Dimplex ELECTRALOG CS4416 User manual

Owner’s Manual
Models
CS4416
CS3311
CS2307
7207400100R08
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this stove. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.
CS3311 Pictured

2
Table of Contents
Always use a qualied technician
or service agency to repair
this stove.
!NOTE: Procedures and
techniques that are considered
important enough to
emphasize.
CAUTION: Procedures
and techniques which, if not
carefully followed, will result in
damage to the equipment.
WARNING: Procedures
and techniques which, if not
carefully followed, will expose
the user to the risk of re,
serious injury, or death.
Welcome & Congratulations ........... 3
IMPORTANT INSTRUCTIONS . . . . . . . . . . . . . . .4
Quick Reference Guide ............... 7
Compact Stove Installation ............ 7
Operation .......................... 8
Maintenance....................... 10
Warranty ...............................12
ReplacementParts........................14

3
Welcome & Congratulations
Thank you and congratulations for choosing to purchase an electric
stove from Electralog.
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in a
possible electric shock, re hazard and will void the warranty.
Please record your model and serial numbers below for future
reference: model and serial numbers can be found on the Model and
Serial Number labels of your stove.
Model Number
Serial Number
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)
Monday to Friday 8:00 a.m. to 4:30 p.m. EST
Please have your model number and product serial
number ready. (See above)

4
When using electrical appliances,
basic precautions should always be
followed to reduce the risk of re,
electric shock, and injury to persons,
including the following:
①Read all instructions before using
the Compact Stove.
②The heater is hot when in use.
To avoid burns, do not let bare skin
touch hot surfaces. The trim around
the heater outlet becomes hot during
heater operation. Keep combustible
materials, such as furniture, pillows,
bedding, papers, clothes, and
curtains at least 3 feet (0.9m) from
the front of the unit.
CAUTION: High Temperature.
Keep electrical cords, drapery, and
other furnishings at least 3 feet
(0.9m) from the front of the heater
and away from the side and rear.
③Extreme caution is necessary
when any heater is used by or
near children or invalids and
whenever the unit is left operating
and unattended.
④Always unplug the Compact
Stove when not in use.
⑤Do not operate any unit with a
damaged cord or plug, or if the heater
has malfunctioned, or if the Compact
Stove has been dropped or damaged
IMPORTANT INSTRUCTIONS
in any manner. Return heater
to authorized service facility for
examination, electrical or mechanical
adjustment, or repair.
⑥Do not use outdoors.
⑦The Compact Stove is not
intended for use in bathrooms,
laundry areas and similar indoor
locations. Never locate heater where
it may fall into a bathtub or other
water container.
⑧Do not run the cord under
carpeting. Do not cover cord with
throw rugs, runners, or the like.
Arrange cord away from trafc area
and where it will not be tripped over.
⑨To disconnect the unit, turn the
controls off, then remove the plug
from the outlet.
⑩Do not insert or allow foreign
objects to enter any ventilation or
exhaust opening as this may cause
an electric shock or re, or damage to
the heater.
⑪ To prevent a possible re, do
not block air intake or exhaust in any
manner. Do not use on soft surfaces,
like a bed, where openings may
become blocked.
⑫All electrical heaters have hot
and arcing or sparking parts inside.

5
SAVE THESE INSTRUCTIONS
Do not use in areas where gasoline,
paint, or ammable liquids are used
or stored or where the unit will be
exposed to ammable vapors.
⑬Do not modify the Compact
Stove. Use it only as described in
this manual. Any other use not
recommended by the manufacturer
may cause re, electric shock or
injury to persons.
⑭To reduce the risk of electric
shock, this appliance has a polarized
plug (one blade is wider than the
other). This plug will t in a polarized
outlet only one way. If the plug does
not t fully in the outlet, reverse the
plug. If it still does not t, contact
a qualied electrician to install the
proper outlet. Do not change the
plug in any way. Avoid the use of an
extension cord. Plug the cord directly
into an appropriate wall receptacle.
⑮Do not burn wood or other
materials in the Compact Stove.
⑯Do not strike the clear door
panel.
⑰ Always use a certied electrician
should new circuits or outlets be
required.
⑱Always use properly grounded,
fused and polarized outlets.
⑲Disconnect all power supply
before performing any cleaning,
maintenance or relocation of the unit.
⑳When transporting or storing the
unit and cord, keep in a dry place,
free from excessive vibration and
store so as to avoid damage.
IMPORTANT INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICABLE PARTS INSIDE

