Desoutter SC2 User manual

www.desouttertools.com
Part no 6159946740
Issue no 10
Series C
Date 09/2017
Page 1 / 32
SC2 – SC2P – SC2-8 – SC2P8 – SC2-14 – SC2P14
SC3 – SC3P – SC3-8 – SC3P8 – SC3-14 – SC3P14
SC4 – SC4P – SC4-8 – SC4P8 – SC4-14 – SC4P14
SP3 – SP3P – SMRD60H– SMRD60HC – SMRD60HV
WARNING
To reduce the risk of injury, before using or servicing tool, read and understand the
following information as well as separately provided safety instructions
(Item number: 354343).

12
AVERTISSEMENT
Avant toute utilisation ou intervention sur l’outil, veillez à ce que les informations
suivantes ainsi que les instructions fournies dans le guide de sécurité
(Code article : 354343) aient été lues, comprises et respectées.

14
ADVERTENCIA
Antes de utilizar la herramienta o intervenir sobre ella, asegúrense de que la
información que gura a continuación, así como las instrucciones que aparecen
en la guía de seguridad (Código artículo: 354343) han sido leídas, entendidas y
respetadas.

16
WARNUNG
Werkzeuge erst benutzen, wenn die nachstehenden Hinweise und die Regeln des
Sicherheitsleitfaden (Artikel-Nr. 354343) gelesen und verstanden wurden.

18

6159946740_10
Series: C
2 / 32 09/2017
WARNING
AVVISO
Prima di qualsiasi utilizzazione o intervento sull’attrezzo, vericate che le informazioni
che seguono e le istruzioni contenute nella guida di sicurezza
(Codice articolo: 354343) siano state lette, comprese e rispettate.

20
AVISO
Antes de utilizar ou intervir na ferramenta, leia atentamente e respeite as informações
seguintes assim como as instruções fornecidas no manual de segurança
(Código artigo: 354343).

22
VARNING
Läs noga igenom dessa säkerhetsinstruktioner liksom anvisningarna i
säkerhetsguiden (Artikelkod: 354343) innan du börjar använda verktyget.

24
WAARSCHUWING
Voor gebruik of demontage van het gereedschap altijd eerst zekerstellen dat de
navolgende informatie evenals de geleverde veiligheidsinstructies
(Code artikel: 354343) gelezen, begrepen en in acht genomen zijn.

26
Find more information and your Desoutter contacts on:
Software and documentation available at:
www.desouttertools.com
http://cadles.desouttertools.com
No login/password required.

6159946740_10
Series: C
3 / 3209/2017
Fig. 1
1
Fig. 2
41
52
TECHNICAL DATA

6159946740_10
Series: C
4 / 32 09/2017
Part no 6159946740
Issue no 07
Series no C
Date 04/2012
Page 3 / 52
SC2 – SC2P – SC2-8 – SC2P8 – SC2-14 – SC2P14
SC3 – SC3P – SC3-8 – SC3P8 – SC3-14 – SC3P14
SC4 – SC4P – SC4-8 – SC4P8 – SC4-14 – SC4P14
SP3 – SP3P – SMRD60H– SMRD60HC – SMRD60HV
80
54
SC2-8 / SC2P-8
SC2-14 / SC2P-14
SP3 / SP3P
SMRD60H.
59
SC2-8/14
SC3-8/14
SC4-8/14
30
49
45
46
47
1
2
1
2
4
4
3
4
10
13
34 33
36
14
15
16
4
5
9
31
18
19
24 25
7
8
11 12
6
6
SC2 / SC3
SC4 / SP3
SC2P / SC3P
SC4P / SP3P
SMRD60H
SC2(P) / SC3(P)
SC4(P) / SP3(P)
SMRD60H
SC4-8 / SC4P-8
SMRD60HC/HV
SC3-8 / SC3P-8
SC3-14 / SC3P-14
SC2(P)-14 / SC3(P)-14
SC4(P)-14
SMRD60HV
SC2P8/14
SC3P8/14
SC4P8/14
SMRD60HC
SMRD60HV
26 / 17
4 / 17
49-80 / 45
37 / 45
33 / 24
1,5 - 1,6 N.m
2,5 - 3 N.m
7,5 - 8 N.m
2,5 - 3 N.m
0,5 - 0,7 N.m
*
"Loctite 243"
4
26
37
38
39
40
41
42
43
44
41
102
40
47
45 46
9
50 51
29
22
28
27
32
19
23
20
21 20
17
52
56 80
57
55
53
80
SP3 / SP3P
SMRD60H/HC/HV
81
Speed r/min
N° Série
6.3 bar / 90 psig max
Réf
G. RENAULT SA 44236 FRANCE
101
82
SC2 / SC2P
SC3 / SC3P
SC4 / SC4P
*
Tightening direction Kiristyssuunta
Sens de serrage Åtdragningsriktning
Sentido de apriete Tilstrammingsretning
Anziehrichtung Tilspændingsretning
Senso di serraggio Schroefrichting
Sentido de aperto Φορά σύσφιξης
SC.. SP3 SMRD60H.
rpm 10 000 10 000 10 000
W (hp) 375 (0.5) 375 (0.5) 375 (0.5)
COMPLETE TOOL

