Contents
1 Options You Can Upgrade
Overview ................................................. 1–1
Chapter Overview ....................................... 1–1
Purpose of Manual ....................................... 1–1
Options You Can Upgrade . ................................... 1–2
Internal/External Options ................................. 1–2
External Options ........................................ 1–5
Warning ............................................... 1–8
Mounting Bracket ....................................... 1–8
What to Read Next ......................................... 1–8
Using This Manual . . . ................................... 1–8
2 Upgrading a VAXstation 4000 Model 60/90/90A
Topics Covered in This Chapter . . ........................... 2–1
Upgrade Procedure ......................................... 2–1
Step 1: If Your System Has Factory-Installed Drives . . .......... 2–1
Step 2: Shut Down System ................................ 2–3
Step 3: Disconnect Cables ................................. 2–3
Step 4: Remove System Cover . . . ........................... 2–3
Step 5: Remove H-Bracket................................. 2–4
Step 6: Remove Drives from the H-Bracket . ................... 2–5
Step 7: Remove SPXgt Graphics Module . . . ................... 2–6
Step 8: Remove Removable-Media Bracket . ................... 2–8
Step 9: Remove Drive from Bracket.......................... 2–9
Step 10: Set SCSI IDs on Drives . ........................... 2–10
Step 11: Install New Mounting Brackets . . . ................... 2–10
Note: Other Accessory Kit Brackets ......................... 2–11
Step 12: Complete the Upgrade . . ........................... 2–11
Step 13: Return Your VAXstation to Digital ................... 2–11
iii

3 Upgrading a DECstation 5000 Model 120/125/133/150
Topics Covered in This Chapter ............................. 3–1
Upgrade Procedure . ........................................ 3–1
Step 1: If Your System Has Factory-Installed Drives ............ 3–1
Step 2: Shut Down System ................................ 3–2
Step 3: Disconnect Cables . ................................ 3–2
Step 4: Remove System Cover .............................. 3–2
Step 5: Remove Front Drive Panel . . ........................ 3–4
Step 6: Remove Removable Media Drives ..................... 3–5
Step 7: Remove Fixed Disk Drives. . . ........................ 3–5
Step 8: Remove Modules . . ................................ 3–6
Step 9: Set the SCSI IDs on the Drives ....................... 3–7
Step 10: Install New Mounting Bracket ...................... 3–7
Step 11: Complete the Upgrade ............................. 3–7
Step 12: Return Your DECstation to Digital . . . ................ 3–8
4 Upgrading a DECstation 5000 Model 200/240/260
Topics Covered in This Chapter ............................. 4–1
Upgrade Procedure . ........................................ 4–2
Step 1: If Your System Has Factory-Installed Drives ............ 4–2
Step 2: Shut Down System ................................ 4–2
Step 3: Disconnect Cables . ................................ 4–3
Step 4: Remove System Cover .............................. 4–3
Step 5: Remove Option Modules ............................ 4–4
Step 6: Set the SCSI IDs on the Drives ....................... 4–5
Step 7: Complete the Upgrade .............................. 4–5
Step 8: Return Your DECstation to Digital .................... 4–5
5 Upgrading a DEC 3000 Model 400 AXP
Topics Covered in This Chapter ............................. 5–1
Upgrade Procedure . ........................................ 5–1
Step 1: Removing Options . ................................ 5–1
Mounting Brackets for Drives .............................. 5–1
Step 2: Set SCSI IDs on Drives ............................. 5–1
Step 3: Complete the Upgrade .............................. 5–2
Step 4: Return Your System to Digital ....................... 5–2
Step 5: Service Contract . . ................................ 5–2
iv

A SCSI ID Settings for Drives
Setting a Unique SCSI Address ................................ A–1
Selecting SCSI ADDRESS ................................. A–1
Changing the Setting . . ................................... A–2
Setting the Unit Select Switch . . . ........................... A–7
Remote SCSI Address Jumpers . . ........................... A–13
Figures
1–1 Upgrade Kit Contents . . . ........................... 1–7
2–1 SPXgt 24-Plane Graphics Module . . ................... 2–6
2–2 Removing the SPXgt 24-Plane Graphics Module .......... 2–7
A–1 TZK10/11 Tape Drive SCSI ID Settings ................. A–3
A–2 RRD42 Compact Disk Drive SCSI ID Settings . . .......... A–4
A–3 RRD43 Compact Disk Drive SCSI ID Settings . . .......... A–5
A–4 RX26 Diskette Drive SCSI ID Settings ................. A–6
A–5 RX26 Unit Select Switch . ........................... A–7
A–6 TZ30 SCSI Switches................................ A–8
A–7 TLZ06 Tape Drive SCSI ID Settings ................... A–9
A–8 RZ23L Fixed Disk Drive SCSI Settings ................. A–10
A–9 RZ24L/24 Fixed Disk Drive SCSI Settings ............... A–11
A–10 RZ25 Fixed Disk Drive SCSI Settings .................. A–12
A–11 RZ25 Secondary SCSI Address Port . ................... A–13
A–12 RZ25L Fixed Disk Drive SCSI Settings ................. A–14
A–13 RZ26 Fixed Disk Drive SCSI Settings .................. A–15
A–14 RZ26B Fixed Disk Drive SCSI Settings ................. A–16
A–15 RZ26L Fixed Disk Drive SCSI Settings ................. A–17
A–16 RZ28 Fixed Disk Drive SCSI Settings .................. A–18
A–17 RZ28B Fixed Disk Drive SCSI Settings ................. A–19
v

