN ON<CR> ✓✓✓
“GUI Menu OFF” Control MNMEN OFF<CR> ✓✓✓
※Remote Lock/Panel Lock
COMMAND function example NA EU OTHER
SY REMOTE CONTROL LOCK ON SYREMOTE LOCK ON<CR> ✓✓✓
REMOTE CONTROL LOCK OFF SYREMOTE LOCK OFF<CR> ✓✓✓
Return Remote Lock Status SYREMOTE LOCK ?<CR> ✓✓✓
PANEL BUTTON CONTROL LOCK ON SYPANEL LOCK ON<CR> ✓✓✓
PANEL BUTTUM CONTROL LOCK OFF SYPANEL LOCK OFF<CR> ✓✓✓
Return Panel Lock Status SYPANEL LOCK ?<CR> ✓✓✓
※Tuner Type Check
COMMAND function example NA EU OTHER
TU S* ? Return Terget Slot Tuner-Type TUS*? ✓✓✓
Return All Slot Tuner-Type TU? ✓✓✓
PARAMETER
PARAMETER
CUP
CDN
CLT
CRT
ENT
REMOTE LOCK ON
REMOTE LOCK OFF
PANEL LOCK ON
PANEL LOCK ?
?
PARAMETER
PANEL LOCK OFF
REMOTE LOCK ?
RTN
MEN ON
MEN OFF
8/17

29.May.2008
※ANALOG TUNER Control
COMMAND function example NA EU OTHER
TF S* ANUP TUNER Frequency UP TFS*ANUP<CR> ✓✓✓
ANDOWN TUNER Frequency DOWN TFS*ANDOWN<CR> ✓✓✓
AN******
(6 digits) --- ****.** kHz at AM band (>050000 is AM.)
****.** MHz at FM band (<050000 is FM.) TFS*AN105000<CR> (1050.00kHz at AM) ✓✓✓
AN? Return TF Status TFS*AN?<CR> ✓✓✓
TP S* ANUP TUNER PRESET CH UP TPS*ANUP<CR> ✓✓✓
ANDOWN TUNER PRESET CH DOWN TPS*ANDOWN<CR> ✓✓✓
AN**(PRESET No.) TUNER PRESET CH direct change to No.** TPS*ANA1<CR> (PRESET ✓✓✓
AN? Return TP Status TPS*AN?<CR> ✓✓✓
MEM TUNER PRESET MEMORY TPS*ANMEM<CR> ✓✓✓
TM S* ANAM TUNER BAND , MODE Select---Band set to AM TMS*ANAM<CR> ✓✓✓
ANFM TUNER BAND , MODE Select---Band set to FM TMS*ANFM<CR> ✓✓✓
AN? Return TM Status TMS*AN?<CR> ✓✓✓
ANAUTO ---Tuning mode set to AUTO mode TMS*ANAUTO<CR> ✓✓✓
ANMANUAL ---Tuning mode set to MANUAL mode TMS*ANMANUAL<CR> ✓✓✓
AN S* ? Return RDS Status
- PS NAME、PTY ANS*?<CR> ✓✓
TF, TP, TM COMMAND : '*' parameters can NOT operate when INPUT source isn’t TUNER.
PARAMETER
9/17

29.May.2008
※XM Control(North America model only)
COMMAND function example NA EU OTHER
TF S* XMUP XM Channel UP TFS*XMUP<CR> ✓
XMDOWN XM Channel DOWN TFS*XMDOWN<CR> ✓
XM*** (3 digits) --- ***:XM CH No. TFS*XM001<CR> (XM001 CH at ✓
XM? Return TFXM Status TFS*XM?<CR> ✓
TP S* XMUP XM PRESET CH UP TPS*XMUP<CR> ✓
XMDOWN XM PRESET CH DOWN TPS*XMDOWN<CR> ✓
XM**(PRESET No.) XM PRESET CH direct change to No.** TPS*XMA1<CR> (PRESET No.”A1”) ✓
XM? Return TPXM Status TPS*XM?<CR> ✓
XMMEM XM PRESET MEMORY TPS*XMMEM<CR> ✓
XM S* ? Return XM Status
- CHANNEL NAME, ARTIST, TITLE, SIGNAL LEVEL XMS*?<CR> ✓
PARAMETER
10/17

