Advantech PCA-6144V User manual

PCA-6144V
Half-size 486 CPU Card
with SVGA Controller

Copyright Notice
This document is copyrighted, 1996, by Advantech Co., Ltd. All
rights are reserved. Advantech Co., Ltd., reserves the right to make
improvements to the products described in this manual at any time
without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of Advantech Co., Ltd. Information provided in this
manual is intended to be accurate and reliable. However, Advan-
tech Co., Ltd. assumes no responsibility for its use, nor for any
infringements upon the rights of third parties which may result
from its use.
Acknowledgements
AMD is a trademark of Advanced Micro Devices, Inc.
Award is a trademark of Award Software International, Inc.
IBM, PC AT and VGA are trademarks of International Business
Machines Corporation.
Microsoft Windows®and MS-DOS are trademarks of Microsoft
Corporation.
SMC is a trademark of Standard Microsystems Corporation.
TGUI 9440 is a trademark of Trident MicroSystems, Inc.
Cyrix is a trademark of Cyrix Corporation.
Intel is a trademark of Intel Corporation.
PartNo.2006144010 2ndEdition
Printed in Taiwan May 1996

A Message to the Customer....
Advantech Customer Services
Each and every Advantech product is built to the most exacting
specifications to ensure reliable performance in the unusual and
demanding conditions typical of industrial environments. Whether
your new Advantech equipment is destined for the laboratory or
the factory floor, you can be assured that it will provide the
reliability and ease of operation for which the name Advantech has
come to be known.
Your satisfaction is our number one concern. Here is a guide to
Advantech’s customer services. To ensure you get the full benefit
of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your prod-
ucts. If you run into technical difficulties, we are here to help. But
please consult this manual first.
If you still can’t find the answer, gather all the information or
questions that apply to your problem and, with the product close at
hand, call your dealer. Our dealers are trained and ready to give
you the support you need to get the most from your Advantech
products. In fact, most problems reported are minor and are able to
be easily solved over the phone.
In addition, free technical support is available from Advantech
engineers every business day. We are always ready to give advice
on application requirements or specific information on the
installation and operation of any of our products.

Product warranty
Advantech warrants to you, the original purchaser, that each of its
products will be free from defects in materials and workmanship
for one year from the date of purchase.
This warranty does not apply to any products which have been
repaired or altered by other than repair personnel authorized by
Advantech, or which have been subject to misuse, abuse, accident
or improper installation. Advantech assumes no liability as a
consequence of such events under the terms of this Warranty.
Because of Advantech’s high quality-control standards and
rigorous testing, most of our customers never need to use our
repair and replacement service. If an Advantech product ever does
prove defective, it will be repaired at no charge during the warran-
ty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time and freight.
Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered (e.g.
type of PC, CPU speed, Advantech products used, other
hardware and software used etc.). Note anything abnormal and
list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your
manual, product and any other information readily available.
3. If your product is diagnosed as defective, obtain an RMA
(return material authorization) number from your dealer. This
allows us to process your return more quickly.
4. Carefully pack the defective product, a completely filled-out
Repair and Replacement Order Card and a photocopy of a
dated proof of purchase (such as your sales receipt) in a
shippable container. A product returned without dated proof of
purchase is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package
and ship it prepaid to your dealer.

Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 PCA-6144V CPU card
• 1 6-pin mini-DIN keyboard & PS/2 mouse adapter
• 1 Hard disk drive (IDE) interface cable (40 pin)
• 1 Floppy disk drive interface cable (34 pin)
• 1 Parallel port adapter (26 pin) and COM2 adapter (9 pin) kit
• 3 Utility disks with SVGA utility programs and drivers
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.

