DEVA Broadcast DB9009-TX User manual

MAINTENANCE AND OPERATION
INSTRUCTION MANUAL
Publish Date: 20-Jun-2019
DB9009-TX
Second Generation
Multi Protocol Audio over IP Encoder

Contents
Introduction........................................................................................................................................ 5
Typographic conventions .................................................................................................................. 6
General Information.......................................................................................................................... 7
Product Features ................................................................................................................................ 8
Technical Specications .................................................................................................................. 9
Panel Indicators and Appointments............................................................................................... 11
Front Panel.................................................................................................................................... 11
Rear Panel..................................................................................................................................... 12
GPIO Connectors Pinouts............................................................................................................. 13
GPI Port Pinouts ...................................................................................................................... 13
GPI 1 Example Connection...................................................................................................... 13
RS-232 Port Pinouts................................................................................................................. 13
Block diagram ............................................................................................................................... 14
Safety Precautions............................................................................................................................ 15
Before you start ................................................................................................................................ 16
Safety warning............................................................................................................................... 16
Operating recommendations ......................................................................................................... 16
Unpacking and Inspection............................................................................................................... 17
Mounting .......................................................................................................................................... 18
Rack equipment ............................................................................................................................. 18
Heat Dissipation............................................................................................................................ 18
Radio Frequency Interference....................................................................................................... 18
Basic Setup ....................................................................................................................................... 19
Analog Audio Inputs...................................................................................................................... 19
Digital Audio Inputs...................................................................................................................... 19
LAN port........................................................................................................................................ 19
RS-232 COM Port ......................................................................................................................... 19
GPI port ........................................................................................................................................ 19
Front Panel - OLED Display, Navigational & Soft Buttons......................................................... 20
Display .......................................................................................................................................... 20
Header Area .................................................................................................................................. 20
Soft buttons.................................................................................................................................... 21
Main screen working area............................................................................................................. 21
Operating Modes and Pages ........................................................................................................... 22
Home Page .................................................................................................................................... 22
Graphs page .................................................................................................................................. 23
Levels page.................................................................................................................................... 25
Settings page ................................................................................................................................. 26
Settings menu title................................................................................................................ 26
Navigation area ................................................................................................................... 26
Numerical parameter (INT). Represents numerical value. ................................................. 27
Enumerated parameter (ENUM). ....................................................................................... 27
IP address (IP). Represents IPv4 address............................................................................ 28
IP port (PORT). Represents IP port..................................................................................... 28
String (STR). Represents string............................................................................................ 29

Date (DATE). Represent date information. ......................................................................... 29
Time (TIME). Represent time information........................................................................... 30
Timer (TIMER). Represents relative time interval............................................................... 30
Status page .................................................................................................................................... 31
About page .................................................................................................................................... 32
WEB Interface.................................................................................................................................. 33
Network Discovery ........................................................................................................................ 33
Access............................................................................................................................................ 33
WEB Interface Menu pages ............................................................................................................ 34
Status ............................................................................................................................................. 34
Settings .......................................................................................................................................... 35
Input .............................................................................................................................................. 36
Encoding ....................................................................................................................................... 37
IP Audio......................................................................................................................................... 39
IP Audio Server.................................................................................................................... 39
IP Audio Sender 1/2/3.......................................................................................................... 39
General.......................................................................................................................................... 41
Network ......................................................................................................................................... 42
Network ............................................................................................................................... 42
E-mail .................................................................................................................................. 42
HTTP Server ....................................................................................................................... 43
FTP Server .......................................................................................................................... 43
SNMP Agent ........................................................................................................................ 43
GPIO ............................................................................................................................................. 44
Other ............................................................................................................................................. 45
Firmware Update ................................................................................................................ 45
Storage ................................................................................................................................ 45
System Log .......................................................................................................................... 45
Factory Defaults ................................................................................................................. 45
Reboot Device...................................................................................................................... 45
APPENDIX A ................................................................................................................................... 46
RDS: Europe vs America .............................................................................................................. 46
The RDS System ........................................................................................................................... 46
APPENDIX B ................................................................................................................................... 47
How should I congure the connection between my DEVA Device and an FTP Client? 47
1. FTP Server Settings ......................................................................................................... 47
2. IP Router and Port Translation Settings.......................................................................... 47
3. Example of FTP Client (FileZilla) Settings .................................................................... 48
APPENDIX C.1................................................................................................................................ 49
PTY Code Description Used in RBDS Mode – North America..................................................... 49
APPENDIX C.2................................................................................................................................ 50
PTY Code Description Used in RDS Mode – Europe, Asia .......................................................... 50
WARRANTY TERMS AND CONDITIONS................................................................................. 51
Product Registration Card.............................................................................................................. 52

