Digi XBee Grove Development Board Series User manual

XBee Grove Development Board
User Guide

Revision history—90001457-13
Revision Date Description
A June 2016 Converted files to new format and completed minor updates to screens
and content.
B October
2017
Updated USB VBUS line graphic.
Trademarks and copyright
Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United
States and other countries worldwide. All other trademarks mentioned in this document are the
property of their respective owners.
© 2019 Digi International Inc. All rights reserved.
Disclaimers
Information in this document is subject to change without notice and does not represent a
commitment on the part of Digi International. Digi provides this document “as is,” without warranty of
any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or
merchantability for a particular purpose. Digi may make improvements and/or changes in this manual
or in the product(s) and/or the program(s) described in this manual at any time.
Warranty
To view product warranty information, go to the following website:
www.digi.com/howtobuy/terms
Customer support
Gather support information: Before contacting Digi technical support for help, gather the following
information:
Product name and model
Product serial number (s)
Firmware version
Operating system/browser (if applicable)
Logs (from time of reported issue)
Trace (if possible)
Description of issue
Steps to reproduce
Contact Digi technical support: Digi offers multiple technical support plans and service packages.
Contact us at +1 952.912.3444 or visit us at www.digi.com/support.
XBee Grove Development Board User Guide 2

Feedback
To provide feedback on this document, email your comments to
[e-mail]
Include the document title and part number (XBee Grove Development Board User Guide, 90001457-
13 V) in the subject line of your email.
XBee Grove Development Board User Guide 3

Contents
Overview
Development board variants 7
XBee THT Grove Development Board 7
XBee SMT Grove Development Board 7
XBee surface-mount (SMT)Grove development board 8
XBee through-hole (TH) Grove development board 10
Mechanical 12
XBee THT Grove Development Board variant 12
XBee SMT Grove Development Board variant 12
Power supply 13
XBee THT Grove Development Board power supply 13
XBee SMT Grove Development Board power supply 13
Power supply battery connector 14
XBee connector 14
XBee THT Grove Development Board XBee connector 15
XBee SMT Grove Development Board XBee connector 17
USB 19
XBee THT Grove Development Board USB 19
XBee SMT Grove Development Board USB 20
USB VBUS line 20
Reset button 21
XBee THT Grove Development Board Reset button 21
XBee SMT Grove Development Board Reset button 21
Commissioning button 22
XBee THT Grove Development Board Commissioning button 22
XBee SMT Grove Development Board Commissioning button 22
Commissioning pin and Grove AD0 connection 23
Association led 24
XBee THT Grove Development Board Association LED 24
XBee SMT Grove Development Board Association LED 24
RSSI led 25
XBee THT Grove Development Board RSSI LED 25
XBee SMT Grove Development Board RSSI LED 25
PWM0 RSSI configuration 26
User LED and User button 27
XBee THT Grove Development Board User LED and User button 27
XBee SMT Grove Development Board User LED and User button 27
User LED and User Button connection to DIO4 27
On/sleep LED 29
XBee THT Grove Development Board On/Sleep LED 29
XBee SMT Grove Development Board On/Sleep LED 29
XBee Grove Development Board User Guide 4

XBee Grove Development Board User Guide 5
On/sleep LED connection to DIO9 30
Potentiometer 31
XBee THT Grove Development Board Potentiometer 31
XBee SMT Grove Development Board Potentiometer 32
I2C 33
XBee THT Grove Development Board I2C bus 33
XBee SMT Grove Development Board I2C bus 33
XBee/XBee-PRO connection to Grove sensor 33
Grove I2C connector pinout 34
Grove Connectors 35
THT board Grove connectors pinout 36
SMT board Grove connectors pinout 38
Loopback jumper 40
XBee THT Grove Development Board Loopback jumper 40
XBee SMT Grove Development Board Loopback jumper 40
Schematic and Gerber files
XBee THT Grove Development Board schematic 42
Gerber files 42
XBee SMT Grove Development Board schematic 43
Gerber files 43

Overview
This section provides an overview of the XBee Grove Development Board.
XBee Grove Development Board User Guide 6

Overview Development board variants
XBee Grove Development Board User Guide 7
Development board variants
The THT and SMT are the two variants of the board.
XBee THT Grove Development Board
XBee SMT Grove Development Board

Overview XBee surface-mount (SMT)Grove development board
XBee Grove Development Board User Guide 8
XBee surface-mount (SMT)Grove development board
This picture shows the XBee SMTGrove development board and the table that follows explains the
callouts in the picture.

