Devolo Magic 2 LAN1-1 User manual

Manual
devolo Magic 2 LAN 1-1

devolo Magic 2 LAN1-1

© 2021 devolo AG Aachen (Germany)
The reproduction and distribution of the documentation and software supplied with this product and the use of its contents is
subject to written authorization from devolo. We reserve the right to make any alterations that arise as the result of technical de-
velopment.
Trademarks
Android TM is a registered trademark of Open Handset Alliance.
Linux®is a registered trademark of Linus Torvalds.
Ubuntu®is a registered trademark of Canonical Ltd.
Mac®and Mac OS X®are registered trademarks of Apple Computer, Inc.
iPhone®,iPad® and iPod®are registered trademarks of Apple Computer, Inc.
Windows®and Microsoft®are registered trademarks of Microsoft, Corp.
devolo and the devolo logo are registered trademarks of devolo AG.
All other names mentioned may be trademarks or registered trademarks of their respective owners. Subject to change without
notice. No liability for technical errors or omissions.
This product has been manufactured and is sold under a licence granted to devolo AG by Vectis One Ltd for patents concerning
WiFi-technology and owned by Wi-Fi One, LLC (“Licence”). The Licence is limited exclusively to finished electronics for end-use
and does not extend rights to any third party device or process used or sold in combination with this product.
devolo AG
Charlottenburger Allee 67
52068 Aachen
Germany
www.devolo.global
Version 1.2_03/21

devolo Magic 2 LAN 1-1
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.5 devolo on the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 devolo Magic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2 Introduction to the devolo Magic adapter: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3 Pairing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3.1 Reading the indicator light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.3.2 Network connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.3.3 Integrated electrical socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3 Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.1 Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.3 Connecting the devolo Magic 2 LAN 1-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.3.1 Starter Kit – Automatic set-up for a new devolo Magic network . . . . . . . . . . . . . . . . . . 20
3.3.2 Addition – Expanding an existing network by adding another devolo Magic
adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.3.3 Changing the network password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.4 Installation of devolo software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.5 Removing the devolo Magic adapter from a network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.1 Calling up the built-in web interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2 Menu description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.2.2 Powerline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

devolo Magic 2 LAN 1-1
4.2.3 LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.2.4 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.1 Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.2 Bandwidth optimization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.3 Disposal of old devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.4 Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Preface 6
devolo Magic 2 LAN1-1
1Preface
Welcome to the fantastic world of
devolo Magic!
In no time at all, devolo Magic transforms your
house into a multimedia home that is ready for the
future today. devolo Magic gives you noticeably
higher speeds, more stability and greater range,
providing the perfect Internet experience as a re-
sult!
1.1 About this manual
Carefully read all instructions before setting up the
device and store the manual and/or installation
guide for later reference.
After a brief introduction to „devolo Magic“ and to
the devolo Magic 2 LAN 1-1 in Chapter 2,
Chapter 3 tells you how to successfully start using
the adapter in your network.
Chapter 4 describes in detail the setting options of
the built-in configuration interface.
Tips for bandwidth optimisation, information
about environmental compatibility of the device,
as well as our warranty terms, can be found in
Chapter 5 at the end of the manual.
Description of the icons
This section contains a brief description of the
icons used in this manual and/or on the rating pla-
te, the device connector, as well as the icons used
on the package:
Icon Description
Very important safety symbol that
warns you of hazardous electrical
voltage which if not avoided can re-
sult in serious injury or death.
Very important safety symbol that
warns you of a potentially dange-
rous situation which if not avoided
can result in serious injury or death.
An important safety symbol that
warns you of a potentially burn ha-
zard which if not avoided can result
in minor injuries or damage to pro-
perty.
An important safety symbol that
warns you of a potentially dange-
rous situation involving a tripping
hazard which can result in injuries.