Contents
Chapter 1 Hardware Configuration ........................... 1
Introduction............................................................................ 2
Specifications.......................................................................... 3
System...................................................................................... 3
I/O ............................................................................................ 3
General..................................................................................... 4
Boardlayout............................................................................ 5
Jumpers and connectors........................................................ 6
Safety precautions .................................................................. 7
Jumper settings ...................................................................... 8
How to set jumpers .................................................................. 8
CPU type select (J1 - J16)........................................................ 9
RTC data erase On/Off (J17) ................................................. 11
Parallel port IRQ select (J18) ................................................ 12
Parallel port ECP/EPP DMA channel (J20, J21)................... 12
Watchdog timer (J28)............................................................. 12
COM2 settings for RS-232/485 (J23-27) .............................. 13
Installing DRAM (SIMMs) ................................................. 14
Chapter 2 Connecting peripherals .......................... 15
Enhanced IDE connectors (CN1) ....................................... 17
Floppy drive connector (CN4)............................................. 18
Parallel port (CN7)............................................................... 18
Keyboard & PS/2 mouse connectors (CN5)....................... 18
Reset switch (J29)................................................................. 19
Hard disk drive LED (D2)................................................... 19
VGA display connector (CN8)............................................. 19
Serial Ports............................................................................ 19
RS-232 connections (COM1) ................................................ 20
RS-232/485 connections (COM2) ......................................... 20
Power connectors (CN9, CN10)............................................. 21
External speaker connector (CN13)....................................... 21
Keyboard pin-header connector (CN14)................................ 22
Power LED and keylock (CN15) ........................................... 22

Chapter 3 AWARD BIOS SETUP ................................... 23
AWARD BIOS Setup............................................................ 24
Entering setup ........................................................................ 24
Standard CMOS setup ........................................................... 25
BIOS features setup ............................................................... 26
CHIPSET features setup ........................................................ 30
Power management setup....................................................... 31
Load BIOS defaults ............................................................... 32
Load setup defaults ................................................................ 32
Password setting ..................................................................... 32
IDE HDD auto detection........................................................ 33
Save & Exit setup................................................................... 33
Exit without saving ................................................................ 33
Chapter 4 SVGA Setup ............................................... 35
SVGA driver installation ..................................................... 36
Installing from Windows........................................................ 36
Screen Control...................................................................... 38
Advanced features (Virtual Screen Control).......................... 40
DPMS (Display Power Management Signaling) ................ 43
Delay Time ............................................................................. 44
Activity Select........................................................................ 44
Clock ...................................................................................... 44
Alarm ..................................................................................... 45
Password Option .................................................................... 45
Startup On/Off ....................................................................... 45
Default ................................................................................... 45
Test ......................................................................................... 45
Save ........................................................................................ 45

Display driver Uninstallation .............................................. 46
MicrosoftWindowsNT ........................................................ 47
Installation ............................................................................. 47
Microsoft Windows NT 3.5 Installation ................................ 47
Utilities installation .............................................................. 49
Utilities summary .................................................................. 50
Software drivers installation ............................................... 55
Appendix A Programming the Watchdog Timer .... 57
Appendix B Hardware Interrupt Information ........ 60

Chapter 1 Hardware Configuration 1
1
Hardware
Configuration
This chapter gives background informa-
tion on the PCA-6144V. It then shows you
how to configure the card to match your
application and prepare it for installation
into your PC.
Sections include:
• Card specifications
• Board layout
• Safety precautions
• Jumper settings
• Installing DRAM (SIMMs)
CHAPTER

2PCA-6144V User's Manual
Introduction
The PCA-6144V is an all-in-one single board 486 computer that includes
an on-board SVGA controller. It packs all the functions of an industrial
computer, including display capabilities, on a single half-size card. The
PCA-6144V is fully PC/AT compatible, so your software will run without
modifications.
The on-board VL-bus SVGA controller uses the Trident TGUI 9440
chipset with 1 MB video memory. This chipset, used with the local bus,
enables 32-bit graphic throughput at up to 33 MHz. The TGUI 9440 also
offers Windows graphics acceleration. These features are excellent for
display-intensive applications.
Another feature of the PCA-6144V is the inclusion of a fast VL bus
enhanced IDE controller. This controller supports mode 4, which enables
data transfer rates in excess of 16 MB/second. Up to two IDE devices can
be connected, including large hard disks (up to 8 GB), CD-ROM drives,
Tape backup drives or other enhanced IDE devices.
On-board features also include two high-speed serial ports with 16C550
UARTs, one bidirectional SPP/EPP/ECP parallel port and a floppy drive
controller. In addition to the 486's 8 KB of on-chip cache memory, the
PCA-6144V includes an extra 128 KB of second level cache memory on-
board.
If program execution is halted by a program bug or EMI, the board's 63-
level watchdog timer can automatically reset the CPU or generate an
interrupt. This ensures reliability in unmanned or standalone systems. The
timer interval of the watchdog timer is set by software, eliminating jumper
switch setting.
The PCA-6144V provides two 72-pin SIMM (Single In-line Memory
Module) sockets for its on-board system DRAM. These sockets give you
the flexibility to configure your system from 1 MB to 64 MB of DRAM
using the most economical combination of SIMMs.

