Digital Equipment DECsystem 5500 Instruction Manual

DECsystem 5500
Operation
Order Number EK–332AA–OP–001
Digital Equipment Corporation
Maynard, Massachusetts

First Printing, August 1990
The information in this document is subject to change without notice and should not be
construed as a commitment by Digital Equipment Corporation.
Digital Equipment Corporation assumes no responsibility for any errors that may appear in
this document.
The software, if any, described in this document is furnished under a license and may be used
or copied only in accordance with the terms of such license. No responsibility is assumed
for the use or reliability of software or equipment that is not supplied by Digital Equipment
Corporation or its affiliated companies.
Restricted Rights: Use, duplication or disclosure by the U.S. Government is subject to
restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer
Software clause at DFARS 252.227–7013.
© Digital Equipment Corporation 1990
All rights reserved. Printed in U.S.A.
The Reader’s Comments form at the end of this document requests your critical evaluation to
assist in preparing future documentation.
The following are trademarks of Digital Equipment Corporation.
CompacTape
DDCMP
DEC
DECdirect
DECnet
DECserver
DECsystem 5500
DECUS
DECwriter
DELNI
DELQA
DEQNA
DESTA
DSSI
IVIS
MicroVAX
PDP
Professional
Q-bus
ReGIS
RQDX
ThinWire
ULTRIX
UNIBUS
VAX
VAX 4000
VAXcluster
VAX DOCUMENT
VAXELN
VAXlab
VMS
VT
the DIGITAL Logo
Prestoserve is a trademark of Legato Systems, Inc.
X Window System is a trademark of Massachusetts Institute of Technology.
FCC NOTICE: The equipment described in this manual generates, uses, and may emit radio
frequency energy. The equipment has been type tested and found to comply with the limits for
a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed
to provide reasonable protection against such radio frequency interference when operated in
a commercial environment. Operation of this equipment in a residential area may cause
interference, in which case the user at his own expense may be required to take measures to
correct the interference.
S1298
This document was prepared using VAX DOCUMENT, Version 1.2.

Contents
Preface ix
Chapter 1 System Overview
1.1 Front View and Physical Description . . . . . . . . . . . . . . . . . . . 1–2
1.1.1 The BA430 Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
1.1.1.1 Mass Storage Shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8
1.1.1.2 CardCage ................................... 1–9
1.1.1.3 CPU Cover Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–11
1.1.1.4 DSSI and SCSI Connectors . . . . . . . . . . . . . . . . . . . . . . 1–14
1.1.1.5 Power Supply Controls and Indicators . . . . . . . . . . . . . . 1–14
1.1.1.6 Fans........................................ 1–17
1.2 Functional Description of Base System . . . . . . . . . . . . . . . . . 1–18
1.2.1 Base System Components . . . . . . . . . . . . . . . . . . . . . . . . . 1–18
1.2.1.1 Central Processing Unit (CPU) . . . . . . . . . . . . . . . . . . . 1–19
1.2.1.2 Console Serial Line Unit (SLU) . . . . . . . . . . . . . . . . . . . 1–19
1.2.1.3 MainMemory................................. 1–19
1.2.1.4 Network Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–19
1.2.1.5 Embedded DSSI Adapter . . . . . . . . . . . . . . . . . . . . . . . . 1–20
1.2.1.6 Embedded SCSI Adapter . . . . . . . . . . . . . . . . . . . . . . . . 1–20
1.2.2 Optional Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–20
1.2.2.1 Mass Storage Devices and Controllers . . . . . . . . . . . . . . 1–20
1.2.2.2 Mass Storage Subsystems . . . . . . . . . . . . . . . . . . . . . . . 1–21
1.2.2.3 Mass Storage and Q-bus Expanders . . . . . . . . . . . . . . . . 1–22
1.2.2.4 Communications Controllers . . . . . . . . . . . . . . . . . . . . . 1–22
1.2.2.5 Printer Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–24
1.2.2.6 Other Available Options . . . . . . . . . . . . . . . . . . . . . . . . . 1–24
iii

