Owner’s Manual
Model
CDFI400RH/DFI400RH (6909051142)
CDFI400CH/DFI400CH (6909051143)
DFI600RH (6909051162)
DFI600CH (6909051163)
7213810100R02
IMPORTANT SAFETY INFORMATION: Always read this manual
rst before attempting to install or use the Optimyst® cassette. For
your safety, always comply with all warnings and safety instructions
contained in this manual to prevent personal injury or property
damage.
To view the full line of Dimplex products, please visit
www.dimplex.com

2 www.dimplex.com
Table of Contents
Always use a qualied technician
or service agency to repair
this cassette.
!NOTE: Procedures and
techniques that are considered
important enough to
emphasize.
CAUTION: Procedures and
techniques which, if not
carefully followed, will result in
damage to the equipment.
WARNING: Procedures
and techniques which, if not
carefully followed, will expose
the user to the risk of re,
serious injury, or death.
Welcome & Congratulations....................3
IMPORTANT SAFETY INSTRUCTIONS ..........4
Installation..................................6
Assembly...................................9
Operation..................................11
Maintenance...............................13
Warranty .................................15
Replacement Parts ..........................17

3
Welcome & Congratulations
Thank you and congratulations for choosing to purchase an Optimyst®
cassette from Dimplex, the world leader in electric replaces.
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in a
possible electric shock, re hazard and will void the warranty.
Please record your model and serial numbers below for future
reference: model and serial numbers can be found on the Model and
Serial Number Label of your cassette.
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)
Monday to Friday 8:00 a.m. to 4:30 p.m. EST
Please have your model number and product serial
number ready. (See above)
Model Number
Serial Number

4 www.dimplex.com
IMPORTANT SAFETY INSTRUCTIONS
THE ELECTRICAL RATING FOR
THESE MODELS IS
120VAC, 60 HZ, 12 AMP.
When using an electrical furnishing,
basic precautions should always be
followed, including the following:
Read all instructions before using
(this furnishing).
DANGER: To reduce the risk
of electric shock always unplug
this furnishing from the electri-
cal outlet before cleaning.
WARNING: To reduce the risk
of burns, re, electric shock, or
injury to persons:
① Unplug from outlet before putting
on or taking off parts.
② Close supervision is necessary
when this furnishing is used by, or
near children, invalids, or disabled
persons.
③ Use this furnishing only for its
intended use as described in these
instructions. Do not use attach-
ments not recommended by the
manufacturer.
④ Never operate this furnishing if it
has a damaged cord or plug, if it is
not working properly, if it has been
dropped or damaged, or dropped
into water. Contact Dimplex Techni-
cal Service at 1-888-346-7539 for
replacement parts.
⑤ Keep the cord away from heated
surfaces.
⑥ Never operate the furnishing with
the air openings blocked. Keep the
air openings free of lint, hair, and
the like.
⑦ Never drop or insert any object
into any opening.
⑧ Do not use outdoors.
⑨ Do not operate where aerosol
(spray) products are being used
or where oxygen is being adminis-
tered.
⑩ To disconnect, turn all controls to
the off position, then remove plug
from outlet.
WARNING: Risk of Electric
Shock – Connect this furnishing
to a properly grounded outlet
only. See Grounding Instruc-
tions.
⑪ This electrical appliance has hot
and arcing or sparking parts inside.
Do not use in areas where gaso-
line, paint, or ammable liquids are
used or stored.
⑫ Do not modify the unit. Use it
only as described in this manual.
Any other use not recommended by
the manufacturer may cause re,

