DeWalt DCM200 User manual

final page size: 8.5 x 5.5 in
If you have questions or comments, contactus.
Pour toute question ou tout commentaire, nouscontacter.
Si tiene dudas o comentarios,contáctenos.
1‑800‑4‑DeWALT
DCM200
20V Max* 18" Brushless Bandfile
Lime à ruban sans balais 20V Max* 18po
Lima de banda sin escobillas de 18" 20V Max*
Instruction Manual
Guide D’utilisation
Manual de instrucciones

English (original instructions) 7
Français (traduction de la notice d’instructions originale) 17
Español (traducido de las instrucciones originales) 28

1
Fig. A
1 Variable speed dial
2 Variable speed trigger
3 Lock‑off button
4 Main handle
5 Side handle
6 Belt tensioning lever
7 Belt tracking screw
8 Straight arm
9 Lock lever
10 Dust shroud (sold separately)
11 Dust port
12 Rotatable LED worklight
13 Battery pack
14 Battery pack release button
1
8
5 3
12
6
10
11
4
13
14
9
2
7
1 Cadran de vitesse variable
2 Gâchette de vitesse variable
3 Bouton de verrouillage
4 Poignée principale
5 Poignée latérale
6 Levier de tension de la bande
7 Vis d’entraînement de la bande
8 Bras droit
9 Levier de verrouillage
10 Coiffe antipoussière (vendue
séparément)
11 Capteur de poussière
12 Lampe de travail à DEL orientable
13 Bloc‑piles
14 Déclencheur du bloc‑piles
1 Carátula de velocidad variable
2 Gatillo de velocidad variable
3 Botón de bloqueo de apagado
4 Manija principal
5 Manija lateral
6 Palanca de tensión de banda
7 Tornillo de rastreo de banda
8 Brazo recto
9 Palanca de bloqueo
10 Cubierta de polvo (vendida por
separado)
11 Puerto de polvo
12 Luz de trabajo LED giratoria
13 Batería
14 Liberación de batería

2
Fig.B Fig.C
Fig.D Fig.E
Fig.F1
8
15
7
6
18
17
19
20
6
16
29
18
20
17
Fig. F2
Fig. F3
20
29
18
75–100% charged
Chargé de 75 à 100 %
75–100% cargada
51–74% charged
Chargé de 51 à 74 %
51–74% cargada
< 50% charged
Chargé de < 50 %
< 50% cargada
Pack needs to be charged
Le bloc‑piles doit être rechargé
La batería tiene que cargarse
Indicators/Témoin/Indicador
Charging
Bloc‑piles en Cours
de Chargement
Unidad en Proceso de Carga
Fully Charged
Bloc‑piles Chargé
Unidad Cargada
Hot/Cold Pack Delay
Suspension de Charge Contre
le Chaud/Froid
Restraso por Unidad Caliente/
Fría

3
Fig.H
Fig.I Fig.J
Fig.K Fig.L
Fig.G
7
10
5
11
21
22
3 2
13
14
4
5

4
Fig.N
Fig.O Fig.P
Fig.Q Fig.R
12
1
11
23
A
8
9
B
Fig.M
9 3

5
Fig.S
27
28
24
25
26
Fig.T
Fig.U
Fig.W
Fig.V
Fig.X
11
31
30
A
8
B
32
19
C
8
D
8

6
Fig.Y
8
EF
15
Fig.Z

7
ENGLISH
English (original instructions)
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with
this power tool. Failure to follow all instructions
listed below may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
c ) Keep children and bystanders away while
operating a power tool. Distractions can cause you
to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electricshock.
f ) If operating a power tool in a damp location
is unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Use of a GFCI
reduces the risk of electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personalinjury.
b ) Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non‑skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energizing power tools that have the switch
on invitesaccidents.
d ) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personalinjury.
e ) Do not overreach. Keep proper footing and
balance at all times. This enables better control of the
power tool in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long
hair can be caught in movingparts.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with
this power tool. Failure to follow all instructions
listed below may result in electric shock, fire and/or
seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FORFUTUREREFERENCE.
The term "power tool" in the warnings refers to your
mains‑operated (corded) power tool or battery‑operated
(cordless) powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust orfumes.
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert
symbols and words to alert you to hazardous situations and
your risk of personal injury or propertydamage.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
(Used without word) Indicates a safety
relatedmessage.
Intended use
Your Belt Sander Bandfile has been designed for sanding
wood, metal, plastics and painted surfaces.
For optimal balance, use 5Ah battery or smaller.
DO NOT use under wet conditions or in presence of
flammable liquids orgases.
Your Belt Sander Bandfile is a professional power tool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.

ENGLISH
8
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or afire.
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation
orburns.
e ) Do not use a battery pack or tool that is damaged
or modified. Damaged or modified batteries may
exhibit unpredictable behavior resulting in fire,
explosion or risk ofinjury.
f ) Do not expose a battery pack or tool to
fire or excessive temperature. Exposure to
fire or temperature above 265°F (130°C) may
causeexplosion.
g ) Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside the
specified range may damage the battery and increase
the risk offire.
6) Service
a ) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power tool
ismaintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized serviceproviders.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust‑relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of
untrainedusers.
e ) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits, etc.
in accordance with these instructions, taking
into account the working conditions and the
work to be performed. Use of the power tool for
operations different from those intended could result in
a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpectedsituations.
5) Battery Tool Use and Care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury andfire.
c ) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
Belt Sander Supplemental Safety
Warnings
• Always use proper eye protection and a respirator
whensanding.
• Use clamps or another practical way to secure and support
the workpiece to a stable platform. Holding the workpiece
by hand or against your body leaves it unstable and may
lead to loss ofcontrol.
• Sanding of lead‑based paint is not recommended. See
Sanding Lead-Based Paint for additional information
before sandingpaint.
• Clean your tool outperiodically.
• Do not wet sand with this sander. Liquids may enter the
motor housing and cause damage to the beltsander.
• Static shocks are possible in dry areas or when the relative
humidity of the air is low. This is only temporary and
does not affect the use of the belt sander. To reduce the
frequency of static shocks, add moisture to the air with a
console, or installedhumidifier.
• If included with tool, empty dust bag frequently.
Especially when sanding resin‑coated surfaces such as
polyurethane, varnish, shellac, etc. The accumulation of
fine sanding dust particles may self‑ignite and causefire.
• Do not operate this tool for long periods of time.
Vibration caused by the operating action of this tool may