Chapter 1 Hardware Configuration 3
Specifications
System
•CPU: 80486SX/DX/DX2/DX4-25/33/40/50/66/75/100/120 MHz,
Cyrix 5x86-100/120 MHz, or AMD 5x86-133 MHz
•2nd level cache: 128 KB on board
•Bus interface: ISA
•Chipset: VIA VT82C496G
•BIOS: AWARD
•Display controller: SVGA, VL bus, Trident TGUI chipset with
1 MB standard video memory. Provides 32-bit graphic throughput
with Windows acceleration. Supports resolutions up to 1280 x 1024
in 16 colors, 800 x 600 in 65536 colors, or 640 x 480 in 16.8
million colors.
•Processing ability: 32 bit
•Bus speed: 8 MHz (ISA)
•RAM memory: 1 MB to 64 MB. Uses two 72-pin SIMM sockets.
72-pin sockets accept 1, 2, 4, 8, 16 or 32 MB SIMMs
•Shadow RAM memory: Supports system and video BIOS of up to
256 KB in 16 KB blocks
I/O
•Enhanced IDE hard disk drive interface:
Fast VL bus. Supports up to two IDE (AT bus) large (up to 8 GB)
hard disk drives or other enhanced IDE devices. Supports mode 4
(16.6 MB/sec. data transfer rate). BIOS enabled/disabled
•Floppy disk drive interface: Supports up to two floppy disk drives,
5.25" (360 KB and 1.2 MB) and/or 3.5" (720 KB, 1.44 MB and 2.88
MB). BIOS enabled/disabled

4PCA-6144V User's Manual
•Enhanced bidirectional parallel port: Configurable to LPT1,
LPT2, LPT3, or disabled. Standard DB-25 female connector
provided. Supports SPP/EPP/ECP
•Serial ports: Two serial ports, both with 16C550 UARTs (or
compatible) with 16-byte FIFO buffer. COM1 is RS-232, COM2 is
RS-232 or RS-485. Support speeds up to 115 Kbps. Ports can be
individually configured as COM1, COM2 or disabled.
•Keyboard & PS/2 mouse connector: A 6-pin mini DIN keyboard
connector is located on the mounting bracket for easy connection of
a keyboard or a PS/2 mouse.
•Watchdog timer: Can generate a system reset or IRQ15. The timer
interval is 1 - 63 sec. (63 levels), set up by software.
General
•System performance (with 80486DX4-100 MHz CPU):
363 MHz, Landmark speed V2.0
•Max. power requirements: +5 V, 3.5 A
•Power supply voltage: +5 V (4.75 V to 5.25 V)
•Operating temperature: 32 to 140oF (0 to 60oC)
•Storage temperature: -40 to +176°F (-40 to +80oC)
•Humidity: 5 to 95%, non-condensing
•Board size: 7.3" (L) x 4.8" (W) (185 mm x 122 mm)
•Board weight: 1.2 lb. (0.5 kg)

Chapter 1 Hardware Configuration 5
Board layout
PCA-6144V PCB Layout
486 CPU
11
J1
1
J2
J5 J4
J3
J6 J7 J8
J9 J10
J12 J14
J11 J13 J15 J16
CN13
J17 J18 J20
J21
J22
J23
J24 J25 J26 J27
J28
J29
CN1 CN4 CN7
CN8
CN11
CN9 CN10
CN6
CN5
Bank 1 0
CN12
D2
+
CN15
CN14
CN15
1 1
1 1
1

6PCA-6144V User's Manual
Jumpers and connectors
Connectors on the board link it to external devices such as hard disk
drives, a keyboard, or floppy drives. In addition, the board has a
number of jumpers which you use to configure it for your application.
The table below lists the function of each of the board jumpers and
connectors. Later sections in this chapter give instructions on setting
jumpers and detailed information on each jumper setting. Chapter 2
gives instructions for connecting external devices to your card.
PCA-6144V Jumpers
Number Function
J1-J8 CPU type select
J9 CPU voltage select
J10 CPU voltage select
J11 CPU type select
J12 CPU type select
J13 CPU type select
J14 Factory reserved
J15 CPU type select
J16 CPU type select
J17 RTC erase On/Off
J18 Parallel port IRQ select
J20 Parallel port DMA select
J21 Parallel port DMA select
J22 Factory reserved
J23 COM2 select
J24 COM2 select
J25 COM2 select
J26 COM2 select
J27 COM2 select
J28 Watchdog timer reset/IRQ15 select
J29 Reset
D2 HDD LED