29.May.2008
※HD RADIO Control(North model only)
COMMAND function example NA EU OTHER
TF S* HDUP HD Channel UP TFS*HDUP<CR> ✓
HDDOWN HD Channel DOWN TFS*HDDOWN<CR> ✓
HD******
(6 digits) HD Channel direct change
--- ****.** kHz at AM band (>050000 is AM.)
****.** MHz at FM band (<050000 is FM.)
TFS*HD105000<CR>
(1050.00kHz at AM) ✓
HDMC*
(
1 di
g
it
)
---HD Multi Cast CH Select
(
*:0 〜8
)
TFS*HDMC2<CR> ✓
HD? Return TFHD Status TFS*HD?<CR> ✓
TP S* HDUP HD PRESET CH UP TPS*HDUP<CR> ✓
HDDOWN HD PRESET CH DOWN TPS*HDDOWN<CR> ✓
HD**(PRESET No.) HD PRESET CH direct change to No.** TPS*HDA1<CR> (PRESET ✓
HD? Return TPHD Status TPS*HD?<CR> ✓
HDMEM HD PRESET MEMORY TPS*HDMEM<CR> ✓
TM S* HDAM HD RADIO BAND , MODE Select---Band set to AM TMS*HDAM<CR> ✓
HDFM HD RADIO BAND , MODE Select---Band set to FM TMS*HDFM<CR> ✓
HD? Return TMHD Status TMS*HD?<CR> ✓
HDAUTOHD ---Tuning mode set to AUTO-HD mode TMS*HDAUTOHD<CR> ✓
HDAUTO ---Tuning mode set to AUTO mode TMS*HDAUTO<CR> ✓
HDMANUAL ---Tuning mode set to MANUAL mode TMS*HDMANUAL<CR> ✓
HD S* ? Return HD Status
---BAND, STATION NAME, STATION LONG NAME, MULTI CAST
CURRENT, MULTI CAST PROGRAM, SIGNAL LEVEL,ARTIST,
TITLE,ALBUM, GENRE, PROGRAM TYPE,
HDS*?<CR> ✓
PARAMETER
11/17

29.May.2008
※DAB Control(Europe model only)
COMMAND function example NA EU OTHER
TF S* DAUP DAB Channel UP TFS*DAUP<CR> ✓
DADOWN DAB Channel DOWN TFS*DADOWN<CR> ✓
DA? Return TFDAB Status TFS*DA?<CR> ✓
TP S* DAUP DAB PRESET CH UP TPS*DAUP<CR> ✓
DADOWN DAB PRESET CH DOWN TPS*DADOWN<CR> ✓
DA**(PRESET No.) DAB PRESET CH direct change to No.** TPS*DAA1<CR> (PRESET No.”A1”) ✓
DA? Return TPDAB Status TPS*DA?<CR> ✓
DAMEM DAB PRESET MEMORY TPS*DAMEM<CR> ✓
TM S* DAENS DAB MODE Select---Tuning mode set to ENSEMBLE mode TMS*DAENS<CR> ✓
DAALPHA DAB MODE Select---Tuning mode set to ALPHANUMERIC mode TMS*DAALPHA<CR> ✓
DAAS DAB MODE Select---Tuning mode set to ACTIVE STATION mode TMS*DAAS<CR> ✓
DAFS DAB MODE Select---Tuning mode set to FAVORITE STATION TMS*DA<FS> ✓
DA? Return TMDAB Status TMS*DA?<CR> ✓
DA S* ? Return DAB Status
---STATION NAME, STATION LONG NAME, ENSEMBLE NAME,
PROGRAM TYPE, CH No., FREQUENCY,MONO/STEREO, SIGNAL
DAS*?<CR> ✓
PARAMETER
12/17