5
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
electric shock or injury to persons.
⑬ To reduce the risk of electric
shock, this appliance has a three
pronged plug. This plug will t in a
grounded outlet only one way. If the
plug does not t, contact a quali-
ed electrician to install the proper
outlet. Do not change the plug in
any way. Always plug this appliance
directly into a wall outlet/receptacle.
Never use with an extension cord
or relocatable power tap (outlet/
power strip).
⑭ Keep away from curtains, drap-
eries and similar materials.
⑮ Always use a certied electrician
should new circuits or outlets be
required.
⑯ Always use properly grounded,
fused and polarized outlets.
⑰ When transporting or storing the
unit and cord, keep in a dry place,
free from excessive vibration and
store so as to avoid damage.
⑱ This furnishing has not been
evaluated for ammability or ciga-
rette ignition resistance.
⑲ Do not submerse.
⑳ Light bulb requirement: 45W,
12VAC halogen bulbs type MR 16.
Contact Dimplex Technical Service
at 1-888-346-7539 for replacement
bulbs.
㉑ The electric fireplace shall be
installed in an enclosure no smaller
than that indicated. (See Figure 2)
CAUTION: The receptacle
cord is intended for use only with
the Dimplex heater 6909070159,
120VAC, 60Hz., 1000W.
!NOTE: Changes or modica-
tions not expressly approved by the
party responsible for compliance
could void user's authority to oper-
ate the equipment.
WARNING: Remote control con-
tains small batteries. Keep away
from children. If swallowed, seek
medical attention immediately.
WARNING: Do not install bat-
tery backwards, charge, put in re
or mix with used or other battery
types - may explode or leak caus-
ing injury.

6 www.dimplex.com
Installation
WARNING: Ensure the power
cord is not installed so that it is
pinched or against a sharp edge
and ensure that the power cord is
stored or secured to avoid tripping
or snagging to reduce the risk
of re, electric shock or injury to
persons.
Grounding Instructions
This product must be grounded.
If it should malfunction or break-
down, grounding provides a path
of least resistance for electric
current to reduce the risk of
electric shock. This product is
equipped with a cord having an
equipment-grounding conductor
and a grounding plug. The plug
must be plugged into an appropri-
ate outlet that is properly installed
and grounded in accordance with
all local codes and ordinances.
DANGER: Improper connec-
tion of the equipment-grounding
conductor can result in a risk
of electric shock. Check with a
qualied electrician or serviceman
if you are in doubt as to whether
the product is properly grounded.
Do not modify the plug provided
with the product – if it will not t
the outlet, have a proper outlet
installed by a qualied electrician.
This product is for use on a
nominal 120-volt circuit and has
a grounding plug that looks like
the plug in Figure 1. Make sure
that the product is connected to
an outlet having the same con-
guration as the plug. No adapter
should be used with this product.
CAUTION: Risk of Electric
Shock. This product has two
cords. Unplug both cords before
moving or servicing this furnishing.
!NOTE: A 15 Amp, 120 Volt cir-
cuit is required. A dedicated circuit
is preferred but not essential in
all cases. A dedicated circuit will
be required if, after installation,
the circuit breaker trips or fuse
blows on a regular basis when the
cassette is operating. Additional
appliances on the same circuit
may exceed the current rating of
the circuit breaker.
Mantel Installation
Install the replace into the
mantel (refer to mantel assembly
instructions).
Figure 1

7
Installation
Figure 2
New Construction
1. Mark the desired location on
the oor and store the replace
in a safe, dry and dust free
location.
2. Use studs to frame an enclo-
sure with the following mini-
mum internal/opening dimen-
sions (Figure 2).
!NOTE: An air inlet is required
for optimum mist production, see
Figure 2 for minimum dimen-
sions.
!NOTE: For optimal perfor-
mance, the following minimum
clearances between the instal-
lation surface and any surface
above should be maintained:
• Cassette Only: 12 in. (305 mm)
• Cassette with Dimplex heater:
19 in. (483 mm)
Figure 3
3. Secure unit through the two
holes in the bottom of the unit
into supports to prevent the
unit from hanging from the top
ange, see gure 3 for dimen-
sions.
4. The unit is equipped with a
power supply plug and a fused
receptacle (Figure 4), the plug
should be plugged directly into
a 15 A, 120 V outlet.
CAUTION: During operation
8.5 in.
(216mm)
6.7 in.
(170mm)
Air Inlet
DFI400: 100cm2
DFI600: 150cm2
Supports: 0.75 in (19 mm) high
Exit for Cord
DFI400: 15.75 in. (400mm)
DFI600: 22.05 in. (560mm)
Installation
Surface
FRONT
1.2 in.
(30.0 mm)
3.5 in.
(90.0 mm)
3.1 in.
(80.0 mm)
4.8 in.
(122.0 mm)
5.4 in.
(137.0 mm)
1.2 in.
(30.0mm)

