DI-ACRO
#3 HAND BENDER
INSTRUCTION MANUAL

REV. E 09/12
2
TABLE OF CONTENTS
A. SAFETY INFORMATION PG. 3
B. MAINTENANCE PG. 3
C. #3 HAND BENDER BREAKDOWN AND PARTS LIST PG. 4-5
D. QUIK-LOK MOUNTING INSTRUCTIONS PG. 6
E. QUIK-LOK BREAKDOWN AND PARTS LIST PG. 7-8
F. SPECIFICATIONS & THE ART OF BENDING PG. 9
G. OPTIONAL STAND PG. 10
WARRANTY PG. 11

REV. E 09/12
3
A. SAFETY INFORMATION
Before bender is set up for operation, mount on work bench or
stand* with stand or work bench bolted in place.
*IF BENDER IS MOUNTED ON ITS OWN STAND, SECURE STAND
TO FLOOR
B. MAINTENANCE
Add grease in grease zerk periodically.

REV. E 09/12
4
C. #3 HAND BENDER PARTS BREAKDOWN
8130800-080

REV. E 09/12
5
Parts List
8130800-080
ITEM PART NUMBER DESCRIPTION QTY
1
8130110-100
BASE
1
2
8100120-800
HANDLE ARM WELDMENT
1
3
8150650-110
NAMEPLATE
1
5
120-0191-P
GREASE FITTING
1
6
8130120-800
HANDLE
2
8
20C0104C0508
SCREW-FHSCS 1/4-20X5/8
4
10
8130110-501
MOUNTING PLATE
1
11
8310300-200
ROLLER BEARING
109
12
8130570-203
SHIM
6
13
8130120-301
MOUNTING PLATE PIN
2
14
20A0308C1102
SCREW-SHCS 3/8-16X1-1/2
3
15
8200121-701
NOSE HOLDER
1
16
8000120-301
NOSE PIN
1
17
23A0308C0102
SCREW-SSS 3/8-16X1/2
1
18
8158121-702
TRIGGER
1
19
18A0104X3000
PIN-SPRING 1/4X3
1
20
8010461-000
STEEL BALL
1
21
8210510-204
SPRING
1
22
8310301-200
NEEDLE ROLLER
2
23
8120510-401
NOSE SPRING
2
24
21A0516C0102
SCREW-HHCS 5/16-18X1/2
2
25
23A0104C0102
SCREW-SSS 1/4-20X1/2
1
26
8130121-701
FORMING NOSE
1
27
21A0102F3000
SCREW-HHCS 1/2-20X3
2
28
0102WILLIAMS
WASHER
1/2 WILLIAMS WASHER
4
29
21A0102F1304
SCREW-HHCS 1/2-20X1-3/4
2
30
8120121-701
NOSE HOLDER SUPPORT
1
31
8120142-071
BEND LOCATING
8200142-003
BEND LOC GAUGE ARM ASSY (SEE
COMPONENTS BELOW)
1
8130142-003
BEND LOC ROD
1
8300142-003
STOP BUTTON
1
8470510-900
RETAINING RING
2
35
8130016-970
RADIUS PIN
1
36
8130120-371
LOCKING PIN ASSEMBLY
1
38
8130120-303
HOLDING PIN
1
39
8120142-001
ANGLE GAUGE
1
40
21A0308C2104
SCREW-HHCS 3/8-16X2-1/4
2
41
61X0308
WASHER-FLAT 3/8
2
42
30X0308C
NUT-FULL 3/8-16
3
43
8100142-001
RETURN STOP
1
44
21A0308C2104
SCREW-HHCS 3/8-16X2-1/4
1
