iSolution iMove 50S User manual

iMove 50S
User Guide
Professional Entertainment Technology

1A
TABLE OF CONTENTS
1. Safety Instructions
2. Technical Specifications
3. How To Set The Unit
4. How To Control The Unit
5. Troubleshooting
6. Fixture Cleaning

2A
1. Safety Instruction
WARNING
Please keep this User Guide for future use.. If you sell the unit to another user, be sure
that they also receive this user manual.
Unpack and check carefully there is no transportation damage before using the unit.
Before operating, ensure that the voltage and frequency of the power supply match the
power requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order to avoid electric
shock.
The unit is for indoor use only. Use only in a dry location.
The unit must be installed in a location with adequate ventilation, at least 50cm from
adjacent surfaces. Be sure that no ventilation slots are blocked.
Disconnect main power before replacement or servicing.
Make sure there is no flammable materials close to the unit while operating as it is a fire
hazard.
Always use a safety cable when installing this unit. Don’t carry the unit by its head only,
but always carry it using the base.
The maximum ambient temperature is to: 40℃. Don’t operate it where the temperature is
higher than this.
Unit surface temperature may reach up to 85℃. Don’t touch the housing bare-hand during
its operation. Turn off the power and allow about 15 minutes for the unit to cool down
before replacing or servicing.
In the event of serious operating problem, stop using the unit immediately. Never try to
repair the unit by yourself. Repairs carried out by unskilled people can lead to damage or
malfunction. Please contact the nearest authorized technical assistance center. Always
use the same type spare parts.
Do not touch any wire during operation as high voltage might be causing electric shock.
Warning
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or
moisture.
Do not open the unit within five minutes after switching off.
Please read carefully the instruction, which includes important information
about the installation, usage and maintenance.

3A
The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly
damaged.
Caution
There are no user serviceable parts inside this unit. Do not open the housing or attempt
any repairs yourself. In the unlikely event your unit may require service, please contact
your nearest dealer.
Installation
The unit should be mounted via its screw holes on the bracket. Always ensure that the unit
is firmly fixed to avoid vibration and slipping while operating. And make sure that the
structure to which you are attaching the unit is secure and is able to support a weight of 10
times of the unit’s weight. Also always use a safety cable that can hold 12 times of the
weight of the unit when installing the fixture.
The equipment must be fixed by professionals. And it must be fixed at a place where is out
of the touch of people and has no one pass by or under it.
2. Technical Specification
iMove 50S is the combination of the latest high powered LED technology, excellent optics
and great features.
DMX control: 8/11 channels selectable.
3 operation modes: DMX, Master/Slave, Sound Activation.
Great built-in lighting programs under master/slave mode triggered by music.
Optional CA-8 easy controller or CA-9 RTX (wireless easy control kit) for instant lighting
shows.
Rotating gobo wheel with 6 gobos plus white.
Color wheel with 8 colors plus white.
Beam angle: 15°
Automatic Pan/Tilt position correction.
Smooth 0~100% dimming and variable strobe speeds.
LED display for easy navigation and addressing.
Perfect for disco, club, bar, parties and Mobile DJs.
Pan: 540°. Tilt: 270°

4A
Voltage: 120V/230V, 50/60Hz
Power consumption: 112W at 230V
Light source: 1 x 50W LED
Dimensions: 299 x 247 x 420 mm
Φgobo wheel=109 mm
Φgobo =19 mm
Weight: 10 kgs
Photometric diagram:
3. How To Set The Unit
3.1 Control panel