9
ENGLISH
Additional Safety Information
WARNING: Never modify the power tool or any part of
it. Damage or personal injury couldresult.
WARNING: ALWAYS use safety glasses. Everyday
eyeglasses are NOT safety glasses. Also use face or dust
mask if operation is dusty. ALWAYS WEAR CERTIFIED
SAFETYEQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3),
• ANSI S12.6 (S3.19) hearing protection,
• NIOSH/OSHA/MSHA respiratoryprotection.
WARNING:
Some dust created by power sanding,
sawing, grinding, drilling, and other construction
activities contains chemicals known to the State
of California to cause cancer, birth defects or
other reproductive harm. Some examples of these
chemicalsare:
• lead from lead‑based paints,
• crystalline silica from bricks and cement and other
masonry products, and
• arsenic and chromium from
chemically‑treatedlumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well‑ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to filter
out microscopicparticles.
• Wear protective clothing and wash exposed areas
with soap and water. Allowing dust to get into your
mouth, eyes, or lie on the skin may promote absorption
of harmfulchemicals. Direct particles away from face
andbody.
WARNING: Always wear proper personal hearing
protection that conforms to ANSI S12.6 (S3.19)
during use. Under some conditions and duration
of use, noise from this product may contribute to
hearingloss.
• Use the appropriate dust extractor vacuum to remove
the vast majority of static and airborne dust.Failure
to remove static and airborne dust could contaminate the
working environment or pose an increased health risk to
the operator and those in closeproximity.
• Use clamps or other practical ways to secure and
support the workpiece to a stable platform. Holding
Cleaning and Disposal
• All surfaces in the work area should be vacuumed
and thoroughly cleaned daily for the duration of
the sanding project. Vacuum filter bags should be
changedfrequently.
• Plastic drop cloths should be gathered up and disposed
of along with any dust chips or other removal debris.
They should be placed in sealed refuse receptacles and
disposed of through regular trash pick‑up procedures.
During clean‑up, children and pregnant women should
be kept away from the immediate workarea.
• All toys, washable furniture and utensils used by children
should be washed thoroughly before being usedagain.
Specific Safety Warnings and
Instructions:Sanders
Sanding Lead‑Based Paint
Sanding of lead‑based paint is NOT RECOMMENDED due
to the difficulty of controlling the contaminated dust.
The greatest danger of lead poisoning is to children and
pregnantwomen.
Since it is difficult to identify whether or not a paint contains
lead without a chemical analysis, we recommend the
following precautions when sanding any paint:
Personal Safety
• No children or pregnant women should enter the work
area where the paint sanding is being done until all
clean‑up iscompleted.
• A dust mask or respirator should be worn by all persons
entering the work area. The filter should be replaced daily
or whenever the wearer has difficultybreathing.
NOTE: Only those dust masks suitable for working with lead
paint dust and fumes should be used. Ordinary painting
masks do not offer this protection. See your local hardware
dealer for the proper (NIOSH approved)mask.
• NO EATING, DRINKING or SMOKING should be done in
the work area to prevent ingesting contaminated paint
particles. Workers should wash and clean up BEFORE
eating, drinking or smoking. Articles of food, drink, or
smoking should not be left in the work area where dust
would settle onthem.
Environmental Safety
• Paint should be removed in such a manner as to
minimize the amount of dustgenerated.
• Areas where paint removal is occurring should be sealed
with plastic sheeting of 4milsthickness.
• Sanding should be done in a manner to reduce tracking
of paint dust outside the workarea.
cause permanent injury to fingers, hands, and arms. Use
gloves to provide extra cushion, take frequent rest periods,
and limit daily time ofuse.
• Sanding of lead‑based paint, chemically pressure
treated lumber or other materials that may contain
carcinogens is not recommended. Sanding of these
materials should only be performed by aprofessional.
• ALWAYS disconnect tool from the power source
before changing abrasive belts. Such preventive
safety measures reduce the risk of starting the power
toolaccidentally.
• ALWAYS maintain a firm grip with both hands on the
belt sander handles to prevent loss ofcontrol.
• ALWAYS keep fingers away from the moving belt
and areas where the belt enters the housing to avoid
severeabrasion.
• Do not operate belt sander without all guards and
covers securely inplace.
• To avoid injury, do not use this tool in a stand that
would invert it for use as a stationary belt sander. This
tool is not made for thatapplication.

