CYP CHDBT-1H2CE User manual

CHDBT-1H2CE
1×3 HDMI over HDMI and CAT5e/6/7 Splitter
with PoE and LAN Serving
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 29/10/12 Preliminary Release
VS0 08/04/13 Updated format/diagrams

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 2
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel.........................................3
6.2 Rear Panel .........................................4
6.3 IR Cable Pin Assignment ..................5
7. Connection Diagram ............................ 6
8. Specications ........................................ 7
9. Acronyms ............................................... 7

1
1. INTRODUCTION
The HDMI Splitter over HDMI and CAT5e/6/7 supports resolutions up
to 1080p Full HD, Deep Color, 4K×2K, 3D and multi-channel digital
audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus
and DTS-HD from Hi-Def sources to an HDMI and 2 CAT5e/6/7 outputs.
This splitter has the ability to provide you with simultaneous HDMI and
2 CAT5e/6/7 outputs where the HDMI output can be connected to
display or cascaded with another splitter. The CAT5e/6/7 outputs
can be connected to CAT5e/6/7 to HDMI receivers to extend the
operating distance up to 100 meters. The LAN connectivity will allow a
100BaseT network to be served to both CAT outputs.
2. APPLICATIONS
• Domestic entertainment and network sharing
• Combined HDMI and HDBaseT Splitter
• HDMI source distribution and control
• Educational source distribution and control
• Commercial system display and control
3. PACKAGE CONTENTS
• 1×1 by 3 HDMI over HDMI and CAT5e/6/7 Splitter
• 2×IR Extender
• 1×IR Blaster 'Y' Cable
• 2×3.5 mm mini-jack to D-Sub 9-pin adaptor cable
• 1×24 V/2.7 A DC Power Adaptor
• 1×Power Cord
• Operation Manual

2
4. SYSTEM REQUIREMENTS
• HDMI equipped source device, connected with an HDMI cable or
DVI equipped source, connected with DVI to HDMI cables
• HDMI equipped displays (TVs or monitors) or HDMI equipped AV
receivers, connected with HDMI cables
• Industry standard CAT5e/6/7 cables
• HDBaseT™ Receivers (i.e. CH-506RX, CH-507RX or CH-1109RX)
5. FEATURES
• HDMI with 4K×2K resolution and 3D support, HDCP and DVI
compliant
• Simultaneous output of the same source through HDMI and
CAT5e/5/7 outputs
• Supports Deep Color up to 1080p/36-bit
• Supports wide range of PC resolutions from VGA to WUXGA (RB)
and HDTV resolutions up to 4K×2K
• Supports transmission of High Denition audio: LPCM 7.1CH, Dolby
TrueHD, Dolby Digital Plus and DTS-HD Master Audio (32 kHz~192 kHz
sample rate)
• Supports distances up to 100 meters over CAT5e/6/7 cables
• HDBaseT™ 5PlayT™ convergence: uncompressed high denition
Video and Audio, LAN serving, Power over Ethernet and RS-232/IR
control
• 3D signal display is dependent on the TV/Display’s EDID settings
Note:
1. This system was tested with CAT6/23AWG cables, results may vary
with cables of a different specication.
2. The PoE function is designed for powering compatible Receiver
units only, non-PoE Receivers will need their own power supply.
Receivers of another brand may not be compatible.
3. For playback of 4k×2k HDMI source signals, a 4K×2K capable
display and High Speed HDMI cables are required.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
RS232 IN
A
RS232 IN
B
HDMI OUT HDMI IN
REWOPKNIL
SERVICE
DC 24V
1 2 3 4 5 6 7
1RS232 IN A/B: Connect to a PC/laptop or RS-232 control system
(with supplied 3.5mm phone jack to D-Sub 9 pin adaptor) for the
transmission of RS-232 commands.
2HDMI OUT: Connect to a HDMI equipped TV/monitor for display of
the HDMI input source signal.
3HDMI IN: Connect to HDMI source equipment such as a DVD or
Blu-ray player.
4LINK LED: The yellow LED will illuminate when both the input and
output signals are connected.
5SERVICE: Reserved for service only.
6DC 24V: Connect the 24 V DC power supply to the unit and plug the
adaptor into an AC outlet.
7POWER LED: The LED will illuminate when the device is connected
to a power supply.

