DFI OPS150-CS User manual

OPS150-CS
Digital Signage Embedded OPS Computer
User’s Manual
A-584-M-2016
Preliminary
Version
Preliminary
Version

2User's Manual | OPS150-CS
Copyright
This publication contains information that is protected by copyright. No part of it may be repro-
duced in any form or by any means or used to make any transformation/adaptation without the
prior written permission from the copyright holders.
This publication is provided for informational purposes only. The manufacturer makes no
representations or warranties with respect to the contents or use of this manual and specifi-
cally disclaims any express or implied warranties of merchantability or fitness for any particular
purpose. The user will assume the entire risk of the use or the results of the use of this docu-
ment. Further, the manufacturer reserves the right to revise this publication and make changes
to its contents at any time, without obligation to notify any person or entity of such revisions or
changes.
Changes after the publication’s first release will be based on the product’s revision. The website
will always provide the most updated information.
© 2020. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for identification purpose only and
are the properties of the respective owners.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the re-
ceiver is connected.
• Consult the dealer or an experienced radio TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party responsible for com-
pliance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission limits.

3User's Manual | OPS150-CS
Table of Contents
Chapter 1 - Introduction................................................................................................................6
Specifications ......................................................................................................................... 6
Features .................................................................................................................................. 7
DDR4................................................................................................................................. 7
Chapter 2 - Hardware Installation................................................................................................8
Overview..................................................................................................................................8
Front Panel.......................................................................................................................8
Rear Panel I/O..................................................................................................................8
Top and Side View........................................................................................................... 8
Bottom View.....................................................................................................................8
Dimensions ...................................................................................................................... 8
Installation .............................................................................................................................. 9
Mounting into OPS Display............................................................................................. 9
Assembly ..............................................................................................................................10
Top Cover .......................................................................................................................10
Heatsink and Fan...........................................................................................................11
Module Bracket..............................................................................................................15
System Board.................................................................................................................15
Board Layout.........................................................................................................................16
LEDs ......................................................................................................................................16
System Memory ...................................................................................................................17
Installing the SO-DIMM Module ...................................................................................17
CPU........................................................................................................................................19
Installing the CPU..........................................................................................................19
Jumper Settings ...................................................................................................................21
Clear CMOS (JP1) .........................................................................................................21
I/O Ports................................................................................................................................22
Graphics Display............................................................................................................22
USB Ports .......................................................................................................................22
RJ45 LAN Ports .............................................................................................................23
COM (Serial) Port ..........................................................................................................23
Audio...............................................................................................................................24
LPC .................................................................................................................................24
Battery ............................................................................................................................25
CPU Fan..........................................................................................................................25
Expansion Slots .............................................................................................................26
Installing the M.2 Module .............................................................................................26
Installing the Wifi Antenna for the M.2 E Key Wifi Module (Optional)......................27
OPS Display....................................................................................................................28
Chapter 3 - BIOS Settings...........................................................................................................29
Overview ...............................................................................................................................29
Main.......................................................................................................................................30
Advanced .............................................................................................................................30
RC ACPI Configuration..................................................................................................31
CPU Configuration.........................................................................................................31
Power & Performance ...................................................................................................32
PCH-FW Configuration ..................................................................................................32
Trusted Computing........................................................................................................33
NCT5525D Super IO Configuration ..............................................................................33
NCT5525D HW Monitor ................................................................................................34
Serial Port Console Redirection ...................................................................................35
USB Configuration .........................................................................................................36
CSM Configuration ........................................................................................................37
USB Power Control........................................................................................................37
Network Stack Configuration........................................................................................38
Chipset ..................................................................................................................................39
Graphics Configuration .................................................................................................39
PCH-IO Configuration....................................................................................................40
PCI Express Configuration............................................................................................40
SATA And RST Configuration .......................................................................................41
HD Audio Configuration ................................................................................................41
Security .................................................................................................................................42
Secure Boot....................................................................................................................42
Boot .......................................................................................................................................43
Save & Exit ............................................................................................................................43
Updating the BIOS................................................................................................................44
Notice: BIOS SPI ROM..........................................................................................................44
Chapter 4 - Supported Software ................................................................................................45
Auto-run Menu......................................................................................................................45
Intel Chipset Software Installation Utility...........................................................................45
Intel HD Graphics Drivers ...................................................................................................46
Realtek Audio Drivers...........................................................................................................47
Intel ME Drivers ....................................................................................................................48
Intel Serial IO Drivers ...........................................................................................................49
Intel Rapid Storage Technology .........................................................................................50
Intel Wi-Fi Drivers .................................................................................................................52
Intel Bluetooth Drivers .........................................................................................................53
Realtek LAN Driver ..............................................................................................................54
Adobe Acrobat Reader 9.3 ..................................................................................................55

