Luminaire led FFW1212 Series User manual

INSTALLATION GUIDE FOR FFW1212 SERIES
RETAIN THESE INSTRUCTION FOR FUTURE USE
One Lithonia Way, Conyers GA 30012 | 1.800.705.SERV (7378) | www.luminaireled.net | © 2020 Acuity Brands Lighting, Inc. All rights reserved.
Page 1of 3
SAFETY PRECAUTIONS
WARNING - Risk of fire or electric shock. Basic safety precautions should always be
followed when using electrical equipment.
WARNING - This product must be installed in accordance with the applicable
installation code by a person familiar with the construction and operation of the
product and the hazards involved.
WARNING - Disconnect power to all circuits before wiring fixture.
WARNING - Install in accordance with all national, state, and local codes.
WARNING - Do not connect to an ungrounded supply.
WARNING - Read all fixture markings and labels to ensure correct installation of
fixture.
WARNING – Do not apply power to the fixture until the LED Board assembly is
connected to the driver. If power is applied to the fixture prior to connecting the LED
Board assembly to the driver, this will cause the LED Board to fail and void the
warranty.

INSTALLATION GUIDE FOR FFW1212 SERIES
RETAIN THESE INSTRUCTION FOR FUTURE USE
One Lithonia Way, Conyers GA 30012 | 1.800.705.SERV (7378) | www.luminaireled.net | © 2020 Acuity Brands Lighting, Inc. All rights reserved.
Page 2of 3
CAN ICES-005 (A) / NMB-005 (A)
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
ISED CANADA STATEMENT / DECLARATION POUR ISDE CANADA
This class A lighting equipment complies with Innovation, Science and Economic
Development (ISED) Canada Standard for radio interference-causing equipment ICES-
005, 5th edition.
Ce matériel d’éclairage de classe A est conforme avec la norme sur le matériel
brouilleur radio NMB-005, 5ième édition, publié par innovation, science et
développement économique (ISDE) Canada.

INSTALLATION GUIDE FOR FFW1212 SERIES
RETAIN THESE INSTRUCTION FOR FUTURE USE
One Lithonia Way, Conyers GA 30012 | 1.800.705.SERV (7378) | www.luminaireled.net | © 2020 Acuity Brands Lighting, Inc. All rights reserved.
Page 3 of 3
INSTALLATION INSTRUCTIONS
1. Remove Luminaire from carton and check for damage.
2. Remove Lens clamps via 8-32 screws, set aside.
3. Remove Lens, set aside.
4. Remove LED Board Assembly by loosening (4) ¼ hex screws.
5. Unplug the LED Board Assembly from the Driver wires, set aside.
6. Mount fixture to surface using (4) ¼ bolts (not included).
7. Connect all supply wires in accordance with national and local electrical codes.
8. Plug the LED Board Assembly into the Driver wires.
9. Re-install LED Board Assembly using (4) ¼ hex screws. Do not over tighten
10. Re-Install Lens
11. Re-Install Lens Clamps
12. Energize and test.
Lens Clamp
End Cap
Housing
Lens
