Digitus DN-651154 User manual

L2 Managed Switch (PoE)
Quick Installation Guide
DN-651154, DN-651155
DN-651156, DN-651157
DN-651158, DN-651159

2
Table of content
1. Overview ..................................................................................2
2. Features....................................................................................3
3. Specification .............................................................................3
3.1 standard..............................................................................3
3.2 Interface..............................................................................3
3.3 Work environment..............................................................4
3.4 Power supply ......................................................................4
3.5 Mechanical characteristic ...................................................4
3.7 Industrial standard..............................................................4
3.8 Spec table ...........................................................................5
4. Package.....................................................................................8
5. Switch Panel..............................................................................8
6. LED Indicator...........................................................................10
7. Installation Caution.................................................................10
7.1 Installation precautions ....................................................10
7.2 Din rail installation ............................................................11
7.3 grounding..........................................................................11
7.4 Power Connection.............................................................11
8. Management system Login.....................................................12
1. Overview
This series are (PoE) Ethernet switches with 4 / 8 / 16 port Gigabit
Ethernet + 2 port 1000Mbps SFP (PoE version available) with console
port. The Ethernet switch uses the Layer 2 protocol, which is required
in the industry to ensure the stability of the communication network.
The switches in this series have low power consumption and a fanless
design, so there is no noise. They support a wide operating
temperature range of -40~80°C and offer good electromagnetic
compatibility (EMC) to ensure stable operation in harsh industrial
environments and quickly cater to industrial applications such as
factory automation, intelligent transportation and video surveillance.
A stable network terminal provides a secure and reliable solution.

3
2. Features
Data control: support 802.3X full-duplex flow control, support
network storm suppression
Redundant network: support STP/RSTP/MSTP, support ERPS (self-
healing time <20ms)
Multicast management: support IGMP Snooping V1/V2/V3
VLAN: Support IEEE 802.1Q VLAN, effectively isolate the
broadcast domain
Link aggregation: support link static/dynamic aggregation,
providing perfect bandwidth utilization
QOS: Support COS\DSCP, 4 queues, support WRR\SP scheduling
mode
Security management: support ACL access control list, support
802.1X
Management function: support WEB, CLI, SNMP management
methods
Monitoring and maintenance: support port mirroring, interface
status monitoring, log management
IP40 protection grade
3. Specification
3.1 standard
IEEE802.3-10BaseT, IEEE802.3u-100BaseTX/100Base-FX,
IEEE802.3x-Flow Control, IEEE802.3af, IEEE802.3at
IEEE802.3z-1000BaseLX, IEEE802.3ab-1000BaseTX,
IEEE802.1ab, IEEE802.1D-Spanning Tree Protocol,
IEEE802.1w-Rapid Spanning Tree Protocol,
IEEE802.1Q -VLAN Tagging, IEEE802.1p -Class of Service,
IEEE802.1X-Port Based Network Access Control etc.
3.2 Interface
DN-651154 / DN-651155 (PoE)
4 Port Gigabit RJ45+2 Port Gigabit SFP
DN-651156 / DN-651157 (PoE)

4
8 Port Gigabit RJ45+2 Port Gigabit SFP
DN-651158 / DN-651159 (PoE)
16 Port Gigabit RJ45+2 Port Gigabit SFP
3.3 Work environment
Work environment: -40～80 °C
storage temperature: -40～85 °C
relative humidity: 5%～95% (no condensation)
3.4 Power supply
input voltage: DC12-48V
Input voltage: DC48-57V (PoE Version)
(Two-way power redundancy backup)
Access terminal: Terminal block
Support dual power redundancy
Support reverse connection protection
3.5 Mechanical characteristic
IP40 aluminum housing
DIN rail installation
Natural colling / No fan.
3.7 Industrial standard
FCC CFR47 Part 15, EN55032, Class A
IEC61000-4-2 (ESD): ±8kV (contact), ±12kV (air)
IEC61000-4-3 (RS): 10V/m (80~1000MHz)
IEC61000-4-4 (EFT): Power Port: ±4kV; Data Port: ±2kV
IEC61000-4-5 (Surge): Power Port: ±2kV/DM, ±4kV/CM;
Data Port: ±2kV
IEC61000-4-6 (CS): 3V (10kHz-150kHz); 10V (150kHz-80MHz)
IEC61000-4-16 (Common mode conduction): 30V (cont.), 300V (1s)
Frequency range：150kHz-80MHz
Impact: IEC 60068-2-27; Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6

5
3.8 Spec table
Model No
DN-651154
DN-651155
Network port
4 x 1000Mbps
SFP slot
2 x 1000Mbps
PoE Spec.
NA
IEEE802.3af
IEEE802.3at
Power Pin
Assignment
NA
1/2+;3/6-
Bandwidth
20 Gbps
Packet Buffer
Memory
4.1 Mbit
Forwarding rate
15 Mpps
Mac address table
4 K
Max. Frame Size
10240 bytes
Power
consumption
< 5 watts
ESD protection
contact 8KV, air 12KV
Surge protection
CM±4KV, DM±2KV
Enclosure
IP40
Power Supply
DC12-48V
DC48-57V
MTBF
300,000 hours
Working Temp.
-40 to 80C
Dimension (mm)
143.7*104*47.7
Weight (kg)
0.7