4User's Manual | OPS150-CS
About this Manual
This manual can be downloaded from the website, or acquired as an electronic file included in
the optional CD/DVD. The manual is subject to change and update without notice, and may be
based on editions that do not resemble your actual products. Please visit our website or con-
tact our sales representatives for the latest editions.
Warranty
1. Warranty does not cover damages or failures that arised from misuse of the product,
inability to use the product, unauthorized replacement or alteration of components and
product specifications.
2. The warranty is void if the product has been subjected to physical abuse, improper in-
stallation, modification, accidents or unauthorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-
stances, attempt to perform service, adjustments or repairs on the product, whether in
or out of warranty. It must be returned to the purchase point, factory or authorized ser-
vice agency for all such work.
4. We will not be liable for any indirect, special, incidental or consequencial damages to
the product that has been modified or altered.
About the Package
The package contains the following items. If any of these items are missing or damaged,
please contact your dealer or sales representative for assistance.
• One OPS150-CS System
The system and accessories in the package may not come similar to the information listed
above. This may differ in accordance with the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.
Optional Items
• DDR4 SO-DIMM (4G/8G/16G)
• M.2 M Key SSD (128G/256G/512G/1TB)
• M.2 E Key Wifi + BT module withtwo antennas
• Microsoft Windows 10 IoT Enterprise 2019
The system and accessories in the package may not come similar to the information listed
above. This may differ in accordance with the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.

5User's Manual | OPS150-CS
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board, components or devices even
before installing them in your system unit. Static electrical discharge can damage computer
components without causing any signs of physical damage. You must take extra care in han-
dling them to ensure against electrostatic build-up.
1. To prevent electrostatic build-up, leave the system board in its anti-static bag until you
are ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of the components, con-
tacts or connections.
5. Avoid touching the pins or contacts on all modules and connectors. Hold modules or
connectors by their ends.
Safety Precautions
• Use the correct DC / AC input voltage range.
• Unplug the power cord before removing the system chassis cover for installation or
servicing. After installation or servicing, cover the system chassis before plugging in
the power cord.
• There is danger of explosion if battery incorrectly replaced.
• Replace only with the same or equivalent specifications of batteries recommend by
the manufacturer.
• Dispose of used batteries according to local ordinance.
• Keep this system away from humid environments.
• Make sure the system is placed or mounted correctly and stably to prevent the chance
of dropping or falling may cause damage.
• The openings on the system shall not be blocked and shall be kept in distance from
other objects to make sure of proper air ventilation to protect the system from over-
heating.
• Dress the cables, especially the power cord, so they will not be stepped on, in contact
with high temperature surfaces, or cause any tripping hazards.
• Do not place anything on top of the power cord. Use a power cord that has been ap-
proved for use with the system and is compliant with the voltage and current ranges
required by the system’s electrical specifications.
• If the system is to be unused or stored for a long time, disconnect it from the power
source to avoid damage by transient overvoltage.
• If one of the following occurs, consult a service personnel:
- The power cord or plug is damaged.
- Liquid has penetrated the system.
- The system has been exposed to moisture.
- The system is not working properly.
- The system is physically damaged.
• The unit uses a three-wire ground cable which is equipped with a third pin to ground
the unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet
does not support this kind of plug, contact your electrician to replace the outlet.
• Disconnect the system from the electricity outlet before cleaning. Use a damp cloth
for cleaning the surface. Do not use liquid or spray detergents for cleaning.
Important:
Electrostatic discharge (ESD) can damage your processor, disk drive and other
components. Perform the upgrade instruction procedures described at an ESD
workstation only. If such a station is not available, you can provide some ESD pro-
tection by wearing an antistatic wrist strap and attaching it to a metal part of the
system chassis. If a wrist strap is unavailable, establish and maintain contact with
the system chassis throughout any procedures requiring ESD protection.