6
IMPORTANT INSTRUCTIONS
CAUTION: This equipment has
been tested and found to comply with
the limits for Class B digital device,
pursuant to part 15 of the FCC
Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses and can radiate
radio frequency energy and, if not
installed and used in accordance with
the instructions, may cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
Reorient or relocate the receiving•
antenna.
Increase the separation between•
the equipment and the receiver.
Connect the equipment into an•
outlet on a circuit different from
that to which the receiver is
connected.
Consult the dealer or an•
experienced radio/TV technician
for help.
Operation is subject to the following
two conditions: (1) this device may
not cause interference and (2) this
device must accept any interference,
including interference that may cause
undesired operation of the device.
WARNING: Remote control
contains small batteries. Keep away
from children. If swallowed, seek
medical attention immediately.
WARNING: Do not install battery
backwards, charge, put in re or mix
with used or other battery types - may
explode or leak causing injury.
!NOTE: Changes or modications
not expressly approved by the party
responsible for compliance could
void user's authority to operate the
equipment.

7
Quick Reference Guide
① Prior to the rst use of
the Compact Stove verify the
following:
Are the circuit breakers for•
the unit on?
Are the light bulbs in your•
Compact Stove loose? (To
check, follow the instructions
for replacing the light bulbs
under the Maintenance
section of this manual)
②The heater on your Compact
Stove may emit a slight, harmless
odor when rst used. This odor is
a normal condition caused by the
initial heating of internal heater
parts and will not occur again.
Compact Stove Installation
!NOTE: A 15 Amp, 120
Volt circuit is required. A
dedicated circuit is preferred
but not essential in all cases.
A dedicated circuit will be
required if, after installation,
the circuit breaker trips or
fuses blow on a regular basis
when the heater is operating.
Additional appliances on the
same circuit may exceed the
current rating of the circuit
breaker.
WARNING: Ensure the
power cord is not installed so
that it is pinched or against a
sharp edge and ensure that
the power cord is stored or
secured to avoid tripping or
snagging to reduce the risk of
re, electric shock or injury to
persons.
Construction and electrical
wiring must comply with local
building codes and other
applicable regulations to
reduce the risk of re, electric
shock and injury to persons.
Do not attempt to wire your
own new outlets or circuits. To
reduce the risk of re, electric
shock or injury to persons,
always use a licensed
electrician.
① Make sure the unit’s 3-Position
switch is switched OFF (refer to
operating instruction section).
② Plug the unit directly into a 15
Amp, 120 VAC outlet.

8
Operation
fan and the heater element.
When the switch is in the on “ I”
position the heater operates if the
thermostat calls for heat.
C. Heater Thermostat Control
To adjust the temperature to
your individual requirements,
turn the thermostat control
clockwise all the way to turn
on the heater. When the room
reaches the desired temperature,
turn the thermostat knob counter
clockwise until you hear a click.
Leave in this position to maintain
the room temperature at this
setting. For additional heat, turn
clockwise until you hear the click
again and the heater will turn on.
!NOTE: When the heater
is switched on, the heater
fan will operate. The heater
element may or may not be on
depending on the thermostat
control setting (see “Heater
Thermostat Control”).
Resetting the Temperature
Cutoff Switch
Should the heater overheat, an
automatic cut out will turn the
heater off and it will not come
back on without being reset. It
can be reset by switching the
Figure 1
A
B
C
A. 3-Position Switch
The switch has two On positions
marked with “ ” and “MANUAL”.
The “MANUAL” position is for
manual operation. In this position
the built-in remote control is by-
passed.
The “ ” position is for operating
the unit with the provided remote
control. When in this position
the unit is operated with the ON
and OFF buttons of the remote
control.
When the switch is in the center
“ O” position the unit is off.
B. Heater On/Off Switch
The Heater On/Off Switch
supplies power to the heater

