The Dialogic®1000 Media Gateway Series (DMG1000 Gateways)
allows for a well-planned, phased migration to an IP network, making
the gateways a smart solution for enterprises looking to enhance their
legacy PBX equipment with new VoIP access and applications.
Connected between a PBX or a digital handset and a LAN or WAN,
the DMG1000 Gateways convert proprietary digital PBX messages
into a format suitable for transmission over standard IP networks.
Datasheet
Media Gateway
Dialogic® 1000 Media
Gateway Series
Applications
•Centralized VoIP and FoIP application servers, including IP-based voice mail and unified messaging
•IVR and announcements
•IP PBX
•VoIP extension to branch offices
•Contact centers
Features Benets
Suitable for small to medium enterprises and easy to install,
configure, and maintain
Compatible with a variety of popular PBX manufacturers
including Alcatel, Avaya, Ericsson, Fujitsu, Mitel, NEC, Nortel,
and Siemens
Protects investment in legacy telecommunications equipment
and allows a controlled migration to IP technology
Designed, developed, and tested in Dialogic’s state-of-the-art
PBX lab and optimized for use in an Enterprise environment
Ideally suited for Enterprise Unified Messaging applications
(tested and certified with Microsoft®Exchange Server UM)
Support for IP load balancing and IP fault tolerance Allows the ability for inbound (TDM-to-IP) calls to round-robin
between available media servers and automatically routes
calls away from unresponsive media or proxy servers
Seamless interoperability with Dialogic®HMP Software Provides the options for customers to build enhanced
applications on top of base gateway and PBX functions
Supports configuration via serial, telnet, and a web browser
including context-sensitive help
Easy to install, configure, debug, and maintain
IP security features include TLS, SRTP, and HTTPS Enables secure communications for SIP messages via TLS,
for media stream via SRTP, and for web interface via HTTPS

Table 1. PBX Digital Network Interface PBX Compatibility
Datasheet Dialogic®1000 Media Gateway Series
2
Specific PBX digital network interface gateway units are compatible with the PBXs listed in Table 1. Units are specified by
product code for convenient ordering. Older product code equivalents are provided in parentheses for reference.
Manufacturer Models Software Version Product Code
Avaya DEFINITY G3 Version 3 or greater DMG1008DNIW
S8100, S8300, S8700, and S8710 Communications Manager SW V2.0 or greater (PIMG80DNIW)
Legend Release 7.0 or greater DMG1008LSW
(PIMG80LSW)
Magix Release 2.0 or greater DMG1008DNIW
PIMG80DNIW
Mitel SX-200D, SX-200 Light, SX-2000 Lightware Release 17 or greater DMG1008MTLDNIW
Light, SX-2000 S, and SX-2000 VS (PIMG80MTLDNIW)
NEC 2000 IPS Release 8.2 or greater DMG1008DNIW
2400 IMG Release 7400 or greater (PIMG80DNIW)
2400 IMX Release 5200 Dec. 92 1b or greater
2400 IPX Release V.17 issue 3.46.001 or greater
Nortel Meridian 1 – Option 11, 21, 21A, Release 15 or greater and options 19 and 46 DMG1008DNIW
51, 61, 71, and 81 are required (PIMG80DNIW)
Meridian SL1 – Generic X11 Release 15 or greater and options 19 and 46
are required
Nortel Communication Server – Release V3.0 or greater
1000E, 1000M, and 1000S
Norstar 8X24 DR5 Release 1.2 or greater
Norstar MICS Release 4.5 or greater
Siemens Hicom 300E CS Release 9006.4 or greater DMG1008DNIW
(Note: North American software load only) (PIMG80DNIW)
Hicom 300E Release 2.0 or greater DMG1008LSW
(Note: EU software load only) (PIMG80DNIW) or
DMG1008LSW
(PIMG80LSW)
8000 Release 80003 or greater DMG1008RLMDNIW
9000 Any release (PIMG80RLMDNIW)
9751 Any release of 9005
Release 9006.3 or greater; Release 9006.4
or greater is required for end-to-end signaling
Various Including Alcatel, Avaya, Ericsson, DMG1008LSW
Fujitsu, Mitel, Siemens, etc., through (PIMG80LSW) or
analog port and/or serial port integration DMG1004LSW
Cables are not included. Each unit requires one Ethernet cable per unit and one RJ-11 cable per PBX channel.

