Digimerge DCS100033 User manual

010101111010011000 001010011000100101110001001011000111010101111010011000 0010100110001001011100010010110001110101011
Digimerge’s new DCS100033 is your choice of Day / Night
surveillance camera. The camera produces high quality
images regardless of lighting conditions, and OSD (On Screen
Display) consists of main and special modes with privacy &
motion detection, sharpness control, and DNR (Digital Noise
Reduction) mode as standard features. DCS100033 is also
cost-effective with quality, performance, and functions you have
been looking for.
High Resolution Color Digital
Day/Night Professional Camera
DCS100033
www.digimerge.com
Features:
Ultra High Resolution (540 TV Lines)
DAY & NIGHT: Automatically selects the mode that is
appropriate for daytime or night-time conditions.
High Sensitivity: The built-in high sensitivity SONY COLOR
CCD produces clear images even in extremely low light
conditions. 0.3Lux (0.1Lux B/W) and 0.002 Lux with
SENS-UP enabled.
DNR (Digital Noise Reduction): Reduced noise coupled
with improved signal-to-noise ratio (S/N ratio) provides
a sharper, clearer image display even in the low light
conditions. Eliminating the noise also reduces image sizes
(when recording onto a hard drive) by up to 30%.
Electronic IRIS: The electronic IRIS function enables
continuous automatic control of the shutter between
1/60~1/120,000 seconds.
PRIVACY Function: The PRIVACY function conceals the
areas you do not wish to appear on the screen.
ß
ß
ß
ß
ß
ß

Digimerge Technologies Inc.
300 Alden Road, Markham, ON Canada L3R 4C1
Tel: [phone] Fax: [phone]
Because our products are subject to continuous
improvement, Digimerge reserves the right to
modify product design and specifications without
notice and without incurring any obligation. E&O.E.
®
Specifications:
480 TV lines
530 TV lines
480 TV lines
530 TV lines
540 TV Lines
The DCS100033 is packed with Digimerge’s latest CCTV technologies.
Using high performance image sensor, and new DSP chip, DCS100033
will capture 540 TV lines of high resolution images even under severe
lighting conditions.
480 TV lines
530 TV lines
480 TV lines
530 TV lines
Conventional Camera DCS100033
Max 70% Disk Saving Effect
Under low light environments, DNR reduces significant amount of random
and fixed noise, produces a high signal to noise ratio, and prevents ghost
effects at the same time. As a result, images are sharp and clear-suitable
for identification purposes. Additionally, file sizes are reduced by 40%
using JPEG format and by 70% using MPEG format.
Day Night
Day & Night Capability
480 TV lines
530 TV lines
480 TV lines
530 TV lines
480 TV lines
530 TV lines
Motion
Detection
Motion Detection & Privacy Masking
The DCS100033 ensures high resolution color images down to 0.3 Lux
@ F1.2 in daytime. The camera switches to monochrome mode when the
light level falls below the range of color image processing. The sensitivity
of camera can reach 0.002 Lux for excellent low light operation with
Sense-Up function.
Conventional Camera DCS100033
This camera is capable of
detecting moving objects
in the scene.
DCS100033 can mask the
captured image in four different
zones in the scene. The size
of privacy zone can also be
adjusted.
Power Source AC24V / DC12V
170mA(AC24V)/260mA(DC12V)
Total Pixels 811(H) x 508(V)
Effective Pixels 768(H) x 494(V)
Size 1/ 3 inch interline transfer CCD
Scanning System 2:1 Interlace
Synchronization INT/LL Selectable 0~359°(Adjustable)
Frequency Horizontal:15.734 KHz Vertical :59.94 Hz
Resolution 540 TV Lines
Video Output 1.0Vp-p/75(Video 0.714Vp-p Sync 0.286Vp-p)
S/N (Y signal) 50dB (AGC Off)
Min. Illumination 0.3Lux/F1.2(Color), 0.1Lux/F1.2(B/W),
0.002Lux(Sens-up)
COLOR ON / AUTO
Gain Control OFF / LOW / MIDDLE / HIGH
White Balance ATW / AWC / MANUAL(1,800°K~10,500°K)
Electronic shutter speed AUTO / MANUAL(1/60~1/120,000)
Sens-Up OFF / AUTO
O.S.D Built-in
Motion Detection ON / OFF (4 Programmable Zone)
DNR OFF / LOW / MIDDLE / HIGH(Noise Reduction)
MIRROR OFF/ON (Horizontal Image Inversion)
Privacy Function ON / OFF (4 Programmable Zone)
IRIS Control DC / VIDEO
Lens Mount C/CS Mount (Screw Lock)
Operating temperature/Humidity -10°C ~ +50°C (14°F ~ 122°F ) / 30~90% RH
Weight 360g/0.75 lbs
Dimensions:
2.75in/
70mm
2.75in/
70mm
5in/127mm
2-18122006
