Diamond Radeon 2400PRO256A User manual

Featuring: RADEONTM HD 2400PRO
Memory: 256/512 MB
Slot Type: PCIE/AGP
With:  Dual Link DVI + HDTV-Out
  and VGA
Stealth HD 2400PRO
Overview
The Diamond Stealth®HD 2400PRO is a feature-rich upgrade from
integrated graphics for an immersive experience with DirectX®10 gaming
and HD video. Connect to big-screen TVs with HDMI* and built-in 5.1
surround sound audio to enjoy Blu-ray™and HD DVD movies. ATI Catalyst™
graphics configuration software is designed for quick setup and stable
operation with Windows Vista™.
FEATURING
• Native PCI Express®x16 bus interface
• 64 Bit DDR2 memory interface
• Support for Microsoft®DirectX®10 & 
 Shader Model 4.0, OpenGL 2.0
• Up to 24x Custom Filter Anti-Aliasing
• CATALYSTTM Software Drivers
• Windows Vista™3D environment Support
ATI Avivo™HD Video and Display  
Technology
• Built-in HDMI and 5.1 surround sound
• RoHS compliant
• Support for the ATI Radeon™DVI to HDMI 
 adapter
• HDCP Support
• Supports all display resolutions up to  
 1920x1080
• Unified Video Decoder (UVD) for Blu-ray™
 and HD DVD
• CrossFire™* multi-GPU
SPECIFICATIONS
•GPU: ATI RadeonTM 2400PRO
•Bus Type: PCI-Express / AGP
• Core Clock: 600Mhz
• Memory Size: 256/512MB DDR2
• Memory Configuration: 8Mx32/
 16Mx32
• Memory Speed: 800Mhz
• Memory Interface: 64 Bit
• HDCP: Yes
• CrossFire Support - Software
• Display Formats: Dual Link DVI + 
 HDTV-Out and VGA
System Requirements
•AMD Athlon
®
or Intel
®
Pentium
®
4
•512MB of system memory; 1GB or more for best  
 performance.
•Optical drive for installation software
 (CD-ROM or DVD ROM drive).
•400 Watt or greater (550 for CrossFire
™
)
 power supply recommended
Package Includes
•Diamond Stealth Radeon HD 2400PRO graphics card
•Quick Start Guide
•Installation CD
• S-Video
• Component Cable
Diamond, Diamond Multimedia,Viper and Stealth are registered trademarks of Diamond Multimedia. ©2006 Advanced Micro Devices, Inc.,ATI, the ATI logo,
Avivo, Catalyst, CrossFire, HyperMemory, and Radeon are trademarks of Advanced Micro Devices, Inc.. All other trademarks are property of their respective
owners. © 2007 Diamond Multimedia. All rights reserved.
2400PRO256PE
2400PRO512PE
2400PRO256A
2400PRO512A
9650 DeSoto Ave
Chatsworth, CA 91311
Tel: [phone]
Fax: [phone]
www.diamondmm.com
KL-062207
*CrossFireTM only available on motherboards that support dual PCI Express x16 slots.
*HDMI only available with PCI Express
