DIODE LED TOUCHDIAL User manual

DRY LOCATION
1 OF 2 IG101315-2.0
TOUCHDIAL
™
Remote INSTALLATION GUIDE
®
COLOR-CHANGING
INSTALLATION GUIDE
TOUCHDIAL™RGB/RGBW 4-Zone
Remote Control
1. This product is rated for indoor installaon and is not protected
against moisture.
2. Do not modify product beyond instrucons or warranty will be void.
SAFETY & WARNINGS
QUICK SPECS / MODELS
TOOLS FOR INSTALL
Phillips-head screwdriver
(For mounng TOUCHDIAL Remote Control Mounng Bracket)
SYNCING INSTRUCTIONS
1
Input Operang Frequency
3x AAA 1.5V Baeries
(Not Included) 434MHz / 868 MHz
2
INSTALL TOUCHDIAL RECEIVER SYSTEM
TOUCHDIAL WiFi Hub: DI-WIFI-RF-TRMS
1. 5VDC Adapter
2. 75in. CAT5 / RJ45 Cable
LED Driver TOUCHDIAL Receiver LED Luminaire
V−
V+
V+
W
B
G
R
®
TOUCHDIAL™ Receiver
RECEIVER REPEATER
DATA IN/OUT
V−
D1+
GND
V+
V+
V+
OUTPUT
TO LOAD
POWER
INPUT
LEARNINGKEY
WW
WW
CW
CW
W
W
W
W
D1─
D2+
D2─
V+
V−
L
N
GND
ADDITIONAL TOUCHDIAL COMPONENTS
DI-RF-REM-RGBW-4
DI-RF-REC-CV-A
TOUCHDIAL Receiver
DI-WIFI-RF-TRMS
TOUCHDIAL WiFi Hub
SYNC MASTER RECEIVER TO TOUCHDIAL CONTROL
V−
V+
V+
W
B
G
R
®
TOUCHDIAL™ Receiver
D
ATA IN/OUT
V−
D1+
GND
V+
V+
V+
OUTPUT TO LOAD
POWER
INPUT
LEARNING KEY
WW
WW
CW
CW
W
W
W
W
D1─
D2+
D2─
MASTER SLAVE
d. Luminaire will ash to indicate pairing.
a. Wake up TOUCHDIAL control by
pressing Power buon.
®
S1 S2 S3
W+
1 2 3 4
W
b. Press LEARNING KEY
buon on TOUCHDIAL
MASTER receiver.
®
S1 S2 S3
W+
1 2 3 4
W
c. (1) Press any zone buon on
control, then (2) swipe nger on
color wheel.
V−
V+
V+
W
B
G
R
®
TOUCHDIAL™ Receiver
DATAIN/OUT
V−
D1+
GND
V+
V+
V+
OUTPUT
TO LOAD
POWER
INPUT
LEARNINGKEY
WW
WW
CW
CW
W
W
W
W
D1─
D2+
D2─
MASTER SLAVE
SUPPLIED ACCESSORIES
TOUCHDIAL Remote Control Mounng Bracket
Refer to TOUCHDIAL Receiver Installaon Guide.
®
S1 S2 S3
W+
1 2 3 4
W
Add 3x AAA baeries (not included).

2 OF 2
®Toll Free: 877.817.6028 | Fax: [phone] | www.DiodeLED.com | [e-mail]
© 2015 Elemental LED Inc. All rights reserved. Specicaons are subject to change without noce.
IG101315-2.0TOUCHDIAL
™
Remote INSTALLATION GUIDE
V−
V+
V+
W
B
G
R
®
TOUCHDIAL™ Receiver
D
ATA IN/OUT
V−
D1+
GND
V+
V+
V+
OUTPUT TO LOAD
POWER
INPUT
LEARNING KEY
WW
WW
CW
CW
W
W
W
W
D1─
D2+
D2─
MASTER SLAVE
SYNCING CONT.
Jumper
Header
SLAVE MASTER
SYNCING NOTE
When syncing the TOUCHDIAL Remote, the 1st receiver must be
set to the MASTER funcon as outlined below. See the TOUCHDIAL
Receiver Installaon Guide for more thorough informaon.
Symptom Common Cause
Remote won’t funcon
• Check for dead AAA baeries.
• Remote must be turned on for
operaon (red indicator light on).
Master receiver does not
sync with remote
• Ensure funcon is set to MASTER (1
pin) - See Syncing Note or TOUCHDIAL
Receiver Installaon Guide.
• If sll not syncing do following: 1) Turn
o main power to receiver and turn
back on. 2) Reset receiver by holding
LEARNING KEY for 5 seconds unl LED
ashes. 3) Re-sync receiver to control.
TROUBLESHOOTING
Visit the product web page at www.DiodeLED.com for addional product specicaons & warranty informaon.
TOUCHDIAL RGB/RGBW 4-ZONE REMOTE CONTROL SPECIFICATION SHEET
For full specicaons.
TOUCHDIAL RECEIVER SPECIFICATION SHEET & INSTALL GUIDE
For full specicaons and installaon instrucons.
TOUCHDIAL WIFI HUB SPECIFICATION SHEET & INSTALL GUIDE
For full specicaons and installaon instrucons.
ADDITIONAL RESOURCES
OPERATION
See TOUCHDIAL Receiver and WIFI Hub Install Guide for more
troubleshoong ps.
®
S1 S2 S3
W+
1 2 3 4
W
Color Wheel
Adjust RGB color mixing.
Zone Control
Short press to control zones 1-4. Long
press to turn individual zone ON/OFF.
White Channel Control
Short press to turn CH4 ON/OFF.
Long press to adjust brightness.
RGB Brightness
Press to increase or decrease 8
levels of RGB Brightness.
Power
Press to turn all zones ON/OFF.
RGB ON/OFF & White Presets
Double tap to turn RGB channels ON/OFF.
Short press for 3 variaons of “white” created
with RGB color mixing (Cool, Neutral, Warm).
Useful for applicaons that don’t ulize 4th
channel for RGBW applicaons.
Dynamic Modes
Short press switches mode/pauses
mode. Long press adjusts speed of
dynamic mode. See ‘Dynamic Mode
Chart’ for mode descripons.
Save Funcon
Save up to 3 colors. Long press to
save color. Short press to retreive
saved color.
Power Indicator Mode Descripon
1 Random Fade
2 Random Fade
3 Random Fade
4 Random Fade
5 RGB Fade In/Out
6 RGB Fade In
7 RGB Fade Out
8 RGB Skip
9 Random Fade
10 Random Fade
DYNAMIC MODE CHART