29.May.2008
EVENT (or RESPONSE) and PARAMETER list
EVENT function example
PW POWER ON change PWON<CR>
POWER STANDBY change PWSTANDBY<CR>
*RES. : NOT returns '*' parameters as RESPONSE .
The PARAMETER of MV, CV EVENT : Uses two or three ASCII characters. (see page4 J) section)
EVENT function example
PW S* ON Each Tuner POWER ON change PWS*ON<CR>
STANDBY POWER STANDBY change PWS*STANDBY<CR>
S*:Slot-1=>S1 *mark is Target slot No.
*RES. : NOT returns '*' parameters as RESPONSE .
The PARAMETER of MV, CV EVENT : Uses two or three ASCII characters. (see page4 J) section)
EVENT function example
SI Select source (Change Display) SITU1<CR>
SITU2<CR>
SITU3<CR>
SITU4<CR>
SITU5<CR>
SITU6<CR>
※Tuner Type Check
EVENT function example
TU S* AN Tuner-Type is ANALOG TUNER TUS*AN
S* XM Tuner-Type is XM TUS*XM
S* HD Tuner-Type is HD RADIO TUS*HD
S* DA Tuner-Type is DAB TUS*DA
S* NO Tuner-Type is NONE TUS*NO
TU5
TU6
PARAMETER
TU1
TU2
TU3
TU4
PARAMETER
PARAMETER
ON
STANDBY
PARAMETER
13/17

29.May.2008
※Remote Lock/Panel Lock
COMMA
ND
function example
SY REMOTE CONTROL LOCK ON SYREMOTE LOCK ON<CR>
REMOTE CONTROL LOCK OFF SYREMOTE LOCK OFF<CR>
PANEL BUTTON CONTROL LOCK ON SYPANEL LOCK ON<CR>
PANEL BUTTUM CONTROL LOCK OFF SYPANEL LOCK OFF<CR>
※ANALOG TUNER Control
EVENT function example
TF S* AN******
(6 digits) TUNER Frequency change
--- ****.** kHz at AM band
****.** MHz at FM band
TFS*AN105000<CR>
(1050.00kHz at AM)
ANCMP TFS*ANCMP<CR>
TP S* AN**(PRESET No.) TUNER PRESET change to No.** TPS*ANA1<CR> (PRESET No.”A1”)
TM S* ANAM TUNER BAND change---Band set to AM TMS*ANAM<CR>
ANFM TUNER BAND change---Band set to FM TMS*ANFM<CR>
ANAUTO TUNER MODE change---Tuning mode set to AUTO mode TMS*ANAUTO<CR>
ANMANUAL TUNER MODE change---Tuning mode set to MANUAL mode TMS*ANMANUAL<CR>
AN S* PS NAME (8digit) RDS PS NAME ANS*PS NAME (8digit)<CR>
PTY (8digit) RDS Program Type ANS*PTY (8digit)<CR>
PARAMETER
PARAMETER
REMOTE LOCK ON
REMOTE LOCK OFF
PANEL LOCK ON
PANEL LOCK OFF
14/17

29.May.2008
※XM Control(North America model only)
EVENT function example
TF S* XM*** (3 digits) --- ***:XM CH No. TFS*XM001<CR> (XM001 CH)
XMCMP TFS*XMCMP<CR>
TP S* XM**(PRESET No.) XM PRESET change to No.** TPS*XMA1<CR> (PRESET No.”A1”)
XM S* CH NAME ********
(8 digit) XM CH NAME change TMS*CH NAME 20 on 20<CR>
ARTIST ****************
(16 digit) XM ARTIST NAME change TMS*ARTIST EMINEM <CR>
TITLE ****************
(16 digit) XM TITLE NAME change TMS*TITLE JUST LOSE IT <CR>
XMID ******** (8 XM RADIO ID(XM000 Selected) TMS*XMID J3JU703B<CR>
SIGNAL GOOD XM ANTENNA SIGNAL STATUS change TMS*SIGNAL GOOD<CR>
SIGNAL WEAK TMS*SIGNAL WEAK<CR>
SIGNAL MARGINAL TMS*SIGNAL MARGINAL<CR>
SIGNAL NOSIGNAL TMS*SIGNAL NOSIGNAL<CR>
PARAMETER
15/17