Overview XBee surface-mount (SMT)Grove development board
XBee Grove Development Board User Guide 9
Number Item Description
1 SMT XBee
socket
2 Grove
connectors
The board provides eight vertical Grove connectors connected to XBee
DIO lines.
3 Reset button Button connected to the XBee reset pin.
4 User button Button connected to the XBee DIO4 line. The button shares the same
DIO line with one user LED.
5 Commissioning
button
Button connected to the XBee commissioning pin.
6 Loopback
jumper
Three-pin jumper to connect the UART to the USB (normal mode) or to
make a loopback connection between the Rx and Tx signals of the UART.
7 Micro USB The XBee serial port is connected through a USB to RS-232 converter to
a micro USB connector provided on the board.
8 Battery
connector
Two-pin, 2 mm pitch, PH type connector from JST to power the board
from an external battery.
9 Potentiometer 10 K potentiometer connected to the XBee AD3 line. One jumper is
available to save power when it is not used.
10 RX and TX
indicators
Yellow: UART Rx / RFTx
Blue: UART Tx / RF Rx
11 Association
indicator
LED connected to the XBee association pin.
12 ON/SLEEP LED LED connected to the ON/SLEEP pin (DIO9).
On: XBee is awake
Off: XBee is asleep
13 RSSIindicator LED connected to the XBee RSSI pin.
14 I2C bus Bus connected to XBee DIO1/DIO19, to be used with several Grove
sensors.
15 User LED Shares DIO4 with the user button.
16 Test points

Overview XBee through-hole (TH) Grove development board
XBee Grove Development Board User Guide 10
XBee through-hole (TH) Grove development board
This picture shows the XBee THGrove development board and the table that follows explains the
callouts in the picture.

Overview XBee through-hole (TH) Grove development board
XBee Grove Development Board User Guide 11
Number Item Description
1 Through-hole
XBee sockets
Two 10-pin, 2 mm pitch.
2 Grove
connectors
The board provides six vertical Grove connectors, connected to XBee
DIO lines.
3 Association
indicator
LED connected to the XBee association pin.
4 RSSI indicator LED connected to the XBee RSSI pin.
5 Reset button Button connected to the XBee reset pin.
6 Potentiometer 10 K potentiometer connected to the XBee AD3 line. One jumper is
available to save power when it is not used.
7 Micro USB The XBee serial port is connected through a USB to RS-232 converter to
a micro USB connector provided on the board.
8 Commissioning
button
Button connected to the XBee commissioning pin.
9 Battery
connector
Two-pin, 2 mm pitch, PH type connector from JST to power the board
from an external battery.
10 Loopback
jumper
Three-pin jumper to connect the UART to the USB (normal mode) or to
make a loopback connection between the Rx and Tx signals of the UART.
11 User button Button connected to XBee DIO4 line. The button shares the same DIO
line with one user LED.
12 ON/SLEEP LED LED connected to the ON/SLEEP pin (DIO9).
On: XBee is awake
Off:XBee is asleep
13 User LED A user LED that shares the DIO4 with the user button.
14 RX and
TXindicator
Yellow: UART Rx / RF Tx
15 I2C bus Bus connected to XBee DIO1/DIO11 to be used with several Grove
sensors.

Overview Mechanical
XBee Grove Development Board User Guide 12
Mechanical
There are two variants of the XBee Grove Development Board:
nTHT variant is 48.8 mm x 66 mm
nSMT variant is 53.68 mm x 72.60 mm with a shape similar to a regular XBee module.
The board provides four 3.2 mm assembly drills.
XBee THT Grove Development Board variant
XBee SMT Grove Development Board variant

Overview Power supply
XBee Grove Development Board User Guide 13
Power supply
You can power the XBee Grove Development Board from the 5 V supply available on the USB
connector or from an external battery connected to a 2-pin, 2 mm pitch, PH-type connector from JST.
When you power the board from both supplies, it uses the USB.
The board has a 3.3 V regulator that generates 500 mA supply.
Note The power supply battery connector is not mounted in the board.
XBee THT Grove Development Board power supply
XBee SMT Grove Development Board power supply

Overview XBee connector
XBee Grove Development Board User Guide 14
Power supply battery connector
The following table shows the pinout of the battery connector:
Battery connector Signal Comments
2 GND
1 VBAT Battery supply input
Note The power supply battery connector is not mounted in the board.
XBee connector
The XBee THT Grove Development Board provides two 10-pin, THT, 2 mm pitch sockets to connect a
THT XBee module. It is compatible with the XBee/XBee-PRO and the programmable XBee.