7 Preface
devolo Magic 2 LAN 1-1
1.2 Intended use
Use devolo devices, devolo software and the provi-
ded accessories as described to prevent damage
and injury.
Products
devolo devices are communication devices desi-
gned for indoors.* Depending on the product, they
An important note that should be
observed which can potentially
lead to material damages.
The device may only be used in-
doors in dry conditions.
The device is a Class I product. All
electrically conductive (made of
metal) housing parts where a volta-
ge can be applied during operation
or maintenance in the event of an
error must be continuously
connected to the earth wire.
The manufacturer/distributing
company uses the CE marking to
declare that the product meets all
applicable European regulations
and has been subjected to the pres-
cribed conformity assessment
procedures.
Icon Description
It is used to prevent the occurrence
of waste electrical and electronic
equipment and to reduce this type
of waste through reuse, recycling
and other forms of utilisation. The
European Community WEEE Direc-
tive establishes minimum standards
for handling waste electrical and
electronic equipment in the EU.
Additional information,
background material and
configuration tips for your device.
Indicates a completed course of ac-
tion
Icon Description

Preface 8
devolo Magic 2 LAN1-1
are equipped with a PLC - (PowerLine Communica-
tion) and/or a Wi-Fi module and/or a broadband
module. The devices communicate with each other
by means of, depending on the product, PLC, data
and telephone line (e.g. coaxial or twisted pair)
and/or Wi-Fi.
devolo devices do not replace the existing router.
They enable transmission of the existing Internet/
data signal over the in-house wiring and via Wi-Fi
and integrate Internet-compatible terminal de-
vices into the home network.
Under no circumstances may devolo devices be
used outdoors, because large temperature fluctua-
tions and moisture can damage both the device
and the power line*. devolo devices may not be in-
stalled at a height above two metres unless an ad-
ditional fastening mechanism is available. The
products are intended for operation in the EU,
Switzerland and Norway.
* This does not include devolo outdoor devices, which are
suitable for outdoor applications based on their IP classification.
Software
devolo devices can be used only with the free,
downloadable programs approved and available
on devolo AG's website (www.devolo.global) and
in app stores (iOS and Google Play). Any modifica-
tions to the product-specific firmware or software
could damage the products and, in the worst-case
scenario, render them unusable, negatively affect
conformity and cause the warranty claims to beco-
me void.
Always use the most up-to-date software version
to make sure you have the latest security functions
and device updates. The installed devolo software
notifies you automatically if a new software versi-
on is available.
Accessories
Use only the provided accessories.
1.3 CE Conformity
This product complies with the technical
requirements of the directives 2014/35/
EU, 2014/30/EU, 2011/65/EU und 2009/
125/EC.
This product is designed for use in the EU,
Switzerland and Norway.
A printout of the simplified CE declaration of this
product is separately included and can also be
found under www.devolo.global/support/ce.

9 Preface
devolo Magic 2 LAN 1-1
1.4 Safety notes
It is essential to have read and understood all safe-
ty and operating instructions before the devolo de-
vice is used for the first time; keep them safe for
future reference.
DANGER! Electrical shock caused by
electricity
Do not reach into the electrical socket.
Do not open the device.
Do not insert any objects into the electrical
socket or into the ventilation openings
DANGER! Electric shock caused by
electricity
Device must be plugged into a power soc-
ket with a connected earth wire
devolo devices may be operated only on a mains
power supply as described on the rating plate.
CAUTION! Tripping hazard
Lay the network cable in a barrier-free
manner;
ensure that the electrical socket and the
connected network devices are easily ac-
cessible
To disconnect devolo devices from the mains sup-
ply, unplug the device from the electrical socket.
CAUTION! Damage to the device caused
by ambient conditions
Only use device indoors in dry conditions
CAUTION! Heat development during
operation
Certain housing components can become
very hot in certain situations. Attach device
so that it is touch-proof, observing optimal
positioning
devolo devices should only be installed at locations
that guarantee adequate ventilation. Slots and
openings on the housing are used for ventilation:
bDo not cover devolo devices during operation.
bDo not place any objects on devolo devices.
bDo not insert any objects into the openings of
devolo devices.
bdevolo devices must not be placed directly
next to a naked flame (such as fire or candles).
bdevolo devices must not be exposed to direct
heat radiation (e.g. radiator, direct sunlight).
Users do not need to carry out any maintenance
on devolo devices. In the event of damage, dis-
connect the devolo device from the mains supply
by pulling it or its plug out of the electrical socket.
Then contact qualified specialist personnel (after-