Chapter 2 Operating the System
2.1 Before You Operate the System . . . . . . . . . . . . . . . . . . . . . . . 2–1
2.2 SwitchSettings ................................... 2–1
2.2.1 Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
2.2.2 Special Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
2.3 Turning On the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–4
2.4 Booting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
2.4.1 Booting the System from Console Mode . . . . . . . . . . . . . . . 2–6
2.4.2 Autobooting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–7
2.5 Using Console Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–8
2.6 UsingtheSystem.................................. 2–10
2.7 Halting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–10
2.8 Restarting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–11
2.9 Turning Off the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–11
2.10 Recovering from an Over Temperature Condition . . . . . . . . . 2–12
2.11 Console Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–12
2.11.1 The boot Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–15
2.11.2 The continue Command . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–17
2.11.3 The d (deposit) Command . . . . . . . . . . . . . . . . . . . . . . . . . 2–17
2.11.4 The dump Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–18
2.11.5 The e (examine) Command . . . . . . . . . . . . . . . . . . . . . . . . . 2–20
2.11.6 The exit Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–21
2.11.7 The fill Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–21
2.11.8 The go Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–22
2.11.9 The help Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–22
2.11.10 The?Command................................. 2–22
2.11.11 The init Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–22
2.11.12 The maint Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–22
2.11.13 The passwd Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–23
2.11.14 The printenv Command . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–24
2.11.15 The setenv Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–26
2.11.16 The show device Command . . . . . . . . . . . . . . . . . . . . . . . . 2–26
2.11.17 The show dssi Command . . . . . . . . . . . . . . . . . . . . . . . . . . 2–27
2.11.18 The show ethernet Command . . . . . . . . . . . . . . . . . . . . . . 2–27
2.11.19 The show scsi Command . . . . . . . . . . . . . . . . . . . . . . . . . . 2–28
2.11.20 The unpriv Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–29
iv

2.11.21 The unsetenv Command . . . . . . . . . . . . . . . . . . . . . . . . . . 2–29
2.12 Control Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–30
Chapter 3 Operating the System Options
3.1 Mass Storage Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1
3.1.1 TK70TapeDrive ................................ 3–2
3.1.1.1 Design of the Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–3
3.1.1.2 Labeling a Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . . 3–4
3.1.1.3 Write-Protecting a Tape Cartridge . . . . . . . . . . . . . . . . . 3–5
3.1.1.4 Tape Cartridge Handling and Storage Guidelines . . . . . 3–7
3.1.1.5 Inserting a Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . . 3–7
3.1.1.6 Removing a Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . 3–10
3.1.1.7 Summary of TK70 Tape Drive Controls and Indicator
Lights....................................... 3–12
3.1.2 TLZ04 Tape Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–13
3.1.2.1 Proper Handling of Cassette Tapes . . . . . . . . . . . . . . . . 3–15
3.1.2.2 Setting the Write-Protect Tab on the Cassette Tape . . . . 3–15
3.1.2.3 Inserting a Cassette Tape into the Drive . . . . . . . . . . . . 3–16
3.1.2.4 System Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–17
3.1.2.5 Cleaning the Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–18
3.1.3 RF/RZ-Series Integrated Storage Elements . . . . . . . . . . . . 3–19
3.1.4 RV20 Optical Disk Subsystem . . . . . . . . . . . . . . . . . . . . . . 3–24
3.1.5 RRD40 Digital Disk Subsystem . . . . . . . . . . . . . . . . . . . . . 3–24
3.1.6 TS05 Tape Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–24
3.1.7 TU81–Plus Tape Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–24
3.2 Communications Controller Options . . . . . . . . . . . . . . . . . . . 3–24
3.2.1 Asynchronous Serial Controllers . . . . . . . . . . . . . . . . . . . . 3–24
3.2.1.1 Without Modem Support . . . . . . . . . . . . . . . . . . . . . . . . 3–25
3.2.1.2 With Modem Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–26
3.2.2 Synchronous Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . 3–27
3.2.3 Network Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–27
3.3 PrinterOptions ................................... 3–28
3.4 AddingOptions ................................... 3–29
v

