Digitus DS-45320 User manual

4+1 PORT
HDMI VIDEO SWITCH
User Manual
DS-45320

１
Table of Contents
1.0 Introduction......................................................................... 1
2.0 Specifications ..................................................................... 2
3.0 Package Contents .............................................................. 2
4.0 Panel Descriptions ............................................................. 3
5.0 Connection and Operation ................................................ 4

２
DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
1.0 INTRODUCTION
It is a Home Entertainment System with very powerful functions. It supports 4
HDMI inputs and 1 HDMI output. With Built-in HDCP engine for Instant Port
Switching (IPS), 4 Ports switching can be very fast because there is no need to
redo HDCP authentication when port switching occurs. With the built-in HEC
(HDMI Ethernet) and ARC (Audio Return Channel) chips, it can split HEC
which is from HDTV to Ethernet signals and can split ARC which is also from
HDTV to Coaxial, Toslink, Stereo audio signals that are also from source
device through ARC ON/OFF button on the Remote Control.
1.1 FEATURES
HDMI with HEAC, 3D, CEC.
Supports 4 HDMI inputs and 1 HDMI output.
Built-in HDCP engine for Instant Port Switching (IPS), 4 Ports switching
can be very fast because there is no need to redo HDCP authentication
when port switching occurs.
Supports Audio Return Channel (ARC) from sink device. Connects ARC
port to Amplifier Receiver.
Supports digital audio Toslink and COAX output simultaneously and
Stereo audio output from source device. Connects these ports to Amplifier
Receiver.
Supports 3D all format, including [email protected]/24Hz,
[email protected]/60Hz/50Hz, bandwidth up to 225MHz.
Supports CEC.
Supports highest video resolution 1080p.
Supports 225MHz/2.25Gbps per channel (6.75Gbps all channel)
bandwidth.
Supports 12bit per channel (36bit all channel) deep color.
Supports uncompressed audio such as LPCM.
Supports compressed audio such as DTS Digital, Dolby Digital（including
DTS-HD and Dolby True HD）.

３
2.0 SPECIFICATIONS
Signal Inputs/Output
Input DDC Signal 5 volts p-p (TTL)
Input and Output Signal HDMI with HEAC,3D
Output Audio Signal Toslink, Coaxial, Stereo
Operating Frequency
Vertical Frequency Range 50/60Hz
Video Amplifier Bandwidth 2.25Gbps/225MHz
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Mechanical
Size(L-W-H) 157mm x 70mm x 23mm
Weight(Net) 260g
Warranty
Limited Warranty 1 Year Parts and Labor
Environmental
Operating Temperature 0℃to +70℃
Operating Humidity 10% to 80 % RH (no condensation)
Storage Temperature -10℃to +80℃
Storage Humidity 5% to 90 % RH (no condensation)
Power Requirement
External Power Supply 5V DC @2A
Power Consumption (max) 5 W
Regulatory Approvals
Converter Unit FCC,CE,UL
Power Supply UL,CE,FCC
Accessories Adapter
AC Power Adapter US standard, UK standard and so on
User Manual
Note: Specifications are subject to change without notice. Weight and dimensions
are approximate.
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the shipping carton:
1) Main unit
2) 5V/2A DC Power Supply x1
3) User’s Manual
4) Remote Control x1

４
4.0 PANEL DESCRIPTIONS
1. DC/5V
Connect this port to Power Supply
2. Audio Port
Connect the three ports to Amplifier Receiver, through Remote Control or
button，you can select ARC ON or OFF.
2.1 Toslink and Coaxial Port
When selecting ARC ON, Toslink and Coaxial will output audio from
Sink device，such as HDTV with ARC.
When selecting ARC OFF, Toslink and Coaxial will output audio from
Source
2.2 Stereo Port
It only can output audio from source device (such as blu-ray DVD,
PS3), and cannot be controlled by ARC ON/OFF button.
Note: Stereo can’t support compressive audio format because of the
limitation itself.

５
3. HDMI Output
Connect this port to HDTV
4-7.HDMI Input
Connect these ports to source devices.
8. Ethernet
Connect this port to PC. When HDTV with HEC enables HEC function, PC
will be connected to Ethernet.
9. Power LED
When the switching is working, LED turns blue; when it is standby, LED
turns red;
10. IR
Receive the signal from Infrared Remote Control.
11-14. Input LED
LED will turn on when input port is selected.
15. 2CH/5.1CH LED
LED will turn on when 5.1CH button is pressed; LED will turn off when 2CH
button is pressed.
16. Select
Press this button to select 4 inputs circularly.
17. ARC ON/OFF LED
LED will turn on when ARC ON button is pressed, then this product will
enable ARC function, and audio signal will be from HDTV; LED will turn off
when ARC OFF button is pressed, then ARC function will be turned off,
and audio signal will be from source devices.
18. Select
Press this button to select ARC on or off.

６
5.0 CONNECTION AND OPERATION
5.1 CONNECTION
1) Connect HDMI input of the product to source devices. (Input cables are
optional)
2) Connect HDMI output of the product to HDTV.
3) Connect audio port to Amplifier Receiver.
4) Connect Ethernet port to PC
5) Insert the DC side of 5V power supply into the unit and then connect the
AC side of the power supply into the wall outlet.
6) Turn on the power.
5.2 OPERATION
1）Source Select
Press "Select" button or remote control to switch Input sources from Input1
to Input4 manually.
2）2CH/5.1CH Audio Output Select
Note：Only when the source supports 5.1CH output (including CD), this
function is effective and it realizes through the 2.1CH and 5.1CH buttons on
the remote control. Press “2CH” button, the product outputs 2CH audio and
the LED turns off; press “5.1CH” button, the product outputs 5.1CH audio
and the LED turns on. When provided with power, it automatically selects
5.1CH audio output. If the source can only supports 2CH audio output, the
“5.1CH” button will become invalid, that is to say, although you press
“5.1CH” button, the product still outputs 2CH audio and the LED is still on.
3）ARC ON/OFF
When selecting ARC ON, audio output is from HDTV with ARC.
When selecting ARC OFF, audio output is from Source device.
Attention: Insert / Extract cable gently.

７
5.3 CONECTION DIAGRAM