6
Model No
DN-651156
DN-651157
Network port
8 x 1000Mbps
SFP slot
2 x 1000Mbps
PoE Spec.
NA
IEEE802.3af
IEEE802.3at
Power Pin
Assignment
NA
1/2+;3/6-
Bandwidth
20 Gbps
Packet Buffer
Memory
4.1 Mbit
Forwarding rate
15 Mpps
Mac address table
4 K
Max. Frame Size
10240 bytes
Power
consumption
< 10 watts
ESD protection
contact 8KV, air 12KV
Surge protection
CM±4KV, DM±2KV
Enclosure
IP40
Power Supply
DC12-48V
DC48-57V
MTBF
300,000 hours
Working Temp.
-40 to 80C
Dimension (mm)
143.7*125*47.7
Weight (kg)
0.7

7
Model No
DN-651158
DN-651159
Network port
16 x 1000Mbps
SFP slot
2 x 1000Mbps
PoE Spec.
NA
IEEE802.3af
IEEE802.3at
Power Pin
Assignment
NA
1/2+;3/6-
Bandwidth
56 Gbps
Packet Buffer
Memory
4.1 Mbit
Forwarding rate
42 Mpps
Mac address table
8 K
Max. Frame Size
10240 bytes
Power
consumption
< 15 watts
ESD protection
contact 8KV, air 12KV
Surge protection
CM±4KV, DM±2KV
Enclosure
IP40
Power Supply
DC12-48V
DC48-57V
MTBF
300,000 hours
Working Temp.
-40 to 80C
Dimension (mm)
175.6*135*45.5
Weight (kg)
1.2

8
4. Package
Industrial switch 1pcs
User manual 1pcs
Terminal block 1pcs
5. Switch Panel
Side panel: P1 and P2 are the number of connecting terminals, P+1
and P-1 are respectively to the positive and negative poles to be
connected; Earthing screw used for earthing equipment.
DN-651154 / DN-651155 4+2 port
DN-651156 / DN-651157 8+2 port

9
DN-651158 / DN-651159 16+2port
Front panel: the yellow light on RJ45 port is the link light, it is on
when the connection is established, and the transmission data is
flashing; the green light on RJ45 port is the POE light, which is only
on when the switch port supplies power to the downlink PD; green
LED on is for system operation. the power indicator “POW” shows
Whether the current device is received power in normal. The green
LED for optical link
Switch size(mm)
DN-651154/DN-651155 4port: 143.7*104*47.7mm
DN-651156/DN-651157 8port: 143.7*125*47.7mm
DN-651158 / DN-651159 16port: 175.6*135*45.5mm

10
6. LED Indicator
LED Indicator
Status
Definition
Power
Red LED on
Power work in normal
Red LED off
No power or power in
trouble
RJ45 LED
Yellow LED on
Ethernet work in normal
Yellow LED flashing
Link communication in
normal
Green LED on
PoE feeding to PD
device in normal
Green LED off
No PoE work
RUN
Green LED slowing
flashing
System run in normal
Optical LED
Green LED on
Optical work in normal
7. Installation Caution
7.1 Installation precautions
In order to avoid damage to equipment and personal injury caused
by improper use, please follow the following precautions:
In order to avoid damage caused by falling of the equipment,
please put the equipment in a stable environment.
When supplying power to the equipment, pay attention to
confirm the range of power supply voltage, as well as the
positive and negative poles of the power supply, so as not to
damage the equipment by wrong operation.
In order to reduce the risk of electric shock, ensure that the
equipment is well grounded in the working environment.
No matter when, please do not arbitrarily remove the equipment
shell.
When placing the switch, please avoid the area with dust and
strong electromagnetic interference

11
7.2 Din rail installation
The first step is to check the grounding and
stability of the guide rail: the guide rail slot of
the switch is clamped into the guide rail; The
second step: from the center to both sides of
the guide rail positioning screws in order. Step
3: Use screws to fix the mounting rail card slot
on the fixed guide groove at both ends of the
guide rail to ensure that the guide rail and the
switch are fixed on the guide rail vertically and
stably.
7.3 grounding
Fix the grounding wire to the grounding screw
above the switch, and ensure good reliable
connection of the grounding system.
7.4 Power Connection
Insert the power cord into the specified position of the 6-core
terminal, and insert the terminal into the standard power supply inlet
(P+1 and P-1 input corresponding to the first power supply P1, and
P+2 and P-2 input corresponding to the second power supply P2).
The available voltage standard of the power supply is supported from
48V DC to 57V DC

12
8. Management system Login
This series of Managed ethernet switches provides a serial port-
based management system program debugging port. Located at the
front of panel to log in to the command line via a standard Cisco line.
Console port: baud rate 115200
Web IP: 192.168.10.12
User name: admin Password: admin
For detail Web User Instruction, which is available on
www.assmann.com
This is a Class A product. In home environment, this product may
cause radio interference. In this case, the user may be required to
take appropriate measures.
Hereby Assmann Electronic GmbH, declares that the Declaration of
Conformity is part of the shipping content. If the Declaration of
Conformity is missing, you can request it by post under the below
mentioned manufacturer address
www.assmann.com
ASSMANN Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid, Germany