Appendix A Related Documentation
Glossary
Index
Figures
1–1 DECsystem 5500 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
1–2 KeyPositions..................................... 1–3
1–3 UpperDoorOpened................................ 1–4
1–4 Entire Door Opened . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–5
1–5 Front View of the BA430 Enclosure . . . . . . . . . . . . . . . . . . . . 1–7
1–6 Mass Storage Shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8
1–7 CardCage ....................................... 1–10
1–8 CPUCoverPanel.................................. 1–12
1–9 Connectors for DSSI and SCSI Busses . . . . . . . . . . . . . . . . . . 1–14
1–10 Power Supply Controls and Indicators . . . . . . . . . . . . . . . . . . 1–15
1–11 Sample Power Bus Configuration . . . . . . . . . . . . . . . . . . . . . . 1–17
1–12 System Air Circulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–18
2–1 Language Selection Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–3
2–2 Sample Error Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
2–3 Successful Power-Up to Console Mode . . . . . . . . . . . . . . . . . . 2–6
2–4 Successful Power-Up and Automatic Boot . . . . . . . . . . . . . . . 2–7
3–1 TK70TapeDrive .................................. 3–3
3–2 Labeling a Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–4
3–3 Tape Cartridge Write-Protect Switch . . . . . . . . . . . . . . . . . . . 3–6
3–4 Inserting a Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–9
3–5 Removing a Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . 3–11
3–6 TLZ04TapeDrive ................................. 3–14
3–7 Setting the Write-Protect Tab on the Cassette Tape . . . . . . . . 3–16
3–8 Inserting a Cassette Tape into the Drive . . . . . . . . . . . . . . . . 3–17
3–9 Inserting the Head Cleaning Cassette . . . . . . . . . . . . . . . . . . 3–19
3–10 RF-Series ISE Controls and Indicators . . . . . . . . . . . . . . . . . 3–20
vi

3–11 RZ-Series ISE Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–22
3–12 Inserting Bus Node ID Plugs . . . . . . . . . . . . . . . . . . . . . . . . . 3–23
Tables
2–1 Normal Power-Up Indications . . . . . . . . . . . . . . . . . . . . . . . . 2–4
2–2 Console Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–14
2–3 DeviceNames .................................... 2–15
2–4 Default Environment Variables . . . . . . . . . . . . . . . . . . . . . . . 2–25
2–5 Normal-Mode Control Characters . . . . . . . . . . . . . . . . . . . . . 2–30
3–1 TK70 Tape Drive Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–12
3–2 TK70 Tape Drive Indicator Lights . . . . . . . . . . . . . . . . . . . . . 3–12
3–3 TLZ04 Drive Indicators (Normal Conditions) . . . . . . . . . . . . . 3–14
3–4 TLZ04 Drive Indicators (Abnormal Conditions) . . . . . . . . . . . 3–15
3–5 RF-Series Controls and Indicators . . . . . . . . . . . . . . . . . . . . . 3–21
vii

Preface
This manual describes how to use the DECsystem 5500 system. The
system uses the RISC-based KN220 CPU module set and ULTRIX operating
system. The DECsystem 5500 system is housed in the BA430 pedestal
enclosure.
The manual is structured as follows:
• Chapter 1 provides an overview of the system.
• Chapter 2 describes how to use the system.
• Chapter 3 describes how to use options installed in the system.
• Appendix A lists related documentation.
• A glossary explains key terms.
ix

Conventions
The following conventions are used in this manual:
Convention Meaning
Return A key name is shown enclosed to indicate that you press a named
key on the keyboard.
Ctrl/x A sequence such as Ctrl/x indicates that you must hold down the
key labeled Ctrl while you press another key.
[ ] Arguments enclosed in square brackets are optional.
Italic type Italic type indicates an argument for which you must supply a
value, environment variables, and references to other documents.
bold This bold lowercase type indicates a command name. For
example: The setenv command is described in the next section.
bold user input This bold upper or lowercase type indicates user input. For
example:
Type maint at the console prompt.
or
>>> show device
NOTE Notes provide general information about the current topic.
CAUTION Cautions provide information to prevent damage to equipment
or software. Read these carefully.
WARNING Warnings provide information to prevent personal injury. Read
these carefully.
x