1
Options You Can Upgrade
Overview
Chapter
Overview This chapter contains the following topics:
• Options You Can Upgrade
• Upgrade kit contents
• Using the Manual
Purpose of
Manual The purpose of this guide is to tell customers and Digital
Services which options can be removed from the current system
and used, either internally or externally, in the DEC 3000 Model
700. Step-by-step instructions are provided for removing the
options.
Options You Can Upgrade 1–1

Options You Can Upgrade
Options You Can Upgrade
Internal/External
Options Options that are supported internally or externally on the DEC
3000 Model 700 are listed in the following tables:
Fixed Disk Drives Comment
RZ23L
RZ24L
RZ24
RZ25
RZ25L
RZ26
RZ26B OpenVMS support only
RZ26L
RZ28
RZ28B
Removable-Media
Drives Comment
RRD42 Including tabletop device
RRD43 Including tabletop device
TLZ06 Including tabletop device
TZK10
TZK11
RX26
TZ30
1–2 Options You Can Upgrade

Options You Can Upgrade
TURBOchannel
Options Comment
DEFTA–FA
Graphics Modules Comment
PMAGB–BA/BB
PMAGB–BC/BD
PMAGB–BE/BF
PMAGB–JA/JB OSF/1 AXP support only
PMAGB–DA/DB DEC Open3D required for software support
PMAGB–DC/DD DEC Open3D required for software support
PMAGB–EA/EB DEC Open3D required for software support
PMAGB–EC/ED DEC Open3D required for software support
PMAGB–FA/FB DEC Open3D required for software support
PMAG–DB/DA
PMAG–EA/EB
PMAG–FA/FB
PMAGC–AA
PMAGC–BA
PMAGD–AA
PMAGD–BA
PMAGD–CA
AV300–AA
PEXGA–AA OSF/1.3 AXP support and KWS 1.3 required
PEXGA–BA OSF/1.3 AXP support and KWS 1.3 required
PEXGA–CA OSF/1.3 AXP support and KWS 1.3 required
PEXGA–AB OSF/1.3 AXP support and KWS 1.3 required
PEXGA–AC OSF/1.3 AXP support and KWS 1.3 required
Options You Can Upgrade 1–3

Options You Can Upgrade
Memory Comment
MS15–BA
MS15–CA
MS15–DA
MS15–EA
MS15–FA
1–4 Options You Can Upgrade

Options You Can Upgrade
External
Options Options that are supported externally on the DEC 3000 Model
700 are listed in the following tables:
Expansion Boxes Comment
BA350
BA353
SZ03
SZ12
SZ16
Disk/Tape Drives Comment
TZ85
TZ86
TZ87
TZ857 Requires DEC NSR for OSF/1 support
TZ867 Requires DEC NSR for OSF/1 support
TZ875 Requires DEC NSR for OSF/1 support
TZ877 Requires DEC NSR for OSF/1 support
RZ55
RZ56
RZ57 Requires firmware update 6000
RZ58
RZ73
RZ74
TSZ07
TLZ04
RWZ01 OpenVMS support only
RX23 OSF/1 support only
TKZ08 OSF/1 support only
TKZ09
TKZ60
Options You Can Upgrade 1–5

Options You Can Upgrade
Monitors Comment
VRC21–H%
VR319–CA Appropriate 66 Hz graphics option required
VR319–DA
VR320–CA Appropriate 66 Hz graphics option required
VR320–DA
VRC16–H%
VRM17–A%
VRM17–H%
VRT16–H%
VRT19–DA Appropriate 66 Hz graphics option required
VRT19–H%
Input Devices Comment
VSXXX–AB
VSXXX–FA
VSXXX–AA
VSXXX–JA
VSXXX–GA
LK401/201
VSX10–AA/A3 DEC Open3D required for software support
VSX20–AA/A3 DEC Open3D required for software support
VSX30–AA/A3 DEC Open3D required for software support
1–6 Options You Can Upgrade

Options You Can Upgrade
Figure 1–1 Upgrade Kit Contents
Monitor
Video Cable
Antistatic
Wrist Strap
Monitor
Power Cord
System Power
Cord
Screwdriver
System Unit
Documentation
Modem Loopback
Connector
Universal
Strain Relief
Strap
Keyboard/Mouse
Extension Cable
Accessory Kit:
Monitor*
Keyboard*
System Kit:
Mouse with
Mousepad*
Ethernet Loopback
Connector
SCSI
Terminator Printer Port
Terminator
Network
Label
xxxxxxx
xxxxxxxxxxx
xxx
Upgrade
Guide
Return Address Label
Rubber
Grommets
TZ30 RFI
Shield
RX26 Brackets
Metal Support
Plate
RX26 Bezel
Screws
*included in some configurations MLO-012114
Options You Can Upgrade 1–7