Preface 10
devolo Magic 2 LAN1-1
sales service) exclusively. Damage is deemed to
have occurred, for example,
bif a button is damaged.
bif the power plug is damaged.
bif the devolo device has been showered with
liquid (such as rain or other water).
bif the devolo device is inoperable.
bif the housing of the devolo device is damaged.
CAUTION! Damage to housing from
cleaning agents containing solvents
Clean only electroless and with dry cloth
Do not plug devolo devices directly into each
other. Devices that are plugged into each
other can experience a decrease in transmis-
sion rate.
1.5 devolo on the Internet
For detailed information on our products, visit
www.devolo.global.
There you will find product descriptions and docu-
mentation, and also updates of devolo software
and your device's firmware.
If you have any further ideas or suggestions related
to our products, please don't hesitate to contact us
at [email protected]!

11 Introduction
devolo Magic 2 LAN 1-1
2 Introduction
2.1 devolo Magic
Home is where devolo Magic is – in no time at all,
devolo Magic transforms your house or flat into a
multimedia home of the future with noticeably
higher speed, more stability and greater range,
providing the perfect Internet experience as a
result!
Be inspired by products that are astonishingly easy
to install, with impressive, innovative technology
and unbeatable performance.
Be ready for the technology of the future today
devolo Magic embodies the new generation of the
tried-and-tested Powerline technology (PLC) ba-
sed on the cutting-edge G.hn architecture. G.hn
was developed by the International Telecommuni-
cation Union (ITU) with ongoing development pro-
vided primarily by the HomeGrid Forum industry
association. devolo Magic products are certified
Fig. 1 devolo Magic throughout the home

Introduction 12
devolo Magic 2 LAN1-1
according to HomeGrid standards and are compa-
tible with other HomeGrid-certified products.
Like the HomePlug AV technology used in establis-
hed devolo dLAN devices, devolo Magic uses the
household mains supply for data transmission and
secures ideal performance and stability in locations
where network cables are not viable or desired
and/or the Wi-Fi frequently falls short due to cei-
lings and walls.
To set up a devolo Magic network, you need
at least two devolo Magic devices. For tech-
nical reasons, devices from the
devolo Magic series are not compatible with
dLAN devices.
2.2 Introduction to the
devolo Magic adapter:
Unpack – plug in – get started and be ready for
the new generation of tried-and-tested Powerline
technology:
bSpeed and stability – thanks to consistent data
transmission speed at up to 2400 Mbps over
distances of up to 500 meters, the
devolo Magic 2 LAN 1-1 promises entertain-
ment at the highest level.
bSecurity – with 128-bit AES Powerline encryp-
tion
bEnergy-efficiency – the integrated PowerSave
mode cuts energy consumption automatically
during low data traffic.
bA devolo Magic 2 LAN 1-1 transforms any
electrical socket in your household electrical
wiring into a Gigabit LAN Internet access point.
bIts integrated electrical socket can be used (like
a normal wall socket) to supply power to an
additional network device or a power strip.
bThe Gigabit LAN port on the
devolo Magic 2 LAN 1-1 lets you connect a sta-
tionary network device – such as a game con-
sole, television or media receiver – to your
Internet access point over the Powerline net-
work (e.g. Internet router).
The devolo Magic 2 LAN 1-1 features
bOne Gigabit network connection
bOne indicator light
The LED status display can be disabled. You
can find more information about this in
Chapter 4 Configuration or in the product
manual for the devolo Cockpit software
available online at
www.devolo.global/devolo-cockpit.

