Owner’s Manual
KS SP28W-4
KS SP60W-3
KS SP90W-3
Portable solar panel
EN
Please, read this manual
carefully before use!

INTRODUCTION
PREFACE 1
Thank you for your purchase of Könner & Söhnen®products. This manual contains a brief description of
safety, use and debugging. More information can be found on the ocial manufacturer’s website in the
support section: konner-sohnen.com/manuals
You can also go to the support section and download the full version of the manual by scanning the QR code,
or on the website of the ocial importer of Könner & Söhnen products: www.konner-sohnen.com
Manufacturer reserves the right to make alterations into the generators, which may not be reected in this
manual. Pictures and photos of the product may vary from its actual appearance. At the end of this manual,
You may nd contact information which you are free to use in case of any issues occurrence.
All data, specied in this operation manual is the most up to date for the moment of its publishing. The cur-
rent list of service centers you can nd at the website of ocial importer: www.konner-sohnen.com
This solar panel charger is compatible with cell phone, iPad, digital camera, PSP, GPS, power bank, power
station and so on. It is suitable for any occasion where you can expose it to the sun. It is highly ecient in
charging, easy you use, safe, environment-friendly, and energy-ecient.
We care about the environment, therefore, we consider it expedient to saveWe care about the environment, therefore, we consider it expedient to save
paper and leave in print a short description of the most important sections.paper and leave in print a short description of the most important sections.
Be sure to read the full version of the manual before
getting started!
Failure to follow the recommendations marked with this
sign may lead to serious injury or death of the operator
or third parties.
Useful information while operating the machine.
ATTENTION – DANGER!
IMPORTANT!
PACKAGE CONTENTSPACKAGE CONTENTS
1 x Solar panel
1 x User manual
1 x Different DC Cables
1. Please, do to hit, throw, prick the product, squeezing or bending the product and protect
it from falling down to avoid irreversible damage.
2. Please, keep it away from humidity to ensure its long service life.
3. The actual power of a solar panel charger is aected by solar illumination, exposure
angle and ambient temperature, so the dierence between the nominal power and the
actual power of solar panel charging is a normal phenomenon.
4. The intensity of sunlight must be high and the pane is should be as perpendicular to the
light as possible.
5. When absorbing sunlight to charge, the solar panel surface must not be shadowed.
ATTENTION – DANGER!
konner-sohnen.com |1

• Environment-friendly, practical and convenient for outdoor emergency power supply.
• Foldable design with portable size, easy to carry with just a single hand.
• The high-quality solar mono-crystalline silicon provides high charging eciency and long service life.
• The product is compatible with the portable power stations. You can convert and store solar power in
a battery of portable power stations in the day and charge devices at night. The portable solar panel kit
includes an adapter with USB connectors, which can be used to charge mobile phones, tablets, power
banks, etc.
3 folds: 21W/30W/60W/90W/120W
4 folds: 28W/40W/80W/100W
MODEL KS SP28W-4MODEL KS SP28W-4
1. DC 18V output
2. Indicator light
3. USB output
MODEL KS SP90W-3MODEL KS SP90W-3
1. USB output
2. USB QC 3.0 output
3. Indicator light
4. Type-C output
5. DC 18V output
MODEL KS SP60W-3MODEL KS SP60W-3
1. Indicator light
2. USB output
3. USB QC 3.0 output
4. DC 18V output
The portable power station should be purchased sepa-
rately.
NOTE
OUTPUT BOXOUTPUT BOX
There may be some differences between different models. Please adhere to the actual product.
FEATURE 2
MAIN OVERVIEW 3
111122223333441122334455
konner-sohnen.com |2