Overview XBee connector XBee Grove Development Board User Guide 15
XBee THT Grove Development Board XBee connector
The board provides footprints for two 10-pin, THT, 2.54 mm pitch connectors. You can use these footprints to solder a pin header on the top or bottom to
access the XBee signals or to connect the XBee Grove Development Board to a bread board.
Left Right
Pin Signal Comments Pin Signal Comments
1 3.3V XBee supply 1 DIO4 To GROVE_DIO4 and user LED/button
2 XBEE_TX To serial to USB device 2 XBEE_CTS_N To serial to USB device

Overview XBee connector XBee Grove Development Board User Guide 16
Left Right
3 XBEE_RX To serial to USB device 3 DIO9 To On/Sleep LED
4 DIO12 To GROVE_DIO12 4 VREF
5 RESET_N To reset button 5 ASSOC_LED To association LED
6 RSSI/PWM0 To RSSI LED and GROVE_PWM 6 XBEE_RTS_N To serial to USB device
7 DIO11/I2C_SDA To GROVE_I2C 7 AD3 To potentiometer
8 XBEE_PIN8 Connected to breadboard header 8 AD2 To GROVE_AD2
9 XBEE_DTR_N To serial to USB device 9 DIO1/ISC_SCL To GROVE_I2C
10 GND 10 AD0/CB To commissioning button and GROVE_AD0

Overview XBee connector XBee Grove Development Board User Guide 17
XBee SMT Grove Development Board XBee connector
The XBee SMT Grove Development Board provides three spring sockets. A spring header is a custom Digi header that provides a reliable connection to
SMT XBee modules without soldering the module in place.
Left Bottom Right
Pin Signal Comments Pin Signal Comments Pin Signal Comments
1 GND 1 DIO18 To GROVE_
DIO18
1
2 3.3V XBee supply 2 2 AD0/CB To commissioning button and GROVE_
AD0

Overview XBee connector XBee Grove Development Board User Guide 18
Left Bottom Right
3 XBEE_TX To serial to USB device 3 3 DIO1/I2C_SCL To GROVE_I2C
4 XBEE_RX To serial to USB device 4 4 AD2 To potentiometer
5 DIO12 To GROVE_DIO12 5 5 AD3 To GROVE_AD3
6 RESET_N To reset button 6 6 XBEE_RTS_N To serial to USB device
7 RSSI/PWM0 To RSSI LED and GROVE_
PWM0
7 7 ASSOC_LED To association LED
8 DIO11/I2C_
SDA
To GROVE_I2C 8 8 VREF
9 - 9 9 DIO9 To On/Sleep LED
10 XBEE_DTR_N To serial to USB device 10 10 XBEE_CTS_N To serial to USB device
11 GND 11 11 DIO4 To GROVE_DIO4 and user LED/button
12 DIO19 To GROVE_DIO19 12 12
13 GND 13 13

Overview USB
XBee Grove Development Board User Guide 19
USB
The XBee Grove Development Board includes a micro USB connector and an FT232RL USB to RS-232
converter to communicate with the serial port of the XBee.
A green LED and a yellow LED show the status of the TX and RX lines.
The hardware flow control signals of the XBee (XBee_RTS and XBee_CTS) connect to the FT232RL
device. Two serial or resistors disconnect the flow control of the chip if this functionality is not needed.
The XBEE_DTR_N signal is also connected to the FT232 chip. XCTU uses this signal to enter in the boot
loader and recover the module from incorrect firmware. A configurable OR resistor disconnects this
signal if the functionality is not needed.
A three-pin jumper configures the serial port in a loopback mode, connecting the RX and TX lines
together. When you close positions 1 and 2, the serial port is configured in normal mode and the serial
port of the XBee is connected to the micro USB connector. If you close positions 2 and 3, the serial
port works in loopback mode and the data transmitted by the XBee connects to the RX pin.
The USB connector also powers the board through the VBUS line.
XBee THT Grove Development Board USB

Overview USB
XBee Grove Development Board User Guide 20
XBee SMT Grove Development Board USB
USB VBUS line
The following graphic illustrates how the USB powers the board through the VBUS line.
