Diamond Multimedia Radeon X1650AGP256 User manual

X1650PRO256/512
X1650AGP256/512
9650 DeSoto Ave
Chatsworth, CA 91311
Tel: [phone]
Fax: [phone]
www.diamondmm.com
Featuring:RADEONTM X1650PRO
Memory: 256/512MB
Slot Type: AGP/PCIE
With:  Dual DVI (Dual Link) / HDTV / D-Sub
Viper X1650PRO
The World Fastest Graphics Card
Overview
THE GAME IS ON!
The Radeon®X1650 PRO delivers stunning 3D graphics, excellent performance, and all the extensive features of a high-end
graphics card. Your system will be able to handle the latest games, high definition digital video, and Windows Vista™ with
aplomb. The X1650 PRO is capable of displaying a billion colors more than competing graphics cards, boasts one of the
highest video performance scores in the industry, and can bring today’s top games to life through outstanding shader
performance and simultaneous high dynamic range lighting and full screen anti-aliasing, available only with ATI products.
Radeon X1650 PRO graphics technology. Exceptional graphics performance.
FEATURING
• DirectX 9.0 and OpenGL 2.0
• CATALYST Software Drivers
• 12 Pixel Pipelines Architecture
• 8 Vertex Shader
• SMARTSHADER Technology
• VIDEOSHADER Technology
• SMOOTHVISION Technology
• HYPER Z III+ Technology
• Dual Display Support
CROSSFIRE
• Combined Multi-GPU power for a new 
 dimension of graphics capability
• High-performance processor sharing
• High compatibility with games, graphics 
 cards, motherboards, and third party 
 component
• Crossfire only available on motherboards 
 that support dual PCI-Express x16 slot
System Requirements
• 420 Watt ATX 2.0 or greater power supply.
Consult your computer system manual to ensure the power supply is designed to accommodate
 a high-end graphics card with peak dissipation above 75 watts.
• Intel®Pentium®IV or AMD Athlon®, Athlon®64, Athlon®XP
• System Memory: 512 MB or higher. 512MB recommended
• 480MB available hard disk space
• Motherboard with free PCI Express™ slot and correct PCIe chipset driver.
• CD-ROM/DVD-ROM drive (for installation software).
• PCI Express™ compatible system with a specialized 12v graphics  
 card power connector or
AGP 2.0,3.0/4X,8X
 * DVD-ROM required for DVD Playback.
• Microsoft Windows®XP (Home or Pro) or Windows®2000
• High-resolution MultiSync or multi-frequency monitors or any other 
 type or VGA monitor.
• Digital flat-panel (DFP) displays or digital CRT display.
• Connecting Device for CrossFireTM-Only one display while enable Cross-Fire
Package Includes:
• Quick Install Guide
• Install CD : ATI CATALYST Drivers
• Software : Diamond Tools, DVD Playback, 3D Mark '03
• DVI to VGA adapter
• HDTV Composite Adapter
• S-Video Cable
AVIVOTM
•Video and Display Perfection
•True-to-Life Image Reproduction
•Sharp video and photos, smooth video playback
•Universal connectivity for TVs and display
* CrossFire not available on AGP models
SPECIFICATIONS
• GPU: ATI Radeon®X1650PRO
• Bus Type: PCI-Express x16/AGP
• Memory: 256/512MB GDDR2-128bit
• Core Clock: 600 MHz
• Memory Speed: 1.5 GHz
• RAMDACS: Dual 400 MHz
• API Support: DirectX 9.0, Shader Model 
 3.0 and OpenGL 2.0
• Output: Dual DVI, TV-Out
Diamond, Diamond Multimedia and Viper are registered trademarks of Diamond Multimedia. ©2006 Advanced Micro Devices, Inc.,ATI, the ATI logo, Avivo,
Catalyst, CrossFire, HyperMemory, and Radeon are trademarks of Advanced Micro Devices, Inc.. All other trademarks are property of their respective owners.
© 2006 Diamond Multimedia. All rights reserved.