THIS PAGE
IS INTENTIONALLY
LEFT BLANK

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 5 -
Introduction
DEVA Broadcast Ltd. is an international communications and high-technology manufacturing
organization, its corporate headquarters and facility located in Burgas, Bulgaria. The company
serves the broadcast and corporate markets worldwide – from consumers and small businesses to
the largest global organizations. It is dedicated to the research, design, development and provision
of advanced products, systems and services. DEVA launched its own brand back in 1997 and has
nowadays evolved to become known as a market leader and internationally reputed manufacturer
of user-friendly, cost-effective and innovative broadcast products.
Creativity and innovation are deeply woven into DEVA corporate culture. Through successful
engineering, marketing and management our team of dedicated professionals creates future-
oriented solutions to improve customers’ performance. You may rely that all issues communicated
to our crew would be addressed accordingly. We pride ourselves on our pre and post-sales support
and purchase services, which along with the outstanding quality of our radio gear have won us due
respect and the market authority position.
DEVA best-of-breed solutions have become the best sellers for our partners. The strategic
partnerships which have been formed with industry leaders during all these years that we have been
operating on the broadcasting market, have proved us a reliable business partner and a valuable
asset, as our dealers worldwide would conrm. In constant pursuit of precision and long-term
satisfaction, DEVA enhances the reputation of our partners and clients alike. Furthermore, we have
already a proven merit as a credible partner provider.
Our portfolio offers complete line of high quality and competitive products for FM and Digital
Radio, Radio Networks, Telecommunication Operators and regulation authorities. For almost
two decades of intensive software and hardware development, we have achieved a unique price-
performance and endurance of our product lines. Our company’s multitude of equipment and
services is in line with the latest technologies and key trends. The most recognizable characteristics
attributed to DEVA products are their clear-cut, streamlined design, easiness of use and cost-
effectiveness: simplicity of forms but multiplicity of functions.
For us there is no stage when we deem that we have reached the most satisfactory level in our
work. Our engineers are in constant pursuit of new ideas and technologies to be captured in DEVA
solutions. Simultaneously, a strict control is being exercised at each step of any new development.
Experience and hard work are our fundament but the continuous improving process is what we
never leave aside. DEVA participates on a regular basis in all landmark broadcasting events, not
only to promote its products, but to exchange valuable know-how and experience. We are also
engaged in international large-scale projects involving radio and audio solutions which makes us
even more competitive on the global market.
All DEVA products are developed and produced in accordance with the latest ISO 9001 quality
control standards.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 6 -
Typographic conventions
This manual uses the following typographic conventions:
Style Used for
NOTE Important notes and recommendations
Example Used when example text is cited
“Menu” on page XX. References
[OK] Interface Interactive buttons.
Settings Menu paths are represented as follows: Settings> General> Backup

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 7 -
General Information
DB9009-TX is a second generation multi protocol Audio over IP Encoder, designed in line with
the latest market requirements. Designed to be user friendly in terms of operation, this device is
perfect for both inexperienced and professional broadcasters alike. DB9009-TX can work with
either analog or digital audio signal. The compressed output signal is directly transmitted over the
IP-based networks to one or more compatible IP Audio players or decoders.
Since DEVA’s products are manufactured to meet the highest standards, the encoding of the
audio sources into high quality congurable format, is made in real time by HE-AAC Versions
1 and 2 or MPEG-1 Layer 3. This in combination with the lossless uncompressed PCM stream,
unaffected by the variable network conditions, guarantees long distance audio transmission without
quality loss.
This affordable device impresses with its new and precise milled front panel, aluminum sheet
body, OLED Graphical Display and Intuitive navigation menu. The status monitoring of the audio
levels (visualized in bar graphs) and the connection information and conguration, have never
been so easy, thanks to the OLED Graphical Display and the Intuitive Navigation Menu. The Soft
Buttons indicators placed on the bottom side of the OLED display are used for navigation through
the menus and for quick access to the parameters, modes, functions and as well as for altering their
values.
Upon selecting the audio source, the encoded in real time audio will be instantly send to the
network. The new and improved DB9009-TX can act simultaneously as an Icecast compatible
Server, Icecast source client or Real Time Protocol (RTP) sender. Through the RS-232 port,
this device could be easily transformed from an Ethernet to a serial Redirector, enabling quick
integration of the existing audio systems to the Internet.
DB9009-TX offers exceptional features at an affordable price. Its trouble-free operation
guarantees long term reliability and easy rmware updates, directly on the eld or remotely via
the free of charge, password protected WEB Interface. Once installed on its operation place, this
device will be ready for the 24/7/365 operation.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 8 -
Product Features
• Excellent Audio Performances
• Easy to read OLED Graphical Display
• Intuitive Navigation Menu
• High Quality HE-AAC (v.1 and v.2) and MPEG-1 Layer 3 Codecs
• 32 kHz, 44.1 and 48 kHz sample rates support
• Up to 320 kbps under MPEG-1 Layer 3
• Up to 56 kbps under HE-AAC
• Shoutcast/Icecast compatible TCP/IP stream server (10 clients)
• Icecast Source Client functionality
• RTP Audio Compatible
• 5 LEDs and Phones output for quick diagnostics
• IP address pronunciation at startup (through the headphones)
• Full Control and easy setup via a standard web browser
• Conguration and Monitoring via SNMP Ver.2C
• UPnP for easy discovery in Local Networks
• Ethernet to RS-232 Redirector