8 www.dimplex.com
ensure that the receptacle cord is
positioned so that the face is per-
pendicular to the oor as in Figure
4.
CAUTION: For continued pro-
tection against risk of re, replace
only with same type and rating of
fuse, 10 amp fuse maximum.
5. The receptacle is intended for
plugging in a Dimplex heater
(supplied with the mantel),
which will allow the heater to
be controlled with the provided
remote. (Figure 4)
CAUTION: The receptacle
cord is intended for use only with
the Dimplex heater 6909070159.
If this receptacle is used with any
other product, Dimplex will not be
liable for any damage or issues
that may arise.
Installation
15A 120V
Plug
10A 120V
Receptacle
Figure 4

9
Transducer
Rock
Media
Removable Rell
Container
Light Bulbs
Assembly
Figure 5
1. Carefully unpack all of the
components from the box.
(Figure 5)
2. Remove top cover by turning
the retaining tabs on both ends
of the water reservoir. (Figure
6)
3. Install the light bulbs by
aligning the pins on the bulbs
and the xture and pressing
down until they are fully
inserted. (Figure 7)
4. Install the transducer so that
it is sitting level in the circular
holding area in the reservoir.
5. Orient transducer wire so that
it does not sit directly above
the emitter and the wire passes
through the slot in the side of
the tank. (Figure 6)
6. Reinstall the top cover and
ensure both retaining tabs have
been turned so that they are
pointing inwards.
7. Fill and install the Rell
Container.
!NOTE: Normal tap water can
be used in the Optimyst® as long
as the tap water is not considered
to be hard water. In the event your
tap water is hard, you may use soft-
ened water or distilled water with
1/8 tsp of salt (0.5 mL) added to the
water reservoir. (The addition of
additional salt should only be used
when you notice that the unit is not
producing mist as expected.)
!NOTE: During initial installation,
the Rell Container should be
relled after the Reservoir has lled
to ensure the maximum operating
time.
Remote
Control
Curved Tray
Housing
Media
Tray

10 www.dimplex.com
Figure 6
Top
Cover
Transducer
Emitter
Wire Slot
Assembly
8. Install the media on top, media
tray and media (if applicable),
so that the opening is not
blocked (Figure 7).
CAUTION: Do not arrange the
media while the unit is running,
since the media and/or tray may be
hot.
9. Make sure the On/Off switch
is switched to Off (refer to
Operating Instruction section).
10. Plug the unit into a 15 Amp/
120 volt outlet.
Retaining
Tab
Figure 7
!NOTE: Rock media shown, install
other medias in the same way.
Fan
Housing
Water Tank