5A
Display
To show the various menus and the selected functions
LED
DMX
On
DMX input present
MASTER
On
Master Mode
SLAVE
On
Slave Mode
SOUND
Flashing
Sound activation
Button
MENU
To select the programming functions
DOWN
To go backward in the selected functions
UP
To go forward in the selected functions
ENTER
To confirm the selected functions
Only for remote control
Connecting with CA-8/CA-9/CA-9RTX to control the unit for Stand by, Function and Mode
function.
Mains input
Connect to power supply.
DMX input/output
For DMX512 link, use 3/5-pin XLR cable to link the unit together.
3.2 Main Function
To select any of the given functions, press the MENU button up to when the required one is
showing on the display. Select the function by pressing the ENTER button and the display
will blink. Use the DOWN and UP buttons to change the mode. Once the required mode has
been selected, press the ENTER button to setup, to go back to the functions without any
change press the MENU button again. Hold and press the MENU button for about one
second or wait for one minute to exit the menu mode.
The main functions are showing below:

6A

7A
DMX 512 Address Setting
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to change the DMX512 address. Once the
address has been selected, press the ENTER button to setup, to go back to the functions
without any change press the MENU button again. Hold and press the MENU button for
about one second or wait for one minute to exit the menu mode.
Channel Mode
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the (8 channel mode) or
(11 channel mode) mode. Once the mode has been selected, press the ENTER
button to setup, to go back to the functions without any change press the MENU button
again.Hold and press the MENU button for about one second or wait for one minute to exit
the menu mode.
Show Mode
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the (show 1) or
(show 2) or (show 3) or (show 4) mode. Once the mode has been selected,
press the ENTER button to setup, to go back to the functions without any change press the
MENU button again. Hold and press the MENU button for about one second or wait for one
minute to exit the menu mode.
Split Color Mode
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the (Split color mode) or
(normal) mode. Once the mode has been selected, press the ENTER button to
setup, to go back to the functions without any change press the MENU button again. Hold
and press the MENU button for about one second or wait for one minute to exit the menu
mode.
Slave Mode
Press the MENU button to show on the display. Press the ENTER button and the

8A
display will blink. Use the DOWN and UP buttons to select the (normal) or
(2 light show) mode. Once the mode has been selected, press the ENTER button to setup,
to go back to the functions without any change press the MENU button again. Hold and
press the MENU button for about one second or wait for one minute to exit the menu mode.
Blackout Mode
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the (yes blackout) or
(no blackout) mode. Once the mode has been selected, press the ENTER button to
setup, to go back to the functions without any change press the MENU button again. Hold
and press the MENU button for about one second or wait for one minute to exit the menu
mode.
Sound Mode
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the (sound on) or
(sound off) mode. Once the mode has been selected, press the ENTER button to
setup, to go back to the functions without any change press the MENU button again. Hold
and press the MENU button for about one second or wait for one minute to exit the menu
mode.
Sound Mode
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the …mode.
Once the mode has been selected, press the ENTER button to setup, to go back to the
functions without any change press the MENU button again. Hold and press the MENU
button for about one second or wait for one minute to exit the menu mode.
Pan Inversion
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the (normal) or
(pan inversion) mode. Once the mode has been selected, press the ENTER button to setup,
to go back to the functions without any change press the MENU button again. Hold and
press the MENU button for about one second or wait for one minute to exit the menu mode.

9A
Tilt Inversion
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the (normal) or
(tilt inversion) mode. Once the mode has been selected, press the ENTER button to setup,
to go back to the functions without any change press the MENU button again.Hold and
press the MENU button for about one second or wait for one minute to exit the menu mode.
Led Display
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP buttons to select the (Led on) or
(Led off) mode. Once the mode has been selected, press the ENTER button to setup, to go
back to the functions without any change press the MENU button again. Hold and press the
MENU button for about one second or wait for one minute to exit the menu mode.
Display Inversion
It is good for you to install the unit on the floor or under ceiling. Press the MENU button to
show on the display. Press the ENTER button to change to the mode
(display normal), It will automatically store after 8 seconds. Or press the ENTER button
again return to the mode (display inversion). To go back to the functions press the
MENU button. Hold and press the MENU button for about one second or wait for one minute
to exit the menu mode.
Display normal mode for the fixture putting on the floor.
Display inversion mode for the fixture fixing under ceiling.
Function Delay
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP button to select the 0(No Delay) or 1/2/3 (Wait for
1/2/3 seconds before these Functions of 15/16 CH are activated/deactivated) mode. Once
the mode has been selected, press the ENTER button to setup, to go back to the functions
without any change press the MENU button again. Hold and press the MENU button about
one second or wait for one minute to exit the menu mode.

