Owner’s Manual
Model
CS1205
7207040100R06
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this stove. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.

2
Table of Contents
Always use a qualied technician
or service agency to repair
this stove.
!NOTE: Procedures and
techniques that are considered
important enough to
emphasize.
CAUTION: Procedures
and techniques which, if not
carefully followed, will result in
damage to the equipment.
WARNING: Procedures
and techniques which, if not
carefully followed, will expose
the user to the risk of re,
serious injury, or death.
Welcome & Congratulations . . . . . . . . . . . . . . . . .3
IMPORTANT INSTRUCTIONS . . . . . . . . . . . . . . .4
Quick Reference Guide . . . . . . . . . . . . . . . . . . . . .6
Sub-Compact Stove Installation . . . . . . . . . . . . . .6
Operation................................7
Maintenance..............................8
Warranty ...............................10
ReplacementParts........................12

3
Welcome & Congratulations
Thank you and congratulations for choosing to purchase an electric
stove from Electralog.
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in
a possible electric shock, re hazard and will void the warranty.
Please record your model and serial numbers below for future
reference: model and serial numbers can be found on the Model and
Serial Number Labels of your stove.
Model Number
Serial Number
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)
Monday to Friday 8:00 a.m. to 4:30 p.m. EST
Please have your model number and product serial
number ready. (See above)

4
When using electrical appliances,
basic precautions should always be
followed to reduce the risk of re,
electric shock, and injury to persons,
including the following:
①Read all instructions before using
the Sub-Compact Stove.
②The heater is hot when in use.
To avoid burns, do not let bare skin
touch hot surfaces. The trim around
the heater outlet becomes hot during
heater operation. Keep combustible
materials, such as furniture, pillows,
bedding, papers, clothes, and
curtains at least 3 feet (0.9m) from
the front of the unit.
CAUTION: High Temperature.
Keep electrical cords, drapery, and
other furnishings at least 3 feet
(0.9m) from the front of the heater
and away from the side and rear.
③Extreme caution is necessary
when any heater is used by or near
children or invalids and whenever the
unit is left operating and unattended.
④Always unplug the Sub-Compact
Stove when not in use.
⑤Do not operate any unit with a
damaged cord or plug, or if the heater
has malfunctioned, or if the Sub-
Compact Stove has been dropped
or damaged in any manner. Return
heater to authorized service facility for
IMPORTANT INSTRUCTIONS
examination, electrical or mechanical
adjustment, or repair.
⑥Do not use outdoors.
⑦The Sub-Compact Stove is
not intended for use in bathrooms,
laundry areas and similar indoor
locations. Never locate heater where
it may fall into a bathtub or other
water container.
⑧Do not run the cord under
carpeting. Do not cover cord with
throw rugs, runners, or the like.
Arrange cord away from trafc area
and where it will not be tripped over.
⑨To disconnect the unit, turn the
controls off, then remove the plug
from the outlet.
⑩Do not insert or allow foreign
objects to enter any ventilation or
exhaust opening as this may cause
an electric shock or re, or damage to
the heater.
⑪ To prevent a possible re, do
not block air intake or exhaust in any
manner. Do not use on soft surfaces,
like a bed, where openings may
become blocked.
⑫All electrical heaters have hot
and arcing or sparking parts inside.
Do not use in areas where gasoline,
paint, or ammable liquids are used
or stored or where the unit will be

5
SAVE THESE INSTRUCTIONS
exposed to ammable vapors.
⑬Do not modify the Sub-Compact
Stove. Use it only as described in this
manual. Any other use not
recommended by the manufacturer
may cause re, electric shock or
injury to persons.
⑭To reduce the risk of electric
shock, this appliance has a polarized
plug (one blade is wider than the
other). This plug will t in a polarized
outlet only one way. If the plug does
not t fully in the outlet, reverse the
plug. If it still does not t, contact
a qualied electrician to install the
proper outlet. Do not change the
plug in any way. Avoid the use of an
extension cord. Extension cords may
overheat and cause a risk of re. If
you must use an extension cord, the
cord must be No. 14 AWG minimum
size and rated no less than 1875
Watts.
IMPORTANT INSTRUCTIONS
⑮Do not burn wood or other
materials in the Sub-Compact Stove.
⑯Do not strike the clear door
panel.
⑰ Always use a certied electrician
should new circuits or outlets be
required.
⑱Always use properly grounded,
fused and polarized outlets.
⑲Disconnect all power supply
before performing any cleaning,
maintenance or relocation of the unit.
⑳When transporting or storing the
unit and cord, keep in a dry place,
free from excessive vibration and
store so as to avoid damage.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICABLE PARTS INSIDE