ENGLISH
10
The RBRC® Seal
Please take your spent battery packs to
an authorized DeWALT service center or
to your local retailer for recycling. In some
areas, it is illegal to place spent battery
at temperatures outside of the specified range may damage
the battery and increase the risk offire.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open
eye for 15minutes or until irritation ceases. If medical
attention is needed, the battery electrolyte is composed of a
mixture of liquid organic carbonates and lithiumsalts.
• Contents of opened battery cells may cause
respiratory irritation. Provide fresh air. If symptoms
persist, seek medicalattention.
• Battery liquid may be flammable if exposed to spark
orflame.
• Never attempt to open the battery pack for any
reason. If the battery pack case is cracked or
damaged, do not insert into the charger. Do not crush,
drop or damage the battery pack. Do not use a battery pack
or charger that has received a sharp blow, been dropped,
run over or damaged in any way (e.g., pierced with a nail,
hit with a hammer, stepped on). Damaged battery packs
should be returned to the service center forrecycling.
Storage Recommendations
The best storage place is one that is cool and dry, away
from direct sunlight and excess heat or cold. Store the fully
charged battery pack out of thecharger.
Battery Pack Cleaning Instructions
Dirt and grease may be removed from the exterior of the
battery pack using a cloth or soft non‑metallic brush. Do not
use water or any cleaningsolutions.
Fuel Gauge Battery Packs (Fig.B)
Some battery packs include a fuel gauge. When the fuel
gauge button is pressed and held, the LED lights will
indicate the approximate level of charge remaining. This
does not indicate tool functionality and is subject to
variation based on product components, temperature, and
end‑userapplication.
Transportation
WARNING: Fire hazard. Do not store, carry, or
transport the battery pack so that metal objects
can contact exposed battery terminals. For
example, do not place the battery pack in aprons,
pockets, tool boxes, product kit boxes, drawers, etc.,
with loose nails, screws, keys, coins, hand tools, etc.
When transporting individual battery packs, make
sure that the battery terminals are protected and well
insulated from materials that could contact them and
cause a short circuit. NOTE: Li‑ion battery packs should
not be put in checked baggage on airplanes and must
be properly protected from short circuits if they are in
carry‑onbaggage.
READ ALL INSTRUCTIONS
Important Safety Instructions for All
Battery Packs
WARNING: Read all safety warnings, instructions,
and cautionary markings for the battery pack,
charger and product. Failure to follow the
warnings and instructions may result in electric
shock, fire and/or seriousinjury.
• Do not charge or use the battery pack in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Inserting or removing the battery
pack from the charger may ignite the dust orfumes.
• NEVER force the battery pack into the charger. DO
NOT modify the battery pack in any way to fit into a
non‑compatible charger as battery pack may rupture
causing serious personal injury. Consult the chart at the
end of this manual for compatibility of batteries andchargers.
• Charge the battery packs only in DeWALTchargers.
• DO NOT splash or immerse in water or otherliquids.
• DO NOT allow water or any liquid to enter batterypack.
• Do not store or use the tool and battery pack in
locations where the temperature may reach or
exceed 104°F (40°C) (such as outside sheds or metal
buildings in summer). For best life, store battery packs in
a cool, drylocation.
NOTE: Do not store the battery packs in a tool with
the trigger switch locked on. Never tape the trigger
switch in the ONposition.
• Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack
can explode in a fire. Toxic fumes and materials are created
when lithium‑ion battery packs areburned.
• Do not expose a battery pack or appliance to fire or
excessive temperature. Exposure to fire or temperature
above 265°F (130°C) may causeexplosion.
• Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specified in the instructions. Charging improperly or
BATTERIES AND CHARGERS
The battery pack is not fully charged out of the carton.
Before using the battery pack and charger, read the
safety instructions below and then follow charging
proceduresoutlined. When ordering replacement battery
packs, be sure to include the catalog number andvoltage.
the workpiece by hand or against your body is unstable
and may lead to loss of control andinjury.
• Air vents often cover moving parts and should be
avoided. Loose clothes, jewelry or long hair can be caught
in movingparts.
CAUTION: When not in use, place tool on its
side on a stable surface where it will not cause
a tripping or falling hazard. Some tools with large
battery packs will stand upright on the battery pack
but may be easily knockedover.

11
ENGLISH
• Do not place any object on top of the charger or place
the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat.
Place the charger in a position away from any heat source.
The charger is ventilated through slots in the top and the
bottom of thehousing.
• Do not operate the charger with a damaged cord
orplug. Have them replacedimmediately.
• Do not operate the charger if it has received a sharp
blow, been dropped or otherwise damaged in any
way. Take it to an authorized servicecenter.
• Do not disassemble the charger; take it to an
authorized service center when service or repair
is required. Incorrect reassembly may result in a risk of
electric shock, electrocution orfire.
• The charger is designed to operate on standard
120V household electrical power. Do not attempt to
use it on any other voltage. This does not apply to the
vehicularcharger.
• Foreign materials of a conductive nature, such as, but
not limited to, grinding dust, metal chips, steel wool,
aluminum foil or any buildup of metallic particles
should be kept away from the charger cavities and
ventilation slots.
• Always unplug the charger from the power supply
when there is no battery pack in thecavity.
Charging a Battery (Fig.A, C)
1. Plug the charger into an appropriate outlet.
2. Insert and fully seat battery pack13. The red charging
light(s) will continuously blink whilecharging.
3. Charging is complete when the red charging light(s)
remain(s) continuously ON. Battery pack can be left in
charger orremoved.
WARNING:
Only charge batteries in air temperature over
40° F (4.5° C) and below 104° F (40°C).
4. Charger will not charge a faulty battery pack, which may
be indicated by the charging light(s) staying OFF. Take
charger and battery pack to an authorized service center
if light(s) stay(s)OFF.
NOTE: Refer to label near charging light(s) on charger
for blinkpatterns. Older chargers may have additional
information and/or may not have a yellow indicatorlight.
NOTE: To remove the battery pack, some chargers
require the battery pack release button14 to
bepressed.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot
or too cold, it automatically starts a Hot/Cold Pack Delay,
suspending charging until the battery pack has reached an
appropriate temperature. The charger then automatically
switches to the pack charging mode. This feature ensures
maximum battery packlife.
A cold battery pack may charge at a slower rate than a warm
batterypack.
The hot/cold pack delay will be indicated by the red light(s)
continuing to blink but with the yellow light continuously
Important Safety Instructions for All
Battery Chargers
WARNING: Read all safety warnings, instructions,
and cautionary markings for the battery pack,
charger and product. Failure to follow the
warnings and instructions may result in electric
shock, fire and/or seriousinjury.
• DO NOT attempt to charge the battery pack with
any chargers other than a DeWALT charger. DeWALT
chargers and battery packs are specifically designed to
worktogether.
• These chargers are not intended for any uses other
than charging DeWALT rechargeable battery packs.
Charging other types of battery packs may cause them to
overheat and burst, resulting in personal injury, property
damage, fire, electric shock orelectrocution.
• Do not expose the charger to rain orsnow.
• Do not allow water or any liquid to entercharger.
• Pull by the plug rather than the cord when
disconnecting the charger. This will reduce the risk of
damage to the electric plug andcord.
• Make sure that the cord is located so that it will not
be stepped on, tripped over or otherwise subjected to
damage orstress.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in
risk of fire, electric shock orelectrocution.
• When operating a charger outdoors, always provide
a dry location and use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electricshock.
• An extension cord must have adequate wire size
(AWG or American Wire Gauge) for safety. The smaller
the gauge number of the wire, the heavier the cord and
thus the greater its capacity. An undersized cord will
cause a drop in line voltage resulting in loss of power and
overheating. The following table shows the correct size
to use depending on total length of all extension cords
plugged together, and nameplate ampere rating. If in
doubt, use the next heaviergauge.
Minimum Gauge for Cord Sets
Volts Total Length of Cord in Feet
(meters)
120V 25 (7.6) 50 (15.2) 100 (30.5) 150 (45.7)
Ampere Rating
American Wire Gauge
More Than Not More
Than
0 6 18 16 16 14
610 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
packs in the trash. You may also contact your local recycling
center for information on where to drop off the spent
battery pack. Do not place in curbside recycling. For more
information visit www.call2recycle.org or call the toll‑free
number in the RBRC®Seal.
RBRC® is a registered trademark of Call 2Recycle,Inc.

