DFI SD106 User manual

1
SD106
Mini-ITX Industrial Motherboard
User’s Manual
A40300937

2
Copyright
This publication contains information that is protected by copyright. No part of it may be re-
produced in any form or by any means or used to make any transformation/adaptation without
the prior written permission from the copyright holders.
This publication is provided for informational purposes only. The manufacturer makes no
representations or warranties with respect to the contents or use of this manual and specifi-
cally disclaims any express or implied warranties of merchantability or fitness for any particular
purpose. The user will assume the entire risk of the use or the results of the use of this docu-
ment. Further, the manufacturer reserves the right to revise this publication and make changes
to its contents at any time, without obligation to notify any person or entity of such revisions
or changes.
Changes after the publication’s first release will be based on the product’s revision. The website
will always provide the most updated information.
© 2019. All Rights Reserved.
Trademarks
Product names or trademarks appearing in this manual are for identification purpose only and
are the properties of the respective owners.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission limits.

3
Copyright .....................................................................2
Trademarks..................................................................2
FCC and DOC Statement on Class B.................2
About this Manual .....................................................4
Warranty......................................................................4
Static Electricity Precautions...................................4
Safety Measures..........................................................4
About the Package ....................................................5
Chapter 1 - Introduction.........................................6
Specifications.......................................................................................................... 6
Features ................................................................................................................. 7
Chapter 2 - Hardware Installation ........................9
Board Layout.......................................................................................................... 9
System Memory..................................................................................................10
Installing the DIMM Module ....................................................... 10
CPU........................................................................................................................11
Installing the CPU .................................................................... 12
Installing the Fan and Heat Sink ................................................ 14
Jumper Settings ...................................................................................................15
Clear CMOS Data ..................................................................... 15
Auto Power-on Select ............................................................... 15
LVDS Panel Power Select........................................................... 16
PCIE 1 Signal Select................................................................. 16
LVDS Inverter Power Select....................................................... 17
LVDS Backlight Power Select ..................................................... 17
Mini PCIe Slot 1 Signal Select.................................................... 18
Mini PCIe Slot 2 Signal Select.................................................... 18
eDP Panel Power Select ............................................................ 19
eDP Inverter Power Select......................................................... 19
eDP Backlight Power Select ....................................................... 20
Copyright.............................................................................................................2
Trademarks ........................................................................................................2
FCC and DOC Statement on Class B..................................................... 2
Warranty..............................................................................................................4
Static Electricity Precautions......................................................................4
Safety Measures ..............................................................................................4
About the Package.........................................................................................5
Optional Items..................................................................................................5
Before Using the System Board...............................................................5
Chapter 1 - Introduction .............................................................................6
Specifications ................................................................................................6
Features..........................................................................................................7
Chapter 2 - Hardware Installation................................................ 8
Board Layout.................................................................................................8
System LED ...................................................................................................8
System Memory............................................................................................9
Installing the DIMM Module ..........................................................................9
CPU ................................................................................................................ 10
Installing the CPU....................................................................................... 11
Installing the Fan and Heat Sink.................................................................. 13
Jumper Settings ......................................................................................... 14
Clear CMOS Data........................................................................................ 14
Auto Power-on Select.................................................................................. 14
LVDS Panel Power Select ............................................................................ 15
PCIE1 Signal Select..................................................................................... 15
LCD/Inverter Power Select .......................................................................... 16
LVDS Backlight Power Select ....................................................................... 16
Mini PCIe 1 Signal Select ............................................................................ 17
Mini PCIe 2 Signal Select ............................................................................ 17
eDP Panel Power Select .............................................................................. 18
eDP Inverter Power Select .......................................................................... 18
eDP Backlight Power Select......................................................................... 19
Rear Panel I/O Ports................................................................................. 20
Graphics Interfaces..................................................................................... 20
RJ45 LAN Ports........................................................................................... 21
USB Ports................................................................................................... 21
I/O Connectors ........................................................................................... 22
SATA (Serial ATA) Connectors...................................................................... 22
SATA (Serial ATA) Power Connectors............................................................ 22
Digital I/O.................................................................................................. 23
Cooling Fan Connectors............................................................................... 23
Chassis Intrusion Connector ........................................................................ 24
Front Panel Connector ................................................................................ 24
Expansion Slots .......................................................................................... 25
Standby Power LED .................................................................................... 26
LVDS Panel................................................................................................. 27
SMBus Connector ....................................................................................... 28
Speaker Connector ..................................................................................... 28
COM (Serial) Ports ...................................................................................... 29
Front Audio Connector ................................................................................ 29
Power ATX Mode ........................................................................................ 30
15~36V DC-in ........................................................................................... 30
EDP Connector ........................................................................................... 31
Battery....................................................................................................... 32
Chapter 3 - BIOS Setup............................................................... 33
Overview....................................................................................................... 33
Main............................................................................................................... 34
Advanced...................................................................................................... 34
ACPI Configuration ..................................................................................... 35
CPU Configuration....................................................................................... 36
Video Configuration .................................................................................... 36
Audio Configuration .................................................................................... 37
SATA Configuration ..................................................................................... 38
USB Configuration....................................................................................... 38
PCI Express Configuration ........................................................................... 39
ME Configuration ........................................................................................ 40
Active Management Technology Support ...................................................... 40
MEBX Configuration .................................................................................... 41
Debug Configuration ................................................................................... 41
Device Manager.......................................................................................... 42
SIO NUVOTON6106D .................................................................................. 43
Console Redirection .................................................................................... 45
Security......................................................................................................... 47
Boot ............................................................................................................... 47
Exit................................................................................................................. 48
Updating the BIOS .................................................................................... 49
Notice: BIOS SPI ROM ............................................................................. 49
Chapter 4 - Supported Software ................................................ 50
Chapter 5 - RAID .......................................................................... 67
Chapter 6 - Intel AMT Settings ................................................. 71
Table of Contents