6159946740_10
Series: C
5 / 3209/2017
Part no 6159946740
Issue no 07
Series no C
Date 04/2012
Page 4 / 52
SC2 – SC2P – SC2-8 – SC2P8 – SC2-14 – SC2P14
SC3 – SC3P – SC3-8 – SC3P8 – SC3-14 – SC3P14
SC4 – SC4P – SC4-8 – SC4P8 – SC4-14 – SC4P14
SP3 – SP3P – SMRD60H– SMRD60HC – SMRD60HV
Item New part no Qty Specifics parts Description Désignation
Rep Réf. standard Qté Pièces spécifiques
1 690.79 1 SC. / SC.P / SP3 /
SP3P / SMRD60H
Retainer ring Clips de retenue
2 574.38 1 SC. / SC.P / SP3 /
SP3P / SMRD60H
Silencer Silencieux
3 658.57 1 SC. / SP3 O ring Joint torique
4 614.64 4 Screw Vis
5 307.140 1 SC. / SP3 Connector Chapeau arrière
6 656.129 1 SC. / SC.P / SP3 /
SP3P / SMRD60H
Gasket Joint
7 658.55 1 SC2P / SC3P / SC4P /
SMRD60H
O ring Joint torique
8 303.94 1 SC2P / SC3P / SC4P /
SMRD60H
Handle Poignée
9 687.29 1 SC. / SP3 / SMRD60H Retainer ring Circlips
9 687.29 2 SC.P Retainer ring Circlips
10 570.344 1 SC.P / SP3P /
SMRD60H
Isolating sleeve Manchon d'isolation
11 307.141 1 SC.-8 / SC.-14 Connector Chapeau AR
12 303.95 1 SC.P8 / SC.P14 /
SMRD60HC/HV
Handle Poignée
13 321.152 1 SC.(P) / SP3(P) /
SMRD60H
Plug Bouchon
14 658.53 1 SC.-14/ SC.P14 /
SMRD60HV
O ring Joint torique
15 321.151 1 SC.-14/ SC.P14 /
SMRD60HV
Venturi Venturi
16 658.69 1 SC.-14/ SC.P14 /
SMRD60HV
O ring Joint torique
17 566.383 1 SC. Motor housing complete
(20-23-24-25-26-27-28-31-33-34-
35)
Carter complet
(20-23-24-25-26-27-28-31-33-34-
35)
17 566.384 1 SC.P / SMRD60H/HC/
HV
Motor housing complete
(20-21-24-25-26-27-29-31-33-34-
35)
Carter complet
(20-21-24-25-26-27-29-31-33-34-
35)
18 320.119 1 SC.P / SMRD60H/HC/
HV
Lever Levier
19 637.141 2 SC.P / SMRD60H/HC/
HV
Pin Goupille
20 615 610072 0 2 Screw Vis
21 990.97 1 SC.P / SMRD60H/HC/
HV
Hinge-lever Support de levier