ENGLISH
12
Fitting and Removing Sanding Arms
(Fig.D, E)
13 mm x 457 mm (1/2" x 18") width belts can be
installed with the optional arms that are designed for the
corresponding beltwidths.
Your tool is supplied with the following:
• A straight arm 8 (sanding width 13mm).
These parts are also available as an accessory from your
DeWALT dealer:
• The offset arm 15 (sanding width 13mm)
(DCM2012OSsold separately).
NOTE: Your tool comes with the straight arm already
assembled.
Fitting
1. Make sure that the belt tensioning lever 6 is in the
positionshown in Fig. D.
2. Loosen and remove the belt tracking screw 7 .
3. Check that the spring 16 is located in its mountinghole.
4. Position the arm 8 or 15 asshown.
5. Fit the belt tracking screw and tighten it until the arm is
aligned with thetool.
ASSEMBLY AND ADJUSTMENTS
WARNING:
To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
The label on your tool may include the following symbols. The
symbols and their definitions are asfollows:
V.........................volts
Hz .......................hertz
min..................... minutes
or DC......direct current
......................Class I Construction
(grounded)
…/min.............. per minute
BPM....................beats per minute
IPM.....................impacts per minute
OPM.................... oscillations per minute
RPM.................... revolutions per minute
sfpm ................... surface feet per minute
SPM....................strokes per minute
A.........................amperes
W........................watts
Wh...................... watt hours
Ah.......................amp hours
or AC........... alternating current
or AC/DC.... alternating or direct
current
......................Class II Construction
(double insulated)
no.......................no load speed
n.........................rated speed
PSI....................... pounds per square inch
......................earthing terminal
..................... safety alert symbol
..................... visible radiation–
do not stare into
the light
..................... wear respiratory
protection
..................... wear eye protection
..................... wear hearing
protection
..................... r ead all documentation
..................... do not expose to rain
..................... hot surface
Wall Mounting
Some DeWALT chargers are designed to be wall mountable
or to sit upright on a table or work surface.If wall mounting,
locate the charger within reach of an electrical outlet, and
away from a corner or other obstructions which may impede
air flow. Use the back of the charger as a template for the
location of the mounting screws on the wall. Mount the
charger securely using drywall screws (purchased separately)
at least 1” (25.4mm) long, with a screw head diameter of
0.28–0.35” (7–9mm), screwed into wood to an optimal
ON. Once the battery pack has reached an appropriate
temperature, the yellow light will turn OFF and the charger
will resume the chargingprocedure.
DCB118 and DCB1112 Chargers
The DCB118 and DCB1112 chargers are equipped with
an internal fan designed to cool the battery pack. The fan
will turn on automatically when the battery pack needs to
becooled.
Never operate the charger if the fan does not operate
properly or if ventilation slots are blocked. Do not permit
foreign objects to enter the interior of thecharger.
Electronic Protection System
Li‑ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deep discharge. The tool will automatically
turn off and the battery pack will need to berecharged.
Important Charging Notes
1. Longest life and best performance can be obtained if
the battery pack is charged when the air temperature is
between 65° F – 75° F (18°C– 24° C). DO NOT charge
when the battery pack is below 40° F (4.5° C), or above
104° F (40° C). This is important and will prevent serious
damage to the batterypack.
2. The charger and battery pack may become warm to the
touch while charging. This is a normal condition, and
does not indicate a problem. To facilitate the cooling of
the battery pack after use, avoid placing the charger or
battery pack in a warm environment such as in a metal
shed or an uninsulatedtrailer.
3. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp
or other appliance;
b. Check to see if receptacle is connected to a light
switch which turns power off when you turn out
thelights;
c. If charging problems persist, take the tool, battery
pack and charger to your local servicecenter.
4. You may charge a partially used pack whenever you
desire with no adverse effect on the batterypack.
Charger Cleaning Instructions
WARNING:Shock hazard. Disconnectthe charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using
a cloth or soft non‑metallic brush. Do not use water or
any cleaningsolutions.
depth leaving approximately 7/32” (5.5 mm) of the screw
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in theslots.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE

