Devialet Phantom User manual

+
I have one
PHANTOM
PLUG & PLAY START
I WANT TO
DO A QUICK SETUP AND
PLAY MUSIC OVER BLUETOOTH
+
ETHERNET
1
2
?
1. Plug in your PHANTOM to a power outlet.
Wait until PHANTOM emits a subtle breathing sound.
2. Pair your smartphone, tablet or computer by selecting
the Bluetooth network called: PHANTOM - XXXX
3. PHANTOM will stop emitting sound, you can now
play music from any application.
I have several
PHANTOM
and DIALOG
I have a
PHANTOM
and DIALOG
I WANT TO PLAY MUSIC OVER WIFI
OR BLUETOOTH AND ENJOY THE KEY
FEATURES OF THE SPARK APP
REFER TO SETUP 3
1
2
Are you having diculties setting up PHANTOM ? If so,
follow the reset instructions on the back of this guide.
For more personalized support, our team is always happy to help: help.devialet.com
I WANT TO SETUP A DUO SYSTEM IN ONE ROOM
OR CREATE A MULTI ROOM INSTALLATION
Gather Dialog and PHANTOM in the same room as your router or
Wi-Fi broadband to complete the setup.
You will be able to change their location at the end of the operation.
1. Plug in Dialog to a power outlet close to your router or Wi-Fi broadband.
Connect it to an available slot on your router or Wi-Fi broadband using
the Ethernet cable provided.
2. Plug in PHANTOM to a power outlet in the same room as Dialog.
3. Wait until PHANTOM starts emitting a subtle breathing sound.
4. During this process, each PHANTOM will emit a distinct sound to
signal that it is connected to Dialog.
5. Download the Devialet Spark application on Apple App Store,
Google Play or at www.devialet.com/Spark
6. Make sure the device you are using with Spark is connected to your
home Wi-Fi or wired network where Dialog is connected.
7. Launch Spark and click on start.
8. Follow the instructions provided by Spark.
Once the setup is complete, you can either play music on PHANTOM
using Spark or Bluetooth (step 1.2), you decide !
3
QUICKSTART

Unbox PHANTOM
Gently cut the plastic adhesive seals on the dotted
lines (steps 1 and 3).
Before carefully removing PHANTOM from its box,
make sure that the box is in the proper upright position
as pictured below.
Plug in PHANTOM to a power outlet, wait
for 30 seconds and press the button on
the back of PHANTOM 3 consecutive
times.
PHANTOM will then let you know that
it has initiated the resetting process by
moving and emitting a sound.
Wait again 30 seconds before
starting a new setup.
Do you need to do a RESET ?
Connectors
1. 2.
3. 4.
OPTICALETHERNET
Using PHANTOM with Spotify Connect
You’ll need Spotify Premium to use Connect.
1. Connect PHANTOM to the same wifi network as your phone, tablet or PC by downloading the Devialet SPARK application and following the easy setup steps.
2. Open the Spotify app on your phone, tablet or PC, and play any song.
3. If you’re using the app on a phone - tap the song image in the bottom left of the screen. For tablet and PC move to step 4.
4. Tap the Connect icon
5. Pick your device from the list. If you can’t see it, just check it’s connected to the same wi network as your phone, tablet or PC.
For information on how to use Spotify Connect please visit www.spotify.com/connect
Licenses
The Spotify Software is subject to third party licenses found here: www.spotify.com/connect/third-party-licenses.