10A
Dimmer Calibrate
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP button to calibrate the dimmer for a maximum output
from (limited to 50% of the really max. output) to (maximum output is not
limited). Once the mode has been selected, press the ENTER button to setup, to go back to
the functions without any change press the MENU button again.Hold and press the MENU
button about one second or wait for one minute to exit the menu mode.
Self-Test
Press the MENU button to show on the display. Press the ENTER button and the unit
will run self-test by built-in program. To go back to the functions press the MENU button again.
Hold and press the MENU button for about one second or wait for one minute to exit the menu
mode.
Temperature Test
Press the MENU button to show on the display. Press the ENTER button and the
display will show the temperature of the unit. To go back to the functions press the MENU
button again. Hold and press the MENU button for about one second or wait for one minute
to exit the menu mode.
Fixture Hours
Press the MENU button to show on the display. Press the ENTER button and the
display will show the number of working hours of the unit. To go back to the functions press
the MENU button again. Hold and press the MENU button for about one second or wait for
one minute to exit the menu mode.
Software version
Press the MENU button to show on the display. Press the ENTER button and the
display will show the version of software of the unit. To go back to the functions press the
MENU button again. Hold and press the MENU button for about one second or wait for one
minute to exit the menu mode.

11A
Defaults Setting
Press the MENU button to show on the display. Press the ENTER button and the
display will blink. Use the DOWN and UP button to select the or . Once the
has been selected, press the ENTER button and use the UP and Down button to
select the or .
: For professional users, detailed explanation as followings:










: Mostly automatic mode, for non professional users, detailed explanation as
followings:










(Notice: Other settings are NOT changed while choosing Defaults Setting!)
Press the ENTER button and the corresponding functions will set to defaults setting, to go
back to the functions without any change press the MENU button again. Hold and press the
MENU button about one second or wait for one minute to exit the menu mode.

12A
Reset
Press the MENU button to show on the display. Press the ENTER button and all
channels of the unit will return to their standard position. To go back to the functions without
any change press the MENU button again. Hold and press the MENU button for about one
second or wait for one minute to exit the menu mode.
3.3 Home Position Adjust
In the main functions, hold the Enter button for at least 3 seconds into offset mode, use the
DOWN and UP buttons up to chose , , or , Pressing the
ENTER button and the display will blink. Use the DOWN and UP buttons to adjust the home
position of the Pan, Tilt, Color, Gobo. Once the position has been selected, press the
ENTER button to setup, Hold and press the MENU button for about one second or wait for
one minute to exit the menu mode.
4. How To Control The Unit
You can operate the unit in three ways:
1. Master/slave built-in preprogram function
2. Easy controller
3. Universal DMX controller
No need to turn the unit off when you change the DMX address, as new DMX address
setting will take effect at once. Every time you turn the unit on, it will show on the
display and move all the motors to their ‘home’ position and you may hear some noises for
about 20 seconds. After that the unit will be ready to receive DMX signal or run the built in
programs.

