Digitus DS-45316 User manual

1
UHD HDMI Switch, 3x1
User Manual
DS-45316 Rev.2
Introduction
DIGITUS® UHD HDMI Switch, 3x1 is a high-performance HDMI UHD
Switcher. This switcher not only has the key-press-switching function, it
also has intelligent switching function. The switcher routes high definition
video (in multiple resolutions up to 4kx2k@60HZ) and digital audio from
any one of the several sources to display units. All inputs accommodate the
connections of the high definition video sources simultaneously.
All brand names and logos which mentioned above are trademarks or registered trademarks of
the respective owner.

2
Features
This HDMI UHD Switcher has many features that enable it to perform in a
superior manner. Among those features you will find:
Supports to switch 3 HDMI sources to 1 HDMI display
Multifunctional on switching: intelligent or mechanical
Support highest video resolution up to 4K2K/60Hz
Support Full 3D
HDCP Pass through
Support compressed audio such as DTS Digital, Dolby Digital (including
DTS-HD and Dolby True HD)
EDID bypass
Package Contents
Before attempting to use this unit, please check the packaging and make
sure the following items are contained in the shipping carton:
Main unit
User Manual
Remote control
5V/1A Power Adapter

3
Specifications
Signal Inputs/Output
Input Video
HDMI
Maximum Single Link Range
Full 3D and 4Kx2K@60HZ
Output Video
HDMI
Operating Frequency
Vertical Frequency Range
24/30/50/60Hz
Video Amplifier Bandwidth
6Gbps/600MHz
Resolutions (HDTV)
Interlaced (50&60Hz)
480i, 576i, 1080i
Progressive (50&60Hz)
480p, 576p, 720p, 1080p, 4K2K@30HZ,
4K2K@60HZ,
Environmental
Operating Temperature
0°C to +40°C
Operating Humidity
10% to 85% RH (no condensation)
Storage Temperature
-10°C to +80°C
Storage Humidity
5% to 90% RH (no condensation)
Power Requirement
External Power Supply
5V/1A
Power consumption (Max)
1.6W
Note: Specifications are subject to change without notice.
Connection
1) Connect the HDMI input source into the HDMI switcher
*Please refer to connection diagram section
2) Press the button to select the inputs
3) It is recommended to give a 5V DC power supply to the switch unit
Attention: Insert/Extract cable gently.

4
Connection Diagram
Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is part of the
shipping content. If the Declaration of Conformity is missing, you can request it by post under
the below mentioned manufacturer address.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
5V Power Adapter
HDMI Display
HDMI Source 1
HDMI Source 2
HDMI Source 3