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 9 -
TECHNICAL SPECIFICATIONS
AUDIO ENCODER
Count 2 user selectable plus 1 xed (PCM)
Codec HE-AAC (v.1 and v.2), MPEG-1 Layer 3 or raw PCM
Sample rates 32 kHz, 44.1 kHz and 48 kHz
Channels 1 or 2
Bit Rates Up to 88 kbps (HE-AAC);
Up to 320 kbps (MPEG-1);
Up to 1536 kbps (PCM)
MPEG-1 LAYER 3 SPECIFIC
Encoding mode Mono and Stereo, Joint Stereo or Dual Channel
Emphasis 50µs, CCITT J.17 or none
IP AUDIO SERVER
Type SHOUTcast/Icecast compatible TCP/IP stream server
Codec Any of the available
Count Up to 10 simultaneously connected clients
ICECAST SOURCE CLIENT
Type Icecast Source Client
Codec Any of the available
Count Up to 3 independent streams
SHOUTCAST SOURCE
Type SHOUTcast v1 Source
Codec Any of the available
Count Up to 3 independent streams
RTP SENDER
Type Unicast/Multicast RTP Sender
Codec Any of the available
Count Up to 3 independent streams
ANALOG AUDIO INPUT
Connector 2 x XLR, stereo
Type Balanced
Level +18 dBu (max. +19dBu), user selectable
Distortion <0.01% THD+N
Sample rate 32 kHz, 44.1 kHz and 48 kHz
Dynamic range 102 dB
DIGITAL AUDIO INPUT
Connector XLR
Type AES/EBU
Resampling Thru build-in sample rate converter

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 10 -
FRONT PANEL
Display High-resolution OLED
Status Indicators 5 LEDs
Headphones 1/4” (6.3mm) phones jack
USER INTERFACE
Indicators OLED display + 5 LEDs on front panel
Web interface Full control and status information
Connector RJ-45
Type Ethernet
Device discovery UPnP support
OPERATING CONDITIONS
Temperature 10°C - 45°C
Humidity < 75%, non-condensing
POWER REQUIREMENTS
Connector IEC320
Power supply 100-240V / 50-60 Hz / 25W
SIZE AND WEIGHT
Dimensions (W;H;D) 485 x 44 x 180 mm
Shipping Weight 540 x 115 x 300 mm / 2.6kg

- 11 -
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
Panel Indicators and Appointments
FRONT PANEL
1. Phones Output - The following audio signals are reproduced through the headphones:
- Voice Announcement of DB9009-TX IP Audio Encoder’s IP address upon startup;
- Audio signal from the selected input.
2. LED Indicators
- Power
- Network
- IP Audio
- MP3 Audio
- Memory
3. OLED Screen
4. Soft buttons