13
ENGLISH
Attaching the Dust Shroud (Fig.J)
The DCM200DC dust shroud (sold separately) is also available
for use with this tool. This accessory connects to the tool's
fileheadbody.
To attach the dust shroud10, FIRST disconnect the battery
from thetool.
1. Place the ribs22 of the dust shroud10 along the
groove of the filehead body21.
2. Position the dust port11 against the filehead body to
let the dust port hole align with the filehead bodyhole.
3. Use the side handle5 to tighten the dust shroud to the
fileheadbody.
Attaching a Dust Extractor to the Dust
Shroud (Fig.R, S)
WARNING: Do not attach the dust port and connect
the dust extractor when grinding or sanding metals.
WARNING: Risk of dust inhalation.To reduce the
risk of personal injury, ALWAYS wear an approved
dustmask.
WARNING: Collected sanding dust from sanding
surface coatings (polyurethane, linseed oil, etc.) can
self‑ignite in dust extractor or elsewhere and cause
fire. To reduce risk, strictly follow sander manual and
coating manufacturer’sinstructions.
The DCM200DC dust shroud is compatible with the DWH161
DEWALT Universal Dust Extractor (soldseparately).
• Friction‑fit the dust port11 to the hose23 of the
DWH161 Universal DustExtractor.
If available, the DWV9170 adaptor30 can be used to
connect your tool to the DeWALT AirLock™ connection
system (soldseparately).
1. Push the AirLock™ connector31 onto the
DWV9170adaptor.
2. Friction‑fit the DWV9170 adaptor to the dust port.
Attaching the Side Handle (Fig.J)
WARNING: This handle SHOULD BE USED AT ALL
TIMES to maintain complete control of the tool.
Always make sure the handle istight.
Screw the side handle5 tightly into the threaded mounting
hole of the filehead body21.
Adjusting the Sanding Belt Tracking
(Fig.D, E, G, H)
1. Make sure that the sanding belt18 is properly aligned
with the straight arm8.
2. Switch the tool on and do a trial run at lowspeed.
3. Turn the belt tracking screw7 clockwise to move belt to
right, or counterclockwise to move belt to left until the
sanding belt runs straight along the length of thearm.
Fitting and Removing Sanding Belts
(Fig.E, F1–F3)
WARNING! The spring must be fitted. Be careful not to
lose thespring.
Fitting
1. Pull the belt tensioning lever6back.
2. Make sure that the arrows on the inside of the sanding
belt18face the same direction as the arrow17 on
thehousing.
3. Place the sanding belt over the rear pulley20 first. The
sanding belt should be placed under the shoulder29
(Fig. F1, F2), then hook the other side over the front
pulley19.
4. Move the belt tensioning lever to its original
forwardposition.
5. Adjust the belt tracking as describedin the Adjusting
the Sanding Belt Trackingsection.
NOTE: The sanding belt should not ride on the shoulder
of the rear pulley (Fig. F3). Be sure to place the sanding belt
under theshoulder.
NOTE: The area surrounding the rear pulley20 must be
cleaned after each use due to the risk of gatheringdust.
Removing
1. Pull the belt tensioning lever6 back to release the
tension on thebelt.
2. Slide the sanding belt18 off thepulleys.
Removing
1. Remove the sanding belt 18 (if present) as describedin
the Fitting and Removing Sanding Belts section.
2. Loosen and remove the belt tracking screw 7 .
3. Remove the arm 8 or 15 .
WARNING! Be careful not to lose the spring.
WARNING: DO NOT touch the sanding arms after
working as a high temperature may cause injury.
Adjusting the Arm Inclination (Fig.M, N)
The straight arm8 or offset arm15 can pivot and be fixed
at any desired angle within the range A (102°) as shown in
Fig. N. Make a comfortable working postion by adjusting
theangle.
1. Loosen the lock lever9 by flipping it downwards.
2. Pivot the arm to the desiredposition.
3. Secure the position of the arm firmly by flipping the lock
leverup.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
WARNING: DO NOT touch the filehead body during
use as a high temperature may causeinjury.

ENGLISH
14
MAINTENANCE
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
Switching On and Off (Fig.A)
CAUTION: DO NOT pull the variable speed trigger hard
without first unlocking the tool. Refer to the Lock-off
Button section. This can cause a breakage to the
variable speedtrigger.
1. To start the tool, pull the variable speed trigger2.
2. To turn the tool off, release the variable speedtrigger.
Variable Speed Dial (Fig.Q)
The variable speed dial1 allows you to adapt the speed of
the tool to the workpiecematerial.
The tool speed can be adjusted between 1to7.
Use a low speed setting when using a fine grit, when
working with plastics or ceramics and when removing
painted or varnishedsurfaces.
Use a high speed setting when using a coarse grit and when
removing a lot ofmaterial.
• Set the variable speed dial1 to the requiredsetting.
LED Worklight (Fig.A, P)
CAUTION: Do not stare into the LED worklight.
Serious eye injury couldresult.
The rotatable LED worklight12 can be adjusted at three
levels through an angle of 60°. When the tool is activated
by depressing the variable speed trigger2, the rotatable
LED worklight will automatically turn on. The rotatable LED
worklight will turn off 20seconds after the variable speed
trigger has beenreleased.
NOTE: Be careful not to scratch the lens of the worklight as
loss of illumination may occur. Use a dry cloth to wipe dirt off
the lens of theworklight.
Proper Hand Position (Fig.L)
WARNING: To reduce the risk of serious personal
injury, ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the main
handle4 and one hand on the side handle5.
Installing and Removing the Battery Pack
(Fig.I)
WARNING: Ensure the tool/appliance is in the off
position before inserting the batterypack.
NOTE: For best results, make sure your battery pack is
fullycharged.
1. To install the battery pack13 into the tool handle, align
the battery pack with the rails inside the tool’s handle
and slide it into the handle until the battery pack is firmly
seated in the tool and ensure that it does notdisengage.
2. To remove the battery pack from the tool, press the
battery pack release button14 and firmly pull the
battery pack out of the tool handle. Insert it into
the charger as described in the charger section of
thismanual.
Lock‑off Button (Fig.K)
WARNING: To prevent accidental start‑up, this tool is
equipped with a lock‑offbutton.
1. To lock the tool, depress the lock‑off button3 to the
locked position. When the lock‑off button is in the
locked position, the tool is locked and the variable speed
trigger2 cannot bepulled.
2. To unlock the tool, depress the lock‑off button3 to the
unlocked position.
NOTE: The tool is locked and the speed trigger can’t be
pulled while the arm is being pivoted to the storage position
(beyond102°).
Special Applications (Fig.A, V–Z)
WARNING: To reduce the risk of fire or serious injury,
avoid sanding ignitable materials such as aluminum
andmagnesium.
WARNING! DO NOT allow bystanders in front of the
tool while in operation as there may be a risk of the
sanding belt breaking and dislodging from thearm.
Straight Arm (Fig.V–Y)
Use the straight arm8 for general use, sanding, deburring,
andslotting. Work should always be performed within range
(A) of the front pulley19(Fig. V) or within range(B) of the
platen32, as shown on the straight arm (Fig. V).
• Refer to area C of the straight arm (Fig. W) for sanding in
confinedareas.
• Refer to areas D and E of the straight arm (Fig. X, Y) for
generalsanding.
Offset Arm (Fig.Z)
Where Supplied
• Use the offset arm15 for sanding curvedsurfaces.
‑Refer to area F (Fig. Z) of the offset arm for sanding a
curvedsurface.
Hints for Optimum Use
• Always hold the tool with bothhands.
• Do not exert too much pressure on thetool.
• For best belt life, sand only with the bottom side ofbelt.
• Do not exert much force in line with thearm.
• Regularly check the condition of the sanding belt18.
Replace whennecessary.
• Always sand with the grain of thewood.
• When sanding new layers of paint before applying
another layer, use extra finegrit.
• Consult your retailer for more information on
availableaccessories.