29.May.2008
※HD RADIO Control(North America model only)
EVENT function example
TF S* HD****** (6 digits) --- ****.** kHz at AM band (>050000 is AM.)
****.** MHz at FM band (<050000 is FM.) TPS*HD105000<CR> (1050.00kHz at AM)
HDMC*(1 digit) ---HD Multi Cast CH change(*:0〜8) TFS*HDMC2<CR>
HDCMP TFS*HDCMP<CR>
TP S* HD**(PRESET No.) HD PRESET change to No.** TPS*HDA1<CR> (PRESET No.”A1”)
TM S* HDAM HD RADIO BAND change---Band set to AM TMS*HDAM<CR>
HDFM HD RADIO BAND change---Band set to FM TMS*HDFM<CR>
HDAUTOHD HD RADIO MODE change---Tuning mode set to AUTO-HD mode TMS*HDAUTOHD<CR>
HDAUTO HD RADIO MODE change---Tuning mode set to AUTO mode TMS*HDAUTO<CR>
HDMANUAL HD RADIO MODE change---Tuning mode set to MANUAL mode TMS*HDMANUAL<CR>
HD S* ST NAME (8 digits) HD STATION NAME change HDS*ST NAME ********<CR>
STL NAME (56 digits) HD STATION LONG NAME change HDS*STL NAME (56 digits)<CR>
SIG LEV* HD ANTENNA SIGNAL STATUS change LEV0 HDS*SIG LEV0<CR>
(1 digit) HD ANTENNA SIGNAL STATUS change LEV1 HDS*SIG LEV1<CR>
HD ANTENNA SIGNAL STATUS change LEV2 HDS*SIG LEV2<CR>
HD ANTENNA SIGNAL STATUS change LEV3 HDS*SIG LEV3<CR>
HD ANTENNA SIGNAL STATUS change LEV4 HDS*SIG LEV4<CR>
HD ANTENNA SIGNAL STATUS change LEV5 HDS*SIG LEV5<CR>
HD ANTENNA SIGNAL STATUS change LEV6 HDS*SIG LEV6<CR>
MLT CURRENT* (1 digit) HD MULTI CAST CURRENT CH change HDS*MLT CURRENT*<CR>
MLT CAST CH* (1 digit) HD MULTI CAST CH change HDS*MLT CAST CH*<CR>
PTY (18 digits) HD PROGRAM TYPE change HDS*PTY (18 digits)<CR>
ARTIST(40 digits) HD ARTIST NAME change HDS*ARTIST (40 digits)<CR>
TITLE(40 digits) HD TITLE NAME change HDS*TITLE (40 digits)<CR>
ALBUM(40 digits) HD ALBUM NAME change HDS*ALBUM (40 digits)<CR>
GENRE(23 digits) HD GANRE change HDS*GENRE (23 digits)<CR>
PARAMETER
16/17

29.May.2008
※DAB Control(Europe model only)
EVENT function example
TF S* DA*** (3 digits) Channel No TFS*DA5A <CR>、TFDA12C<CR>
DACMP TFS*DACMP<CR>
TP S* DA**(PRESET No.) DAB PRESET change to No.** TPS*DAA1<CR> (PRESET No.”A1”)
TM S* DAENS DAB MODE change---Tuning mode set to ENSEMBLE mode TMS*DAENS<CR>
DAALPHA DAB MODE change---Tuning mode set to ALPHANUMERIC mode TMS*DAALPHA<CR>
DAAS DAB MODE change---Tuning mode set to ACTIVE STATION mode TMS*DAAS<CR>
DAFS DAB MODE change---Tuning mode set to FAVORITE STATION mode TMS*DAFS<CR>
DA S* ST NAME(8 digits) DAB STATION NAME change DAS*ST NAME ********<CR> (8
STL NAME(16 digits) DAB STATION LONG NAME change DAS*STL NAME (16 digits)<CR>
EN NAME(16 digits) DAB ENSEMBLE NAME change DAS*EN NAME (16 digits)<CR>
PTY (16 digits) DAB PROGRAM TYPE change DAS*PTY (16 digits)<CR>
CHANNEL*** DAB CHANNLE change DAS*5A <CR>、DA12C<CR>
FREQ*******(7 digits) DAB FREQUENCY change DAS*0174928<CR> (174.928MkHz)
MODE DAB MODE(MONO/STEREO) change DAS*MODE ST<CR>
DAB MODE(MONO/STEREO) change DAS*MODE MN<CR>
SIGNAL*** DAB SIGNAL QUALITY change DAS*SIGNAL100<CR>
TIME**：** DAB TIME display (only when request(“DAB?”) is received) DAS*TIME14:41<CR>
DATE**/**/**** DAB DATE display(only when request(“DAB?”) is received) DAS*DATE18/11/2006<CR>
(Day/Month/Year)
PARAMETER
17/17
