RGBlink ASK plus p2p User manual

ASK plus p2p
4K Wireless HDMI Extender
Quick Start

ASK plus p2p Quick Start
1
Content
About Your Product ........................................................................................................................................... 2
Product Overview ......................................................................................................................................... 2
Key Features................................................................................................................................................... 2
Packing List.....................................................................................................................................................3
Panel................................................................................................................................................................. 3
Dimensions ..................................................................................................................................................... 4
Use Your Product ................................................................................................................................................ 5
Pairing of TX and RX .................................................................................................................................... 5
Application Diagram....................................................................................................................................5
Specification ......................................................................................................................................................... 6
Warranty .................................................................................................................................................................7

ASK plus p2p Quick Start
2
About Your Product
Product Overview
ASK plus p2p, 4K wireless transmitter and receiver, supports 4K@60 resolution, super
smooth playback with 100ms low latency. .
Each TX and RX works point to point in designated channel and up to 20 TX and 20 RX
can work simultaneously without interfering each other.
ASK plus p2p allows users to wireless stream the video content without latency, excellent
for applications like education or digital signage.
Key Features
● Each TX and RX works point to point in designated channel and up to 20 TX and 20
RX can work simultaneously without interfering each other
● Smooth video playback
● Supports 4K60 high definition resolution
● As low as 100ms latency
● USB KVM function
● Transmission distance up to 150 meters in the clear line of sight for 1*RX
● Touch panel back control function
● Auto channel selection
● Equipped with the fast 802. 11ac 2T2R WiFi MIMO module
● High-security protection
● Suitable for outdoor rotating display

ASK plus p2p Quick Start
3
Packing List
● 3 * USB A -USB-C Power Cable
● 3 * 5V 2A USB Power Adapter
● 3 * HDMI Cable
● 1 * micro USB Cable
Panel
Transmitter
No.
Name
Description
1
HDMI IN
Connect with the video source
2
HDMI OUT
Connect with display for pass-through
3
Micro USB
Connect with USB of video source for KVM function
4
IR Port
Connect with IR probe of video source for IR extended function
（to be developed)
5
USB-C
Connect with 5V/2A power adapter
6
LED Indicator
● Red: TX system is booting on
● Flashing Blue: Waiting for connection
● Static Blue: Connected
● Purple: No video in

ASK plus p2p Quick Start
4
Receiver
No.
Name
Description
1
HDMI OUT
Connect to display or or projector
2
USB-A
● Connect with mouse and keyboard for USB KVM function
● Connect with touch panel USB port for touch panel back
control
3
Reset
Reset to factory
4
USB-C
Connect with 5V/2A power adapter
5
IR Window
IR extended function（to be developed）
6
LED Indicator
● Flashing Blue: Waiting for connection
● Static Blue: Connected
Dimensions
ASK plus p2p (TX/RX) ：154.0mm x 77.5mm x 21.0mm

ASK plus p2p Quick Start
5
Use Your Product
Pairing of TX and RX
1）Power on the transmitter；
2）Power on the receiver till it’s on the main menu；
3）Press the receiver’s reset button and hold for 10 seconds till the interface shows reset picture;
4）Wait around 30 seconds, the transmitter and receiver will pair automatically.
Application Diagram

ASK plus p2p Quick Start
6
Specification
Interface
Input
TX
HDMI
1×HDMI -A
Output
TX
HDMI
1×HDMI-A
RX
HDMI
1×HDMI-A
Control
TX
USB
1×Micro-USB (PC)
IR
1×IR (to be developed)
RX
USB
2×USB-A
(keyboard/mouse/touch panel
control cable)
Power
TX
Power
1×USB-C
RX
Power
1×USB-C
Performance
Video
Resolutions
SMPTE
4K@60 | 4K@30 | 4K@24 | 1080p@60/50/30/24 |
720p@60/50/30 | 480p
HDMI Version
HDMI
2.0
HDCP 1.4/2.2
Wireless
Standard
IEEE 802. 11b/g/n/ac, 2.4G/5GHz, 2T2R
Platform
Supported
Any devices that support HDMI port
Latency
About 100ms latency
Audio
Stereo, 44. 1KHz
Distance
About 150 meters in the clear line of sight
Power
Power Supply
TX
DC 5V/2A
RX
DC 5V/2A
Power
Consumption
TX
7W
RX
5W
Environment
Operating
Temperature
0°C to +40°C (+32°F to + 104°F)
Storage
Temperature
- 10°C to +60°C (+14°F to + 140°F)
Operating
Humidity
10% to 80% RH
Physical
Net
Dimension
TX
154*77.5*21mm
RX 154*77.5*21mm
Net Weight
TX
330g
RX
330g

ASK plus p2p Quick Start
7
Warranty
All products are designed and tested to the highest quality standard and backed by 1
year parts and labor warranty. Warranties are effective upon delivery date to customer
and are non-transferable. RGBlink warranties are only valid to the original
purchase/owner.
Warranty related repairs include parts and labor, but do not include faults resulting from
user negligence, special modification, lighting strikes, abuse(drop/crush), and/or other
unusual damages.
The customer shall pay shipping charges when unit is returned for repair.