11
Operation
CAUTION: During operation
ensure that the receptacle cord is
positioned so that the face is per-
pendicular to the oor as in Figure 4.
!NOTE: Always ensure that the
appliance is in an upright position
before operating the unit.
!NOTE: When the cassette
is used in an environment where
background noise is very low, it
may be possible to hear a sound
which is related to the operation of
the ame effect. This is normal and
should not be a cause for concern.
The manual controls for the cas-
sette are located on the top of
the unit, below the control cover.
(Figure 8)
A. On/Off Switch
Supplies power to the cassette.
B. Mode Selector Switch
Press once to turn on the ame
effect. This will be indicated by an
audible “beep”. Although the lights
turn on immediately it will take 30
seconds before the ame effect
starts.
• Press again to give ame effect
and heat*. This will be indicated
by two “beeps”.
• Press again to return to ame
effect only. This will be indi-
cated by one “beep”.
• Press to put re in to stand-
by mode. This will be indicated
by one “beep”.
C. Flame Intensity Control
Adjusts the intensity of the ame
effect when the heater has been
activated.
Turning the control knob clockwise
to decrease the intensity of the
ame effect. Turning the control
knob counter-clockwise will in-
crease the ame effect.
!NOTE: Give the ame genera-
tor some time to react to changes
you may make on the ame control
knob.
!NOTE: When the water tank is
empty the unit will turn off after 30
seconds. See instructions under
Maintenance Section for relling
tank. When this procedure is com-
plete, the main lamps will illuminate
but it will take 30 seconds before
the ames return.
D. Thermostat Control*
To adjust the temperature to your
BA
C
D
Figure 8
Remote Control
Sensor

12 www.dimplex.com
individual requirements, turn the
thermostat control clockwise all the
way to turn on the heater. When the
room reaches the desired tem-
perature, turn the thermostat knob
counter-clockwise until you hear a
click. Leave thermostat in this posi-
tion to maintain the room tempera-
ture at this setting. For additional
heat, turn clockwise until you hear
the click again and the heater will
turn on.
* Only applicable when the Dimplex
heater has been plugged into the
receptacle.
Remote Control
The On/Off Switch must be in the
‘ON’ ( I ) position in order for the
remote control to operate. There
are 3 buttons on the remote control.
(Figure 9)
!NOTE: To operate correctly,
the remote control must be pointed
towards the remote control sensor.
The remote control functions are as
follows:
Press once to turn on Flame
effect only. This will be indi-
cated by one beep.
Press once to turn on heat
and Flame effect. This will be
indicated by two beeps.
Standby - This will be indicated
by one beep.
!NOTE: Once the mist has been
activated, the unit will have to be
turned Off, using either the switches
on the unit, or the standby button
on the remote control, then back on
to return to ame effect operation
only.
Battery Replacement
To replace the battery:
1. Slide battery cover open on the
remote control (Figure 9).
2. Install two 1.5 Volt (AAA) bat-
teries in the battery holder.
3. Close the battery cover.
Battery must be recycled or
disposed of properly. Check
with your Local Authority
or Retailer for recycling advice in
your area.
Operation
Battery Cover
Figure 9
Standby
Button
Flame
Button
Heat
Button

13
WARNING: Disconnect power
before attempting any main-
tenance or cleaning to reduce
the risk of re, electric shock or
damage to persons.
Filling the water tank
When the water tank is empty, the
ame shuts off and you will hear 2
audible beeps, follow these steps.
CAUTION: Allow at least ve
minutes for components to cool be-
fore disassembling the unit to rell.
1. Turn the On/Off switch to the
off position (0) (Figure 8)
2. Gently remove the media tray
and media (if applicable) and
place them carefully on the
ground.
3. Remove the rell container by
lifting upwards and outwards.
4. Rell the container with tap
water.
!NOTE: Normal tap water can
be used in the Optimyst® as long
as the tap water is not considered
to be hard water. In the event your
tap water is hard, you may use
softened water or distilled water
with 1/8 tsp of salt (0.5 mL) added
to the water reservoir. (The addi-
tion of additional salt should only be
when you notice that the unit is not
producing mist as expected.)
5. Screw the cap back on, do not
overtighten.
6. Return the rell container to the
water tank.
7. Gently place the media tray
and media (if applicable) back
into position.
8. Turn the On/Off switch to the
off position (I). (Figure 8)
If you do not intend on using the
unit for longer than 2 weeks, empty
and drain the unit of water, and dry
all of the water containing compo-
nents.
Replacing the Light bulbs
If a large amount of the ame ap-
pears grey or colourless it may be
that one or more of the light bulbs
have burnt out.
CAUTION: Allow at least 5 min-
utes for light bulbs to cool before
touching bulbs to avoid accidental
burning of skin.
Light bulb requirement: 45W,
12VAC halogen bulbs type MR 16.
Contact Dimplex Technical Service
at 1-888-346-7539 for replacement
bulbs.
1. Leaving the ame effect on, re-
move the media (if applicable),
tray and water tank (Figure 6)
and lift out the top cover.
2. View the lamps from a distance
Maintenance