6159946740_10
Series: C
6 / 32 09/2017
Part no 6159946740
Issue no 07
Series no C
Date 04/2012
Page 5 / 52
SC2 – SC2P – SC2-8 – SC2P8 – SC2-14 – SC2P14
SC3 – SC3P – SC3-8 – SC3P8 – SC3-14 – SC3P14
SC4 – SC4P – SC4-8 – SC4P8 – SC4-14 – SC4P14
SP3 – SP3P – SMRD60H– SMRD60HC – SMRD60HV
22 320.122 1 SC. Lever Levier
23 312.79 1 SC. Latch Verrou de sécurité
24 317.35 1 Valve Boisseau de réglage
25 614.65 1 Adjustment screw Vis de fermeture venturi
26 314.53 1 Valve bushing Guide de poussoir
27 312.78 1 Pin-valve Poussoir
28 658.249 1 O ring Joint torique
29 658.152 1 O ring Joint torique
30 770.32 1 Ball Bille
31 656.145 1 Seat-valve Joint d'appui de bille
32 637.121 1 SC. Pin Goupille
33 618.12 1 Screw Vis
34 320.123 1 Lever-setting Levier de réglage
35 615 657005 0 3 O ring Joint torique
36 656.24 1 Gasket Joint d'admission
37 618.02 1 Screw Vis
38 645.98 1 Washer-lock Rondelle
39 350.076 1 SC2 / SC2P / SC3 /
SC3P
Counterweight Contrepoids supérieur
39 350.077 1 SP3 / SP3P Counterweight Contrepoids supérieur
39 350.079 1 SC4 / SC4P /
SMRD60H/HC/HV
Counterweight Contrepoids supérieur
40 753.71 2 Ball bearing Roulement
41 420.129 2 End plate Joue
42 434.52 3 Vane Palette
43 426.82 1 Rotor Rotor
44 400.133 1 Cylinder Cylindre
45 615 580219 0 1 SC4 / SC4P Shaft-rotor Arbre excentrique
45 615 580131 0 1 SP3 / SP3P /
SMRD60H/HC/HV
Shaft-rotor Arbre excentrique
46 615 630024 0 1 Key Clavette
47 615 350098 0 1 SP3 / SP3P Counterweight Contrepoids inférieur
47 615 350135 0 1 SC2. / SC2P. Counterweight Contrepoids inférieur
47 615 350134 0 1 SC4. / SC4P. Counterweight Contrepoids inférieur
47 615 350133 0 1 SC3. / SC3P. Counterweight Contrepoids inférieur
47 615 350099 0 1 SMRD60H/HC/HV Counterweight Contrepoids inférieur
48 666.139 1 Spacer Entretoise
49 616.66 1 SP3 / SP3P /
SMRD60H/HC/HV
Screw Vis
50 637.106 2 Pin Goupille
Item New part no Qty Specifics parts Description Désignation
Rep Réf. standard Qté Pièces spécifiques

6159946740_10
Series: C
7 / 3209/2017
Part no 6159946740
Issue no 07
Series no C
Date 04/2012
Page 6 / 52
SC2 – SC2P – SC2-8 – SC2P8 – SC2-14 – SC2P14
SC3 – SC3P – SC3-8 – SC3P8 – SC3-14 – SC3P14
SC4 – SC4P – SC4-8 – SC4P8 – SC4-14 – SC4P14
SP3 – SP3P – SMRD60H– SMRD60HC – SMRD60HV
51 399.465 1 Crankpin assy Maneton
52 350.059 1 SC.(P)-8 / SC.(P)-14 /
SP3(P) / SMRD60H/
HC/HV
Cover Support de jupe
53 640.29 4 SC.(P)-8 / SC.(P)-14 /
SMRD60H/HC/HV
Washer Rondelle
54 350.073 1 SC2 / SC2P-8/-14 Cap suction dia. 4-3/8" Jupe Ø110mm
55 350.074 1 SC3 / SC3P-8/-14 Cap suction dia. 5" Jupe Ø127mm
56 350.071 1 SC.(P) Cover Protège doigts
57 350.060 SC4-8 / SC4P8 /
SMRD60HC/HV
Cap suction dia. 6" Jupe Ø150mm
59 615 350100 0 1 SP3(P) / SMRD60H Cap suction dia. 5" Jupe Ø127mm
80 616.99 5 Screw Vis
81 615 872537 0 1 Label Etiquette
82 872.627 1 Warning label Etiquette Warning
101 615 872611 0 1 Instructions label Etiquette instructions
102 615 654036 0 2 SP3(P) / SMRD60H/
HC/HV
Felt disc Rondelle feutre
Item New part no Qty Specifics parts Description Désignation
Rep Réf. standard Qté Pièces spécifiques