4
Warranty
1. Warranty does not cover damages or failures that arised from misuse of the product, in-
ability to use the product, unauthorized replacement or alteration of components and prod-
uct specifications.
2. The warranty is void if the product has been subjected to physical abuse, improper instal-
lation, modification, accidents or unauthorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-
stances, attempt to perform service, adjustments or repairs on the product, whether in or
out of warranty. It must be returned to the purchase point, factory or authorized service
agency for all such work.
4. We will not be liable for any indirect, special, incidental or consequencial damages to the
product that has been modified or altered.
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board, components or devices even
before installing them in your system unit. Static electrical discharge can damage computer
components without causing any signs of physical damage. You must take extra care in han-
dling them to ensure against electrostatic build-up.
1. To prevent electrostatic build-up, leave the system board in its anti-static bag until you are
ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of the components, contacts
or connections.
5. Avoid touching the pins or contacts on all modules and connectors. Hold modules or con-
nectors by their ends.
Safety Measures
To avoid damage to the system:
• Use the correct AC input voltage range.
To reduce the risk of electric shock:
• Unplug the power cord before removing the system chassis cover for installation or servic-
ing. After installation or servicing, cover the system chassis before plugging the power
cord.
Important:
Electrostatic discharge (ESD) can damage your processor, disk drive and other com-
ponents. Perform the upgrade instruction procedures described at an ESD worksta-
tion only. If such a station is not available, you can provide some ESD protection by
wearing an antistatic wrist strap and attaching it to a metal part of the system chas-
sis. If a wrist strap is unavailable, establish and maintain contact with the system
chassis throughout any procedures requiring ESD protection.

5
About the Package
The package contains the following items. If any of these items are missing or damaged,
please contact your dealer or sales representative for assistance.
• 1 SD106-Q170 motherboard
• 1 Battery Addendum
The board and accessories in the package may not come similar to the information listed
above. This may differ in accordance to the sales region or models in which it was sold. For
more information about the standard package in your region, please contact your dealer or
sales representative.
Before Using the System Board
Before using the system board, prepare basic system components.
If you are installing the system board in a new system, you will need at least the following
internal components.
• A CPU
• Memory module
• Storage devices such as hard disk drive, etc.
You will also need external system peripherals you intend to use which will normally include at
least a keyboard, a mouse and a video display monitor.

