Devine Artis Series User manual

Artis series
Artis 10 / Artis 12 / Artis 15
Passive speakers
User manual
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 3.0 Creation date + author initials: 04-12-2013 RV Revision date + author initials: 29-03-2014 RV

Safety instructions
This unit must be operated by, or under the supervision of an adult. This device is not suitable for children.
Every person involved with the installation, operation and maintenance of this device has to:
- Be qualified
- Follow the instructions of this manual
- Ma e sure there is no damage caused by transport. If the device seems damaged from the outside, do not
use it and contact your dealer for more information and consultation.
- To ma e sure the device maintains in perfect condition and for safe operation, it is necessary for the user to
follow the instructions and warning notes of this user manual.
- Damage caused by improper use or modifications to the device are not covered by warranty.
- This device does not have any user-serviceable parts inside. Servicing of this device needs to be done by
qualified technicians.
Important notes regarding safety and health
- Never leave cables lying around
- Do not open the device and do not modify any hard- or software of this unit.
- Do not insert this object into air vents.
- Do not connect this device to a dimmerpac .
- Do not switch the system on and off frequently as this will reduce the lifespan of the device.
- Do not drive the inputs of the fixture with a signal larger than required to wor at full performance.
- Only use this device indoor, avoid contact with water, moist or other liquids. Do not place items filled with
liquids on top of the unit.
- Avoid nearby flames or heat sources, do not place this device near flammable liquids, gas or flammable
items.
- Always disconnect the device when it is not in use for a longer period of time, when servicing is needed or
when the device needs cleaning.
- Never use other types of cables than specified in the manual, do not use defective or bad functioning
cables. Contact your dealer when the included or required cables do not wor properly with this device.
- When the device has been exposed to large temperature differences (for example, transport from outdoor
to indoor), do not connect the device immediately. Do not activate the unit until it has reached room
temperature, as moist might build up inside the unit, which may cause short circuits and/or electrical shoc s.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 3.0 Creation date + author initials: 04-12-2013 RV Revision date + author initials: 29-03-2014 RV
WARNING!
This speaker is not designed for use outside! Keep this speaker away from moisture and rain at
all times! Exposing the speaker to moisture and rain may cause permanent damage to the
housing and components!
WARNING!
This loudspeaker is capable of producing a sound pressure level which can be harmful for
humans and animals when used incorrectly and/or without protection. Possible permanent
hearing loss may occur when humans or animals are exposed to high sound pressure levels for
a longer period of time.

Guidelines and types of use
- This device is intended to be used by professionals on stage, in theatres, clubs and other equal venues.
- This device is not suitable for children and always needs to be operated by an adult.
- Only use the device when the environment is suitable and will not cause any damage. Do not use the
product in moist or dusty environments, or where long-term damage may occur such as:
- indoor swimming pools where chlorine is used.
- Beaches, where sand and salt are present.
- Temporary outdoor setups, without protection
- Indoor areas where intense heat sources are present or where the temperature exceeds levels
which are comfortable for humans.
- Avoid shoc s and collision during use and transport. Do not transport the device while in use. Avoid brute
force during the installation and operation of this device.
- Familiarize yourself with the functions of the device before use. Do not allow operation of the device by
uns illed or unqualified people.
- Use of the device in other ways than described in this user manual may cause damage and injury. Ayra
does not ta e responsibility for any damage or injury caused by improper use.
Storage and transport
- This device is intended for mobile use. When transported, use the original pac aging of the product, or a
fitting flightcase, preferably filled with foam.
- This device is not intended for permanent use. Operation brea s will ensure that the lifespan of the device
remains unchanged.
- If the device is not used for a longer period of time, disconnect it from its power source and store it in its
original pac aging, or in a fitting flightcase.
- Store the device indoor, dry and do not expose the device to extreme temperature differences.
Housing
- Inspect the housing of the device frequently. Severe dents, crac s and missing screws should be avoided
at all costs. Do not use the device when the housing is not in optimal condition. Contact your dealer or a
s illed technician when in doubt about the state of the device
- Chec the fixture and screws for corrosion. Corrosion should not be present on the fixture. Contact your
dealer or a s illed technician when corrosion is found on the fixture
- Every power or signal chassis/connector should be mounted tightly. Do not use the device when connectors
are loose.
- Do not use spea er cables of which the cores are visible (except the ends when using wire terminals).
Contact your dealer for a replacement if needed.
- Avoid the buildup of dust and dirt. Clean the exterior of the fixture every month with a dry or damp cloth.
When using the device intensively, the cleaning frequency needs to be increased.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 3.0 Creation date + author initials: 04-12-2013 RV Revision date + author initials: 29-03-2014 RV