Dialogic®1000 Media Gateway Series Datasheet
3
Figure 1. IP-Enabled PBX in Communication with SIP Devices over a LAN
SIP Application
Server with Fax
SIP
Soft Phone
SIP
Telephone Set
Proprietary Digital
Telephone Set
8 Digital Lines
Dialogic®1000 Media Gateway Series
(Emulating) LANCorporate Office
PSTN
PBX
Functional Description
The DMG1000 Gateways each contain eight digital
PBX emulation interfaces and a 10/100 BaseT Ethernet
connection for connecting to a LAN. An analog loop
start unit designed for voice mail and unified messaging
applications is also available to connect to PBXs that
do not have an appropriate digital interface. The analog
loop start unit supports integration via in-band signaling
(DTMF or FSK) or serial protocols (SMDI, MCI, and
MD-110).
The DMG1000 Gateways provide a simple, cost-
effective transition to voice and data convergence for
enterprises with PBXs. Connected externally, they offer
an IP solution that works with current legacy equipment.
They support SIP-based applications as well as T.38 for
fax transmissions over IP (FoIP).
Gateway unit features include:
•Voice over Internet Protocol (VoIP) – Supports SIP per
RFC 3261. Uses Real-time Transport Protocol/Real-
Time Control Protocol (RTP/RTCP) for delivery of
voice over the LAN or WAN
•IP security — Supports TLS for SIP messages, SRTP
for media stream, and HTTPS for web interface
•Enhanced voice processing – Supports a variety of
compression algorithms, including G.711 A-law and
µ-law, G.723.1, and G.729AB
•T.38 Fax over Internet Protocol (FoIP) – Emulation
units transcode fax from T.30 fax protocol, supporting
V.17, V.21, V.27, and V.29 modulation schemes, to
T.38 for transmission over a packet network
•Hot swap – Allows gateway units to be added or
removed without affecting other gateway units
•Web server interface – Each gateway unit is delivered
with a web server interface, allowing configuration and
software upgrades via a web browser
Congurations
The DMG1000 Gateways can be used to connect IP
telephones to a legacy PBX, integrate network-hosted
applications with the PBX, extend the PBX to branch
offices, and integrate various voice and call processing
capabilities in an enterprise LAN or WAN environment.
Using exclusive PBX network interfaces (emulating),
these media gateway appliances provide exceptional IP to
PBX integration capabilities to protect an investment in
legacy telecom equipment.
Figures 1 and 2 provide sample configurations.

Call Routing
The DMG1000 Gateways route calls from the switched network to a VoIP destination on the IP network. Conversely, it
routes calls from the IP network through a switch port to a destination telephone number on the switched network. The
DMG1000 Gateways support the following call routing options:
•User-configurable list of VoIP servers
•IP load balancing
•IP fault tolerance
•TDM-to-TDM
Datasheet Dialogic®1000 Media Gateway Series
4
SIP
Telephone Sets
Proprietary Digital
Telephone Set
8 Digital Lines
Dialogic®1000 Media
Gateway Series
(Emulating)
Branch Office
Corporate Office SIP Telephone Set
LAN
Router Router
LAN
PBX
PSTN LAN
Figure 2. IP-Enabled PBX in Communication with SIP Devices at a Branch Office over a WAN
Ready
Link
Data 1 2 3 4 5 6 7 8
Port Status
Figure 3. DMG1000 Gateways Front Panel
Physical Description
Figure 3 shows the LEDs on the front panel, which reflects the status of the unit, Ethernet, and PBX telephony ports.
Ready – Shows overall unit status
Link – Shows the unit’s Ethernet status
Data – Shows the unit’s Ethernet RTP activity
Port Status 1–8 – Shows the unit’s PBX link status for each TDM port

Dialogic®1000 Media Gateway Series Datasheet
5
TX
RX
FULL
1QD
Reset
LAN
PBX Ports
1 2 3 4 5 6 7 8
DC Power Diagnostics
Figure 4. DMG1000 Gateways Rear Panel
The back panel (Figure 4) contains both interfaces and indicators.
Interfaces
DC power
Serial port for diagnostics or serial protocol support
4 or 8 telephony ports
Ethernet port
Reset switch
Status Indicators
10/100BaseT
Full/half duplex
RX/TX traffic
Ethernet link state
Ethernet collision