14 www.dimplex.com
in front of the re and ob-
serve which lamp needs to be
changed.
3. Turn the unit off, and unplug
the cassette.
4. Leave the appliance for 5 min-
utes to allow the lamps to cool
down before removing them.
5. Remove the water tank and
top cover (Figure 6) by lifting
upwards and place in a sink.
6. Remove the defective bulb,
by gently lifting vertically and
disengaging the pins from the
lamp holder.
7. Carefully insert the two pins of
the new bulb into the two holes
in the lamp holder. Push lamp
rmly in place.
8. Gently place the media tray
and media (if applicable) back
into position.
Cleaning
It is recommended that all of the
components that contain water are
cleaned with soap and water on a
biweekly basis. A small brush has
been included to assist in cleaning
difcult items/areas, i.e. the trans-
ducer.
CAUTION: Do not put plastic
components in the dishwasher.
Filter Cleaning
The air lter can be removed and
gently rinsed with water to clean
and dried on a towel before rein-
stalling.
!NOTE: Replace the lter so that
the course black lter is facing the
front of the cassette.
Surface Cleaning
Use a warm damp cloth only to
clean surfaces of the cassette. Do
not use abrasive cleaners.
!NOTE: If you need to move the
unit ensure that all of the compo-
nents that contain water have been
emptied before relocating.
Servicing
Except for installation and cleaning
described in this manual, an autho-
rized service representative should
perform any other servicing.
Maintenance

15
ONE YEAR LIMITED WARRANTY
Products to which this limited warranty
applies
This limited warranty applies to your newly
purchased Dimplex cassette and to newly
purchased Dimplex replace surrounds
(mantels) and trims. This limited warranty
applies only to purchases made in any
province of Canada except for Yukon Terri-
tory, Nunavut, or Northwest Territories or
in any of the 50 States of the USA (and
the District of Columbia) except for Hawaii
and Alaska. This limited warranty applies
to the original purchaser of the product
only and is not transferable.
Products excluded from this limited war-
ranty
Products purchased in Yukon Territory,
Nunavut, Northwest Territories, Hawaii, or
Alaska are not covered by this limited war-
ranty. Products purchased in these States,
provinces, or territories are sold AS IS
without warranty or condition of any kind
(including, without limitation, any implied
warranties or conditions of merchant-
ability or tness for a particular purpose)
and the entire risk of as to the quality and
performance of the products is with the
purchaser, and in the event of a defect the
purchaser assumes the entire cost of all
necessary servicing or repair.
What this limited warranty covers and for
how long
Products covered by this limited warranty
have been tested and inspected prior to
shipment and, subject to the provisions
of this warranty, Dimplex warrants such
products to be free from defects in mate-
rial and workmanship for a period of 12
months from the date of the rst purchase
of such product.
The limited 12 month warranty period also
applies to any implied warranties that may
exist under applicable law. Some jurisdic-
tions do not allow limitations on how long
an implied warranty lasts, so the above
limitation may not apply to the purchaser.
What this limited warranty does not cover
This limited warranty does not apply to
products that have been repaired (except
by Dimplex or its authorized service
representatives) or otherwise altered. This
limited warranty does further not apply
to defects resulting from misuse, abuse,
accident, neglect, incorrect installation,
improper maintenance or handling, or
operation with an incorrect power source.
What you must do to get service under
this limited warranty
Defects must be brought to the attention of
Dimplex Technical Service by contacting
Dimplex at 1-888-DIMPLEX (1-888-346-
7539), or 1367 Industrial Road, Cam-
bridge Ontario, Canada N1R 7G8. Please
have proof of purchase, catalogue/model
and serial numbers available when calling.
Limited warranty service requires a proof
of purchase of the product.
What Dimplex will do in the event of a
defect
In the event a product or part covered by
this limited warranty is proven to be defec-
tive in material or workmanship during the
12 month limited warranty period you have
the following rights:
• Dimplex will in its sole discretion
either repair or replace such defec-
tive product or part without charge. If
Dimplex is unable to repair or replace
Warranty