Model KS SP28W-4 KS SP60W-3 KS SP90W-3
Solar power 28W monocrystalline silicon
(4pcs Panel)
60W monocrystalline silicon
(3pcs Panel)
90W monocrystalline silicon
(3pcs Panel)
Conversion eciency >20% >20% >20%
Solar panel output max. max. 18V/1.55A max. 18V/3.33A max.18V/5A
USB Output 5V/2.4A 5V/2.4A 5V/2.4A
USB QC 3.0 Output - 5V/3A, 9V/2A, 12V/1.5A 5V/3A, 9V/2A, 12V/1.5A
Type C Output - - 60W, 5V/3A, 9V/3A, 12V/2.5A,
15V/2A
Folded size (LxWxH), mm 290x200x29 399x355x28 520x370x45
Unfold size (LxWxH), mm 1050x290x4 1218x399x4 1280x520x4
Weight, kg 1.1 2.5 3.18
Operating Temperature -20°C to 85°C -20°C to 85°C -20°C to 85°C
Delivery set
1 x 28W Solar panel
1 x DC-DC Connect cable
1 х Set of DC connectors
1 х Charger adapter with
USB outputs
1 x 60W Solar panel
1 x DC-DC Connect cable
1 x DC-Anderson cable
1 х Set of DC connectors
1 х Charger adapter with
USB outputs
1 x 90W Solar panel
1 x DC-DC Connect cable
1 x DC-Anderson cable
1 х Set of DC connectors
1 х Charger adapter with
USB outputs
PRODUCT INSTRUCTION 5
HOW TO USEHOW TO USE
1. Unfold the solar panel, expose it to sunlight, and connect the devices that need to be changed through
the charger adapter.
2. Indicator: Red light indicates the adapter is receiving solar energy properly.
Smart phone, digital camera, tablet
Manufacturer reserves the right to make changes and/or
improvements in design, components set and technical
attributes without notice and without incurring obliga-
tion. The pictures in this manual are schematical and may
not match the parameters of original product.
IMPORTANT!
konner-sohnen.com |3
SPECIFICATIONS 4

TIPS 6
QUESTIONS & ANSWERS 7
1. Do not connect the charger adapter and the portable power station to the portable solar panel at the
same time.
2. The charger adapter is not waterproof, do not allow moisture, rain, snow, etc. to get on it.
3. Please keep your device cool while charging.
1. Does it have a battery or direct device charging?1. Does it have a battery or direct device charging?
This item is without a battery, but you could use it to directly charge your devices.
2. How soon will it start charging?How soon will it start charging?
It will start charging immediately under direct sunlight on the solar panel.
COMPATIBILITYCOMPATIBILITY
Compatible with most solar generators, with our included dierent sizes of connectors. The included DC-
DC cable with 5.5 x 2.1 mm connectors compatibles with most portable power stations available on the
market.
HOW TO CHARGE A PORTABLE POWER STATION:HOW TO CHARGE A PORTABLE POWER STATION:
Power Station Input:
• DC input
• Anderson PV Input
DC to Anderson cable
DC to DC cable
The portable power station should be purchased sepa-
rately.
NOTE
WARRANTY SERVICE TERMS 8
The international manufacturer warranty is 1 year. The warranty period starts from the date of purchase.
In cases when warranty period is longer than 1 year according to local legislation please contact your local
dealer. The Seller which sells the product is responsible for granting the warranty. Please contact the Seller
for warranty. Within the warranty period, if the product fails because of defects in the production process,
it will be exchanged on the same product or repaired.
All faults caused by the manufacturer during the warranty period will be eliminated free of charge. Warran-
ty repair is carried out only if you have a fully completed warranty card, the Buyer’s signature of acceptance
of the warranty terms, as well as a document supporting the purchase (cash receipt, sales slip or invoice). In
the absence thereof, as well as in the event of errors or corrections not authenticated by the seller’s seal or
illegible inscriptions in the warranty card or tear-o coupon, no warranty repair is carried out, no objections
to quality are accepted and the warranty card is withdrawn by the service center as invalid. The device is
accepted for repair clean and full.
konner-sohnen.com |4


CONTACTS
Deutschland:Deutschland:
DIMAX International GmbH
Flinger Broich 203 -FortunaPark-
40235 Düsseldorf, Deutschland
koenner-soehnen.com
Ihre BestellungenIhre Bestellungen
Kundendienst, technische FragenKundendienst, technische Fragen
und Unterstützungund Unterstützung
Garantie, Reparatur und ServiceGarantie, Reparatur und Service
SonstigesSonstiges
Polska:Polska:
DIMAX International
Poland Sp.z o.o.
Polska, Warczawska,
306B 05-082 Stare Babice,
Україна:Україна:
ТОВ «Техно Трейд КС»,
вул. Електротехнічна 47, 02222,
м. Київ, Україна