6
Sub-Compact Stove Installation
!NOTE: A 15 Amp, 120 Volt
alternating current (VAC)
circuit is required. A dedicated
circuit is preferred but not
essential in all cases. A
dedicated circuit will be
required if, after installation,
the circuit breaker trips or
blows fuses on a regular basis
when the heater is operating.
Additional appliances on the
same circuit may exceed the
current rating of the circuit
breaker.
WARNING: Ensure the power
cord is not installed so that
it is pinched or against a
sharp edge and ensure that
the power cord is stored or
secured to avoid tripping or
snagging to reduce the risk of
re, electric shock or injury to
persons.
Construction and electrical
wiring must comply with local
building codes and other
applicable regulations to
Quick Reference Guide
① Prior to the rst use of the
Sub-Compact Stove verify the
following:
• Are the circuit breakers for the
unit on?
• Are the light bulbs in your
Sub-Compact Stove loose? (to
check, follow the instructions
for replacing the light bulbs
under the Maintenance section
of this manual)
②The heater on your Sub-
Compact Stove may emit a slight,
harmless odor when rst used.
This odor is a normal condition
caused by the initial heating of
internal heater parts and will not
occur again.
③If you have any technical
questions or concerns regarding
the operation of your Sub-
Compact Stove, or require service
contact Customer Service at
1-888-346-7539 before returning
the product to the point of
purchase.

7
reduce the risk of re, electric
shock and injury to persons.
Do not attempt to wire your
own new outlets or circuits. To
reduce the risk of re, electric
shock or injury to persons,
always use a licensed
electrician.
Installation
① Make sure the unit’s Main On/
Off Switch is switched Off (refer to
operating instruction section).
② Plug the unit into a 15 Amp,
120 VAC outlet. If the cord
does not reach, you may use
an extension cord rated for a
minimum of 1875 Watts.
Sub-Compact Stove Installation
Operation
The controls are located on
the right side of the heater pan
(Figure 1).
A. Main On/Off Switch
The Main On/Off switch supplies
power to all unit functions (heat/
ame).
B. Low Heat On/Off Switch
The Low Heat On/Off Switch
supplies power to the heater fan
and the heater element. When the
switch is in the On position the
heater operates on Low.
C. High Heat On/Off Switch
The High Heat On/Off Switch
Figure 1
A
BC

8
Figure 2
Bulb
Screws
(5)
Access Panel
Operation
supplies power to the heater fan
and the heater element, when the
switch is in the ON position the
heater operates on High.
!NOTE: The Low Heat On/
Off Switch must also be in the
On position for the high heat
setting to operate.
Resetting the Temperature
Cutoff Switch
Should the heater overheat, an
automatic cut out will turn the
heater off and it will not come
back on without being reset. It
can be reset by switching the
Main On/Off Switch to Off and
waiting ve (5) minutes before
switching the unit back on.
CAUTION: If you need to
continuously reset the heater,
unplug the unit and call
Customer Service at
1-888-346-7539.
Maintenance
 WARNING: Disconnect
power before attempting any
maintenance or cleaning to
reduce the risk of re, electric
shock or damage to persons.
Light Bulb Replacement
Allow at least ve (5) minutes for
the light bulb to cool off before
touching, to avoid accidental
burning of the skin. The light bulb
needs to be replaced when you

9
notice a dark section of the ame
or when the clarity and detail
of the log exterior disappears.
There is one (1) bulb located at
the back of the unit behind the
access panel.
Light Bulb Requirement
Quantity of one (1) clear
chandelier or candelabra bulb
with an E-12 (small) socket base,
and 60 Watt rating.
To Replace the Bulb (Figure 2)
① Remove the ve Phillips
screws from the access panel,
located on the back of the unit,
and remove access panel.
② Locate and examine the bulb
to determine if replacement is
required.
③Unscrew the bulb counter
clockwise.
④Insert and install new bulb.
⑤Secure access panel to unit.
Clear Door Panel Cleaning
The clear door is cleaned in
the factory during the assembly
operation. During shipment,
installation, handling, etc., the
Maintenance
clear door may collect dust
particles. These can be removed
by dusting lightly with a clean, dry
cloth.
To remove ngerprints or other
marks, the clear doors can be
cleaned with a damp cloth. The
clear door should be completely
dried with a lint free cloth to
prevent water spots. To prevent
scratching, do not use abrasive
cleaners or spray liquids on the
clear door surface.
Sub-Compact Stove
Surface Cleaning
Use warm water only to clean
painted surfaces of the Sub-
Compact Stove. Do not use
abrasive cleaners.
Servicing
Except for light bulb replacement
and cleaning described
above, an authorized service
representative should perform
any other servicing.