6
Chapter 1 - Introduction
Specifications
Chapter 1
Chapter 1 Introduction www.d.com
SYSTEM Processor 6th Generation Intel®CoreTM Processors, LGA 1151 Socket
Intel®Pentium®G4400, Dual Core, 3M Cache, 3.3GHz, 47W
Chipset Intel®Q170 Chipset
Memory Two 260-pin SODIMM up to 32GB
Dual Channel DDR4 1866/2133MHz
BIOS Insyde SPI 128Mbit
GRAPHICS Controller Intel®HD Gen 9 Graphics
Feature OpenGL 5.0, DirectX 12, OpenCL 2.1
HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/H265, VP8, VP9
HW Encode: MPEG2, AVC/H264, JPEG, HEVC/H265, VP8, VP9
Display 1 x eDP eDP: resolution up to 4096x2304 @ 60Hz
1 x LVDS LVDS: resolution up to 1920x1200 @ 60Hz
1 x DP++ DP++: resolution up to 4096x2304 @ 60Hz
Triple
Displays
eDP + LVDS + DP++
EXPANSION Interface 1 x Full-size Mini PCIe (USB/PCIe/mSATA, mSATA by default)
1 x Half-size Mini PCIe (Mini PCIe by default)
1 x PCIe x16
AUDIO
Audio
Codec
Realtek ALC888S-VD2-GR
ETHERNET Controller 1 x Intel®I211AT PCIe (10/100/1000Mbps)
1 x Intel®I219LM PCIe with iAMT 11.0 (10/100/1000Mbps) (only Core i7/i5 supports iAMT)
REAR I/O Ethernet 2 x GbE (RJ-45)
USB 4 x USB 3.0
Display 1 x DP++
INTERNAL I/O Serial 2 x RS-232 (2.54mm pitch)
USB 4 x USB 2.0 (2.00mm pitch)
Display 1 x eDP
1 x LVDS LCD Panel Connector
Audio 1 x Front Audio (Line-out/Mic-in)
1 x Speaker (3W amplifier)
SATA 2 x SATA 3.0 (up to 6Gb/s)
RAID 0/1
DIO 1 x 4-bit DIO
SMBus 1 x SMBus
WATCHDOG
TIMER
Output &
Interval
System Reset, Programmable via Software from 1 to 255 Seconds
SECURITY TPM TPM2.0
POWER Type 15~36V DC
Connector Vertical Type Connector (4-pin)
RTC Battery CR2032 Coin Cell
OS SUPPORT Windows 7
Windows 8.1
Windows 10
ENVIRONMENT Temperature Operating: 0 to 60°C
Storage: -40 to 85°C
Humidity Operating: 5 to 90% RH
Storage: 5 to 90% RH
MECHANICAL Dimensions Mini-ITX Form Factor
170mm (6.7") x 170mm (6.7")

