DEVA Broadcast DB5000 Instruction manual

DEVA Broadcast Limited is an ISO 9001:2008 certified company.
65 Aleksandar Stamboliyski Str., 8000 Burgas, Bulgaria
Tel.: [phone], Fax: [phone]
Email: [email protected], Web: www.devabroadcast.com
DB5000
RDS/RBDS Radio Data Decoder with
TCP/IP, COM & USB Connectivity
Quick User Guide
BEFORE YOU USE THIS PRODUCT
In order to be able to enjoy all the benefits of owning your new
DEVA product, please verify first that the latest software and
firmware release were installed.
Visit www.devabroadcast.com/downloads
recent software and firmware downloads, prior the installation.
for the most

This Quick user guide will make the installation of DB5000 -
TCP/IP, COM & USB Connectivity quick and easy. Following these steps will simplify the process and may
save you extra time and effort. For more information about the Safety precautions and the Operating
environment recommendations please refer to the User Manual.
RDS/RBDS Radio Data Decoder with
1. Install the unit on its operation place;
2. Connect the unit via grounding cable to the ground network of the room space where the unit is installed;
3. Connect the device to the power supply network using the provided power cable;
4. Connect the antenna cable to the RF antenna input connector located on the rear panel of the device;
5. Connect DB5000 to the TCP/IP network using a direct network cable.
DB5000 supports TCP/IP, COM & USB Connectivity. The "Device Manager Software" maintains each
of the connections independently. The device prevents simultaneous connections. The priority of each
connection is controlled by the device, not from the software. The connection priority in ascending order is:
TCP/IP, COM and USB (The USB connection is with the highest priority).
For example, if a connection with lower priority is used any other connection with higher priority
implicates the lower priority connection will be disconnected. Once disconnected, the reconnecting must
be managed manually.
In order to avoid hardware conflicts and connection problems, install the software before connecting
the device to the computer.
1. Use the Installation file which can be found on the supplied CD or downloaded from
www.devabroadcast.com/downloads;
2. The software has an "AutoRun" utility and will automatically begin the installation;
3. If the Setup Wizard does not start automatically follow these steps:
?Click on "Start", then go to "My Computer", and finally double-click on the "CD Drive";
?Find "Software" folder, double click on "DB5000_Device_Manager.exe" to launch the Wizard.
4. Accept the default recommendations and click "Next>" at the end of each step;
5. When asked to place an icon on the computer Desktop, click on the check the box;
6. Finally, select NOT to launch the program;
7. Close the software installation utility.
Follow these steps for the installation of the USB driver:
1. The USB driver should be added into the folder containing DB5000 program path. If you have not made
any changes during the installation process the driver must be located at: My Computer / Local Disk
(C:) / Program Files /DB5000 Device Manager / Drivers;
2. Connect DB5000 to the AC, then connect the front/rear-panel USB port to the computer. Instantly a
"New Hardware" notification will appear. Start the Wizard, select "No, not this time" and then Next>.
Select "Install from a list or specific location (Advanced)" and then Next>;
3. Verify the location of the driver and click Next>;
4. The "Hardware Wizard" will inform you when the installation is complete.
In order for the RDS/RBDS to be measured accurately the Input Level should be manually set to 75
kHz. Both the trim control labeled "Input Level" and the LED Indicator are placed on the rear panel of the
device.
Feed the device with mono signal corresponding to 75kHz modulation. Using a screwdriver start
setting the "Input Level" until the LED Indicator "Level OK" indicates it. The light has to be constantly
switched on while the signal needed for the calibration is fed.
USB Port Installation
STEP 5
Device Manager Software Installation
STEP 4
Connection Priority
STEP 3
RDS/MPX Input Configuration
STEP 2
Connection
STEP 1

Follow one of these steps:
1. Press the "New Device Button" ;
2. Select "New Device" from the Device Menu.
Adialog box requiring obligatory information about the device will appear:
?
?Password protects from unauthorized access. Default password: DEVA. The password should
be exactly 4 characters long;
?Device Type is to defines what kind of connection will be utilized for the device.
Fill in the needed information and press "OK".
Alias is user-defined name for each device and makes it unique and easy for identification;
Select a device from the
"Device List" and press "View
Device Button".
The device Control Window will
appear. Press "Connect" to enter
DB5000 Main menu.
After the installation process is completed, a shortcut to the software will appear on
the desktop of your PC.
Double click on the shortcut will open the main application window. Most of the
functions are disabled, because no devices are listed in the Device Manager currently.
Otherwise the control window looks like this:
View New Device
STEP 8
Defining New Device
STEP 7
Device Manager Software
STEP 6

Please refer to the User manual for detailed information on
how to configure and explore your device.
Defining of New User Map:
Click "View Map" and choose one of the following options:
?Press "New Map" button;
?Select "New Map" from the " Map Menu";
A dialog window acquiring a map picture will appear. JPEG (.jpg, .jpeg) or Bitmap (.bmp) files can be
uploaded.
Device Location
Select a device from the "Device List" through one of the following options:
1. Press "Locate on Map Button";
2. Select "Locate on Map" from the Device Menu;
3. Press Ctrl+M.
The selected device should be positioned in the center of the Map. Manually set the exact position
of the device.
This is an additional tool for fast evaluation of DB5000 condition. Each device is visually represented
on the User Defined Picture (Map).
1.Device List - encloses all registered devices;
2.Hide/Show Device List button - Hides/Shows Device List, accordingly Map is being
expanded/colapsed;
3. Color/Grayscale Mode - switches between Color and Gray Map;
4. Load New Map - loads a new User Map from JPEG or BMP file;
5. Zoom controls;
6. Overflow indicator - indicates if left or/and top parts of the Map are hidden;
7. Devices.
5
1
2 3 4
6
7
Map Configuration
STEP 9