15
ENGLISH
Belt Hook (Fig.U)
Optional Accessory
WARNING:To reduce the risk of serious personal
injury, ONLY use the tool’s belt hook to hang the
tool from a work belt. DO NOT use the belt hook
for tethering or securing the tool to a person or object
during use. DO NOT suspend tool overhead or suspend
objects from the belthook.
WARNING:To reduce the risk of serious personal
injury, ensure the screw holding the belt hook
issecure.
IMPORTANT: When attaching or replacing the belt hook,
use only the mounting screw28 that is provided. Be sure to
securely tighten thescrew.
The belt hook27 can be attached to either side of the tool
using only the screw provided, to accommodate left‑ or
right‑handed users. If the hook is not desired at all, it can be
removed from thetool.
To move belt hook, remove the screw that holds the belt
hook in place, then reassemble on the opposite side. Be sure
to securely tighten thescrew.
Repairs
The worklight is not serviceable. The light bulb cannot be
replaced by the user.
The charger and batteries are notserviceable. There are no
serviceable parts inside the charger or batterypack.
WARNING: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (including
brush inspection and replacement, when applicable)
should be performed by a factory service center or
an authorized service center. Always use identical
replacementparts.
Accessories
WARNING:
Since accessories, other than those offered
by DeWALT, have not been tested with this product,
use of such accessories with this product could be
hazardous. To reduce the risk of injury, only DeWALT
recommended accessories should be used with
thisproduct.
Recommended accessories for use with your product are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact DeWALT. Call 1-800-4-DeWALT
(1-800-433-9258) or visit our website: www.dewalt.com.
Cleaning
WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performing thisprocedure.
WARNING: Never use solvents or other harsh
chemicals for cleaning the non‑metallic parts of the
tool. These chemicals may weaken the plastic materials
used in these parts. Use a cloth dampened only with
water and mild soap. Never let any liquid get inside the
tool; never immerse any part of the tool into aliquid.
Storage (Fig.M–O)
CAUTION: Be careful not to pinch your fingers when
moving the straight arm. Failure to do so may cause
personalinjury.
The straight arm8 can be folded up to save on storage
space as shown in Fig. O. The straight arm can move through
an angle of up to 172°.
1. Loosen the lock lever9 by flipping it down. Pivot the
arm at an angle of 102°.
2. Push the lock‑off button3, and then adjust the angle
of the straight arm in the range B (102° to 172°) shown
in Fig. N.
3. Secure the lock lever by flipping it up to fix thearm.
NOTE: The tool is locked and the speed trigger can’t be
pulled while the arm is being pivoted to the storage position
(beyond102°).
Tool Connect™ Chip (Fig.T)
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
Your tool is Tool Connect™ Chip ready and has a location for
installation of a Tool Connect™ Chip.
Tool Connect™ Chip is an optional application for your
smart device (such as a smart phone or tablet) that connects
the device to utilize the mobile application for inventory
management functions.
Refer to Tool Connect™Chip Instruction Sheet for
moreinformation.
Installing the Tool Connect™ Chip
1. Remove the retaining screws24 that hold the Tool
Connect™ Chip protective cover25 into thetool.
2. Remove the protective cover and insert the Tool
Connect™ Chip into the empty pocket26.
3. Ensure that the Tool Connect™ Chip is flush with the
housing. Secure it with the retaining screws and tighten
thescrews.
4. Refer to Tool Connect™Chip Instruction Sheet for
furtherinstructions.
Register Online
Thank you for your purchase. Register your product nowfor:
• WARRANTY SERVICE: Registering your product will help
you obtain more efficient warranty service in case there is
a problem with yourproduct.
• CONFIRMATION OF OWNERSHIP: In case of
an insurance loss, such as fire, flood or theft, your
registration of ownership will serve as your proof
ofpurchase.
Your DeWALT power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.