6159946740_10
Series: C
8 / 32 09/2017
Part no 6159946740
Issue no 07
Series no C
Date 04/2012
Page 8 / 52
SC2 – SC2P – SC2-8 – SC2P8 – SC2-14 – SC2P14
SC3 – SC3P – SC3-8 – SC3P8 – SC3-14 – SC3P14
SC4 – SC4P – SC4-8 – SC4P8 – SC4-14 – SC4P14
SP3 – SP3P – SMRD60H– SMRD60HC – SMRD60HV
Accessories included Accessoires livrés Accesorios suministrados
Mitgeliefertes Zubehör Accessori forniti Acessórios fornecidos
Varusteet Levererade tillbehör Tilbehør som følger med
Leveret tilbehør Geleverde accessoires Παρεχόμενα εξαρτήματα
Item New part no. Qty Description Désignation
Rep Réf. standard Qté
60 6157040190 1 Air hose nipple 1/4"
for 5/16" ID hose
Busette 1/4" pour tuyau
Ø int. 8mm
61 6155952020 1 Lever Levier de serrage
SC.-14 – SC.P14
SMRD60HV
Item New part no. Qty Description Désignation
Rep Réf. standard Qté
62 6153994710 1 Aspiration kit complete Kit aspiration complet
SC2 – SC2P Item New part no. Qty Description Désignation
Rep Réf. standard Qté
63 6159901020 1 Velcro-backed pad Ø4-3/8" Plateau auto-agrippant Ø110
SC3 – SC3P Item New part no. Qty Description Désignation
Rep Réf. standard Qté
64 6159901560 1 Velcro-backed pad Ø5" Plateau auto-agrippant Ø127
61
60
62
63
64
ACCESSORIES INCLUDED

6159946740_10
Series: C
9 / 3209/2017
Part no 6159946740
Issue no 07
Series no C
Date 04/2012
Page 9 / 52
SC2 – SC2P – SC2-8 – SC2P8 – SC2-14 – SC2P14
SC3 – SC3P – SC3-8 – SC3P8 – SC3-14 – SC3P14
SC4 – SC4P – SC4-8 – SC4P8 – SC4-14 – SC4P14
SP3 – SP3P – SMRD60H– SMRD60HC – SMRD60HV
SC3-8 – SC3P8
SC3-14 – SC3P14
Item New part no. Qty Description Désignation
Rep Réf. standard Qté
65 6159901570 1 Velcro-backed pad Ø5" with
holes
Plateau auto-agrippant percé
Ø127
SC4 – SC4P
SMRD60H
Item New part no. Qty Description Désignation
Rep Réf. standard Qté
66 6159901540 1 Velcro-backed pad Ø6" Plateau auto-agrippant Ø150
SC4-8 – SC4P8
SC4-14 – SC4P14
SMRD60HC
SMRD60HV
Item New part no. Qty Description Désignation
Rep Réf. standard Qté
67 6159901550 1 Velcro-backed pad Ø6" with
holes
Plateau auto-agrippant perce
Ø150
65
66
67

6159946740_10
Series: C
10 / 32 09/2017
Part no 6159946740
Issue no 07
Series no C
Date 04/2012
Page 10 / 52
SC2 – SC2P – SC2-8 – SC2P8 – SC2-14 – SC2P14
SC3 – SC3P – SC3-8 – SC3P8 – SC3-14 – SC3P14
SC4 – SC4P – SC4-8 – SC4P8 – SC4-14 – SC4P14
SP3 – SP3P – SMRD60H– SMRD60HC – SMRD60HV
Optional accessories Accessoires en option Accesorios opcionales
Optionales Zubehör Accessori in opzione Acessórios em opção
Lisävarusteet Tillbehör som tillval Tilbehør som ekstrautstyr
Ekstra tilbehør Optionele accessoires Προαιρετικά εξαρτήματα
SC2 – SC2P Item New part no. Qty Description Désignation
Rep Réf. standard Qté
70 6155705320 1 Suspension ring (SC2P) Anneau de suspension
(SC2P)
71 6159901010 Pad-sanding Ø4-3/8" (PSA) Plateau Ø110mm vinyl
SC3 – SC3P Item New part no. Qty Description Désignation
Rep Réf. standard Qté
70 6155705320 1 Suspension ring (SC3P) Anneau de suspension
(SC3P)
72 6159901610 Pad-sanding Ø5" (PSA) Plateau Ø127mm vinyl
73 6159901620 Pad-sanding Ø5" with holes
(PSA)
Plateau perce Ø127mm vinyl
SC4 - SC4P
SMRD60H/HC/HV
Item New part no. Qty Description Désignation
Rep Réf. standard Qté
70 6155705320 1 Suspension ring (SC4P) Anneau de suspension
(SC4P)
74 6159901590 1 Pad-sanding Ø6" (PSA) Plateau Ø150mm vinyl
75 6159901600 1 Pad-sanding Ø6" with holes
(PSA)
Plateau .150mm a trous vinyl
SP3 – SP3P Item New part no. Qty Description Désignation
Rep Réf. standard Qté
64 6159901230 1 Velcro-backed pad Ø5" Plateau auto-agrippant Ø127
71
70
70
72
73
70
75
74
64
OPTIONAL ACCESSORIES