13 Introduction
devolo Magic 2 LAN 1-1
bOne PLC/reset button (next to the network
connection)
bOne integrated electrical socket
2.3 Pairing
devolo Magic adapters that are in factory default
condition, i.e. have been purchased or successfully
reset (see Chapter Resetting a devolo Magic ad-
apter or removing it from a devolo Magic net-
work), automatically start to attempt to pair with
another devolo Magic adapter when reconnected
to the mains supply.
Starting up a new devolo Magic network
After plugging the devolo Magic adapters into
available power sockets, a new devolo Magic net-
work is established automatically within 3 minutes.
Expanding an existing devolo Magic network
by adding another devolo Magic adapter
In order to use a new devolo Magic 2 LAN 1-1 in
your devolo Magic- network, first you have to
connect it to your existing devolo Magic adapters
devices as a network. This is accomplished by using
a shared password, which can be assigned in va-
rious ways:
bUsing devolo Cockpit or the
devolo Home Netwok App (see Chapter 3.4
Installation of devolo software)
bUsing the web interface (see Chapter 4.2.2
Powerline)
bUsing the PLC/reset button as described
below.
1To do so, plug the new devolo Magic adapter
into an available power socket and, for appro-
ximately 1 second, press the PLC/reset button
on a devolo Magic adapter in your existing
devolo Magic network.
Fig. 2: devolo Magic 2 LAN 1-1 with country-specific
connector and power socket

Introduction 14
devolo Magic 2 LAN1-1
2The new devolo Magic adapter pairs automati-
cally so no button needs to be pressed. The LED
of this adapter now also flashes white.
After a short time, the flashing LED beco-
mes a steady white light. The devolo Magic
adapter has been successfully integrated
into your existing devolo Magic network.
For each pairing operation, only one addi-
tional devolo Magic adapter can be added
at a time.
You can find detailed information about in-
stalling devolo Magic adapters in Chapter
3.3 Connecting the
devolo Magic 2 LAN 1-1.
Resetting a devolo Magic adapter or removing
it from a devolo Magic network
1To remove a devolo Magic adapter from your
devolo Magic network and successfully restore
its entire configuration to the factory default
settings, press and hold the reset button longer
than 10 seconds.
2Wait until the LED flashes white and then dis-
connect the devolo Magic adapter from the
mains supply.
Keep in mind that all settings that have al-
ready been made will be lost!

15 Introduction
devolo Magic 2 LAN 1-1
2.3.1Reading the indicator light
The integrated indicator light (LED) shows the sta-
tus for the devolo Magic 2 LAN 1-1 by illuminating
and/or flashing:
LED Flashing be-
haviour
Meaning LED status display
(web interface*)
1 Red LED Lights up for
up to 2 sec.
Start-up process Cannot be disabled
2 Red LED Flashes at in-
tervals of 0.5
sec. (on/off)
Status 1:
The reset of the devolo Magic adapter was
successful. The PLC/reset button has been
pressed and held for 10 seconds.
Status 2:
The devolo Magic adapter (once again) has
the factory default settings. Since the last re-
set, no pairing with another devolo Magic
adapter has taken place.
Connect the adapter with another
devolo Magic adapter to create a full-
fledged PLC network as described in Chap-
ter 2.3 Pairing.
Cannot be disabled

Introduction 16
devolo Magic 2 LAN1-1
3 Red LED Lights up stea-
dy
Status 1:
The other network nodes are in standby
mode and cannot currently be accessed over
the mains supply. The PLC LEDs of the other
devolo Magic adapters flash white only for a
short time.
Status 2:
The connection to the other network nodes
has been interrupted. There may be electro-
magnetic or radio frequency interference on
the power line. In this case, put the
devolo Magic adapters closer to each other
or try to shut off the source of interference.
Can be disabled
4Redand
white
LED
Flashes at in-
tervals of 0.1
sec. red/2 sec.
white
Data transmission rate not in optimum
range **
Can be disabled
LED Flashing be-
haviour
Meaning LED status display
(web interface*)

17 Introduction
devolo Magic 2 LAN 1-1
5White
LED
Status 1:
Flashes at in-
tervals of
0.5 sec.
(on/off)
Status 2:
Flashes at in-
tervals of
1 sec.
(on/off)
Status 1:
This devolo Magic adapter is in pairing
mode and the system is searching for new
devolo Magic adapters.
Status 2:
Someone has triggered the "Identify device"
function on the web interface or in the
devolo Home Netwok App. This function
identifies the devolo Magic adapter being
sought.
Cannot be disabled
6White
LED
Lights up stea-
dy
The devolo Magic connection does not have
any issues and the devolo Magic adapter is
ready to operate.
Can be disabled
7White
LED
Flashes at in-
tervals of
0.1 sec. on /
5sec.off
The devolo Magic adapter is in standby mo-
de.***
Can be disabled
8Redand
white
LED
Flashes at in-
tervals of
0.5 sec. red/
0.5 sec. white
The devolo Magic adapter is carrying out a
firmware update.
Cannot be disabled
LED Flashing be-
haviour
Meaning LED status display
(web interface*)