Chapter 1
System Overview
DECsystem 5500 systems house all components in a BA430 enclosure. This
enclosure is a free-standing pedestal that houses the following:
• Card cage
• System controls
• Central processing unit (CPU) module set
• Memory modules
• Communications controller modules
• Tape drive controller module
• Console module
• RF-series or RZ-series Integrated Storage Elements, or both
• TK70 tape drive or TLZ04 tape drive
• Power supply
• Fans
Up to four storage devices in the following combinations can be mounted
inside the BA430 enclosure:
• Four RF-series or RZ-series Integrated Storage Elements (ISEs), or a
combination of both
• One tape device, the TK70 or TLZ04 tape drive, and up to three RF-
series or RZ-series ISEs, or a combination of both
This chapter describes the system components and their functions.
Chapters 2 and 3 describe how to use the system and options.
System Overview 1–1

1.1 Front View and Physical Description
The front of the system has a divided door that restricts access to the system
controls. Figure 1–1 shows the system with the front door closed.
Figure 1–1: DECsystem 5500 System
MLO-004032
A three-position rotary lock allows you to lock both the upper and lower
doors, or to lock just the lower door. Opening the upper door allows you to
access the controls for the storage devices and the System Control Panel
(SCP). Opening the entire door allows you to access all system controls and
cable connections.
Figure 1–2 shows the three key positions and the controls accessible in each
position.
1–2 DECsystem 5500 Operation

Figure 1–2: Key Positions
Tape Drive Controls and
Door Handle
(Both Doors) MLO-004958
Middle Key Position:
No Access to Controls
Bottom Key Position:
Access to Power Switch;
All Controls and Indicators
Top Key Position:
Access to SCP, ISEs, and
Rotary Key Lock
Indicators (Upper Door)
Opening and Closing the Divided Door
The divided door allows you to access the mass storage devices and system
control panel (SCP), while restricting access to the power switch and the
console module. Open and close the door as follows:
1. Insert the key in the lock on the front door. Turn the key to the top
position (Figure 1–3) to open just the upper portion of the door, or to
the bottom position (Figure 1–4) to open the entire door.
With the key in the bottom position, the upper and lower doors will
open together.
2. Swing the door open.
3. To close the door, simply reverse the procedure. When pushing the
doors closed, push gently at the top right of the upper door and the
bottom right of the lower door.
System Overview 1–3

Figure 1–3: Upper Door Opened
MLO-005179
Top Key Position
1–4 DECsystem 5500 Operation

Figure 1–4: Entire Door Opened
MLO-005180
Bottom Key Position
The next section describes the BA430 enclosure, which is exposed when you
open the entire door.
System Overview 1–5

1.1.1 The BA430 Enclosure
Opening the front door enables you to access the components housed in the
BA430 enclosure. Figure 1–5 shows a typical configuration.
The BA430 enclosure can contain the following:
• Mass storage —
• TK70 or TLZ04 tape drive and up to three RF-series or RZ-series
ISEs, or a combination of both
• No tape drive and up to four RF-series or RZ-series ISEs, or a
combination of both
All DECsystem 5500 systems contain the following:
• System Control Panel (SCP)
• Card cage containing modules — CPU, memory, communications
controllers, mass storage controllers
• CPU cover panel
• Power supply
• Fans
1–6 DECsystem 5500 Operation

Figure 1–5: Front View of the BA430 Enclosure
MLO-005181
System Control
Power Supply
Integrated Storage Elements (ISEs)
Card Cage
Tape Drive
Panel (SCP)
CPU Cover Panel
Fans
System Overview 1–7

