Digital Watchdog MEGApix DWC-MT94WiAT User manual

1. To install the camera’s SD Card, loosen the lock screw under the
camera lens and rotate the camera module to access the control
panel. Open the control panel cover on the top of the camera module.
Locate the SD card slot by opening the control panel at the base of
the camera module.
2. Insert a class 10 SD/SDHC/SDXC card into the SD card slot by
pressing the SD
card until it clicks.
3. To remove the SD
card, press the
card inward until
it clicks to release
it from the card slot.
Default Login Information
Username: admin Password: admin
Quick Start Guide Quick Start Guide
WHAT’S IN THE BOX
Quick setup
and
Installation
guides
1 set
Tapping
Screws –
3pcs
1 set
Mounting
Template 1Plastic Plugs – 3pcs 1 set
Waterproof
Cap 1 set Rubber Plug 1
Hexagonal
Wrench
0.07” (2mm)
1
DWC-MT94WiAT
STEP 1 – PREPARING TO MOUNT THE CAMERA
STEP 2 – POWERING THE CAMERA
Power requirements Power consumption
DC12V, PoE
(IEEE 802.3af class 3).
Adapter not Included.
<9.5W
1. The mounting surface must bear five times the weight of your camera.
2. Do not let the cables get caught in improper places or the electric line
cover to be damaged. This may cause a breakdown or fire.
3. Using the mounting template sheet or the camera itself, mark and
drill the necessary holes in the wall or ceiling.
Resetting the camera: To reset the camera, use the tip of a
paper clip or a pencil and press the reset button. Loosen the
lock screw under the camera’s lens and rotate the camera
module to access the control panel.
Open the control panel cover on the
top of the camera module to access
the control panel. Pressing the button
for five (5) seconds will initiate a
camera-wide reset of all the settings,
including network settings.
Tel: [phone]
Technical Support Hours:
9:00 AM – 8:00 PM EST, Monday through Friday
digital-watchdog.com
Attention: This document is intended to serve as a quick reference for initial
set-up. It is recommended that the user read the entire instruction manual for
complete and proper installation and usage.
NOTE: Download all your support materials and tools in one place
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in the
‘Search by Product’ search bar. Results for applicable
part numbers will populate automatically based on the
part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
a
b
c
STEP 3 – INSTALLING THE CAMERA
1. Mount the camera to the mounting surface using the included
screws and anchors.
2. To use the camera’s waterproof wiring:
a. Install the LAN cable into .
b. will be assembled
to with a 1/4 turn.
c. Thread tightly to .
3. Loosen the lock screw under the camera’s
lens to adjust the camera module’s position.
a
a
b
bc
STEP 4 – CABLING
STEP 5 – MANAGING THE SD CARD
Use the diagram below to properly connect power, network and audio to
the camera.
SD Card Slot
Cover
Power
Network
Audio Input
Pass the wires through and make all the necessary connections. See
STEP 4.
1. NETWORK CONNECTIONS – Using a PoE Switch
or PoE Injector, connect the camera using an
Ethernet cable for both data and power.
2. NETWORK CONNECTIONS – Not using PoE Switch
or PoE Injector, connect the camera to the switch
using an Ethernet cable for data transmission and
use a power adapter to power the camera.
Rubber Plug

NOTE: This camera’s web client is available via
Internet Explorer®only.
The GUI display may dier by camera models.
Once the camera’s network settings have been setup properly, you can
access the camera’s web viewer.
To open the camera using the DW IP Finder:
1. Find the camera using the DW IP Finder.
2. Double-click on the camera’s view in the results table.
3. Press the ‘View Camera Website’. The camera’s web viewer will open
up in your default web browser.
4. Enter the camera’s username and password.
To open the camera using the web browser:
1. Open a web browser (Internet Explorer® 8.0 or above).
2. Enter the camera’s IP address and port in the address bar.
Example: http://<ipaddress>:<port>.
Port forwarding may be necessary to access the camera from a
dierent network. Contact your network administrator for more
information.
3. Enter the camera’s username and password (default admin/admin).
If you are accessing the camera for the first time, install the ActiveX
player for web files to view video from the camera.
*
Quick Start Guide
STEP 6 – DW® IP FINDER™
Thumbnail view
Firmware version
Camera’s uptime
Open Device
configuration
settings
Filter device type to scan
Scan devices
Select network to scan
Show/hide thumbnail view
Refresh thumbnail view
Bulk IP assignment
Firmware upgrade
Device’s
information
Use the DW®IP Finder™ software to scan the network and detect all MEGApix® cameras, set the camera’s network settings or access the camera’s web client.
Network Setup
1. To install the DW IP Finder, go to
http://www.digital-watchdog.com
2. Enter “DW IP Finder” on the search box at the top of the page.
3. Go to the “Software” tab on the DW IP Finder page to download
the installation file.
4. Follow the installation to install the DW IP Finder. Open the DW IP
Finder and click ‘Scan Devices’. It will scan the selected network
for all supported devices and list the results in the table. During the
scan, the DW® logo will turn gray.
5. When connecting to the camera for the first time, a password must
be set. To set up a password for your new camera:
Select DHCP to allow the camera to receive its IP address automatically
from the DHCP server.
Select “Static” to manually enter the camera’s IP address, (Sub)
Netmask, Gateway and DNS information.
* The camera’s IP must be set to Static if connecting to
Spectrum® IPVMS.
Contact your network administrator for more information.
Default TCP/IP information: DHCP ‘Port forwarding’ has to be set in your network’s
router for external access to the camera.
a. Check the box next to your new camera from
the IP Finder’s search results. You can select
multiple cameras.
b. Click “Bulk Password Assign” on the left.
c. In the pop-up window, enter admin/ admin in the
current username and password fields. Enter a
new username and password to the right.
d. Press “change” to apply all changes.
6. Select a camera from the list by double-clicking on
the camera’s image or clicking on the ‘Click’ button
under the IP Conf. column. The pop-up window
will show the camera’s current network settings,
allowing admin users to adjust the settings as
needed.
7. To access the camera’s web page, go to the
IP Config page and click on the ‘View Camera
Website’.
8. To save the changes made to the camera’s setting,
input the username and password of the camera
and click Apply.
Rev Date: 01/22
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
NOTE: Some menu options may not be available based on the
camera model. See the full manual for more information.
STEP 7 – WEB VIEWER
