Digital Watchdog DWC-V362D User manual

ABOUT MANUAL
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.
Vandal Dome Camera
DWC-V362D
DWC-V362DIR
User Manual
03272012

2
PRECAUTIONS
FCC COMPLIANCE
WARNING : Changes or modifications are not expressly approved by the manufacturer.
Do not open or modify.
Do not open the case except during maintenence and installation,
for it may be dangerous and can cause damages.
Do not put objects into the unit.
Keep metal objects and flammable substances from entering the camera.
It can cause fire, short-circuits, or other damages.
Be careful when handling the unit.
To prevent damages, do not drop the camera or subject it to shock or vibration.
Do not install near electric or magnetic fields.
Protect from humidity and dust.
Protect from high temperature.
Be careful when installing near the ceiling of kitchen or a boiler room,
as the temperature may rise to high levels.
Cleaning :
To remove dirt from the case, moisten a soft cloth with a soft detergent solution and wipe.
Mounting Surface :
The material of the mounting surface must be strong enough to support the camera.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
Provide reasonable protection against harmful interference. when the equipment is
operated in a residential environment. This equipment generates, uses, and radiates
radio frequency energy; and if it is not installed and used in accordance with the
instruction manual, it may cause harmful interference to radio communications.

3
Table of Contents
Introduction
Installation
Camera OSD Menu and Glossary
Troubleshooting
Warranty Information
Specifications
Features
Parts and Descriptions
Dimensions
Included Accessories
Base Installations
Connecting to Monitors
Adjusting the Camera
4
5
6
7
8
9
10
12-15
16
17-18
19
Adjusting the 3-Axis Gimbal 11

4
FEATURES*
DWC-V362D / DWC-V362DIR
Sharp 1/3” CCD
540 TV Lines
2.8 ~ 11mm Varifocal Auto Iris Lens
85ft Range IR with Intelligent Camera Sync [DWC-V362DIR]
Electronic Day and Night
DRC (Dynamic Range Compressor)
HME (Highlight Masking Exposure)
SLC (Side Light Compensation)
AGC / BLC / AWB
Mirror Image Control
Programmable Privacy Zone (4) & Motion Detection
Easy Icon Driven OSD Menu with Built-In Joystick
Auto Sensing 12VDC or 24VAC with Line Lock
Secondary Video-BNC Output
Video Test Output Included
IP66 Certified

5
PART & DESCRIPTIONS*
1Lens
4Upper Case
5Bubble
2Power Input Connctor
12VDC/24VAC Dual Voltage
3Video Output Connector - BNC
6Bubble Rubber
7Mounting Plate
Assemby Screws
9
Bottom Case
10
Control Board
11
Power Board
12
Mounting Screws
13
8Upper Ring
11
10
12
13
3
2
1
6
9
7
8
4
5
NO IR
IR

6
DIMENSIONS IN MILLIMETERS(INCHES)*
See the diagrams below for the exact dimensions for the Surface Mount Housing.
52.2
(2.05”)
96.2
(3.79”)
Ø149.9
(Ø 5.9”)
37.0
(1.46”)
Ø149.9
(Ø 5.9”)
Ø115.0
(Ø 4.53”)
Ø5.0
(Ø 0.2”)
3- Ø4.5
(3- Ø0.18”)

INSTALLATION*
Included with Value Line Vandal Dome Camera
1. User Manual
2. Mounting Template
3. Second Video Jack
4. Four(4) Screw and Four(4) Dry Wall Anchors
5. L-Wrench
12
Ø144.0
Ø5.0
Mounting template
VD101
Ø15.0
34
5
7

8
BASE INSTALLATION*
1. Pull wires through and make connections.
Refer to page 10. Use mounting template to
mount camera with dry wall mounts and wood
screws.
3. Use the joystick to adjust the OSD menu.
See page 13~16 for details.
2. Adjust the camera’s pan,tilt and zoom.
See page 12 for details.
4. Attach the camera housing to the
junction box using the assembly screws.