ENGLISH
16
Three Year Limited Warranty
For warranty terms, go to https://www.dewalt.com/
support/warranty.
To request a written copy of the warranty terms, contact:
Customer Service at DeWALT Industrial Tool Co., 701East
Joppa Road, Towson, MD 21286or call 1-800-4-DeWALT
(1-800-433-9258).
LATIN AMERICA: This warranty does not apply to products
sold in Latin America. For products sold in Latin America,
see country‑specific warranty information contained in
the packaging, call the local company or see website for
warrantyinformation.
FREE WARNING LABEL REPLACEMENT: If your warning
labels become illegible or are missing, call 1-800-4-DeWALT
(1-800-433-9258) for a freereplacement.
• FOR YOUR SAFETY: Registering your product will allow
us to contact you in the unlikely event a safety notification
is required under the Federal Consumer SafetyAct.
• Register online at www.dewalt.com.

FRANÇAIS
17
1) Sécurité du lieu de travail
a ) Tenir l’aire de travail propre et bien éclairée.
Les lieux encombrés ou sombres sont propices
auxaccidents.
b ) Ne pas faire fonctionner d’outils électriques
dans un milieu déflagrant, tel qu’en présence de
liquides, de gaz ou de poussières inflammables.
Les outils électriques produisent des étincelles qui
pourraient enflammer la poussière ou lesvapeurs.
c ) Éloigner les enfants et les personnes à proximité
pendant l’utilisation d’un outil électrique. Une
distraction pourrait en faire perdre la maîtrise
àl’utilisateur.
2) Sécurité en matière d’électricité
a ) Les fiches des outils électriques doivent
correspondre à la prise. Ne jamais modifier la
fiche d’aucune façon. Ne jamais utiliser de fiche
d’adaptation avec un outil électrique mis à la
terre. Le risque de choc électrique sera réduit par
l’utilisation de fiches non modifiées correspondant
àlaprise.
b ) Éviter tout contact physique avec des surfaces
mises à la terre comme des tuyaux, des radiateurs,
des cuisinières et des réfrigérateurs. Le risque de
choc électrique est plus élevé si votre corps est mis
àlaterre.
c ) Ne pas exposer les outils électriques à la pluie ou
à l’humidité. La pénétration de l’eau dans un outil
électrique augmente le risque de chocélectrique.
d ) Ne pas utiliser le cordon de façon abusive. Ne
jamais utiliser le cordon pour transporter, tirer
ou débrancher un outil électrique. Tenir le
cordon éloigné de la chaleur, de l’huile, des bords
tranchants et des pièces mobiles. Les cordons
endommagés ou enchevêtrés augmentent les risques
de chocélectrique.
e ) Pour l’utilisation d’un outil électrique à l’extérieur,
se servir d’une rallonge convenant à cette
application. L’utilisation d’une rallonge conçue pour
l’extérieur réduira les risques de chocélectrique.
f ) S’il est impossible d’éviter l’utilisation d’un
outil électrique dans un endroit humide,
brancher l’outil dans une prise ou sur un circuit
d’alimentation dotés d’un disjoncteur de fuite à
la terre (GFCI). L’utilisation de ce type de disjoncteur
réduit les risques de chocélectrique.
3) Sécurité personnelle
a ) Être vigilant, surveiller le travail effectué et faire
preuve de jugement lorsqu’un outil électrique est
utilisé. Ne pas utiliser d’outil électrique en cas de
fatigue ou sous l’influence de drogues, d’alcool ou
de médicaments. Un simple moment d’inattention en
utilisant un outil électrique peut entraîner des blessures
corporellesgraves.
b ) Utiliser des équipements de protection
individuelle. Toujours porter une protection
oculaire. L’utilisation d’équipements de protection
comme un masque antipoussière, des chaussures
AVERTISSEMENTS GÉNÉRAUX SUR LA
SÉCURITÉ DES OUTILS
AVERTISSEMENT : lisez tous les avertissements de
sécurité, toutes les instructions, les illustrations
et les caractéristiques fournis avec cet outil
électrique. Ne pas suivre toutes les instructions
comprises aux présentes peut conduire à un choc
électrique, un incendie et/ou des blessuresgraves.
CONSERVER TOUS LES
AVERTISSEMENTS ET TOUTES
LES DIRECTIVES POUR UN
USAGEULTÉRIEUR.
Le terme « outil électrique » cité dans les avertissements se
rapporte à votre outil électrique à alimentation sur secteur
(avec fil) ou par piles (sansfil).
Définitions: symboles et mentions d'alerte
de sécurité
Cette notice d'utilisation utilise les symboles et les mentions
d'alerte de sécurité suivants afin de vous alerter sur les
situations dangereuses et les risques de blessures ou de
dégâtsmatériels.
DANGER: indique une situation de risque imminent
qui engendre, si elle n'est pas évitée, la mort ou de
gravesblessures.
AVERTISSEMENT: indique une situation de risque
potentiel qui pourrait engendrer, si elle n'est pas évitée,
la mort ou de gravesblessures.
ATTENTION: indique une situation de risque potentiel
qui peut engendrer, si elle n'est pas évitée, des
blessures bénignes oumodérées.
REMARQUE: indique une pratique n'entraînant
aucun risque de blessures mais qui, si elle n'est pas
évitée, peut entraîner des dommagesmatériels.
(Utilisé sans mention) Indique un message lié à lasécurité.
Utilisation prévue
Votre ponceuse à bande est conçue pour le ponçage du bois,
du métal, du plastique et des surfaces peintes.
Pour un équilibre optimal, utilisez une pile de 5Ah ou moins.
NE PAS utiliser en conditions mouillées ou en présence de
liquides ou de gaz inflammables.
Votre ponceuse à bande est un outil électrique professionnel.
NE PAS laisser les enfants entrer en contact avec l’outil.
Une supervision est requise lorsque des utilisateurs
inexpérimentés utilisent cet outil.
Français (traduction de la notice d’instructions originale)
AVERTISSEMENT: lisez tous les avertissements de
sécurité, toutes les instructions, les illustrations
et les caractéristiques fournis avec cet outil
électrique. Ne pas suivre toutes les instructions
indiquées ci‑dessous peut conduire à un choc
électrique, un incendie et/ou des blessuresgraves.
AVERTISSEMENT: pour réduire le risque de blessure,
lisez le guided’utilisation.

