PRODUCT BULLETIN
DEWALT
DW710 TYPE 2
TABLE MITRE SAW
JUNE 1999
Contents
Attached to this Bulletin :
Copy of service parts lists DW710-----B
Copyof service parts drawings E12685, E12686
Wiring Diagram E12791
Introduction
Introduce the newversion of the DW710 changed to type 2. The product has been
standardised to incorporate some of the features designed into the DW711, for your
information the following items have been changed :
item 121 Newtwo piece fence to provide better adjustment when cutting small
pieces
item 112 Standardise guard (as TGS) to improve the fitting, and angle that the
guard closes to cover the blade.
items 86, 87,Newfixings to improve the fastening of the table, providing
115 greater stability
item 90, 91 Newswitch and cover
item 49 Modified segment to improve the guard locking (user complaints on old
system that used a spring, button, screw)
item 55 Modified frame, which is smaller for the DW711 to prevent it touching
the fence, and is standardised on the DW710
item 57 Modified guard to suit the frame (55), plus dust slots added to umprove
extraction
item 154 The supplementaryguard is increased in size to completelycover the
blade, and is standardised on the DW710 & DW711
item 27 The fixed guard is modified to prevent it touching the PS base used on
the DW711 and is standardised on the DW710
Page 1
items 45, 24
32, 76 New fixings to replace the old system for locking the guard (See also
comments on segment)
item 51 New riving knife to improvem alignment to blade nad allow fitting of
new TGS guard
item 83 Handles standardised between DW711 (needed for new switch) and
DW710
item 84 Longer head lock rod to improve ergonomics
item 104 Position of hole changed for DW711 and standardised on DW710
items 142
847, 137 New motor standardised same as DW711
The new parts specific to DW710 have been released this week on change notes
A6290, plus the parts standardised with the DW711 were released on the DW711
change notes also released this week (A6272,3,4)
Manufacture Tatry, Italy
Parts warehouse Idstein, Germany
Page 2
TYP.
DW710
A2
85
99
103
101
98
104
106
113
83
56
97
102
69
130
74
39
63
64
75
71
79
148
81
149
89 38
95
82 105
144
94 93 39
125
78
115
123
101 98 18
140
142
96
157
155
5
7
135
136 137
138
139
146 150
68
73
72
159
162
161
143
145
166
168
120
03 / 06 / 99
847
128
119
129 160
115
158
116
114
91
84
E12685 / 861438-01
87
86
115 126
131
127
133
121
134
156
112
118
32
117
90
TYP.
DW710 A2
70 34 32
46
47
50
49
38
15
27
48
15
38
60
61
62
64
65
66
67 55 59
58
61
15
37
6
38
36
28
17
39
35
33
12 22
13
11
910 8
1
26
25
16 17
4
14
15
3
18 19
1
2
109
18
23
154
107
57
30
29
40
111
110
108
164
34
31
32
846
17
03 / 06 / 99
37
51
54
16
52
E12686 / 861438-01
45
32
76
24
53
16
TYP.
Switch with drop
voltage device
Line cable with plug, to be
connected to the Line
Capacitor
Black
Yellow / Green
Red
Black
White
Earth
ENGLISH FRENCH ITALIAN GERMAN
BLACK NOIR NERO SCHWARZ
WHITE BLANC BIANCO WEISS
BROWN BRUN MARRONE BRAUN
BLUE BLEU BLU BLAU
RED ROUGE ROSSO ROT
YELLOW JAUNE GIALLO GELB
GREEN VERT VERDE GRUN
ORANGE ORANGE ARANCIO ORANGE
GREY GRIS GRIGIO GRAU
COLOUR KEY
CLEAR
..