13A
4.1 Master/Slave Built In Preprogrammed Function
By linking the units in master/slave, the first unit will control the other units to give an
automatic, sound activated or synchronized light show. This function is good when you want
an instant show. You have to set the first unit into master mode and select
(show 1) or (show 2) or (show 3) or (show 4) mode. Its DMX input
socket will have nothing plugged into it, and Its master LED will be constantly on and sound
LED will flash to the music. The other units will have to set in slave mode and select
(normal) or (2 light show) mode, Their DMX cables plugged into the DMX
input sockets (daisy chain) and the slave led lights will constantly on.
2-light show
In (slave mode), means the unit works normally and means
2-light show. In order to create a great light show, you can set on the second unit to
get contrast movement to each other, even if you have two units only.
4.2 Easy Controller
The easy remote control is used only in master/slave mode. By connecting to the 1/4”
microphone jack of the first unit, you will find that the remote control on the first unit will
control all the other units functions press the MENU button again.
Stand By
Blackout the unit
Function
1. Sync. Strobe
2. Async strobe
3. Sound Strobe
Show
1-4
1. Press to select color
2. Hold to select gobo
Mode
Sound (LED OFF)
Show (LED
Slow Blinking)
LED ON
4.3 DMX Controller
By using a universal DMX controller to control the units, you have to set DMX address from
1 to 512 channel so that the units can receive DMX signal.
Press the MENU button up to when the is showing on the display. Pressing the
ENTER button and the display will blink. Use the DOWN and UP buttons to change the
DMX512 address. Once the address has been selected, press and keep ENTER button
pressed up to when the display stops blinking or storing automatically 8 seconds later. To go
back to the functions without any change press the MENU button again. If you use please
refer to the following diagram to address your DMX512 channel for the first 4 units：

14A
4.4 DMX 512 Configuration
8 channel modes：

15A
11 channel modes:
GOBO:

16A
4.5 DMX512 Connection
3
2
DMX -
1
COMMON
DMX +
31
2
DMX INPUT DMX OUTPUT
23
1
Termination reduces signal errors and avoids signal
transmission problems and interference. It is always
advisable to connect a DMX terminal.
(Resistance 120 ohm 1/4W)between pin2(DMX-)and
pin3(DMX+) of the last fixture.
1. If you are using a controller with 5 pins DMX output, you need to use a 5 to 3 pin
adapter-cable.
2. At the last unit, the DMX cable has to be terminated with a termination plug. Solder a
120 ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug
and plug it in the DMX-output of the last unit.
3. Connect the unit together in a `daisy chain` by XLR plug from the output of the unit to
the input of the next unit. The cable can not be branched or split to a `Y` cable. DMX
512 is a very high-speed signal. Inadequate or damaged cables, soldered joints or
corroded connectors can easily distort the signal and shut down the system.
4. The DMX output and input connectors are pass-through to maintain the DMX circuit,
when one of the units’power is disconnected.
5. Each lighting unit needs to have an address set to receive the data sent by the
controller. The address number is between 1-512 (usually 0 & 1 are equal to 1).
6. The end of the DMX 512 system should be terminated to reduce signal errors.
7. 3 pin XLR connectors are more popular than 5 pin XLR.

17A
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin 4/Pin 5:
Not used.
5. Troubleshooting
Following are a few common problems that may occur during operation. Here are
some suggestions for easy troubleshooting:
A. The unit does not work, no light and the fan does not work
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.
3. Check the power on LED.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly.
2. If the DMX LED is on and no response to the channel, check the address settings and
DMX polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB
of the unit or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or run alongside to high voltage cables that may
cause damage or interference to DMX interface circuit.
C. Some units don’t respond to the easy controller
1. You may have a break in the DMX cabling. Check the LED for the response of the
master/ slave mode signal.
2. Wrong DMX address in the unit. Set the proper address.
D. No response to the sound
1. Make sure the unit does not receive DMX signal.
2. Check microphone to see if it is good by tapping the microphone
E. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to the PCB is broken.
2. The motor’s drive IC on the PCB might be out of condition

18A
6. Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out
periodically to optimize light output. Cleaning frequency depends on the environment in
which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater
accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every
30/60 days.

19A
EC Declaration of Conformity
We declare that our products (lighting equipments) comply with the
following specification and bears CE mark in accordance with the
provision of the Electromagnetic Compatibility (EMC) Directive
89/336/EEC.
EN55014-2: 1997 A1: 2001, EN61000-4-2: 1995; EN61000-4-3: 2002;
EN61000-4-4: 1995; EN61000-4-5: 1995, EN61000-4-6: 1996,
EN61000-4-11: 1994.
&
Harmonized Standard
EN60598-1: 2000+ALL: 2000+A12: 2002
Safety of household and similar electrical appliances
Part 1: General requirements
Innovation, Quality, Performance