1.1.1.1 Mass Storage Shelf
The mass storage shelf extends across the top of the enclosure. The shelf
contains a system control panel (SCP), tape device, and up to three RF-
series or RZ-series ISEs (tapeless systems can have up to four ISEs). Each
ISE has its own panel with controls and indicators. Instructions for using
mass storage devices are in Chapter 3. The SCP is to the right of the
storage devices. Figure 1–6 shows the mass storage shelf.
NOTE: RZ-series hard disk drives do not have controls or indicators on
their front panel.
Figure 1–6: Mass Storage Shelf
ISE 2 ISE 1 ISE 0 Tape Drive
MLO-005386
System Control Panel (SCP)
DC OK Indicator
Over Temperature
Warning Indicator
Halt Button
Restart Button
The SCP has two indicators: the DC OK indicator and the Over
Temperature Warning indicator. The green DC OK light indicates that the
power supply voltages are within the correct operating range. If the DC OK
indicator is not lit when the system power is on, refer to the DECsystem
5500 Troubleshooting and Diagnostics manual included in the Customer
Hardware Information Kit.
The red Over Temperature Warning indicator flashes to indicate that the
system’s internal temperature is approaching a level that may cause system
components to overheat. In addition to the flashing Over Temperature
Warning light, an audible alarm also provides warning of a possible over
temperature condition. If the components continue to heat, the system
will automatically shut down to prevent components from being damaged.
Chapter 2 provides instruction for turning on the system after a preventive
shutdown due to overheat conditions.
1–8 DECsystem 5500 Operation

Below the indicators are the Halt and Restart buttons. The Halt button
is a two-position button. When you press the button, the system halts.
A red indicator on the Halt button lights when the button is set to the
in position. Before you can enter console commands, you must press the
Halt button again to return it to the out position. When the Halt button
is returned to the out position, the console mode prompt (>>) is displayed
on the console terminal screen. Now you can enter console commands. If
you inadvertently press the Halt button, enter continue Return to continue.
Chapter 2 describes halting the system in more detail.
CAUTION: Pressing the Halt button halts the system regardless of the
setting of the Function switch on the console module.
Below the Halt button is the Restart button. The Restart button has a
green indicator. When you press the Restart button, the system returns to
a power-up condition and self-tests are run. If the bootmode variable is set
to aand you have assigned a value to the bootpath environment variable,
the system will reboot system software. Chapter 2 contains additional
instructions on restarting your system.
NOTE: The Halt and Restart buttons can be disabled to prevent accidental
activation. Contact your Digital service representative if you want to disable
the controls on the SCP.
1.1.1.2 Card Cage
The modules in your system are mounted in a 12-slot card cage under the
mass storage shelf, as shown in Figure 1–7.
System Overview 1–9

Figure 1–7: Card Cage
MLO-005182
Slots 12 - 1
The central processing unit (CPU) module set is installed in slots 1 and 2
with its associated memory module in slot 3. Additional memory modules
may be installed in slots 4 through 6. Remaining slots are available for
Q-bus option modules.
The number and type of modules installed in your system depend on your
configuration. Each Q-bus slot, even an empty one, is protected by a module
cover. Together the covers form a shield. The purpose of the shield is as
follows:
• To protect external devices from electrical interference generated by the
system
• To protect the system from electrical interference generated by external
devices
• To maintain air flow integrity
CAUTION: Do not operate the system without Digital-supplied module
covers. The covers are required to protect the equipment and to meet
1–10 DECsystem 5500 Operation

international regulatory standards. Do not substitute other module covers
as they may not meet the required specifications.
Operating the system without the module covers has the following
consequences:
• The system may overheat due to improper air circulation.
• The system will not comply with FCC and VDE requirements for
electrostatic shielding and may produce electrical interference that
affects other equipment.
• The system is susceptible to electrical interference or damage from
external sources.
The design of the module covers varies, depending on the type of module
installed in the slot. Modules requiring external cable connections, such as
communications controllers, have recessed covers that are riveted directly
to the module. The recessed module covers allow space for connecting
cables. Modules requiring no external cable connections, such as mass
storage controllers, are covered by flush covers. Empty slots are also
covered by flush covers which may be single or double width. All covers,
except those covering empty slots, have a label identifying the module
installed in the slot.
Cables connecting your system to peripheral devices (such as terminals,
modems, and printers) are attached to communications controllers. Each
cable can contain multiple lines. The cables run under the BA430 enclosure
and out the back or side of the enclosure, where the cables are split into
individual lines. Chapter 3 describes these connections in more detail.
1.1.1.3 CPU Cover Panel
The CPU module set is behind a double-width cover panel that has internal
cable connections to the memory module(s). Figure 1–8 shows the CPU
cover panel.
System Overview 1–11
