60 & 70 Series Connectors
DESCRIPTION: Sleeve Activated Connectors for Sealing Male
Threads and Formed Tube Ends.
Please thoroughly read the instructions prior to operating the connector. This
connector is designed to provide a safe, reliable leak-tight seal and
connection when properly maintained and operated.
The connector is designed to mate with a specific application. Verify the
application prior to the introduction of pressurized media. Use only in a safe
environment.
Connectors are NOT designed for permanent connections and are for
temporary connections only.
•Installation
•Operation
•Main Seal Replacement
•Connector Maintenance
•Safety Warnings - Guidelines
DO NOT EXCEED pressure rating as marked on connector or corresponding literature.
Before using, verify that this pressure rating is within your working pressures.
INSTALLATION:
1. Connect media hose/fitting to the termination port on connector.
a. Pipe tape and or thread sealant is recommended.
OPERATION:
1. Slide/pull sleeve manually backwards, this will allow collets/jaws to open.
2. Insert male end of the component to be tested into collets/jaws and push connector onto
test piece.
a. NOTE: CONNECTOR OPERATES BEST IF YOUR HAND ISN’T ON
SLEEVE, HOLD THE BODY AND TERMINATION HOSE AS YOU
CONNECT.

OPERATING INSTRUCTIONS / MAIN SEAL REPLACEMENT
www.fastestinc.com
Roseville, MN
Toll Free at 1-800-444-2373
Fax [phone]
WP033 Rev D 5/5/2021
COLLET/JAWS
OPEN
NOTE: DO NOT FORCE CONNECTOR ONTO TEST PART WHEN CONNECTING. THE
SPLIT COLLET SHOULD EASILY MATE WITH TEST PIECE. FORCING THE CONNECTOR
WILL RESULT IN POOR SEALING AND POSSIBLE LEAKAGE. DO NOT TURN OR
ROTATE CONNECTOR AFTER THE COLLETS HAVE GRIPPED TEST PART. DAMAGE TO
TEST PIECE AND THE CONNECTOR’S INTERNAL PARTS MAY RESULT.
3. Make sure green ring indicator is exposed as shown.
4. Tug on the connector to assure proper engagement and gripping before introduction of
pressurized media.
5. Activate test media through connector back port. Pressure will enhance the seat.
6. To disconnect from test piece, deactivate test pressure. Slide knurled sleeve away from
test piece to expand collets. Remove connector from test piece.
MAIN SEAL REPLACEMENT:
NOTE: IN MOST CASES THE MAIN SEAL CAN BE EXTRACTED AND REPLACED IN
THE STEPS THAT FOLLOW. IF CONNECTOR MUST BE DIS-ASSEMBLED TO
REPLACE MAIN SEAL, SEE INSTRUCTION WP122.
1. Slide sleeve back allowing collets/jaws to open. This will help expose the end of the piston
to extract main seal.
2. Using a pick like tool or small flat blade screwdriver, remove main seal from piston and
discard.
3. Use caution not to scratch the main
seal groove surfaces in piston.
4. Install new main seal using your fingers or a non-marring tool. DO NOT LUBRICATE!
5. Make sure main seal is properly seated.
CAUTION: 60 & 70 Connectors are not internally valved. Disconnecting while pressurized
can cause rapid separation and high velocity loss of media.
MAINTENANCE:
 Periodically inspect connector and seal for proper operation. Repair or replace parts as
required to assure positive sealing and performance.
 Establish a regular interval for lubrication. The media and environment will be determining
factors in establishing this interval to prevent dryness and/or corrosion.
 Difficulty of operation after continual use indicates need for lubrication or other
maintenance. Repair parts, instructions and tools are available. Please contact your
FasTest Distributor or the factory for assistance.