16 www.dimplex.com
such product or part, or if repair or
replacement is not commercially
practicable or cannot be timely made,
Dimplex may, in lieu of repair or
replacement, choose to refund the
purchase price for such product or
part.
• Limited warranty service will be per-
formed solely by dealers or service
agents of Dimplex authorized to
provide limited warranty services.
• The purchaser is responsible for
removal and transportation of such
product or part (and any repaired
or replacement product or part) to
and from the authorized dealer's or
service agent's place of business.
• This limited warranty does not entitle
the purchaser to on-site or in-home
services. On-site or in-home services
may be performed at the purchaser's
specic request and expense at
Dimplex’s then-current rates for such
services.
• Dimplex will not be responsible for,
and the limited warranty services
shall not include, any expense
incurred for installation or removal of
the product or part (or any replace-
ment product or part) or any labour or
transportation costs. Such costs shall
be the purchaser’s responsibility.
What Dimplex and its dealers and service
agents are also not responsible for:
IN NO EVENT WILL DIMPLEX, OR ITS
DIRECTORS, OFFICERS, OR AGENTS,
BE LIABLE TO THE PURCHASER OR
ANY THIRD PARTY, WHETHER IN CON-
TRACT, IN TORT, OR ON ANY OTHER
BASIS, FOR ANY INDIRECT, SPECIAL,
PUNITIVE, EXEMPLARY, CONSEQUEN-
TIAL, OR INCIDENTAL LOSS, COST,
OR DAMAGE ARISING OUT OF OR
IN CONNECTION WITH THE SALE,
MAINTENANCE, USE, OR INABILITY TO
USE THE PRODUCT, EVEN IF DIMPLEX
OR ITS DIRECTORS, OFFICERS, OR
AGENTS HAVE BEEN ADVISED OF
THE POSSIBILITY OF SUCH LOSSES,
COSTS OR DAMAGES, OR IF SUCH
LOSSES, COSTS, OR DAMAGES ARE
FORESEEABLE. IN NO EVENT WILL
DIMPLEX, OR ITS OFFICERS, DIREC-
TORS, OR AGENTS BE LIABLE FOR
ANY DIRECT LOSSES, COSTS, OR
DAMAGES THAT EXCEED THE PUR-
CHASE PRICE OF THE PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO
THE PURCHASER.
How State and Provincial law apply
This limited warranty gives you specic
legal rights, and you may also have other
rights which vary from jurisdiction to juris-
diction. The provisions of the United Na-
tions Convention on Contracts for the Sale
of Goods shall not apply to this limited
warranty or the sale of products covered
by this limited warranty.
Warranty

