EPA07 MBE 4000 OPERATOR'S MANUAL
To the Operator
This guide contains instructions on
the safe operation and preventive
maintenance of your Detroit
Diesel EPA07 MBE 4000 engine.
Maintenance instructions cover
routine engine services such as lube
oil and filter changes in enough detail
to permit self-servicing if desired.
The operator should become familiar
with the contents of this guide before
operating the engine or carrying out
maintenance procedures.
Power-driven equipment is only
as safe as the person operating the
controls. You are urged, as the
operator of this diesel engine, to keep
fingers and clothing away from the
revolving belts, drive shafts, etc. on
engine installation.
Throughout this guide CAUTIONS
regarding personal safety and
NOTICES regarding engine
performance or service life will
appear. To avoid personal injury and
ensure long engine service life, always
heed these instructions.
Whenever possible, it will benefit
you to rely on an authorized Detroit
Diesel® service outlet for all your
service needs from maintenance to
major parts replacement. Authorized
service outlets worldwide stock
factory original parts and have
the specialized equipment and
experienced, trained personnel
to provide prompt preventive
maintenance and skilled engine
repairs.
The information and specifications
in this publication are based on the
information in effect at the time of
approval for printing. Contact an
authorized Detroit Diesel service
outlet for information on the latest
revision. The right is reserved to
make changes at any time without
obligation.
The MBE 4000 engine is built in
accordance with sound technological
principles and based on state-of-the-art
technology.
Despite this, the engine may constitute
a risk of damage to property or injury
to persons if it is not used for its
intended purpose.
The engine should not be modified or
converted in an incorrect manner or
the safety instructions included in this
manual disregarded.
All information subject to change without notice. i
DDC-SVC-MAN-0041 Copyright © 2009 DETROIT DIESEL CORPORATION

NOTICE:
Coolant must be inhibited with the
recommended SCAs (supplemental
coolant additives) listed in the
How To section of this engine
operator's guide. In addition, the
engine can be equipped with a
coolant filter/inhibitor system as an
installed option or as an after-sale
item. Failure to check and
maintain SCA levels at required
concentrations will result in
severe damage (corrosion) to
the engine cooling system and
related components.
WARRANTY
The applicable engine warranty is
contained in the booklet “Warranty
Information for MBE 4000 Engines,”
available from authorized Detroit
Diesel service outlets.
Keep this Operator's Guide
with the engine installation at
all times. It contains important
operating, maintenance, and safety
instructions.
Trademark Information
DDC®, Detroit Diesel®, DDEC®,
Optimized Idle®, Diagnostic Link®,
reliabilt®, POWER Trac®, POWER
COOL®, and POWER GUARD®
are registered trademarks of Detroit
Diesel Corporation. Delco Remy®
is a registered trademark of Delco
Remy America, Inc. Bosch® is
a registered trademark of Robert
Bosch Company N.A. Fuel Pro®is
a registered trademarks of Davco
Manufacturing, L.L.C. Nexiq™ is
a trademark of Nexiq Technologies,
Inc. PowerBand® is a registered
trademark of Gates Rubber Company.
Tectyl® is a registered trademark of
Daubert Chemical Company, Inc.
Biobor® is a registered trademark of
United States Borax and Chemical
Corporation. DuPont® is a registered
trademark of E.I. DuPont de Nemours
and Company, Inc. All other
trademarks used are the property of
their respective owners.
ii All information subject to change without notice.
DDC-SVC-MAN-0041 Copyright © 2009 DETROIT DIESEL CORPORATION
