Digital Watchdog DWC-MVH2I4WV User manual

Quick Start Guide
DWC-MBH2i4WV
Username: admin Password: admin
ATTENTION: This document is intended to serve as a quick reference page for initial set-up. It is recommended
that the user read the entire instruction manual for complete and proper camera usage.
Tel: [phone]
Technical Support Hours: 9:00AM – 8:00PM EST, Monday thru Friday
digital-watchdog.com
Quick Start Guide
Step 1 – PREPARING TO MOUNT THE CAMERA
Step 2 – CABLING THE CAMERA TO EXTERNAL DEVICES
1. The mounting surface must bear ve times the weight of your camera.
2. Do not let the cables get caught in improper places or the electric line cover to be damaged.
This may cause a breakdown or re.
3. Using the mounting template sheet or the camera itself, mark and drill the necessary holes in
the wall or ceiling.
5. Pass the wires through the mount bracket and make all necessary connections.
a. NETWORK CONNECTIONS – If you are using a PoE Switch, connect the camera using
an Ethernet cable for both data and power.
b. NETWORK CONNECTIONS – If you are using a non-PoE switch, connect the camera
to the switch using an Ethernet cable for data transmission and use a power adapter to
power the camera.
Power Requirements Power Consumption
DC 12V
PoE IEEE 802.3atPoE+ / PoE Class 2
LED Off: 5W, 416mA
LED On: 7W, 583mA
Resetting the camera: Press RESET about 10 seconds when the camera is powering on
or rebooting to restore the default settings, including the user name, password, IP address,
port No., etc.
WHAT’S IN THE BOX
QSG Manual 1 Set Screw & Plastic
Anchor – 3pcs 1 Set
Manual CD 1 Set L- W r e n c h 1 Set
Template Sheet
for installing by
Bolt & Nut
1 Set
WPS / Reset
Adjust Nut
0°~90°
0°~360°
0°~360°
7
Step 3 – INSTALLING THE CAMERA
6. Using the included three (3) screws, mount and secure the camera to the wall or ceiling.
7. Use the camera’s bracket to adjust the camera’s view. To adjust the camera's view:
a. Loosen the adjustable nut.
b. Adjust the pan direction [0°~360°].
c. Adjust the tilt direction [0°~90°].
d. Rotate the camera [0~360°] to adjust the lens to the surveillance angle.
e. Tighten the adjustable nut to complete the installation.

Note: Please see the full product manual for web viewer setup, functions and camera
settings options.
5. To view the camera’s web viewer, click on ‘View Camera Website’.
6. To save the changes made to the camera’s settings, input the ID and PW of the camera for
authentication and click ‘Save’.
7. If the camera needs to be rebooted after the settings were changed, press the ‘Reboot’
button. The camera will cycle power and will appear back in the search results once the
reboot is complete.
8. To update the camera’s rmware from the DW IP Finder™, click on the rmware tab, upload
the rmware le and select the cameras to update. You can update multiple cameras at the
same time.
4. The camera’s default network information is:
Step 4 – DW IP FINDER™
Use the DW IP Finder™included in the camera’s accessory CD to scan the network and detect all
MEGApix®cameras, set the camera’s network settings, perform rmware upgrade or access the
camera’s web client.
Rev Date: 04/16
Copyright © Digital Watchdog. All rights reserved. Specifications
and pricing are subject to change without notice.
Step 5 – WEB VIEWER
Once the camera’s network settings have been setup properly, you can access the camera’s web
viewer using the DW IP Finder™. To open the camera’s web viewer:
1. Find the camera using the DW IP Finder™.
2. Double-click on the camera’s view in the results table.
3. Press the ‘View Camera Website’. The camera’s web viewer will open up in your default
web browser.
4. Enter the camera’s username and password (default are admin / admin).
5. If you are accessing the camera for the rst time, install the ActiveX les in order to view
video from the camera.
Network Setup
1. Run the CD included with the camera and click on the DW IP Finder™le.
2. The software will scan your network for all supported cameras and display the results in the
table. Allow up to 5 seconds for the IP Finder to nd the camera on the network.
3. Select a camera from the list by double-clicking on the camera’s image or clicking on the
‘Click’ button under the IP Conf. column. The camera’s network information will appear. If
necessary, you can adjust the camera’s network type.
Select DHCP if the internet service is dynamic IP. This will allow the camera to receive its IP
address from the DHCP server.
Select STATIC to manually enter the camera’s IP address, subnet mask, Gateway and DNS
information.
Contact your network administrator for more information.
Default TCP/IP information
• IP: 169.254.x.y*
• Subnet Mask: 255.255.255.0
• Ga t e w ay: 192.16 8.1.1
• DN S : 168 .126 . 6 3.1
*When the camera is connected to
a non-DHCP server.
Quick Start Guide
DWCMF10M28T
DWCMF21M4TIR
DWCMF10M28T
DWCMF21M4TIR
Firmware Upgrade Open Camera's IP
Conguration Screen
Camera Uptime
Camera Name,
Model, IP Address,
and MAC Address
Camera's Firmware
Search for
Cameras
View Camera's
Thumbnail View
Camera's Network Settings
Filter Search
Results
Default ID / PW : admin / admin
‘Port Forwarding’ has to be set in your network’s router for external access to the camera.