17
Replacement Parts
© 2014 Dimplex North America Limited
Dimplex North America Limited
1367 Industrial Road
Cambridge ON
Canada N1R 7G8
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9600385600RP
Remote Control Receiver .....................................9600580100RP
Rock Media (DFI400RH) ......................................9600650100RP
Media Tray (DFI400RH) ......................................9600710100RP
Curved Tray - DFI400CH..................................... 69094941BBRP
- DFI600CH..................................... 69094961BBRP
Light Holder Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9600610200RP
Removable Rell Container with Cap ............................0441440100RP
Cap for Rell Container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0441440300RP
Top Cover Assembly .........................................9600670100RP
Water Tank ................................................0441380100RP
Fan Assembly ..............................................5300300100RP
Fan Housing Assembly .......................................9600540100RP
Fan Filter ..................................................8600300100RP
Transducer ................................................3800040100RP
Power Cord ................................................9600740100RP
Receptacle Cord ............................................9600780100RP
On/Off Switch ..............................................9600383500RP
3-Position Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9600383600RP
Transformers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9600690100RP
Potentiometer ..............................................9600640100RP
Thermostat Assembly ........................................9600620100RP
Control Knob ...............................................9600630200RP
Power Board ...............................................9600590100RP
IR Receiver with Lens ........................................9600600200RP
Light Bulbs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .RB400
Fuse Holder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9600790100RP
Fuse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9600790200RP

Manuel du propriétaire
Modèle
CDFI400RH/DFI400RH (6909051142)
CDFI400CH/DFI400CH (6909051143)
DFI600RH (6909051162)
DFI600CH (6909051163)
7213810100R02
CONSIGNES DE SÉCURITÉ IMPORTANTES : Toujours lire le présent manuel
avant d’essayer d’installer ou d’utiliser le cassette OptimystMD. Pour votre
sécurité, toujours respecter tous les avertissements et suivre les consignes de
sécurité comprises dans le présent manuel an de prévenir les blessures ou
les dommages matériels.
Pour découvrir la gamme complète de produits Dimplex,
visitez www.dimplex.com

2 www.dimplex.com
Table des matières
Toujours recourir à un technicien
qualié ou une entreprise de services
d'entretien pour faire réparer cet
appareil.
!NOTA: Marches à suivre
et techniques considérées
sufsamment importantes pour
qu'on les souligne.
MISE EN GARDE : Marches
à suivre et techniques dont le
non-respect pourrait causer des
dommages matériels.
AVERTISSEMENT : Marches à
suivre et techniques qui, si elles
ne sont pas bien respectées,
exposeront l’utilisateur à des
risques d’incendie, de blessure
grave ou de décès.
Bienvenue et félicitations ......................3
INSTRUCTIONS DE SÉCURITÉ IMPORTANTES ...4
Installation..................................6
Assemblage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Utilisation .................................11
Entretien..................................13
Garantie..................................15
Pièces de rechange..........................17

3
Bienvenue et félicitations
Merci et félicitations d’avoir acheté un cassette OptimystMD de Dimplex, le chef
de le mondial en matière de foyers électriques.
Lire ces consignes attentivement et les conserver.
MISE EN GARDE : Lire attentivement toutes les consignes et tous les
avertissements avant de procéder à l'installation. Le non-respect de ces
consignes pourrait entraîner un risque de choc électrique ou d'incendie et
annulera la garantie.
Prendre en note le numéro de modèle et le numéro de série de l'appareil
en vue d’une consultation ultérieure; les numéros de modèle et de série
se trouvent sur l'étiquette du numéro de modèle et du numéro de série de
l'appareil. Numéro de modèle
Numéro de série
IL N’EST PAS NÉCESSAIRE D’ALLER AU MAGASIN
Des questions à propos de l’assemblage ? Besoin d’information sur des
pièces détachées ? Besoin d’information à propos d’un produit sous une
garantie du fabricant ?
Contactez-nous au: www.dimplex.com/customer_support
Pour le support Dépannage et assistance technique
OU Veuillez téléphoner au numéro sans frais
1-888-DIMPLEX (1 888 346-7539)
Du lundi au vendredi de 8 h à 16 h 30 (HNE)
Veuillez avoir à portée de main les numéros de modèle et de série de votre
appareil. (Voir ci-dessous)
ARRÊT