6
Chapter 1
INTRODUCTION
User's Manual | OPS150-CS
Chapter 1 - Introduction
XSpecifications
The specifications listed here may be based on editions that do not
resemble your actual products. Please visit the download page at go.dfi.
com/OPS150-CS, or via the QR code to the right for the latest datasheet.
SYSTEM Processor 8th/9th Generation Intel®Core™Processors, LGA 1151 Socket
i7-9700TE Octa Core, 12M Cache, 1.8GHz (3.8GHz), 35W
i5-9500TE Hexa Core, 9M Cache, 2.2GHz (3.6GHz), 35W
i3-9100TE Quad Core, 6M Cache, 2.2GHz (3.2GHz), 35W
i7-8700T Hexa Core, 12M Cache, 2.4GHz (4.0GHz), 25W (35W)
i5-8500T Hexa Core, 9M Cache, 2.1GHz (3.5GHz), 25W (35W)
i3-8300T Quad Core, 8M Cache, 2.5GHz (3.2GHz), 25W (35W)
Chipset Intel®H310 Chipset
Memory Two 260-pin SODIMM up to 32GB
Dual Channel DDR4 2666MHz
BIOS Insyde SPI 16Mbit
GRAPHICS Controller Intel®HD Graphics 630
Feature OpenGL 5.0, DirectX 12, OpenCL 2.1
HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/
H265, VP8, VP9
HW Encode: MPEG2, AVC/H264, JPEG, HEVC/H265, VP8, VP9
Display 1 x HDMI 1.4
or 1 x HDMI 2.0 output + 1 x DP 1.2 output (via JAE only)
HDMI 1.4: resolution up to 3840x2160 @ 30Hz
HDMI 2.0: resolution up to 3840x2160 @ 60Hz
DP: resolution up to 4096x2160 @ 60Hz
Triple Displays 2 x HDMI + 1 x DP
EXPANSION Interface 1 x M.2 (2280 M Key) (PCIe NVMe x4/SATA 3.0)
1 x M.2 (2230 E Key) (PCIe/USB 2.0)
ETHERNET Controller Realtek RTL8111H
LED Indicators 1 x Power LED
1 x HDD LED
FRONT I/O Ethernet 1 x GbE (RJ-45)
Serial 1 x RS-232 (DB-9)
USB 2 x USB 3.1 Gen1
Display 1 x HDMI 1.4 output
Audio 1 x Line-out
1 x Mic-in
Buttons 1 x Power Button
1 x Reset Button
Wi-Fi Antenna 2 x Wi-Fi Module Antenna Hole
REAR I/O OPS Interface JAE TX25:
1 x HDMI 2.0
1 x DP 1.2
2 x USB 2.0
1 x USB 3.0
1 x UART
1 x Audio out
1 x 12~19V DC-in
COOLING Fan Active Cooling
WATCHDOG
TIMER
Output & Interval System Reset, Programmable via Software from 1 to 255 Seconds
OS Windows 10 Enterprise (64-bit)
Linux
MECHANISM Construction Aluminum + SGCC
Dimensions 200mm x 30mm x 119mm (W x H x D)
Weight 2.64 kg
ENVIRONMENT Operating
Temperature
-5 to 45°C
Storage
Temperature
-40 to 85°C
Relative Humidity 10 to 90% RH (non-condensing)
COMPLIANCE Certification CE/FCC/CCC