KLAR
DW710 2
03 / 06 / 99E12791
DW710-----B A2
-------------------------------------------------
ITEM DESCRIPTION PART NO. QTY
1 FOOT 402804-00 4
2 LEVER 862002-00 1
3 CAP 760427-00 1
4 BRACKET 863612-00 1
5 SCREW 860094-03 2
6 KNOB 862428-00 1
7 SCREW 949889-02 1
8 BASE 863608-05 1
9 PIN 863072-00 1
10 SPACER 863702-00 1
11 POINTER 863686-00 1
12 SCREW 860093-17 1
13 WASHER SPRING 860074-00 1
14 WASHER 860074-02 1
15 NUT 860083-03 1
16 WASHER 860074-03 1
17 NUT 860083-04 1
18 NUT 860083-02 1
19 SPRING 123255-01 1
22 SCREW 860084-03 1
23 WASHER M8 860073-03 1
24 CIRCLIP 860079-03 1
25 SPANNER 10-13MM 949751-07 1
26 SPANNER 939072-00 1
27 GUARD 861918-01 1
28 FENCE 862099-00 1
29 GUARD SA 864693-01 1
30 HUB 863039-00 1
31 NUT 860092-01 1
32 WASHER M8 860073-03 1
33 TABLE ROTARY 862179-90 1
34 SCREW 860086-10 1
35 BUSH 949748-01 1
36 SCREW 760219-00 1
37 SPACER 862447-00 3
38 SCREW.TEMP 860085-09 1
39 NUT M6 860083-12 1
40 SCREW 862182-01 1
50 PLATE 945641-00 1
51 RIVING KNIFE 861919-00 1
52 SPACER 862075-00 1
53 SCREW 860093-00 1
54 SCREW.TEMP 860093-05 1
55 FRAME 861890-00 1
56 BOLT 949886-21 1
57 SPACER 861920-00 1
58 SHIM 949761-02 1
59 LOCK NUT 949759-01 1
60 SCREW 860085-07 1
61 WASHER 720959-00 1
62 SPRING LH 863606-00 1
63 SPRING RH 863590-00 1
64 SHIM 863611-00 1
65 SCREW 863602-00 1
66 PLATE 863610-00 1
67 SPRING 863604-00 1
68 PIN 863607-00 1
69 CLAMP 861692-00 1
70 SCREW 863262-00 1
71 SCREW 860094-02 1
72 PIN 863605-00 1
73 O RING 949746-02 1
74 PIN 860088-10 1
75 SCREW 949853-04 1
76 SCREW 860093-14 1
78 KNOB 946469-00 1
79 GASKET 863026-00 1
81 WASHER SPRING 944650-00 1
82 INLET 863573-00 1
83 HANDLE & COVER 862429-04 1
84 ROD 863613-01 1
85 GUARD UPPER 402803-01 1
86 SPRING 868082-00 1
87 LOCKING PIN 861963-00 1
89 CAPACITOR 949772-23 1
90 SWITCH SA 861930-00 1
91 COVER 861964-00 1
93 SCREW 860084-09 1
94 GASKET 863026-00 1
95 WASHER 860075-00 1
96 SCREW 860085-07 1
97 OUTER FLANGE 861056-00 1
98 WASHER 720959-00 4
99 SCREW 860094-03 3
101 SCREW 860084-22 4
102 INNER FLANGE 861057-01 1
103 TABLE 402802-02 1
104 BRACKET 402801-00 1
105 SCREW 930076-00 1
106 SCREW 949886-16 1
107 WRENCH 6 MM 860098-04 1
108 HEX KEY 930574-00 1
109 HANDLE 863044-02 1
110 WASHER 860073-01 1
111 SCREW 860089-18 1
112 GUARD 941844-04 1
113 WASHER 949876-06 1
114 SUCTION PIPE 943582-01 1
115 KNOB 861464-00 1
116 WASHER 860073-08 1
117 NUT 860655-01 1
118 SCREW 931462-00 1
119 FENCE 861978-00 1
120 PLASTIC INSERT 861748-00 1
121 FENCE SA 861982-00 1
123 BRACKET 402800-00 1
125 CABLE 860731-00 1 M-CH
125 CABLE SA 860472-00 1 M-DE
125 CABLE 861432-05 1 M-GB
126 FENCE 861422-02 1
127 SPACER 861453-00 1
128 SCREW 949886-11 2
129 SUPPORT 861421-00 1
130 SUPPORT BRACKET 862180-06 1
131 KNOB 861452-00 1
133 END CAP 861423-00 1
134 WASHER 860073-14 2
135 CAP 863112-00 1
136 COVER 860445-00 1
137 FAN 945841-00 1
138 HOUSING SA 861345-00 1
139 * CAP 861336-02 1 T-AFTER WEEK 36-97
139 * CAP 861336-00 1 T-PRE WEEK 36-97
140 TIE ROD 863015-00 1
142 STATOR SA 230V 864313-15 1
143 RING 860080-02 1
144 SHEATH 863025-00 1
145 CIRCLIP 861349-00 1
146 SPRING 861338-00 1
148 RING 860806-00 1
149 BEARING 860155-00 1
150 BEARING 860155-04 1
154 GUARD 861917-00 1
155 NUT 941535-00 1
156 NUT 860083-13 2
157 PUSHROD 860610-01 1
158 SCREW 931997-00 1
159 SCALE 863576-01 1
160 NUT 860083-04 1
161 SCREW 860094-02 1
162 STRAP 123106-00 1
164 SPACER 864049-00 1
166 SCREW 949702-17 1
168 CONNECTOR 861257-00 1
846 PARTS PACK 861446-00 1
847 * ROTOR SA 861835-01 1
CE LPA SOUND PRESSURE DB(A) 90.8
CE LWA ACOUSTIC POWER DB(A) 98.8
VOLTAGE #1 VOLTS 230
INPUT WATTS #1 WATTS 1300
OUTPUT WATTS #1 WATTS 900
RPM #1 2850
FREQUENCY #1 HZ 50