9
Operation
3-Position Switch to Off (“O”) and
waiting ve (5) minutes before
switching the unit back on.
CAUTION: If you need to
continuously reset the heater,
unplug the unit and call
Customer Service at
1-888-346-7539.
Remote Operation
The Compact Stove is supplied
with an integrated On/Off remote
control.
!NOTE: Ensure that the
stove's 3-Position Switch is set
to the remote Control setting
(“ ” position).
!NOTE: Before attempting any
operation with the remote, pull
the plastic insulator strip out from
between the remote casing and
battery cover (Figure 2).
To operate, push the ON button
to turn stove on, push the OFF
button to turn the stove off.
Remote Initialization/
Reprogramming
In the event that your remote
control ceases to operate your
replace, follow these steps to
re-initialize the remote control and
the remote control receiver in the
replace:
Place the1. 3-Position Switch
(Figure 1A) in the OFF (“O”)
position.
Wait a minimum of ve (5) 2.
seconds and then place the
3-Position Switch in the
Remote Control (“ ”) position.
Within3. 10 seconds of
changing the switch position,
press the ON button located
on the remote control
(Figure 2).
This will synchronize the remote
control and the replace receiver.
!NOTE: You will have only 10
seconds to perform this last
step. Failure to do so will result
in these steps needing to be
followed again.
Figure 2
Off Button
On
Button
Battery
Cover
Plastic
Strip

10
Close the battery cover.3.
Battery must be recycled
or disposed of properly.
Check with your Local
Authority or Retailer for recycling
advice in your area.
 WARNING: Disconnect
power before attempting any
maintenance or cleaning to
reduce the risk of re, electric
shock or damage to persons.
Helpful Hints: It is a good idea to
replace all light bulbs at one time
if they are close to the end of their
rated life. Group replacement will
reduce the number of times you
need to open the unit to replace
light bulbs.
Light Bulb Replacement
Allow at least ve (5) minutes for
the light bulbs to cool off before
touching to avoid accidental
burning of the skin. Light bulbs
needs to be replaced when you
notice a dark section of the ame
or when the clarity and detail of
Maintenance
the log exterior disappears.
There are two (2) bulbs located
under the Log Set which generate
the ames and embers.
Tools Required: Phillips
screwdriver
Light Bulb Requirements
Quantity of two (2) clear
chandelier or candelabra bulbs
with an E-12 (small) socket base,
and 25 Watt rating.
To Replace the Light Bulbs
① Remove the ve (5) screws
from the access panel, located on
the back of the unit, and remove
access panel (Figure 3).
② Locate and examine the bulbs
to determine if replacement is
required.
Operation
Battery Replacement
Slide battery cover open on1.
the remote control (Figure 2).
Correctly install one (1) 122.
Volt (A23) battery in the
battery holder.

11
③Unscrew the bulb(s) counter
clockwise.
④Insert and install new bulbs.
⑤Secure access panel to unit.
Clear Door Panel Cleaning
The clear door is cleaned in
the factory during the assembly
operation. During shipment,
installation, handling, etc., the
clear door may collect dust
particles. These can be removed
by dusting lightly with a clean, dry
cloth.
To remove ngerprints or other
marks, the clear doors can be
cleaned with a damp cloth. The
clear door should be completely
dried with a lint free cloth to
prevent water spots.
To prevent scratching, do not use
Maintenance
abrasive cleaners or spray liquids
on the clear door surface.
Compact Stove Surface
Cleaning
Use warm water only to clean
painted surfaces of the Compact
Stove. Do not use abrasive
cleaners.
Servicing
Except for light bulb replacement
and cleaning described above, an
authorized service representative
should perform any other
servicing.
Figure 3
Bulbs (2)
Screws
(5)
Access Panel

12
Products to which this limited warranty
applies
This limited warranty applies to the
following models of your newly purchased
Electralog electric stove CS4416, CS3311,
and CS2307. This limited warranty
applies only to purchases made in any
province of Canada except for Yukon
Territory, Nunavut, or Northwest Territories
or in any of the 50 States of the USA (and
the District of Columbia) except for Hawaii
and Alaska. This limited warranty applies
to the original purchaser of the product
only and is not transferable.
Products excluded from this limited
warranty
Light bulbs are not covered by this limited
warranty and are the sole responsibility of
the owner/purchaser. Products purchased
in Yukon Territory, Nunavut, Northwest
Territories, Hawaii, or Alaska are not
covered by this limited warranty. Products
purchased in these States, provinces, or
territories are sold AS IS without warranty
or condition of any kind (including, without
limitation, any implied warranties or
conditions of merchantability or tness for
a particular purpose) and the entire risk of
as to the quality and performance of the
products is with the purchaser, and in the
event of a defect the purchaser assumes
the entire cost of all necessary servicing
or repair.
What this limited warranty covers and for
how long
Products covered by this limited warranty
have been tested and inspected prior to
shipment and, subject to the provisions
of this warranty, Electralog warrants
such products to be free from defects in
material and workmanship for a period of
90 days from the date of the rst purchase
of such product.
The limited 90 day warranty period also
applies to any implied warranties that
may exist under applicable law. Some
jurisdictions do not allow limitations on
how long an implied warranty lasts, so
the above limitation may not apply to the
purchaser.
What this limited warranty does not cover
This limited warranty does not apply to
products that have been repaired (except
by Electralog or its authorized service
representatives) or otherwise altered. This
limited warranty does further not apply
to defects resulting from misuse, abuse,
accident, neglect, incorrect installation,
improper maintenance or handling, or
operation with an incorrect power source.
What to do when your unit ceases to
operate as described in this manual
Defects must be brought to the attention of
Electralog Technical Service by contacting
Electralog at 1-888-346-7539, or 1367
Industrial Road, Cambridge Ontario,
Canada N1R 7G8. Please have proof
of purchase, catalogue/model and serial
numbers available when calling. Limited
warranty service requires a proof of
purchase of the product.
What Electralog will do in the event of a
defect
In the event a product or part covered
by this limited warranty is proven to be
defective in material or workmanship
during the 90 day limited warranty period
you have the following rights:
Warranty