- 12 -
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
REAR PANEL
1
1a 2
1b
3
4
5
5a
5b 5c 6
7
1- LAN Port / Internet Input – standard RJ-45 port:
1a - Network Activity LED Indicator (RJ-45 built-in);
1b - Network Availability LED Indicator (RJ-45 built-in);
2 - SD Card;
3 - GPI;
4 - RS-232 Serial COM Port - DB-9 Female Connector;
5 - Audio section:
5a - AES/EBU - Digital Audio Input – Balanced XLR Female;
5b - Left - Analog Audio Input – Balanced XLR Female;
5c - Right - Analog Audio Input – Balanced XLR Female;
6 - Power Supply;
7 - GND.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 13 -
GPIO CONNECTORS PINOUTS
GPI Port Pinouts
GND
GPI 3 (Anode)
GPI 2 (Anode)
GPI 1 (Anode)
+12V
GND
GPI 3 (Cathode)GPI 2 (Cathode)
GPI 1 (Cathode)
1 2 3 4 5
6 7 8 9
I = 10 mA
F
I = 50 mA
Fmax
GPI 1 Example Connection
GND
1
2
6
9
+12V
49.9
470
470
RS-232 Port Pinouts
TXD
RXD
GND
12345
6789

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 14 -
BLOCK DIAGRAM
A simplied block diagram of DB9009-TX IP Audio Encoder is shown below:
A/D
ANALOG
AUDIO
L
R
WEB SERVER
STREAMING SERVER
MP3 ENCODER
HE-AAC v2 ENCODER
POWER
D/A
LAN
DIGITAL
AUDIO S/PDIF
RX
PHONE
S
DSP
RS-232
RS-232 REDIRECTOR GPI
Because of the all-digital, minimalist-discrete-component nature of device circuitry, we have
not provided schematic diagrams of the DB9009-TX in this Manual. Please, note that:
NO USER-SERVICEABLE COMPONENTS INSIDE.
REFER ALL SERVICING TO
QUALIFIED TECHNICAL PERSONNEL.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 15 -
Safety Precautions
IMPORTANT: Carefully read this paragraph as it contains important instructions concerning
operator safety and directions regarding the installation, operation and maintenance of the
equipment. Failure to observe the safety instructions and information given in this manual
constitutes an infringement of the safety rules and design specications provided for this piece
of equipment. DEVA Broadcast Ltd. declines all responsibility if any one of the safety rules given
herein is not observed. DEVA Broadcast Ltd. declines all responsibility if the end-user resells the
product. The equipment is to be used by people capable of operating it in a trouble-free manner
and it is assumed that they are aware of the following safety rules.
◊ Keep this manual with the utmost care and close at hand so that it can be consulted whenever
needed
◊ After unpacking the equipment, check its condition.
◊ Avoid banging the equipment.
◊ The packing material (plastic bags, polystyrene, nails, etc.) must never be left within reach of
children, as these items are potential sources of danger.
◊ Do not use the equipment in places where the temperature is not within the recommended
range, as specied by the manufacturer.
◊ Before connecting the equipment, make sure the nameplate specications correspond to the
mains electricity supply (the nameplate is located on the equipment enclosure).
◊ Do not remove the sticker from the equipment as it contains important specications and the
relevant serial number.
◊ To join the equipment to the mains supply, use the power cord purchased with the equipment.
◊ The equipment must be used only for the purposes it was designed for.
◊ Abuse or misuse of the equipment is extremely dangerous for people, pets and property. The
manufacturer declines all responsibility for damage and injury resulting from improper use and
mishandling.
◊ Certain basic safety rules must be observed when using electrical equipment, in particular:
- Never touch the equipment with wet and/or damp hands or other parts of the body.
- Keep the equipment away from drops of water or sprinkling systems.
- Never use the equipment near high heat sources or explosive material.
- Do not introduce any extraneous matter into the equipment.
- Do not allow children or untrained people to use the equipment.
◊ Before cleaning or servicing the equipment outside, disconnect its power supply and wait at
least 2 seconds before working on it, as recommended by current safety regulations.
◊ In the event of faults and/or improper operation, turn off the equipment, shut off the electrical
power and call your dealer.
◊ Do not attempt to make repairs and/or adjustments when covers/guards or circuit boards are to
be removed.
◊ Call your dealer for any repairs and be certain original spare parts are used. Failure to observe
this rule may adversely affect the safety level of your equipment.
◊ The equipment is to be connected to the mains supply and provided with adequate and efcient
earth conductors.
◊ When installing, leave a clearance of at least 1 cm around the equipment to allow air to pass
freely.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 16 -
Before you start
SAFETY WARNING
• The servicing of electronic equipment should be performed only by qualied personnel;
• Before removing the covers DB9009-RX must be switched off and the mains cable
unplugged;
• When the equipment is open, the power supply capacitors should be discharged using a
suitable resistor;
• Never touch the wires or the electrical circuits;
• Use insulated tools only;
• Never touch the metal connectors. They might carry high voltages;