10
Products to which this limited warranty
applies
This limited warranty applies to the
following models of your newly purchased
Electralog Sub-Compact Stove CS1205
and to newly purchased Electralog stove
surrounds (mantels) and trims. This limited
warranty applies only to purchases made
in any province of Canada except for
Yukon Territory, Nunavut, or Northwest
Territories or in any of the 50 States of
the USA (and the District of Columbia)
except for Hawaii and Alaska. This limited
warranty applies to the original purchaser
of the product only and is not transferable.
Products excluded from this limited
warranty
Light bulbs are not covered by this limited
warranty and are the sole responsibility of
the owner/purchaser. Products purchased
in Yukon Territory, Nunavut, Northwest
Territories, Hawaii, or Alaska are not
covered by this limited warranty. Products
purchased in these States, provinces, or
territories are sold AS IS without warranty
or condition of any kind (including, without
limitation, any implied warranties or
conditions of merchantability or tness for
a particular purpose) and the entire risk of
as to the quality and performance of the
products is with the purchaser, and in the
event of a defect the purchaser assumes
the entire cost of all necessary servicing
or repair.
What this limited warranty covers and for
how long
Products covered by this limited warranty
have been tested and inspected prior to
shipment and, subject to the provisions
of this warranty, Electralog warrants
such products to be free from defects in
material and workmanship for a period of
90 days from the date of the rst purchase
of such product.
The limited 90 day warranty period also
applies to any implied warranties that
may exist under applicable law. Some
jurisdictions do not allow limitations on
how long an implied warranty lasts, so
the above limitation may not apply to the
purchaser.
What this limited warranty does not cover
This limited warranty does not apply to
products that have been repaired (except
by Electralog or its authorized service
representatives) or otherwise altered. This
limited warranty does further not apply
to defects resulting from misuse, abuse,
accident, neglect, incorrect installation,
improper maintenance or handling, or
operation with an incorrect power source.
What to do when your unit ceases to
operate as described in this manual
Defects must be brought to the attention of
Electralog Technical Service by contacting
Electralog at 1-888-346-7539, or 1367
Industrial Road, Cambridge Ontario,
Canada N1R 7G8. Please have proof of
purchase, catalogue/model and serial
numbers available when calling. Limited
warranty service requires a proof of
purchase of the product.
What Electralog will do in the event of a
defect
In the event a product or part covered
by this limited warranty is proven to be
defective in material or workmanship
during the 90 day limited warranty period
you have the following rights:
Warranty

11
• Electralog will in its sole discretion
replace such defective part(s) without
charge, or if part replacement proves
not to be commercially practicable
or cannot be timely made, Electralog
may, in lieu of replacing part(s) choose
to replace the unit.
• This limited warranty does not entitle
the purchaser to on-site or in-home
services. On-site or in-home services
may be performed at the purchaser’s
specic request and expense at
Electralog’s then-current rates for such
services.
• The purchaser is responsible for
removal and transportation of such
product or part (and any repaired or
replacement product or part) to and
from the authorized dealer’s or service
agent’s place of business.
• Electralog will not be responsible for,
and the limited warranty services shall
not include, any expense incurred for
installation or removal of the product
or part (or any replacement product or
part) or any labour or transportation
costs. Such costs shall be the
purchaser’s responsibility.
What Electralog and its dealers and
service agents are also not responsible
for:
IN NO EVENT WILL ELECTRALOG,
OR ITS DIRECTORS, OFFICERS,
OR AGENTS, BE LIABLE TO THE
PURCHASER OR ANY THIRD PARTY,
WHETHER IN CONTRACT, IN TORT,
OR ON ANY OTHER BASIS, FOR
ANY INDIRECT, SPECIAL, PUNITIVE,
EXEMPLARY, CONSEQUENTIAL, OR
INCIDENTAL LOSS, COST, OR DAMAGE
ARISING OUT OF OR IN CONNECTION
WITH THE SALE, MAINTENANCE,
USE, OR INABILITY TO USE THE
PRODUCT, EVEN IF ELECTRALOG
OR ITS DIRECTORS, OFFICERS, OR
AGENTS HAVE BEEN ADVISED OF
THE POSSIBILITY OF SUCH LOSSES,
COSTS OR DAMAGES, OR IF SUCH
LOSSES, COSTS, OR DAMAGES ARE
FORESEEABLE. IN NO EVENT WILL
ELECTRALOG, OR ITS OFFICERS,
DIRECTORS, OR AGENTS BE LIABLE
FOR ANY DIRECT LOSSES, COSTS,
OR DAMAGES THAT EXCEED THE
PURCHASE PRICE OF THE PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO
THE PURCHASER.
How State and Provincial law apply
This limited warranty gives you
specic legal rights, and you may
also have other rights which vary
from jurisdiction to jurisdiction. The
provisions of the United Nations
Convention on Contracts for the Sale
of Goods shall not apply to this limited
warranty or the sale of products
covered by this limited warranty.
Warranty

12
© 2011 Dimplex North America Limited
Electralog
1367 Industrial Road
Cambridge ON
Canada N1R 7G8
Logset Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0477850100RP
Motor120V....................................... 2000210200RP
Heater Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2200491000RP
On/OffSwitch ..................................... 2800070700RP
Heater On/Off Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2800070200RP
Cord Set 120V..................................... 4100090201RP
Lampholder....................................... 4200090100RP
Reector Rod. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5900250100RP
Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5900530200RP
Foot ............................................. 0477830159RP
Terminal Block ..................................... 4000070100RP
Capacitor ......................................... 2300030100RP
Replacement Parts
