BARRON EXITRONIX VLEDC Series User manual

IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations, if
applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Do not let power cords touch hot surfaces.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours or 48 hours before first use for models with one or two batteries,
respectively.
SAVE THESE INSTRUCTIONS!
Technical Support ■ [phone] ■ [email protected]
10070203 REV 2 - 05/22 1800-533-3948 www.barronltg.com
VLEDC Series
Installation Instructions

Wall Mount
Note: Max. mounting height is 14ft
1. Remove the front cover from the enclosure and install the (2)
lamp heads; see Lamp Installation section. (Fig. 1)
2. Remove from the backplate the center knockout and any
knockouts that are needed to mount to the J-box.
3. Route wires through the center hole of the backplate.
4. Make electrical connections; see Electrical Connections
section.
5. Secure the backplate to the J-box using appropriate hardware
(provided by others).
6. Connect the remote lamp wires if the fixture is remote capable.
Refer to Remote Lamp Connection section.
7. Plug the male battery connector(s) into the female battery
connector(s) on the PCBA.
8. Remove appropriate chevrons from the front cover, as desired.
9. Snap the front cover back onto the enclosure.
10. Adjust the direction of the lamp heads for optimal lighting
coverage.
Ceiling or End Mount
Note: Max. mounting height is 14ft
1. Secure the crossbar to the J-box, with the longer blade of the
crossbar against the J-box. (Fig. 2 & 3)
2. Remove the front cover from the enclosure and install the (2)
lamp heads; see Lamp Installation section.
3. For a double face fixture, replace the backplate with the
additional faceplate provided.
4. Remove the mounting cover from the top or side of the fixture
for ceiling or end mounting, respectively.
5. Install the canopy in the opening by inserting at a 20° angle,
then rotating until it snaps into place. (Fig. 4)
Caution: Trying to remove the canopy after it is locked in
place may cause damage.
6. Route wires through the hole in the canopy.
7. Make electrical connections; see Electrical Connections section.
8. Secure the canopy to the crossbar using appropriate hardware. The canopy should be securely fastened and tight
against the wall.
9. Follow steps 6-10 in the Wall Mount section to finish installation.
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Frame
Lamp Head J-Box
Normal Battery
Connector
Chevron
Front Cover
Wire Nuts
Canopy Crossbar
Normal Battery
Connector
J-Box
Screws
Canopy
Crossbar
Normal Battery
Connector
J-Box
Screws
10070203 REV 2 - 05/22 2800-533-3948 www.barronltg.com
VLEDC Series
Installation Instructions

Lamp Installation
1. Remove the front cover if not completed already.
2. Snap the lamp heads into place. (Fig. 5)
Note: The lamp heads can be assembled forward or
backward.
3. Connect the lamp head connectors.
Electrical Connections
All electrical connections should be made inside the J-box.
Make electrical connections as follows (Fig. 6):
120-277VAC
White - Common
Black - 120-277VAC
Note: Cap unused leads to prevent shorting.
Remote Lamp Connection: 3.6V, 4W
Fixtures with remote capability have an additional battery
that needs to be connected. Make sure to plug the extra
battery connector into the PCBA. (Fig. 7)
1. Remove the ground male connector from the female
connector. (Fig. 8)
2. Plug the remote male connector into the female
connector. (Fig. 9)
3. Connect extended remote head wires to the remote
wires using wire nuts. Yellow is positive (+) and purple is
negative (–).
Fig. 6 - Wiring Diagram
Fig. 9
Fig. 8
Fig. 7
LED STRIP PCBA
Lamp
Head
Remote
Connector
For
Remote Capability
head
Remote
For
Battery
White NEUTRAL
Black 120-277VAC
MAIN
PCBA
Extra
Battery
Normal
Battery
Only normal battery for fixtures with no remote
capability.
Extra battery for fixtures with remote capability.
Lamp
Head
Normal Battery Extra Battery
Normal Battery
Connector
Remote
Connector
Extra Battery
Connector
Female connector
Male connector
Remote wire
Remote male connector
Female connector
Wire nut
Extended remote wires
Fig. 5
Lamp Head Forward Lamp Head Backward
Attach lamp head
male and female connector
10070203 REV 2 - 05/22 3 800-533-3948 www.barronltg.com
VLEDC Series
Installation Instructions

Self-Test/Self-Diagnostics (G2)
Operation
The purpose of this option is to provide Self-testing and Self-diagnostic capabilities to the emergency unit. At
predetermined intervals, the emergency unit will automatically switch into battery mode. Refer to the Self-Test Feature
section below for timing details. The emergency unit will also perform various Self-diagnostic tests to determine if there
are any faults. Visual signaling will alert maintenance personnel to a fault of the emergency unit electronics, battery,
and/or battery charger. The circuitry continuously monitors the operating condition of the emergency unit and battery
charging circuit/battery supply voltage. Refer to the LED Indicator section below for fault reporting details.
Self-Test Feature
• The emergency unit will automatically switch to battery mode every month for a period of 1 minute.
• The emergency unit will automatically switch to battery mode every 12 months for a period of 90 minutes.
LED Indicator
Once the unit is properly installed according to the installation instruction sheet and AC power is supplied, the unit will turn
on and the Self-diagnostic test function will initiate. After this, the bi-color LED will indicate the status of the unit.
• A steady green LED indicates that normal AC power is being supplied to the emergency unit and the battery is
charged.
• A blinking green LED indicates that the unit is in battery mode. Refer to the Test Button Feature section below for
manual test details.
• A red LED indicates whenever the Self-diagnostic system has detected a fault condition. Refer to the chart below to
determine the fault condition:
Test Button Feature
MANUAL TEST – Pressing the test button will switch the unit into battery mode for a set amount of time. The desired
length of the test is determined by the number of times the test button is pressed.
• Pressing the test button once will switch the unit into battery mode for a period of 30 seconds.
• Pressing the test button twice within 2 seconds will switch the unit into battery mode for a period of 3 minutes.
• Pressing the test button 3 times within 2 seconds will switch the unit into battery mode for a period of 30 minutes.
• Pressing the test button 4 times within 2 seconds will switch the unit into battery mode for a period of 90 minutes.
RESET – Pressing and holding the test button for 2 seconds will reset the LED to a steady green. If multiple faults are
present, it may be necessary to repeat this procedure for each remaining fault indicated by the blinking red LED.
Use in accordance with local building codes.
Red LED Indication
Blinking 1 Time
Blinking 2 Times
Blinking 3 Times
Blinking 4 Times
Blinking 5 Times
Blinking 6 Times
Blinking 7 Times
Unit Fault
Battery is Disconnected
Battery Failure
Charger Board Circuit Fault
Transfer Function Failure
Emergency Lamp Fault
Remote Lamp (If Equipped)
EXIT Lamp Fault
Corrective Action
Check Battery Connection
Check Battery Then Consult Factory
Check Battery Then Consult Factory
Check Battery Then Consult Factory
Check Lamp Connections Then Consult Factory
Check Remote Lamp Connections Then Consult Factory
Check Battery Then Consult Factory
