Digitus DN-80063-1 User manual

Gigabit Ethernet Switch
5-port, unmanaged,
Desktop
Quick Installation Guide
DN-80063-1

2
Installation
Precautions for Installation
Do not install the device in an unstable location such as on an
unsteady table or an inclined surface.
Do not place another hub or object that generates heat on this
unit.
Please route all cables properly to prevent people from tripping
over them.
Ensure the air vents on the product are not blocked by other
equipment or walls.
Only use the power cable included with the product. Using other
power cables may result in damage or fire.
Mounting to a Wall
To mount the unit directly to the wall, use 2 screws (not included).
Install the screws apart and slide the mounting holes on the base of
the switch over them.
Install on the Desk
Put on the Desk, connect with the Network Cable and the power
adapter
1. INTRODUCTION
With this Gigabit Ethernet Switch you can easily expand your Network
with five additional RJ45 Network ports. Thanks to the Auto-MDI/MDI-X
cable detection every port can be used as uplink. Automatic detection
of network speeds 10/100/1000Mbps. No driver of software installation
necessary.

3
2. FEATURES
1. 5-port 10/100/1000Mbps Gigabit Ethernet Switch
2. Compliant to the network standards IEEE 802.3, IEEE 802.3u and
IEEE 802.3ab
3. Auto-negotiation for 10/100/1000 Mbps
4. Auto-MDI/MDI-X detection for each RJ-45 port
5. Noiseless design - without fan
6. External power supply
7. Operating system independent, supports e.g. Windows, Mac OS,
Linux and Sun
3. SPECIFICATIONS
Interface
5 10/100/1000/Mbps RJ45 Ports AUTO
Negotiation/AUTO MDI/MDIX
Chip
EN8850DH
Switching
Capacity
10 Gbps
Housing
Plastic housing
Power Input
External Power adapter 5V DC/1A.
LED
Power, 10/100M,1000M, LINK, ACT
Fan
Fanless
Transfer
Method
Store and forward
Dimension
Product Size:82.6*48.6*20.5 mm ;
Box Size: 90*84*62mm
Weight
Product Weight: 48.5g;
Product with Box weight: 135.5g
Advanced
Functions
Green Technology, saving power up to 85%
802.3X Flow Control, Back Pressure Auto-Uplink
Every Port
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -20℃~70℃ (-4℉~158℉)
Operating Humidity: 10%~90% non-condensing.
Storage Humidity: 5%~90% non-condensing

4
4. PACKAGE CONTENT
The package contains the items shown below. If any items are
missing, please contact the dealer where you purchased this product.
The appearance of this product may vary from the illustration.
1 pcs Switch
1 pcs Power Adapater
1 pcs Quick installation Quide
5. CONNECTION DIAGRAM
1
Network Cable
2
Power Cable
Check whether the connection is correct according to the indicator
status in the table below.
LED
Name
Status
Description
PWR
Power Indicator
Always on
Already Power On
1-5Port
Port Indicator
Always On
Port Connected
Normally
Flashing
Port is transmitting
data
After the connection is completed correctly, the switch does not
require any settings.

5
6. Troubleshooting
If you are unable connect to a network, check the following:
Is the power cable connected correctly? Also, is the power cable
plugged into an outlet or surge protector?
Is the Ethernet cable connected correctly? Are any cables
disconnected or.
Is the link/act/speed LED on? If not, manually set the
communication mode of the connected device to 100 Mbps half
duplex or 10 Mbps half duplex.
Hereby Assmann Electronic GmbH declares that the Declaration of
Conformity is part of the shipping content. If the Declaration of
Conformity is missing, you can request it by post under the below
mentioned manufacturer address.
www.assmann.com
ASSMANN Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