Datasheet Dialogic®1000 Media Gateway Series
6
Technical Specications
PBX Interface
Number of ports 4 and 8 port analog units, and 8 port Digital PBX emulation units
Use multiple gateway units for higher port counts
Connectors 8 shielded female RJ-45 jacks
Network Interface
10/100 Base-T Ethernet LAN port
Connector 1 shielded female RJ-45 jack for LAN
VoIP Protocols
SIP per RFC 3261
RTP/RTCP for delivery of voice
FoIP Protocol
T.38 FoIP Emulation units transcode fax from T.30 fax protocol, supporting V.17, V.21, V.27, and V.29
modulation schemes, to T.38 for transmission over a packet network
Voice Support
G.711 µ-Law and A-Law, G.723.1, G.729AB
Silence suppression with comfort noise
G.168 automatic echo cancellation
Call Progress Analysis (CPA), including Positive Voice Detection, Positive Answering Machine Detection (PAMD), DTMF detection, and fax
tone detection
Quality of Service
Type of Service (ToS)
IP precedence
Configuration and Management
SNMP v1 Read-only for alarm reporting
Web GUI With context-sensitive Help facility
Telnet
BOOTP client and TFTP client Built-in
Call Routing
User configuration list of VoIP endpoints
IP load balancing
IP fault tolerance
Supports configuration of a backup SIP proxy server
IP Security
TLS for SIP messages
SRTP for media stream
HTTPS for web interface
Power Requirements
Line voltage 90 VAC to 264 VAC
Frequency 47 Hz to 63 Hz

Physical Dimensions
Length 10 in. (25.4 cm)
Width 9.5 in. (24.1 cm)
Height 2.1 in. (5.3 cm)
Weight Approximately 2.5 lbs. (1.13 kg)
Environmental Requirements
Operating temperature 32ºF to 122ºF (0ºC to 40ºC)
Non-operating temperature –4ºF to 158ºF (–20ºC to 70ºC)
Approvals
Safety
Canada CAN/CSA 60950, third edition
European Union EN 60950
United States ANSI/UL 60950, third edition
EMC
European Union EN 55022-1998 Class B
Canada IC ES-003 Class B
United States FCC Part 15 Class B
Telecommunications
European Union EN 55024:1998
Canada IC CS03, Issue 7
United States FCC Part 68
Country-specific Approvals Global product approvals database at http://www.dialogic.com/declarations
Hazardous Substances RoHS compliance information at http://www.dialogic.com/rohs
Reliability/Warranty
Estimated MTBF Five years
Warranty Warranty information at http://www.dialogic.com/warranties
Dialogic®1000 Media Gateway Series Datasheet
7
Technical Specications (cont.)
Ordering Information
Dialogic®Product Order Code Description
DMG1004LSW 310-877 Analog FXO, 4 ports
DMG1008LSW 884-214 Analog FXO, 8 ports
DMG1008DNIW 884-211 Digital PBX Emulation, 8 ports (Avaya, Nortel, NEC, Siemens)
DMG1008MTLDNIW 884-212 Digital PBX Emulation, 8 ports (Mitel)
DMG1008RLMDNIW 884-213 Digital PBX Emulation, 8 ports (Rolm)

www.dialogic.com
To learn about Dialogic®products, go to www.dialogic.com.
Dialogic Corporation
9800 Cavendish Blvd., 5th floor
Montreal, Quebec
CANADA H4M 2V9
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH PRODUCTS OF THE DIALOGIC CORPORATION (“DIALOGIC”). NO LICENSE, EXPRESS
OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN A
SIGNED AGREEMENT BETWEEN YOU AND DIALOGIC, DIALOGIC ASSUMES NO LIABILITY WHATSOEVER, AND DIALOGIC DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY, RELATING TO SALE AND/OR USE OF DIALOGIC PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR
PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY INTELLECTUAL PROPERTY RIGHT OF A THIRD PARTY.
Dialogic products are not intended for use in medical, life saving, life sustaining, critical control or safety systems, or in nuclear facility applications.
Dialogic may make changes to specifications, product descriptions, and plans at any time, without notice.
Dialogic is a registered trademark of Dialogic Corporation. Microsoft is a registered trademark of Microsoft Corporation in the United States and/or other countries.
Other names of actual companies and products mentioned herein are the trademarks of their respective owners. Dialogic encourages all users of its products to
procure all necessary intellectual property licenses required to implement their concepts or applications, which licenses may vary from country to country. Dialogic’s
trademarks may be used publicly only with permission from Dialogic. Such permission may only be granted by Dialogic’s legal department at the address listed
above. Any authorized use of Dialogic’s trademarks will be subject to full respect of the trademark guidelines published by Dialogic from time to time, and any use
of Dialogic’s trademarks requires proper acknowledgement.
None of the information provided in this datasheet other than what is listed under the section entitled Technical Specifications forms part of the specifications of the
product and any benefits specified are not guaranteed.
Copyright © 2008 Dialogic Corporation All rights reserved. 04/08 7135-11
