Digicom 8E4095 Owner's manual

NETWORKING
For further information: [email protected] or http://www.digicom.it
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. All other brands, products and trademarks are property of their respective owners.
Ports:
l8 ports RJ-45 10BaseT/100BaseTX
l1 port RJ-451Gigabit on copper
lAny port can automatically turn from MDI-
X to MDI (Cross)
lFull-duplex switch for the connection of
10Mbit/s-100Mbit/s groups
lStore and Forward technology
lSeparate repeater modules for Ethernet
and Fast Ethernet
lCSMA/CD access
lFullspeed Filtering and Forwarding rate
l4096 addresses memory
l2Mbyte Buffer memory
lComplies with following specifications:
IEEE 802.3 10BaseT, IEEE802.3u,
100BaseTX and IEEE802.3ab 1000BaseT
Led Indicators:
lPower
lPLink/Activity
l10/100/1000 Mbps
lFull-Duplex
Mechanical Features:
lMetal chassis
lDesktop version
lPower supply 110-220 VAC
lCustom private MIB support
lConsumption 10 Watt
Size and Weight:
lSize 251x37x118mm; Weight 1 Kg
Operating Features:
lWorking temperature: from 5 to 50 °C
lHumidity: between 10% and 90% non-
condensing
lCE Mark, FCC A
Dual Speed Switch 8G 05.03.2003
The Networking solutions for fast and performing LANs.
DESCRIPTION
8 ports 10/100 + 1 Gigabit, the most compact
switch for the maximum performances on the
cabling Cat. 5. Ideal as root switch to connect to
the server with copper Gigabit technology.
Have you a high performances server and you want
the maximum band available?
Have you a Cat. 5 cabling and you want to overcome
the 100Mbit/s limit?
You will have all this using a Dual Speed Switch 8G.
Any of the 8 ports supports the speeds of 10 or 100
Mbit/s in Autosensing mode.
One port at 1 Gigabit RJ45 on copper is available for
the direct connection to the server or as uplink to the
LAN operating at 1 Gigabit.
Speed and operating mode are automatically detected
and selected.
Any port can turn into a cross (MDI) port and is able to
automatically correct the polarity.
Just Plug & Play! No additional setting is required.
You want to control the LAN status? Just look at the
led indicators placed on the front panel and you will
know about speed, activity and status of each port.
Dual Speed Switch 8G
Code: 8E4095