Introduction 18
devolo Magic 2 LAN1-1
* Information about the web interface can be
found in Chapter 4 Configuration.
** Information on improving the transmission rate
can be found in Chapter 5.2 Bandwidth optimi-
zation.
***A devolo Magic adapter switches to standby
mode after approximately 10 minutes if no active
network device (e.g. computer) is connected to the
network interface. In this mode, the devolo Magic
adapter cannot be accessed over the electrical wi-
ring. As soon as the network device (e.g. computer)
connected to the network interface is switched on
again, your devolo Magic adapter can also be ac-
cessed over the electrical wiring again.
Check whether the adapter is connected to
the mains supply correctly and whether the
pairing operation has been carried out suc-
cessfully. For more information about this,
refer to 3.3 Connecting the
devolo Magic 2 LAN 1-1.
2.3.2Network connection
You can use the network connection on the
devolo Magic adapter to connect it to a PC or tele-
vision using a standard network cable.
2.3.3Integrated electrical socket
Always use the integrated electrical socket on the
devolo Magic adapter when connecting other
consumers to the mains supply. In particular,
electronic devices with mains adapter can negati-
vely affect PLC performance.
The integrated mains filter in the devolo Magic ad-
apter filters any such external interference and re-
duces any impairment of PLC performance.

19 Initial use
devolo Magic 2 LAN 1-1
3Initialuse
This chapter tells you everything you need to know
to set up and use your devolo Magic 2 LAN 1-1. We
describe how to connect the adapter and briefly
describe the devolo software.
3.1 Package contents
Please ensure that the delivery is complete before
beginning with the installation of your
devolo Magic 2 LAN 1-1:
bStarter Kit:
a 2 devolo Magic 2 LAN 1-1
a 2 network cables
a Hard copy of installation guide
a Hard copy security flyer
a CE declaration
or
bExtension:
a 1 devolo Magic 2 LAN 1-1
a 1 Network cable
a Hard copy of installation guide
a Hard copy security flyer
a CE declaration
devolo AG reserves the right to change the packa-
ge contents without prior notice.
3.2 System requirements
bOperating systems supported by
devolo Cockpit:
a from Windows 7 (32-bit/64-bit),
a from Ubuntu 13.10 (32-bit/64-bit),
a from Mac (OS X 10.9)
bGigabit network connection
bNetwork connection
Please note that your computer or other de-
vice must have a network card or network
adapter with a network interface.
To set up a devolo network, you need at
least two devolo adapters.

Initial use 20
devolo Magic 2 LAN1-1
3.3 Connecting the
devolo Magic 2 LAN 1-1
CAUTION! Damage to the device caused
by ambient conditions
Only use device indoors in dry conditions
In the following sections we describe how to
connect the devolo Magic 2 LAN 1-1 and integrate
it into a network. We clarify the exact procedures
based on potential network scenarios.
For the permitted voltage range for opera-
ting the device and the power consumption,
refer to the type plate on the rear of the de-
vice. For additional technical information on
our products, refer to the product area at
www.devolo.global.
3.3.1Starter Kit – Automatic set-up for a
new devolo Magic network
1Connect one devolo Magic 2 LAN 1-1 to your
Internet access device's network connection
(e.g. your Internet router).
2Connect the other devolo Magic 2 LAN 1-1 to
the network connection of your computer or
another network device using a network cable.
CAUTION! Tripping hazard
Lay the network cable in a barrier-free
manner and ensure that the electrical soc-
ket and the connected network devices are
easily accessible
3Plug both devolo Magic adapters into available
power sockets within 3 minutes. As soon as the
LEDs on both adapters flash white at regular
intervals of 0.5 sec., they are ready to operate
and automatically start the process of establis-
hing an encrypted connection to each other
(see Chapter 2.3.1 Reading the indicator
light).
If the LEDs on both devolo Magic adapters
light up in white, then your
devolo Magic network has been set up ac-
cording to your individual specifications
and is protected from unauthorised access.