FRANÇAIS
18
e ) Gardez les poignées et surfaces d’emprise propres
et libres de tout produit lubrifiant. Vérifier si les
pièces mobiles sont mal alignées ou coincées,
si des pièces sont brisées ou présentent toute
autre condition susceptible de nuire au bon
fonctionnement de l’outil électrique. En cas de
dommage, faire réparer l’outil électrique avant
toute nouvelle utilisation. Beaucoup d’accidents
sont causés par des outils électriques malentretenus.
f ) S’assurer que les outils de coupe sont aiguisés et
propres. Les outils de coupe bien entretenus et affûtés
sont moins susceptibles de se coincer et sont plus
faciles àmaîtriser.
g ) Utiliser l’outil électrique, les accessoires, les forets,
etc. conformément aux présentes directives en
tenant compte des conditions de travail et du
travail à effectuer. L’utilisation d’un outil électrique
pour toute opération autre que celle pour laquelle il a
été conçu estdangereuse.
h ) Garder vos mains et les surfaces de prise sèches,
propres et libres de graisse et de poussière. Les
mains et les surfaces de prise glissante ne permettent
pas la manutention et le contrôle sécuritaires de l’outil
dans les situationsimprévues.
5) Utilisation et entretien du bloc‑piles
a ) Ne recharger l’outil qu’au moyen du chargeur
précisé par le fabricant. L’utilisation d’un chargeur
qui convient à un type de bloc‑piles risque de
provoquer un incendie s’il est utilisé avec un autre type
de bloc‑piles.
b ) Utiliser les outils électriques uniquement avec
les blocs‑piles conçus à cet effet. L’utilisation de
tout autre bloc‑piles risque de causer des blessures ou
unincendie.
c ) Lorsque le bloc‑piles n’est pas utilisé, le tenir
éloigné des objets métalliques, notamment
des trombones, de la monnaie, des clés, des
clous, des vis ou autres petits objets métalliques
qui peuvent établir une connexion entre les
deux bornes. Le court‑circuit des bornes du bloc‑piles
risque de provoquer des brûlures ou unincendie.
d ) En cas d’utilisation abusive, le liquide peut gicler
hors du bloc‑piles; éviter tout contact avec ce
liquide. Si un contact accidentel se produit, laver
à grande eau. Si le liquide entre en contact avec
les yeux, obtenir également des soins médicaux.
Le liquide qui gicle hors du bloc‑piles peut provoquer
des irritations ou desbrûlures.
e ) Ne pas utiliser de bloc‑piles ou outil qui a été
endommagé ou modifié. Les unités endommagées
ou modifiées peuvent avoir une réaction imprévisible
résultant en un incendie, une explosion ou un potentiel
deblessure.
f ) Ne pas exposer de bloc‑piles ou l’outil aux
flammes ou à des températures excessives.
L’exposition aux flammes ou à une température
au‑dessus de 130°C (265°F) pourrait causer
uneexplosion.
antidérapantes, un casque de sécurité ou des
protecteurs auditifs lorsque la situation le requiert
réduira les risques de blessurescorporelles.
c ) Empêcher les démarrages intempestifs. S’assurer
que l’interrupteur se trouve à la position d’arrêt
avant de relier l’outil à une source d’alimentation
et/ou d’insérer un bloc‑piles, de ramasser ou de
transporter l’outil. Transporter un outil électrique
alors que le doigt repose sur l’interrupteur ou brancher
un outil électrique dont l’interrupteur est à la position
de marche risque de provoquer unaccident.
d ) Retirer toute clé de réglage ou clé avant de
démarrer l’outil. Une clé ou une clé de réglage
attachée à une partie pivotante de l’outil électrique
peut provoquer des blessurescorporelles.
e ) Ne pas trop tendre les bras. Conserver son
équilibre en tout temps. Cela permet de mieux
maîtriser l’outil électrique dans les situationsimprévues.
f ) S’habiller de manière appropriée. Ne pas porter
de vêtements amples ni de bijoux. Garder les
cheveux, les vêtements et les gants à l’écart des
pièces mobiles. Les vêtements amples, les bijoux ou
les cheveux longs risquent de rester coincés dans les
piècesmobiles.
g ) Si des composants sont fournis pour le
raccordement de dispositifs de dépoussiérage
et de ramassage, s’assurer que ceux‑ci sont bien
raccordés et utilisés. L’utilisation d’un dispositif de
dépoussiérage peut réduire les dangers engendrés par
lespoussières.
h ) Ne pas laisser votre connaissance acquise suite
l’utilisation fréquente des outils vous permettre
de baisser la garde et ignorer les principes de
sécurité de l’outil. Un acte irréfléchi peut causer une
blessure grave en une fraction deseconde.
4) Utilisation et entretien d’un
outilélectrique
a ) Ne pas forcer un outil électrique. Utiliser l’outil
électrique approprié à l’application. L’outil
électrique approprié effectuera un meilleur travail,
de façon plus sûre et à la vitesse pour laquelle il
aétéconçu.
b ) Ne pas utiliser un outil électrique dont
l’interrupteur est défectueux. Tout outil électrique
dont l’interrupteur est défectueux est dangereux et doit
êtreréparé.
c ) Débranchez la fiche de la prise électrique et, si
amovible, retirez le bloc‑piles de l’outil avant
d’effectuer tout ajustement, changement et
entreposage de celui‑ci. Ces mesures préventives
réduisent les risques de démarrage accidentel de
l’outilélectrique.
d ) Ranger les outils électriques hors de la portée
des enfants et ne permettre à aucune personne
n’étant pas familière avec un outil électrique ou
son mode d’emploi d’utiliser cet outil. Les outils
électriques deviennent dangereux entre les mains
d’utilisateursinexpérimentés.