7
Chapter 1
INTRODUCTION
User's Manual | OPS150-CS
XFeatures
OPS Module
Open Pluggable Specification (OPS) is a standard launched by Intel to standardize the architec-
ture between displays and media players. It has flexibility in performance and expandability to
meet emerging demands in current digital signage applications. The OPS computer is modular-
ized to fit into the OPS display as an elegant embedded solution.
Watchdog Timer
The Watchdog Timer function allows your application to regularly “clear” the system at the set
time interval. If the system hangs or fails to function, it will reset at the set time interval so that
your system will continue to operate.
DDR4
DDR4 delivers increased system bandwidth and improves performance. The advantages of
DDR4 provide an extended battery life and improve the performance at a lower power than
DDR3/DDR2.
Graphics
The integrated Intel®HD graphics engine delivers an excellent blend of graphics performance
and features to meet business needs. It provides excellent video and 3D graphics with out-
standing graphics responsiveness. These enhancements deliver the performance and compat-
ibility needed for today’s and tomorrow’s business applications.
M.2 Expansion
M.2 is the Next Generation Form Factor (NGFF) which is designed to support multiple modules
in applications such as solid-state disk storage, wired/wireless LAN connection, Bluetooth, and
etc.
Wake-On-LAN
This feature allows the network to remotely wake up a Soft Power Down (Soft-Off) PC. It is
supported via the onboard LAN port or via a PCI LAN card that uses the PCI PME (Power Man-
agement Event) signal. However, if your system is in the Suspend mode, you can power-on the
system only through an IRQ or DMA interrupt.
Wake-On-USB
This function allows you to use a USB keyboard or USB mouse to wake up a system from the
S3 (STR - Suspend To RAM) state.
ACPI STR
The system board is designed to meet the ACPI (Advanced Configuration and Power Interface)
specification. ACPI has energy saving features that enables PCs to implement Power Manage-
ment and Plug-and-Play with operating systems that support OS Direct Power Management.
ACPI when enabled in the Power Management Setup will allow you to use the Suspend to RAM
function.
With the Suspend to RAM function enabled, you can power-off the system at once by pressing
the power button or selecting “Standby” when you shut down Windows®without having to go
through the sometimes tiresome process of closing files, applications and operating system.
This is because the system is capable of storing all programs and data files during the entire
operating session into RAM (Random Access Memory) when it powers-off. The operating ses-
sion will resume exactly where you left off the next time you power-on the system.
Power Failure Recovery
When power returns after an AC power failure, you may choose to either power-on the system
manually or let the system power-on automatically.
USB
The system board supports the new USB 3.1 Gen 1. It is capable of running at a maximum
transmission speed of USB 3.1 Gen 1 (5 Gbit/s, or 625 MB/s). USB 3.1 reduces the time re-
quired for data transmission, reduces power consumption, and is backward compatible with
USB 2.0. It is a marked improvement in device transfer speeds between your computer and a
wide range of simultaneously accessible external Plug and Play peripherals.
RTC Timer
The Real Time Clock (RTC) installed on the system board allows your system to automatically
power-on on the set date and time.

8
Chapter 2
HARDWARE INSTALLATION
User's Manual | OPS150-CS
Chapter 2 - Hardware Installation
XOverview
Front Panel
Rear Panel I/O
Top and Side View
Bottom View
Dimensions
JAE TX25
USB 3.0 Reset RS232 LAN Mic In
Atenna
Hole
Mounting
Screw
Mounting
Screw
Atenna
Hole
SSD LED Audio OutHDMIPower Button
Removeable
Bracket
Removeable
Bracket
180.00
200.00
30.00
4.00
119.00

9
Chapter 2
HARDWARE INSTALLATION
User's Manual | OPS150-CS
XInstallation
Mounting into OPS Display
Mounting
Screw Hole
Mounting
Screw Hole
Please follow the steps and attend to the safety cautions while
mounting the OPS module into the OPS display.
1. Power off the OPS display and unplug its power cord to
eliminate any chance of electric shock.
2. Insert the OPS module into the OPS slot on the OPS dis-
play while making sure the ventilation holes face the ex-
terior of the slot and align with those on the OPS display.
3. Push the module all the way into the slot. The gap between
the module panel and the slot shall close up.
4. Insert the mount screws into the mounting screw holes, and fasten them tight.
Note:
Two additional spring screws are attached to the front panel and can be used for
mounting if the OPS display has tapped screw holes for them.
Important:
When removing the OPS module, completely cut off the power of both the OPS
module and the OPS display, and remove the power cable to rule out any chances
of ESD/EOS damage to the system.

10
Chapter 2
HARDWARE INSTALLATION
User's Manual | OPS150-CS
XAssembly
Top Cover
The top cover can be removed to reveal the internal I/O connectors and cables. The top metal
cover is secured onto the chassis with six F3*4 zinc-coated screws — two on the front panel,
two on the top, and the other two on the bottom. Use a Phillips screwdriver to unscrew them.
After the six above-mentioned screws are removed, place the system on a stable work surface,
and slide the cover towards the rear before removing it.
Top
Front Panel
Bottom
x6
Top
Bottom
Top
Bottom
Top
Bottom
Top
Bottom
Top
Bottom