- Avoid exposure to high sound pressure levels for a longer period of time. See the charts on this
page for more information about sound pressure levels and exposure to high levels.
Continuous dB Permissible exposure time
85 8 hours
88 4 hours
91 2 hours
94 1 hour
97 30 minutes
100 15 minutes
103 7.5 minutes
106 3.75 minutes (<4 minutes)
109 1.875 minutes (<2 minutes)
112 0.9375 minutes (<1 minute)
115 0.46875 minutes (+/- 30
seconds)
- When installing this spea er on a spea er stand or distance pole, always tighten the screw nobs firmly.
- When using this spea er for the first time, set the gain settings on the amplifier (module) on a minimum
level. After this, raise the volume to a comfortable listening level (not at its maximum level). The spea er
needs to perform on a moderate level for several hours to perform on its full potential, when used for the first
time.
- When transporting the spea er on a cart, use caution during movement. Prevent the cart and spea er
combination from tipping over as this may cause serious injury.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 3.0 Creation date + author initials: 04-12-2013 RV Revision date + author initials: 29-03-2014 RV

Introduction
Than you for purchasing this passive Devine Artis spea er. To ma e sure you use this loudspea er as
intended and for optimal performance and protection of this spea er, Devine recommends you read this user
manual.
Box contents
1x Artis passive spea er (Artis 10 / Artis 12 / Artis 15)
Warning!
- This loudspea er is not suitable for use outside. Keep this spea er away from moisture and rain.
- This loudspea er is capable of producing sound levels that may cause severe and permanent hearing
damage.
- Ma e sure the spea er cabinet is installed on a proper surface when used. Place this spea er on the floor,
on a professional spea er stand or on a suitable wall-brac et. Devine is not responsible for any damage
caused by improper installation of this device.
- To clean this spea er from any dirt or dust and eep it in optimal shape, use a proper vacuum cleaner with
carpet mouthpiece. The grill can be cleaned with a damp cloth or sponge with a non-aggressive soap
solution. The grill can be detached for cleaning, but it is not recommended to remove it frequently. If you wish
to clean the woofer and tweeter, use a dry cloth.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 3.0 Creation date + author initials: 04-12-2013 RV Revision date + author initials: 29-03-2014 RV

Use of the speaker
This spea er is designed to perform in professional environments. Speech, music, or any other type of sound
can be played trough this spea er.
For optimal performance, a suitable PA-amplifier is needed. Each Artis passive spea er has its own
characteristics, based on the internal components. For every Artis passive spea er, there is a maximum
power handling, optimized for the woofer and tweeter.
Devine advises to use a PA-amplifier which is able to provide about 1.5x more power than the RMS power
handling of your spea ers. The RMS values are measured with a static sinus and not with dynamic music,
therefore it is safe to use this configuration. As the Artis passive spea ers have a larger maximum pea
power handling, they are capable of handling short pea power values.
This configuration is also beneficial for your PA-amplifier, as it does not have to wor at full power to provide
your spea ers with optimal power. Ma e sure though that you do not exceed the maximum capability of your
spea ers, which occurs when you hear distorted sounds or when the CLIP LEDs on your amplifier are lit.
It is possible to connect another Artis passive spea er to the second output of your first Artis passive
spea er. However, ta e notice that the impedance of your spea er system drops to 4 Ohm. Ma e sure your
PA-amplifier is suitable for this impedance or contact your local dealer if you have any doubts, as wrong
impedances might damage your spea er system permanently.
Use proper cable and proper connectors to connect your spea ers and amplifier. Devine recommends to use
prefabricated spea ercables with pre-mounted connectors.
Devine also recommends the use of the loc able spea er connectors, for optimal reliability.
When ma ing your own spea er cables, only use good quality spea er cable with at least a 2x 1.5mm² core.
Thin wiring and high power may result in melting cables!
Use your ears to ma e sure you don’t blow up your spea ers or cause any other damage to its internal
components. When you hear any distortion or when your PA-amplifier is clipping, you need to decrease the
volume on your mixer or amplifier.
All Artis passive series spea ers are equipped with a 35mm stand adapter, which ma es it possible to place
the spea er on a suitable height. This ma es the distribution of high and mid-frequencies easier. See the
image for details. 35mm is a standard size for spea er stands, so most spea er stands will fit the spea er
properly.
Warranty is void when damage to this spea er is caused by improper use. When any damage to this spea er
occurs, please contact your local dealer for help.
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 3.0 Creation date + author initials: 04-12-2013 RV Revision date + author initials: 29-03-2014 RV

Features and technical data
- passive spea er
- robust, lightweight construction
- bass-reflex cabinet
- protective grill
- impedance: 8 Ohm
- handle on the side
- 35mm stand adapter with tightening nob
- connections: 2x loc able pro-spea er connection
- monitor stands included
Feature Artis 10 Artis 12 Artis 15
Woofer 10 inch woofer 12 inch woofer 15 inch woofer
Tweeter Tweeter with 1.75 inch
exit
Tweeter with 1.34 inch
exit
Tweeter with 1.34 inch
exit
RMS power handling 150W RMS 300W RMS 450W RMS
Peak power handling 450W pea 750W pea 950W pea
Frequency response 55 Hz – 18 Hz (+/- 10
dB)
50 Hz – 18 Hz (+/- 10
dB)
40 Hz – 18 Hz (+/- 10
dB)
Sensitivity 94 dB (+/- 2 dB) 96 dB (+/- 2 dB) 98 dB (+/- 2 dB)
Dimensions 360 x 270 x 520 mm 420 x 310 x 585 mm 460 x 400 x 685 mm
Weight 6 g 9 g 12 g
