LUMENWERX MIKRO User manual

Prepare the area where the fixture is going to be
installed. Cut hole in the drywall according to the
dimensions [*]given in the client drawings.
If the fixture position need adjustments, remove
screws (G) on one side of the fixture and adjust it.
Reinstall the screws once the position is settled.
Make sure that the lens (A) is installed on the fixture
and protected by a lens cover.
Fasten drywall screws (F) through the obround
holes of the flanges (G).
Unscrew and remove the power plate. Install power
cable (B) through the connector (C) and install
onto the power plate (D) provided. Make electrical
connections between power cable (B) and fixture
cables using electrical marettes (E). Push wires
inside the fixtures and reinstall the power plate (D)
to the fixture.
To reinforce the screws (F) that maintain the fixture
in the drywall, wood blocking (H) or drywall anchors
(I) must be used.
*
*
SINGLE FIXTURE
B
I
H
F
G
F
F
B
C
D
E
WWW.LUMENWERX.COM
www.lumenwerx.com (T) 514-225-4304 (F) 514-931-4862 © All rights are reserved to LumenWerx ULC. FILE NAME:MIKRO-DRYWALL-MUD-FLANGE-INST November 12, 2019 Page: 1 / 3
LumenWerx ULC. reserves the right to change or modify product specifications without notification
DRYWALL MUD FLANGE - INSTALLATION INSTRUCTIONS
MIKRO
NOTE: Wire dimming conductors as Class 1
1
4
23
5

I
H
F
Plaster and sand over mud flange (G) to create a
smooth finish.
For a continuous system, follow steps 1 to 5 for the
first fixture (J) in the run.
Make the wire connection between the first two
sections (J) and (K) using wire connectors (L). Insert
the second section (K) into the drywall hole.
Once the mud is totally dry and painted, remove
gently the lens cover.
G
KK
JJ
J
M
CONTINUOUS SYSTEM
Slide the fixtures (J) and (K) together. Attach the two
fixtures by fastening screws on the joiners (M).
L
Fasten fixture to the ceiling by fastenning drywall
screws (F) through flanges into anchors (I) of wood
blocking (H).
WWW.LUMENWERX.COM
6
9
7
10
8
11
www.lumenwerx.com (T) 514-225-4304 (F) 514-931-4862 © All rights are reserved to LumenWerx ULC. FILE NAME:MIKRO-DRYWALL-MUD-FLANGE-INST November 12, 2019 Page: 2 / 3
LumenWerx ULC. reserves the right to change or modify product specifications without notification
DRYWALL MUD FLANGE - INSTALLATION INSTRUCTIONS
MIKRO

M
Once the fixtures are attached to the ceiling, remove
the joiners (M).
Plaster and sand over mud flange (G) to create a
smooth finish.
Once the mud is totally dry and painted, remove
gently the lens cover.
G
WWW.LUMENWERX.COM
12 13 14
www.lumenwerx.com (T) 514-225-4304 (F) 514-931-4862 © All rights are reserved to LumenWerx ULC. FILE NAME:MIKRO-DRYWALL-MUD-FLANGE-INST November 12, 2019 Page: 3 / 3
LumenWerx ULC. reserves the right to change or modify product specifications without notification
DRYWALL MUD FLANGE - INSTALLATION INSTRUCTIONS
MIKRO