Options You Can Upgrade
Warning Attach an antistatic wrist strap before you begin this upgrade.
As you remove options from your system, place them on an
antistatic mat.
Static discharge can cause irreparable damage to options
modules.
Mounting
Bracket If you are upgrading a disk drive from a VAXstation 4000 Model
60/90/90A, a DECstation 5000 Model 120/125/133/150, or a
DECstation 5000 Model 200/240/260 to a DEC 3000 system, you
must attach a mounting bracket provided in the accessory kit to
each drive before installing it into your new system.
If you are upgrading a disk drive from a DEC 3000 Model 400
AXP, the correct mounting bracket is already attached.
What to Read Next
Using This
Manual Use the following table to determine which upgrade procedure to
use.
If you have this workstation... Go to...
VAXstation 4000-60/90/90A Chapter 2
DECstation 5000-120/125/133/150 Chapter 3
DECstation 5000-200/240/260 Chapter 4
DEC 3000-400 Chapter 5
1–8 Options You Can Upgrade

2
Upgrading a VAXstation 4000 Model
60/90/90A
Topics Covered
in This Chapter • Upgrading your system
• Removing drives
• Completing the upgrade
Upgrade Procedure
Step 1: If Your
System Has
Factory-Installed
Drives
If your DEC 3000 system has factory-installed drives, you may
need to change the SCSI IDs on the drives you are upgrading.
To determine the SCSI ID settings on your drives:
1. Shut down your software following the instructions in your
software documentation.
2. Put the VAXstation into console mode by pressing the halt
button located behind the door on the front of the system
unit.
Upgrading a VAXstation 4000 Model 60/90/90A 2–1

Upgrade Procedure
3. Enter the SHOW CONFIG command.
A screen similar to the following appears:
>>> show config
KN4n-A Vn.n
08-00-2B-OA-7D-CB
32 MB
DEVNBR DEVNAM INFO
--------------------------------------
1 NVR OK
2 LCSPX OK
.
.
10 SCSI 0-RZ24 3-RZ25
This information shows an RZ24 drive set to SCSI ID 0 and an
RZ25 drive set to SCSI ID 3.
Write down your system drives and SCSI ID settings here. You
will need them for future use.
2–2 Upgrading a VAXstation 4000 Model 60/90/90A

Upgrade Procedure
Step 2: Shut
Down System Turn off the system unit by pressing 0 on the On/Off switch on
the front of the system unit.
Caution: After you turn off the system, wait 15 seconds before
unplugging the power cord.
Step 3:
Disconnect
Cables
Disconnect all cables from the rear of the system unit.
Disconnect the power cord from the wall outlet and then
from the system unit.
Step 4:
Remove
System Cover
Release the latches on the right side. Then pull the cover up and
away. You need to pull forcefully to release the retention devices.
MLO-010581
Latches
Retention
Devices
Upgrading a VAXstation 4000 Model 60/90/90A 2–3

Upgrade Procedure
Step 5:
Remove
H-Bracket
To remove the H-bracket from the VAXstation system unit:
1. Push in on the cantilever catch on the bracket (as shown)
and lift the bracket straight up with the strap handle.
Touch here
Masse
Toque aqui
Hier beruhren
MLO-010582
2. Disconnect the SCSI and power cables from the drives in the
bracket.
2–4 Upgrading a VAXstation 4000 Model 60/90/90A

Upgrade Procedure
Step 6:
Remove Drives
from the
H-Bracket
To remove a drive from the H-bracket:
1. Press down on the latch on the front of the bracket.
2. Slide the drive forward until you can pull it up and out of
the bracket.
Latch
MLO-010583
3. Set the drive aside on an antistatic mat.
Upgrading a VAXstation 4000 Model 60/90/90A 2–5

Upgrade Procedure
Step 7:
Remove SPXgt
Graphics
Module
If your system has an SPXgt graphics module, you must remove
it before you can remove the removable-media device from the
system unit. If you do not have an SPXgt graphics module, go to
step 8.
Figure 2–1 SPXgt 24-Plane Graphics Module
MLO-012647
RFI Gasket
To remove the graphics module:
1. Remove the plastic E-clip ! that holds the graphics module
to the frame buffer. (See Figure 2–2.)
2. Lift the frame buffer from the center connector " , then free
it from the ridge # on the disk drive H-bracket. Gently work
the frame buffer free by pulling up from the center of the
module.
3. Pull the frame buffer out of the RFI gasket (shown in
Figure 2–1). The gasket will remain in place, held by the
video connector bracket on the graphics module.
2–6 Upgrading a VAXstation 4000 Model 60/90/90A