7
Chapter 1
Chapter 1 Introduction www.d.comChapter 1 Introduction
Features
• Watchdog Timer
The Watchdog Timer function allows your application to regularly “clear” the system at the set
time interval. If the system hangs or fails to function, it will reset at the set time interval so
that your system will continue to operate.
• DDR4
DDR4 delivers increased system bandwidth and improves performance. The advantages of
DDR4 provide an extended battery life and improve the performance at a lower power than
DDR3/DDR2.
• Graphics
The integrated Intel®HD graphics engine delivers an excellent blend of graphics performance
and features to meet business needs. It provides excellent video and 3D graphics with out-
standing graphics responsiveness. These enhancements deliver the performance and compat-
ibility needed for today’s and tomorrow’s business applications. Supports 1 eDP, 1 LVDS and 1
DP++ interfaces for display outputs.
• PCI Express
PCI Express is a high bandwidth I/O infrastructure that possesses the ability to scale speeds
by forming multiple lanes. The PCI Express architecture also supports high performance graph-
ics infrastructure by enhancing the capability of a PCIe x16 Gen 3 at 16GB/s bandwidth.
• Serial ATA
Serial ATA is a storage interface that is compliant with SATA 1.0a specification. With speed of
up to 6Gb/s (SATA 3.0), it improves hard drive performance faster than the standard parallel
ATA whose data transfer rate is 100MB/s.
• Gigabit LAN
Intel®I211AT PCIe Gigabit Ethernet and Intel®I219LM PCIe with iAMT11.0 Gigabit Ethernet
Phy controllers support up to 1Gbps data transmission.
• Audio
The Realtek ALC888S-VD2-GR audio codec provides 5.1-channel High Definition audio output.
• Wake-On-USB
This function allows you to use a USB keyboard or USB mouse to wake up a system from the
S3 (STR - Suspend To RAM) state.
• RTC Timer
The RTC installed on the system board allows your system to automatically power-on on the
set date and time.
• ACPI STR
The system board is designed to meet the ACPI (Advanced Configuration and Power Interface)
specification. ACPI has energy saving features that enables PCs to implement Power Manage-
ment and Plug-and-Play with operating systems that support OS Direct Power Management.
ACPI when enabled in the Power Management Setup will allow you to use the Suspend to RAM
function.
With the Suspend to RAM function enabled, you can power-off the system at once by pressing
the power button or selecting “Standby” when you shut down Windows®without having to go
through the sometimes tiresome process of closing files, applications and operating system.
This is because the system is capable of storing all programs and data files during the entire
operating session into RAM (Random Access Memory) when it powers-off. The operating ses-
sion will resume exactly where you left off the next time you power-on the system.
• Wake-On-LAN
This feature allows the network to remotely wake up a Soft Power Down (Soft-Off) PC. It is
supported via the onboard LAN port or via a PCIe LAN card that uses the PCIe PME (Power
Management Event) signal. However, if your system is in the Suspend mode, you can power-
on the system only through an IRQ or DMA interrupt.
• Power Failure Recovery
When power returns after an AC power failure, you may choose to either power-on the system
manually or let the system power-on automatically.
• USB
The system board supports the new USB 3.0. It is capable of running at a maximum transmis-
sion speed of up to 5 Gbit/s (625 MB/s) and is faster than USB 2.0 (480 Mbit/s, or 60 MB/s)
and USB 1.1 (12Mb/s). USB 3.0 reduces the time required for data transmission, reduces
power consumption, and is backward compatible with USB 2.0. It is a marked improvement in
device transfer speeds between your computer and a wide range of simultaneously accessible
external Plug and Play peripherals.

www.d.com
8
Chapter 2 Hardware Installation
Chapter 2
Chapter 2 - Hardware Installation
►Board Layout
Socket LGA1151
DDR4_1 SODIMM
DDR4_2 SODIMM
Mini PCIe 2
Mini PCIe 1
Chassis
Intrusion
1
1
2
5111
JP5JP3SMBus
ME Disable
1
JP4
SPI
Flash
BIOS
USB 2.0 (7/8)
USB 2.0 (5/6)
1
2
10
9
1
2
10
9
1
2
Battery
11
SATA 0
SATA 3
1
4
SATA
Power
JP9
JP2
JP10
1
1
2 6
5
1
System
Fan 2
1
JP8
JP6
JP7
1
LCD/Inverter
Power
1
1
1 4 ATX Power
Digital I/O
Digital I/O Power
(USB 3/4)
USB 3.0
(USB 1/2)
USB 3.0
DP++
9 1
10 2
1
1
1
ON
2
SW1
Intel
Q170
CPU
Fan
COM 3
9
COM 4
9
Standby Power LED
Front
Audio
40
PCIe x16 (PCIE1)
DC In
11 Front Panel
1
System
Fan 1
JP1
Buzzer
3
4
1
2
65
21
1 39
eDP
1
1
2
1
2
1
2
1
2
LVDS LCD
Panel
Intel
I211AT
Speaker
LAN 1
LAN 2
►Standby Power LED
Important:
Electrostatic discharge (ESD) can damage your board, pro-
cessor, disk drives, add-in boards, and other components.
Perform installation procedures at an ESD workstation only.
If such a station is not available, you can provide some ESD
protection by wearing an antistatic wrist strap and attaching
it to a metal part of the system chassis. If a wrist strap is
unavailable, establish and maintain contact with the system
chassis throughout any procedures requiring ESD protection.
Important:
When the Standby Power LED lit red, it indicates that there
is power on the system board. Power-off the PC then unplug
the power cord prior to installing any devices. Failure to do
so will cause severe damage to the motherboard and com-
ponents.
Standby
Power LED
This LED lights red when the system is in the standby mode. It indi-
cates that is supplied to the system board. Power-off the PC and then
unplug the power cord prior to installing any devices. Failure to do so
will cause severe damage to the motherboard and components.