13
Electralog• will in its sole discretion
replace such defective part(s) without
charge, or if part replacement proves
not to be commercially practicable
or cannot be timely made, Electralog
may, in lieu of replacing part(s) choose
to replace the unit.
This limited warranty does not entitle•
the purchaser to on-site or in-home
services. On-site or in-home services
may be performed at the purchaser’s
specic request and expense at
Electralog's then-current rates for such
services.
The purchaser is responsible for•
removal and transportation of such
product or part (and any repaired or
replacement product or part) to and
from the authorized dealer’s or service
agent’s place of business.
Electralog• will not be responsible for,
and the limited warranty services shall
not include, any expense incurred for
installation or removal of the product
or part (or any replacement product or
part) or any labour or transportation
costs. Such costs shall be the
purchaser’s responsibility.
What Electralog and its dealers and
service agents are also not responsible
for:
IN NO EVENT WILL ELECTRALOG,
OR ITS DIRECTORS, OFFICERS,
OR AGENTS, BE LIABLE TO THE
PURCHASER OR ANY THIRD PARTY,
WHETHER IN CONTRACT, IN TORT,
OR ON ANY OTHER BASIS, FOR
ANY INDIRECT, SPECIAL, PUNITIVE,
EXEMPLARY, CONSEQUENTIAL, OR
INCIDENTAL LOSS, COST, OR DAMAGE
ARISING OUT OF OR IN CONNECTION
WITH THE SALE, MAINTENANCE,
USE, OR INABILITY TO USE THE
PRODUCT, EVEN IF ELECTRALOG
OR ITS DIRECTORS, OFFICERS, OR
AGENTS HAVE BEEN ADVISED OF
THE POSSIBILITY OF SUCH LOSSES,
COSTS OR DAMAGES, OR IF SUCH
LOSSES, COSTS, OR DAMAGES ARE
FORESEEABLE. IN NO EVENT WILL
ELECTRALOG, OR ITS OFFICERS,
DIRECTORS, OR AGENTS BE LIABLE
FOR ANY DIRECT LOSSES, COSTS,
OR DAMAGES THAT EXCEED THE
PURCHASE PRICE OF THE PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO
THE PURCHASER.
How State and Provincial law apply
This limited warranty gives you
specic legal rights, and you may
also have other rights which vary
from jurisdiction to jurisdiction. The
provisions of the United Nations
Convention on Contracts for the Sale
of Goods shall not apply to this limited
warranty or the sale of products
covered by this limited warranty.
Warranty

14
© 2012 Dimplex North America Limited
Approved for use in the United States and Canada
Electralog
1367 Industrial Road
Cambridge ON
Canada N1R 7G8
Clear Plastic Door Panel ............................. 0438490100RP
Logset Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0438500400RP
Top Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1104120260RP
FlickerMotor...................................... 2000210100RP
Heater Assembly (with cutout)......................... 2200491000RP
Thermostat ....................................... 2300150100RP
3-Position Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2800071100RP
Heater On/Off Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2800070200RP
Cord Set 120V..................................... 4100090202RP
Lampholder....................................... 4200090100RP
Reector Rod. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5900081100RP
Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5900640100RP
Thermostat Knob. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8800000300RP
Foot ............................................. 0438460160RP
Door Knob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8800340100RP
Therminal Block. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4000070100RP
Capacitor ......................................... 2300030100RP
Replacement Parts