• For removing and installing electronic components, follow the recommendations for
handling MOS components.
ATTENTION: DB9009-RX has an internal Lithium battery. Do not try to re-charge this
battery! Please contact us for detailed instructions in case the battery should be changed.
OPERATING RECOMMENDATIONS
For normal operation of DB9009-RX, we recommend following the instructions listed below.
• Install the unit in places with good air conditioning. DB9009-RX is designed to operate
within the ambient temperature range of 10 to 50°C. The equipment rack should be
ventilated in order for the device to keep its internal temperature below the maximum
ambient temperatures;
• We do not recommend installation in rooms with high humidity, dusty places or other
aggressive conditions;
• Locate the device away from abnormally high RF elds;
• Use only checked power supply cables. We strongly recommend the usage of shielded
cables;
• Connect DB9009-RX only to reliable power supply sources. In case of unstable power
supply, please use Uninterruptible Power Supply (UPS);
• Use the device only with its top cover on to avoid electromagnetic anomalies. Otherwise,
this may cause problems with the normal functionality of the unit;
• For the normal remote operation of the unit, connect DB9009-RX to a good quality Internet
connection;
• For the normal operation of DB9009-RX, check if the network settings past through all the
required data trafc.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 17 -
Unpacking and Inspection
Upon receipt, the equipment should be inspected for possible shipping damages. If such are
found or suspected, notify the carrier at once and contact DEVA Broadcast Ltd. The original
shipping carton box and packing materials should be kept for possible reuse, in case of return for
Warranty repair, for example. Shipping damages as a result of improper packing for return may
invalidate the Warranty!
IT IS VERY IMPORTANT that the “Product Registration Card” on page 52 included in the
Manual be completed accurately and returned. This will assure coverage of the terms of the
Warranty and it will provide a means of trace in case of lost or stolen equipment. In addition, the
user will automatically receive SERVICE OR MODIFICATION INSTRUCTIONS from DEVA
Broadcast Ltd.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 18 -
Mounting
RACK EQUIPMENT
The DB9000-TX mounts in a standard 19-inch equipment rack and requires only 1¾ inches
(1U) of vertical rack space. The use of plastic washers is recommended to protect the painted nish
around the mounting holes.
HEAT DISSIPATION
Having very low electricity consumption, the DB9009-RX itself generates negligible heat.
The unit is intended for operation within an ambient temperature range, extending from freezing
to 120°F/50°C. But because adjacent, less efcient equipment may radiate substantial heat, be
sure that the equipment rack is adequately ventilated to keep its internal temperature below the
specied maximum ambient.
RADIO FREQUENCY INTERFERENCE
Although we have made provision for DB9009-RX installation in the immediate proximity of
broadcast transmitters, please do practice some care using the unit near abnormally high RF elds.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 19 -
Basic Setup
ANALOG AUDIO INPUTS
Using a cable ending with two standard XLR jacks connect the analog signal source to the
analog audio inputs of DB9009-TX.
WARNING: Do not exceed maximum input level. This may permanently damage the device.
DIGITAL AUDIO INPUTS
Using a cable ending with a standard XLR jacks connect the S/PDIF signal source to the digital
audio input of DB9009-TX.
NOTE: As only one input can be managed by the encoder at certain point of time, please select
the preferred signal source input – either analog or digital one. Selecting the preferred input can be
performed under CONFIGURATION menu (see “Input” on page 36).
LAN PORT
For normal operation it is necessary the encoder to be connected to a local network or Internet
by cable with RJ-45 connector.
RS-232 COM PORT
Using standart DB-9 cable connect DB9009-TX to any RS-232 compatible equipment.
GPI PORT
The current audio source can be selected/forced using this GPI port.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 20 -
Front Panel - OLED Display,
Navigational & Soft Buttons
DISPLAY
The DB9009-TX’s OLED display has three function areas: Header, Soft Buttons and Main
Screen Working area.
HEADER AREA
Header is located on the left quarter of the screen. Depending on contents of working area the
header may contains the following items:
2
1
3
4
5
6
7
8 9
1. Indicator to show the Left signal audio level
2. Indicator to show the Right signal audio level
3. Selected input - analog or digital
4. Settings applied to Encoder 1
5. Settings applied to Encoder 2
6. SRV (IP Audio Server) – indicates if there are any clients connected.
7. S1, S2, S3 (IP Audio Sender 1/2/3) – indicates if the IP Audio Sender is currently active.
8. Main input (Analog and Digital) levels
9. Connections list – displays a list of all active connections.