www.d.com
9
Chapter 2 Hardware Installation
Chapter 2
Features
• Two 260-pin SODIMM up to 32GB
• Dual Channel DDR4 1866/2133MHz
The system board supports the following memory interface.
Single Channel (SC)
Data will be accessed in chunks of 64 bits from the memory channels.
Dual Channel (DC)
Data will be accessed in chunks of 128 bits from the memory channels. Dual channel provides
better system performance because it doubles the data transfer rate.
Single Channel
DIMMs are on the same channel. DIMMs in a channel can be identi-
cal or completely different. However, we highly recommend using
identical DIMMs. Not all slots need to be populated.
Dual Channel DIMMs of the same memory configuration are on different channels.
BIOS Setting
Enable or disable ECC in the “Advanced” menu of the BIOS. Refer to Chapter 3 for more infor-
mation.
►System Memory
DDR4_1
DDR4_2
Installing the SO-DIMM Module
Before installing the memory module, please make sure that the following safety cautions are
well-attended.
1. Make sure the PC and all other peripheral devices connected to it has been powered
down.
2. Disconnect all power cords and cables.
3. Locate the SO-DIMM socket on the system board
4. Make sure the notch on memory card is aligned to the key on the socket.
►System Memory
Notch
Retention Notch
Key
Socket Top View
DDR4 SO-DIMM
Retention Clip
45°
Step 1
Step 2
Step 3

www.d.com
10
Chapter 2 Hardware Installation
Chapter 2
Please follow the steps below to install the memory card into the socket.
Step 1:
Insert the memory card into the
slot while making sure 1) the
notch and the key are aligned,
and 2) the non-connector end
rises approximately 45 degrees
horizontally. Press the card firmly
into the socket while applying and
maintaining even pressure on both
ends.
Step 2:
Press the end of the card far from
the socket down while making
sure the retention notch and the
clip align as indicated by the dot-
ted line in the illustration. If the
retention notch and the clip do not
align, please remove the card and
re-insert it. Press the card all the
way down.
Step 3:
The clips snap automatically and
abruptly to the retention notches
of the card sounding a distinctive
click, and lock the card in place.
Inspect that the clip sits in the
notch. If not, please pull the clips
outward, release and remove the
card, and mount it again.
Notch
Retention Notch
Key
Socket Top View
DDR4 SO-DIMM
Retention Clip
45°
Step 1
Step 2
Step 3
►System Memory
►Installing the SO-DIMM Module
►CPU
The system board is equipped with a surface mount LGA 1151 socket. This socket is exclu-
sively designed for installing a LGA 1151 packaged Intel CPU.
Protective
cap
Important:
1. Before you proceed, make sure (1) the LGA 1151 socket comes with a protec-
tive cap, (2) the cap is not damaged and (3) the socket’s contact pins are not
bent. If the cap is missing or the cap and/or contact pins are damaged, contact
your dealer immediately.
2. Make sure to keep the protective cap. RMA requests will be accepted and pro-
cessed only if the LGA 1151 socket comes with the protective cap.
Note:
The system board used in the following illustrations may not resemble the actual
board. These illustrations are for reference only.
