Digitus DA-70231 User manual

SUPER-SPEED 4-PORT
USB 3.0 HUB
User’s Manual
(Model No. DA-70231 Rev. 3)

2
Introduction:
Thank you for purchasing the DA-70231: USB 3.0 4-Port
Hub. This easy plug and play external device
is a full featured Universal Serial Bus Hub. It allows your
computer to connect to USB interfaces joysticks,
modems, digital speakers, printers, digital cameras,
monitors, and many other USB devices.
Features:
1. Compliant with the three USB (Universal Serial Bus)
Specifications: 3.0, 2.0 and Revision 1.1
with the Data Rates 5 Gbps, 480 Mbps, 12 Mbps and
1.5 Mbps
2. Includes 1 upstream and 4 downstream USB ports.
3. Plug and play.
4. Over-current detection and protection.
5. Connects up to 127 USB devices.
6. Supports Windows 7, Vista, XP
Specification:
Ports
Four downstream port and one upstream
port
Compliance
CE emissions and FCC regulations for
home/office use
Power
Power supply 5V DC 3.5A

3
Hardware Installation
1. Plug the included AC power adapter into the power
jack at the rear
of the USB 4 port hub and an electrical outlet.
2. Plug the USB 3.0 A type connector into the upstream
port
3. Plug the micro-USB into a computer or USB hub
downstream port
4. Connects USB devices or hubs to the 4 port hub’s
downstream 1 ~ 4 ports.
USB 3.0
Graphics Adapter
Power
Printer
Computer/Laptop
Digital Camera
Digital Video
PDA/Cell Phone
Scanner
MP3 Player
Flash Driver

4
Important Note
The Hub must be connected to a USB 3.0-compliant host in
order to function in super-speed mode
(5 Gbps data rate). If the Hub is connected to a USB 2.0 or
1.1-compliant host, it will operate only
in high-speed, full-speed or low-speed mode (480 / 12 /
1.5 Mbps).
Safety Instructions
Always read the safety instructions carefully
Keep this user’s manual for future reference
Keep this equipment away from humidity.
If any of the following situation arises, get the equipment
checked by a service technician:
• The equipment has been exposed to moisture
• The equipment has been dropped and damaged
• The equipment has obvious sign of breakage
• The equipment has not working well or you cannot
get it work according to this user’s manual.
Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is
part of the shipping content. If the Declaration of Conformity is missing, you can
request it by post under the below mentioned manufacturer address.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