Chapter 1 Hardware Configuration 7
PCA-6144V Connectors
Number Function
CN1 EIDE connector
CN2 PC/104 connector (8 bit)
CN3 PC/104 connector (16 bit)
CN4 Floppy connector
CN5 Keyboard & PS/2 mouse DIN connector
CN6 COM2 pin-header connector
CN7 Parallel port connector
CN8 VGA DB-15 connector
CN9 Power connector (+5 V, +12 V)
CN10 Power connector (-5 V, -12 V)
CN11 COM1 DB-9 connector
CN13 External speaker connector
CN14 Keyboard pin-header connector
CN15 Power LED and keylock
Safety precautions
Follow these simple precautions to protect yourself from harm and
your PC from damage.
1. To avoid electric shock, always disconnect the power from your PC
chassis before you work on it. Don’t touch any components on the
CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card
may damage sensitive electronic components.
3. Always ground yourself to remove any static charge before you
touch your CPU card. Be particularly careful not to touch the chip
connectors. Modern integrated electronic devices, especially CPUs
and memory chips, are extremely sensitive to static electric
discharges and fields. Keep the card in its antistatic packaging
when it is not installed in the PC, and place it on a static dissipative
mat when you are working with it. Wear a grounding wrist strap
for continuous protection.

8PCA-6144V User's Manual
Jumper settings
This section tells how to set the jumpers to configure your card. It
gives the card default configuration and your options for each jumper.
After you set the jumpers and install the card, you will also need to
run the BIOS Setup program (discussed in Chapter 3) to configure the
serial port addresses, floppy/hard disk drive types and system operat-
ing parameters. Connections, such as hard disk cables, appear in
Chapter 2.
For the locations of each jumper, see the board layout diagram
depicted earlier in this chapter.
How to set jumpers
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal clip (often protected by a
plastic cover) that slides over the pins to connect them. To “close” a
jumper you connect the pins with the clip. To “open” a jumper you
remove the clip. Sometimes a jumper will have three pins, labeled 1, 2
and 3. In this case you connect either pins 1 and 2 or 2 and 3.
You may find pair of needle-nose pliers useful for setting the jumpers.
If you have any doubts about the best hardware configuration for your
application, contact your local distributor or sales representative
before you make any changes.
OpenOpen
OpenOpen
Open ClosedClosed
ClosedClosed
Closed Closed2-3Closed2-3
Closed2-3Closed2-3
Closed2-3
13
2

Chapter 1 Hardware Configuration 9
CPU type select (J1 - J16)
In order for the system to function properly, the jumpers must be set to
accommodate the CPU installed on the CPU card.
CPU type select (J1 - J16)
CPU \ J1 2 345678910111213141516
AMD
DX2-66
(5 V)
AMD
DX2-66
(3.3 V)
AMD
DX4-100
(Standard)
AMD
DX4-100
(Enhanced)
AMD
DX4-120

10 PCA-6144V User's Manual
CPU type select (J1 - J16), cont.
CPU \ J1 2 345678910111213141516
AMD
5x86-133
Cyrix
DX2-66
(5 V)
Cyrix
DX2-80
(3.45 V)
Cyrix
DX4-100

Chapter 1 Hardware Configuration 11
CPU type select (J1 - J16), cont.
CPU \ J1 2 345678910111213141516
Cyrix
5x86-100
Cyrix
5x86-120
Intel
DX2-66
Intel
DX4-100
(3.3 V)

12 PCA-6144V User's Manual
RTC data erase On/Off (J17)
RTC data is either kept or erased, depending upon J17's setting status.
RTC data erase On/Off (J17)
On (keep data) Off (lose data)
J17
Parallel port IRQ select (J18)
Parallel port IRQ select (J18)
IRQ5 IRQ7 (default)
J18
Parallel port ECP/EPP DMA channel (J20, J21)
You can set the DMA channel of the parallel port to either DMA 1 or
DMA 3.
Parallel port ECP/EPP DMA channel (J20, J21)
DMA 1 (default) DMA 3
J20
J21
1 2 3 1 2 3
1 2 3 1 2 3
1 2 3 1 2 3
