Digital Watchdog DWC-LPR650U User manual

Quick Start Guide
Tel: [phone]
Technical Support Hours:
9:00AM – 8:00PM EST, Monday through Friday
digital-watchdog.com
Attention: This document is intended to serve as a quick reference for the initial
setup. It is recommended that the user read the entire instruction manual for com-
plete and proper installation and usage.
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/resources.
2. Search your product by entering the part number in the
‘Search by Product’ search bar. Results for applicable
part numbers will populate automatically based on the
part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
DWC-LPR650U
WHAT’S IN THE BOX
Manual 1
Screws and
plastic
anchors – 4pcs
1 set
Mounting
template 1Star wrench 1
Test video cable 1DC plug cable 1
Moisture
absorber and
absorber guide
(recommended)
1 set
STEP 1 – PREPARING TO MOUNT THE CAMERA STEP 3 – MOUNTING AN LPR CAMERA
Quick Start Guide
STEP 2 – CABLING THE CAMERA
Pass the wires through the mount bracket and make all necessary
connections. Connect the BNC cable and power cables to the camera.
Power requirements Power consumption
DC12V/AC24V dual voltage DC12V (LED on): 6.12W
AC24V (LED on): 5.7W
DW® Universal HD over Coax® LPR cameras
THE CAPTURED IMAGE SHOULD BE FILLED WITH THE FULL WIDTH OF THE VEHICLES
THE CAMERA SHOULD BE MOUNTED AT AN ANGLE NO GREATER THAN 30 DEGREES
CAMERA ANGLE NO GREATER THAN 20 DEGREES FOR SIDE MOUNT INSTALLATIONS
>11.5ft
< 30
< 20
Please cut the card type absorber along
a dotted line, overlap and attach them
according to the direction of the arrow.
Please cut the card type absorber along
a dotted line, overlap and attach them
according to the direction of the arrow.
1. The mounting surface must withstand five times the camera weight.
2. Do not let the cables get caught in improper places or the electric line
cover can be damaged. This may cause a short or fire.
3. Install the moisture packet in the base of the camera’s lens.
a. Remove the moisture absorber from the packaging.
b. Cut the card and folder along the dotted line.
c. Place the moisture absorber behind the camera’s lens module. See
drawing for more information.
4. Using the mounting template sheet or the camera itself, mark and drill
the necessary holes in the wall or ceiling.
WARNING: It is highly recommended that you install the moisture
absorber when mounting the camera. The moisture
absorber prevents moisture from being captured
inside the camera's housing, which may cause image
performance issues and damage the camera.
NOTE: The camera will generate enough heat to dry moisture
during operation. In most cases it will not need the
moisture absorber for more than the first day. In cases
where the camera can experience a moisture issue,
users must keep the moisture absorber in the camera.
The moisture absorber has an approximately 6-month
life cycle, varying depending on the environment.
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &

Rev Date: 04/21
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
Quick Start Guide
1. The camera supports HD-Analog, HD-CVI and HD-TVI signals. To switch between the signals:
a. Remove the camera’s dome to access the joystick and OSD control on the base of the camera.
b. Use the OSD Switch to switch the camera’s signal.
• To switch the camera to HD-TVI mode, press OSD joystick to the left for 5 seconds.
• To switch the camera to HD-Analog mode, press OSD joystick to the right for 5 seconds.
• To switch the camera to CVBS mode, press OSD joystick up for 5 seconds.
• To switch the camera to HD- CVI mode, press OSD joystick down for 5 seconds.
STEP 5 – INSTALLING THE CAMERASTEP 4 – CHANGING THE SIGNAL IN THE CAMERA
Zoom lever
Wide Tele
Focus lever
Far Near
Test video connector for
on-site configuration
1. Once all cables have been connected, use the screws included with the camera to properly mount
and secure the camera to the mounting surface.
2. To adjust the camera’s tilt, loosen the screws at the base of the camera’s bracket.
The camera’s max angles are:
Pan: 0°~ 360°
Tilt: 0°~ 90°
3. To adjust the camera’s focus and zoom:
a. Remove the sun-shield and front case from the camera.
b. Unlock the zoom or focus screws by rotating them counterclockwise.
c. Use the wrench included to adjust the zoom and focus screws at the base
of the camera module to achieve a clear image.
d. Tighten the screws and close the front case
by rotating it clockwise.
HD-AHD-TVI
CVBS(960H)
HD-CVI
U
Enter R
L
D
Right
Up
2ND EX-CON
Down