4
6.2 Rear Panel
IR A1
Extender
IR B1
Extender
IR A2
Blaster
IR B2
Blaster
LAN TUO6/e5TACTUO6/e5TAC
MODE LINK
BA
MODE LINK
1
2 3 2 3
4
4
1LAN: Connect to an active network for LAN serving. When any
compatible LAN equipped receivers are connected, this allows
the network access (including internet access if available) to
be shared between any connected LAN equipped receivers.
Connect any Ethernet equipped device e.g. a Smart TV or games
console to the LAN port of a receiver for that device to share the
network/internet access.
Warning: DO NOT connect the LAN connection to the CAT5e/6/7
port. Doing so may cause a power shutdown and may damage
the device.
2IR A1/B1 IR Extender: Connect the IR extenders for IR signal
reception . Ensure that the remote being used is within the direct
line-of-sight of the IR extender.
3IR A2/B2 IR Blaster: Connect to the IR blasters for IR signal
transmission. Place the IR blaster in direct line-of-sight of the
equipment to be controlled. Use the supplied IR 'Y' Cable to ensure
control from each HDBaseT zone.
4CAT5e/6 OUT A/B: Connect to HDMI to CAT5e/6/7 receivers (with
or without PoE function) with CAT5e/6/7 cable to extend the signal
up to 100m.
MODE LED: When the device is powered the LED will ash.
LINK LED: When the device is powered on and this slot is
connected to a compatible receiver device with CAT5e/6/7 cable
the LED will illuminate.

5
6.3 IR Cable Pin Assignment
3
1
3
1
2
2
Power 5 V
NC
IR Blaster Signal
IR Signal
Power 5 V
Grounding
IR Extender
Twin IR Blaster

6
7. CONNECTION DIAGRAM
RX
IR A1
Extender
IR B1
Extender
IR A2
Blaster
IR B2
Blaster
LAN TUO6/e5TACTUO6/e5TAC
MODE LINK
BA
MODE LINK
RS232 IN
A
RS232 IN
B
HDMI OUT HDMI IN
REWOPKNIL
SERVICE
DC 24V
RX
Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
Front Rear
IR BLASTER
1.5m
60°
IR EXTENDER
7m
3m 3m
60°
m
RS-232 Control System
RS-232
RS-232
LAN
HDMI
Output
HDMI
Input
IR Extender
IR Extender
IR Blaster
('Y' Cable)
Power Supply
RS-232 Equipped
PC or Notebook
HDMI Output
IR Input/Output
RS-232 Connection
HDMI Output
IR Input/Output
LAN Connection
CAT5e/6/7
Outputs
SmartPhone
or Tablet
TV/Display
TV/Display Smart TV
RS-232 Device to
be Controlled
DVD/Blu-ray Player
Wireless
Modem/Router
(Internet
Connection)

7
8. SPECIFICATIONS
Video Bandwidth 300 Mbps/10.2 Gbps
Input Ports 1×Female HDMI Type A, 2×3.5 mm RS-232,
2×IR Digital Eyes, 1×LAN (Ethernet),1×USB
(Service Only)
Output Ports 1×HDMI, 2×CAT5e/6/7, 2×IR Emitters
Resolution Uncompressed video Up to 1080p@60 Hz
36-bit plus 4K×2K
Power Supply 24 V/2.7 A DC (US/EU standards, CE/FCC/
UL certied)
Dimensions 145 mm (W)×178 mm (D)×30 mm (H)
Weight 528 g
Chassis Material Aluminum
Color Silver
ESD Protection Human body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Operating Temperature 0 ˚C~40 ˚C/32 ˚F~104 ˚F
Storage Temperature −20 ˚C~60 ˚C/−4 ˚F~140 ˚F
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 23.1 W
9. ACRONYMS
ACRONYM COMPLETE TERM
DTS Digital Theater System
EDID Extended Display Identication Data
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
