Diamond Multimedia 3650PE512H User manual

SKU
SYSTEM BUILDER SKU
PRODUCT
PRODUCT SHORT INTERFACE PCI Express x16
DESCRIPTION GPU HD 3650
CORE CLOCK 725 MHZ
MEMORY CLOCK 800 MHz
MEMORY CONFIGURATION 16Mx32
MEMORY TYPE GDDR2
MEMORY BANDWIDTH 80.6 GB/sec
MEMORY SIZE 512MB
MEMORY CONTROLLER INTERFACE 128-Bit
DUAL MONITOR Dual-Link DVI,HDMI,VGA
DUAL LINK DVI Hydravision 4
EXTERNAL POWER REQUIREMENT NONE
SYSTEM REQUIREMENT CPU Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or higher
SYSTEM REQUIREMENT CPU SPEED 2.0 Ghz or faster
SYSTEM REQUIREMENT MEMORY 1024MB
SYSTEM REQUIREMENT POWER SUPPLY 250 Watt or greater power supply .
SYSTEM REQUIREMENT SPECIAL INSTRUCTIONS
ATI Radeon HD 3870 and ATI Radeon HD 3850 System
Requirements PCI Express® based PC is required with
one X16 lane graphics slot available on the motherboard
450 Watt or greater power supply for dual ATI
CrossFireX™) Certified power supplies are
recommended 1GB of system memory recommended
Installation software requires an optical drive DVD
playback requires DVD drive Blu-ray™ / HD DVD
playback requires a Blu-ray drive For a complete ATI
CrossFireX™ system, additional ATI Radeon™ HD 3800
series graphics card(s)and a ATI CrossFireX Ready
motherboard are required.
SYSTEM REQUIREMENT HARD DISK 480MB available hard disk space
SYSTEM REQUIREMENT BUS PCI Express
SYSTEM REQUIREMENT STANDARD SLOT
SOLUTION SINGLE
SYSTEM REQUIREMENT CHASSIS N/A
SYSTEM REQUIREMENT MONITOR Digital flat-panel (DFP) displays or DVI-I Compatilbe or digital CRT display or High-resolution VGA monitor
DIAMOND MULTIMEDIA Product Setup Sheet
DATE : June 18, 2008 - 1:15 pm
3650PE512H
3650PE512HSB
Diamond Viper - ATI Radeon™ HD 3650 PCIE 512MB GDDR2 Video Card
PRODUCT DETAILED DESCRIPTION ATI Avivo™ HD Video & Media
The ATI Radeon HD 3000 Series of GPUs allow you to experience the power of HD with graphics processing
designed for how you work and play. The Diamond Radeon™ HD 3650 delivers outstanding performance at a
great price. Advance to the next generation of HD game performance and life-like realism thanks to DirectX® 10.1
capabilities and plug-and-play ATI CrossFireX™ multi-GPU upgradeability. Watch the latest Blu-ray videos in full
1080p HD and upscale beyond - without placing huge demands on your CPU. Enjoy break-through efficiency with
more processing performance per watt and energy-saving features to help save you money.
PRODUCT FEATURES Superscale unified shader architecture
PCI Express x16 2.0 support
ATI Crossfire X Multi-GPU Support for highly scalable performance
Up to four GPU support with an AMD 790FX based motherboard
High-speed 128-bit-HDR (High Dynamic Range) rendering
120 Unified Stream Processors
128-bit memory interface
Direct X 10.1 / Shader Model 4.1
Game Physics processing capability
Built-in HDMI with Multi-channel 5.1 surround audio
Unified Video Deoder (UVD) for Blu-ray
Up to 24x Custom Filter Anti-Aliasing
55nm process technology
ATI Avivo HD Video and Display Technology
OpenGL 2.0 Support
SYSTEM REQUIREMENT
ATI PowerPlay energy conserving technology
RoHS compliant
Build in HDCP Support

SYSTEM REQUIREMENT INTERNET ACCESS N/A
SYSTEM REQUIREMENT USB NO
SYSTEM REQUIREMENT CD DVD YES
SYSTEM REQUIREMENT OS WINXP YES
SYSTEM REQUIREMENT OS LINUX32 YES
SYSTEM REQUIREMENT OS LINUX64 YES
PRODUCT DIMENSIONS
RETAIL BOX DIMENSIONS
SYSTEM BUILDER BOX DIMENSIONS
PRODUCT WEIGHT
PRODUCT WEIGHT WITH CONTENT
RETAIL PACKAGE UPC
SYSTEM BUILDER PACKAGE UPC
LINE CARD
SPECS SHEET
PRODUCT IMAGE
RETAIL PACKAGING IMAGE
PACKAGE INCLUDE ITEM DIAMOND VIPER HD 3650 PCIE 512MB GDDR2 VIDEO CARD
PACKAGE INCLUDE ITEM 1 Quick Start Guide
PACKAGE INCLUDE ITEM 2 DVI-TO-VGA ADAPTER
PACKAGE INCLUDE ITEM 3 INSTALL CD
PACKAGE INCLUDE ITEM 4 Diamond Warranty Card
WEB PAGE
OPERATING SYSTEM
4 7/8 X 6/8 X 8 1/4
11.75 X 9.5 X 3
11.75 X 7.25 X 2
2.75 Lbs
3.55 Lbs
757448006452
viper_3650pe2512_3650_pcie_512mb_spec_sheet.pdf
PACKAGE INCLUDE
