This installation guide provides instructions for installing the Digimerge
DNP5320E High Resolution PoE Dual-Codec Professional Outdoor Day/
Night Network Camera on your network. For all other aspects of using the
product, please refer to the user manual available at www.digimerge.com
or on the Installation CD included with this product.
• 1 x High Resolution PoE Dual-Codec Professional Outdoor Day/Night Network Camera
• 1 x DC Power Cable (Optional Use)
• 1 x Professional Stand with Cable Guide for Wall Mounting (with Mounting Hardware)
• 1 x GPIO Connector Cable
• 1 x Quick Installation Guide
• 1 x Installation CD with manuals and software
• 1 x Warranty Card
PACKAGE CONTENTS
Package Contents:
IMPORTANT!
This product must be installed in compliance with local laws and regulations.
4 Back Plate Screws
GPIO PORT (Optional)
Ethernet Port
Power
Network/Power LED Indicators
7 IR LEDs
Lens
Camera DC Power Cable Wall Mount Bracket
GPIO Connector Quick Start
Guide
Installation
CD

DNP5320E_Quick Installation Guide_En_R1
www.digimerge.com
Page 3
Hardware Installation - PoE Enabled Install
This camera is PoE enabled (built-in). The Ethernet
Cable provides both Network Connectivity and Power
if you use this installation option (PoE equipment will
be needed. See page 16 for details).
1. Mounting Instructions: Run the Ethernet cable to
the desired location.
• Mount the stand to the wall or Ceiling using the
provided screws.
• Securely connect the camera to the stand, and
set the desired angle.
2. Network: Connect the network cable to the
Camera Ethernet Cable (Port).
NOTE: CAT-5 Ethernet Cabling has a maximum
effective range of 100m (330 ft.) depending on the
cable/switcher quality. For a longer run, a repeater
device may be required.
Hardware installation:
A. PoE Enabled Install
B. AC Powered Install
C. Optional Connections
HARDWARE CONNECTIONS
1
A
1
2
OPTION 1
OR
These cables should be protected, as they
are not rated for outdoor use. Alternatively,
a weatherproof Ethernet cable can be
connected internally.

Page 4
www.digimerge.com
DNP5320E_Quick Installation Guide_En_R1
HARDWARE CONNECTIONS
1
Continued
Hardware Installation - AC Powered Install
The Hardware installation (using 12V DC
Power) consists of removing the back plate and
installing cables to the Camera.
1. Remove the Back Plate: Once the plate is
removed, access to additional ports and AC
power becomes available:
B
1C
2
C. The back plate can now be removed. Do not
disconnect the cable from the cooling fan.
2. Power: Connect the DC power cable to
the Camera Power port, located to the right
of the Ethernet Port.
To use an external power source, the other end of
the power cable will need to be stripped so it can
be run through the Waterproof cable screw.
Hardwire the camera to the power source.
3. Once the stripped end of the DC power cable is
run through the waterproof cable screw, secure the
waterproof cable screws and then reattach the
backplate securely. If adding optional connections,
skip this step and proceed to the next page.
B. Unscrew the 2 waterproof cable screws on
the bottom of the camera.
A. Use a phillips screwdriver to loosen the 4
corner screws on the back plate.
OPTION 2
1B
1A

DNP5320E_Quick Installation Guide_En_R1
www.digimerge.com
Page 5
Hardware Installation - Optional Connections
The Optional Connection includes the use of the
GPIO Connector Cable for Alarm and/or PTZ
Control.
1. Connect the GPIO Connector Cable to the
GPIO Port located to the left of the Ethernet
Cable Connection. Run it through the
waterproof cable screw that is not used by the
Ethernet cable.
The exposed GPIO wires are color coded.
Please see Hardware Manual Appendix #2 for
Alarm Block connections.
HARDWARE CONNECTIONS
1
C
1
Continued
1
2
2. Once all wires have passed through the
opening, tighten the screw to hold the wires
securely in place. This will also provide a water
tight seal, preventing moisture from entering the
camera through the cable opening.
3. Replace the back panel, and tighten the 4
securing screws.
Replacing the Backplate & Waterproof Sealing
Screws
1. Reconnect the Waterproof screw. All connected
wires will need to pass through the opening in
this screw.
NOTE: The waterproof cable screw used to run the
Ethernet cable through does not offer extra space,
therefore any other connections should go through
the 2nd waterproof cable screw.