9
CONNECTING TO MONITORS*
2nd Video Output
Right
Left
Up Down
CCTV Monitor
Monitor
11.8in
12VDC/24VAC
Power connection - 12VDC/24VAC Dual Voltage. (Auto polarity detection and protection)
All camera are equipped with a 2nd video output on the camera Main Board.
NO IR
IR

10
ADJUSTING THE CAMERA*
ZOOM
FOCUS
NO IRIR Zoom:
Focus:
Tele - Wide
Far - Near
Loosen the Zoom & Focus Handles by rotating them counter-clockwise.
1
Adjust the Field of view by moving the handle to the RIGHT(Tele) to zoom in, or to the
LEFT(Wide) to zoom out.
2
Adjust the Focus the same way as described above AFTER the desires Zoom position
is estabilished.
3
Once the desired adjustments have been made, please tighten the handles back by
turning them clockwise.
4

ADJUSTING THE 3-AXIS GIMBAL*
The Gimbal mechanism yields maximum rotation and placement as shown below.
1Rotation 360º
3Panning 360º
2Tilting 60º
11

12
MODULE OSD MENU*
PRIVACY RGB
LENS
E.SHUTTER
BLC
AGC
EXPOSURE
D&N MODE
MASK 1
MASK 2
MASK 3
MASK 4
COLOR SET
DAY&NIGHT
PRIVACY
CAMERA ID
TITLE EDIT
TITLE RESET
TITLE POS.
DPC SET
LANGUAGE
PC CONT.
SETUPSYNC
WB MODE
R-Y GAIN
B-Y GAIN
COLOR
MIRROR
SHARPNESS
GAMMA
SLC
SYNC MODE
HME
DRC
FUNCTION
EXIT
SAVE & EXIT
FACTORY SET
EXIT
ALARM
MOTION

13
MODULE OSD MENU AND GLOSSARY*
EXPOSURE
COLOR
DAY & NIGHT
LENS
E.SHUTTER
BLC
WB MODE
R-Y GAIN
B-Y GAIN
Day & Night Mode
AGC
MANUAL (ELC LEVEL : 0 ~ 100) / DC (DC LEVEL : 0 ~ 31)
1/60 / 1/100FLC / 1/250 ~ 100000 / AUTO
OFF / ON(Set Level 0~255)
BLC (Back Light Compensation)
0 ~ 255
AWC / ATW / MANUAL / PUSH LOCK
0 ~ 255
AUTO / COLOR / BW
COLOR ▬►BW : Switching from COLOR to BW; If the number is higher, the camera will only switch during a super low light condition.
BW ▬►COLOR : Switching from BW to COLOR; This number should be always lower than COLOR to BW
Read Time : time interval to switch from COLOR to BW
COLOR
B&W : (BURST : OFF/ON) When the burst is OFF, the picture will have less noise.
OFF ~ 36dB
AGC (AUTO GAIN CONTROL)

14
MIRROR
SHARPNESS
GAMMA
SLC
HME
DRC
OFF / ON
0 ~ 49
USER / 0.45 / 0.6 / 1.00
OFF / ON (0 ~ 50)
SLC (Side Light Compensation)
OFF / ON (0 ~ 155)
HME (Highlight Masking Exposure)
OFF / ON
DRC (Dynamic Range Compressor)
FUNCTION
ALARM
SET WINDOW
ALL SET (Set the Entire Screen)
ALL CLEAR (Clear the Entire Screen)
SENSITI. (0 ~ 55)
SHOW INDI. (OFF / ICON / TRACE)
DELAY OUT(1 ~ 15)
Motion Alarm Zoom-In Delay
OFF / ON
MOTION

15
MASK 1
MASK 2
MASK 3
MASK 4
OFF / ON
OFF / ON
OFF / ON
OFF / ON
COLOR SET BLACK / GRAY / COLOR 1~ 6
PRIVACY
SYNC MODE
V_PHASE
INTER. / AUTO
0 ~ 199
SYNC
CAMERA ID
TITLE EDIT
TITLE RESET
TITLE POS.
DPC SET
LANGUAGE
EXIT
SAVE & EXIT
FACTORY SET
0 ~ 254
OFF / ON
DPC ( Dead Pixel Cancellation)
English / Chinese
PC CONT. OFF / ON
Exit the menu
Exit the menu and save the setting
Reset the menu setting to factory default
SETUP
EXIT