Page 6
www.digimerge.com
DNP5320E_Quick Installation Guide_En_R1
SOFTWARE INSTALLATION
2
The Digiconsole application loads
from the CD included with your
package, and provides you with the
following:
1. Web links to various resources
and documentation
2. Discovery of all the Digimerge
IP devices on the network
3. Provides Network
configuration of IP Devices
4. Installs DigiConsole and
Surveillance application on your
local PC
5. Warranty information and DDNS
registration
A
Digiconsole Utility screen consists of
the following menus:
1. Home
2. Find Devices
3. Register
4. Install
B

DNP5320E_Quick Installation Guide_En_R1
www.digimerge.com
Page 7
Home:
Provides basic Digiconsole operating
instructions, links to product informa-
tion/documentation as well as 3rd party
software support links.
SOFTWARE SET-UP
A
Find Devices:
Locates all available Digimerge IP
devices on your network and displays
a snapshot of the results. Click on any
available device to display image on
the right side screen display.
NOTE: You may need to press the Find
Devices button several times as some
devices may not respond immediately.
If you do not see a camera image,
please check that all cables running
from the Camera are connected
properly.
B
C
Menu:
The Menu Button or right clicking on
a device icon provides access to
device specific settings:
• Edit Network Parameters
• View Live Image
• Open Device in Browser
• Update Firmware in Video Device
• Refresh the device list - in order to
remove inactive and disconnected
devices
NOTE: It is recommended that you
record the device specific MAC and
IP address for DDNS registration
purposes. If you have multiple
cameras on a local network, only
one camera needs to be configured
for DDNS.
3
MAC:
IP:

Page 8
www.digimerge.com
DNP5320E_Quick Installation Guide_En_R1
SOFTWARE SET-UP
Edit Network Parameters:
The Network Parameters are
automatically assigned to the
Device by the network router (by
using DHCP). These settings can
be manually changed if desired.
1. Select the IP device you would
like to edit by clicking on its icon.
2. Click on the MENU button or
right click the icon for the device
to access the menu. Select
“Edit Network Parameters” from
the menu.
3. Make the necessary changes
and click OK to save changes or
click CANCEL to close the
window without saving any of the
changes made.
NOTE: If a user name and password
were set-up on the IP Device previ-
ously, you will be required to enter
this authentication information when
attempting to access the device.
C1
Continued
View Live Image:
View live video from the IP Device
using the Apple Quicktime program.
If this application is not installed on
your system, please download it (no
charge) at
http://www.apple.com/quicktime
C2
3
OPTIONAL
If by clicking VIEWING LIVE IMAGE
the image is not automatically shown
in Quicktime, follow these steps in
Quicktime:
1. Go to FILE
2. Choose OPEN URL
3. Enter the following: rtsp://<device
IP address> (i.e. rtsp://192.168.2.102)
A device IP address can be obtained
from the Digiconsole device list.
NOTE: Minimum Quicktime version installed
should be 7.1.6. If you cannot install Quick-
time, use Microsoft Internet Explorer to view
the device. See step C3 for details.

DNP5320E_Quick Installation Guide_En_R1
www.digimerge.com
Page 9
SOFTWARE SET-UP
Continued
Open Device in Browser:
Opens up the DigiViewer Video Browser
using your default web browser (e.g.
Internet Explorer).
The DigiViewer browser allows the user
to view streaming video from the device
as well as change certain settings on the
device depending on the level of access
set by the administrator.
C3
3
Once user names and passwords are set
up by the administrator, the users (except
for a VIEWER level user) are required to
enter this information every time they ac-
cess the DigiViewer.
Click (during streaming mode)
to mute the audio.
Click to capture a snapshot image
in a new browser window.
By default, the image refresh rate
is set to OFF. Move slider to the
right to set image refresh rate.
Click to bring up image brightness and contrast controls
Click to capture a video clip and send it to a FTP site. FTP
must be configured in the SETTINGS screen
Click here to start streaming video

Page 10
www.digimerge.com
DNP5320E_Quick Installation Guide_En_R1
SOFTWARE SET-UP
3 Levels of User Access:
• Administrator (current user)
• Operator (general user)
Default User Name: guest
Password:<leave blank>
• Viewer (anonymous guest)
Creating Current User Account:
1. Click SETTINGS
2. Select ACCOUNTS
3. Fill in a user name and
password in the assigned fields
4. Reconfirm password
5. Click UPDATE ACCOUNTS
1. Administrator: Administrator has
unrestricted access to all the
settings of the device. The
interface will only permit creation
of ONE administrator account.
2. Operator: Operator has restricted
access to the settings of the
server. The interface will only
permit creation of FIVE operator
accounts.
Note: Restrictions - View images.
Requires username and password.
3. Viewer: The interface will permit
the creation of ONE viewer
account (i.e. Anonymous Guest).
This account does not require a
password.
Note: Viewer Restrictions - View im-
ages if permission is granted by ad-
ministrator. Note that the permission
in this case refers to providing the
IP address to someone. Whomever
receives the IP address can view the
camera remotely as a anonymous
guest. No password is required.
Multiple users can access the de-
vice at the same time, however this
will limit the quality and speed of the
video as the feed is shared between
all connected users.
Continued
3