16
TROUBLESHOOTING
No VIDEO
Out-of-Focus VIDEO
Before sending your camera for repair, check the following or contact our technical specialist.
Check the coaxial cable and make sure it is connected securely.
Check the lens’ iris adjustment at the menu setup of the camera.
Check the power supply and make sure the camera has the proper voltage and current.
Check the clear dome cover and the lens for dirt or fingerprints. Use a soft cloth and gently clean.
Check the lens manual focal and zoom adjustment. Field test monitor is recommended.

17
WARRANTY INFORMATION*
Digital Watchdog (referred to as “the Warrantor”)
warrants the Digital Watchdog Camera against defects in
materials or workmanship as follows:
LABOR : For the initial two (2) years and one (1) year on IR LED
from the original purchase date,
if the camera is determined to be defective, the Warrantor will
repair or replace the unit with a new or refurbished product at its
option at no charge.
PARTS : In addition, the Warrantor will supply
replacement parts for the initial two (2) years and one (1) year on IR LED.
To obtain warranty or out of warranty service,
please contact a Technical Support Representative at
1-866-446-3595 Monday through Friday from 8:30AM to 8:00PM
Eastern Standard Time.
A purchase receipt or other proof of the original purchase date is required
before warranty service is rendered. This warranty only covers failures due to
defects in materials and workmanship which arise during normal use.
This warranty does not cover damage which occurs in shipment or failures
which are caused by products not supplied by the Warrantor or failures
which result from accident, misuse, abuse, neglect, mishandling,
misapplication, alteration, modification, faulty installation, set-up adjustments,
improper antenna, inadequate signal pickup, maladjustment of consumer controls,
improper operation, power line surge, improper voltage supply, lightning damage,
rental use of the product or service by anyone other than an authorized repair
facility or damage that is attributable to acts of God.

LIMITS AND EXCLUSIONS*
There are no express warranties except as listed above.
The Warrantor will not be liable for incidental or consequential
damages (including without limitation or damage to recording media),
resulting from the use of these products or arising out of any breach
of the warranty. All express and implied warranties, including the
warranties of merchantability and fitness for particular purpose,
are limited to the applicable warranty period set forth above.
Some States do not allow the exclusion or limitation of incidental
or consequential damages or limitations on how long an implied
warranty lasts, so the exclusions or limitations listed above may not
apply to you. This warranty gives you specific legal rights, and you
may also have other rights that vary from state to state.
If the problem is not handled to your satisfaction,
then write to the Address listed on the next page.
Service calls which do not involve defective materials or
workmanship as determined by the Warrantor, in its sole
discretion, are not covered. Costs of such service calls are
the responsibility of the purchaser.
18

SPECIFICATIONS*
MODEL
General Spec
CCD Type
Total number of pixels
Min. Illumination
DWC-V362D, DWC-V362DIR
1/3” 410K Pixels Color
NTSC
811(H) x 508(V)
0.1Lux [(F1.2, 30IRE), (at COLOR)]
0.001Lux [(F1.2, 30IRE), (at B/W)]
0.00Lux [V362DIR]
Resolution 540 TV Lines [at COLOR]
580 TV Lines [at B/W]
Electric Spec
Operation temp
In storage temp
Operation humidity
Voltage
Power Consumption
Mechanical Spec
LED OFF : 1.8W,150ma(DC12V) / 1.8W,75mA(AC24V)
LED ON : 5.0W,417.7mA(DC12V) / 4.6W,191.7mA(AC24V)
DC 12V (10V ~ 16V), AC 24V (20V ~ 28V)
-20 �~ +70 �(-4°F ~ 158°F)
-10 �~ +55 �(14°F ~ 131°F)
Under 90% (Non-condensing)
Shutter speed
S/N Ratio
Sync System
1/60s - 1/100,000s
50dB or more (AGC off)
Gamma 0.45
Internal / External
19

20
