Directechs PKUCH2GX User manual

REMOTE
SYSTEM
Red
Orange
Green
Blue
Violet (+)
Black
Violet/White
Brown (-)
Pink (+)
(+) 12 VOLT CONSTANT
Pink/White (-)
N/C
N/C
DATA OUTPUT TO VIOLET/BROWN (2ND START WIRE)
+12 VOLT STARTER INPUTTO REMOTE STARTER
DISARM INPUT
IGNITION INPUT
N/C
CHASSIS GROUND
COIL
NOTE:
3 OR 5 TURNS OF LOOP IS REQUIRED
LOCATE THE COILAROUND THE IGNITION KEY
YOU CAN PROGRAM THE TRANSPONDER ONLY ONCE.
Ground when running (remote start installations only)
PKU MODULE PROGRAMMING MODE
You will need 2 valid keys. Proceed as follows:
1-Insert first key and turn to the IGN “ON” position: “THEFT” light will turn ON, then go “OFF”. Remove the first key.
2-Within 5 seconds, insert second key: turn and hold in IGN “ON” position. After approx. 10 seconds, the door chime
will sound** once to indicate vehicle is in programming mode.
YOU NOW HAVE 60 SECONDS TO PROCEED WITH THE NEXT STEP.
3-For the next 2 steps position & hold the PKU module (screw side) towards the front of the ignition barrel (key cylinder).
(Coil Loop is NOT USED during PK programming)
4-Using a jumper wire, power up vehicle ignition, without starting vehicle, for approx. 10 secs. until the “THEFT” light
comes “ON” solid. “THEFT” light will then flash and return back to solid to indicate the PKU module is now
programmed successfully.
IMPORTANT NOTE:
Once the PK (Transponder Bypass) portion has been programmed to a vehicle, it cannot be used on any other
Chrysler vehicle. (This a Chrysler Sentry Key feature from factory.)
**As a reference: door should be left open during programming.
- No wiring harnesses should be connected while programming Transponder Bypass.
- Do not install bypass module on a metal surface.
- Do not install resistor’s they are internal.
TECH NOTE:
Ground When Running (-) (remote Start Installations Only)
N/C
N/C
Data Ouput To Violet/brown 2nd Start Wire (Wire Located In The Steering Column)
12 Volt Starter Input To Remote Starter (Wire In Parallel With Vehicle Start Wire)
Disarm Input (Connect To The Disarm Output From Remote System)
Ignition Input To Vehicle (Connect To Main Ignition Of Vehicle)
N/C
(+)12 Volt Constant
Chassis Ground
WIRE FUNCTIONS
Brown
Green
Blue
Violet/White
Violet
Pink/White
Pink
Orange
Red
Black
10 PIN HARNESS
ST
1 Generation
Connector
ND
2 Generation
Connector
10 PIN HARNESS
Description: Chrysler 1st & 2nd Generation Sentry Key Override with 2nd Start Activation Output (
Functions:
No Key Required)
Installation
Manual (1\3 Pages)
PKUCH2GX
Transponder Bypass Kit for 1st & 2nd generation encrypted Chrysler Sentry key immobilizer systems. This transponder
bypass kit will override all Chrysler, Dodge & Jeep vehicles equipped with the 1st & 2nd generation type of Sentry
transponder key. PKUCH2GX designed with MUX (2nd starter & accessory wire) activation output
Bypass Method: RF override through induction using loop antenna.
which initiates the 2nd
Starter & 2nd accessory wire during start up.

You will need 2 valid keys. Proceed as follows:
1- Insert first key and turn to the IGN “ON” position: “THEFT” light will turn ON, then go “OFF”. Remove the first key.
2- Within 5 seconds, insert second key: turn and hold in IGN “ON” position. After approx. 10 seconds, the door chime
will sound** once to indicate vehicle is in programming mode.
YOU NOW HAVE 60 SECONDS TO PROCEED WITH THE NEXT STEP.
4- Remove cover and PC board from factory remote (See illustration A)
5- Position bypass module on the side of the empty factory remote (See illustration B)
6- Keep the bypass module on the side of the empty factory remote, insert key and turn it to ON position (Ignition) f
The module is now programmed.
7- Close remote and re-install screw.
IMPORTANT NOTE:
Once the PK (Transponder Bypass) portion has been programmed to a vehicle, it cannot be used on any other
Chrysler vehicle. (This a Chrysler Sentry Key feature from factory.)
or a
period of 10 sec, you will hear a chime, the light will turn on for 3 sec. Keep the key at this position for 5 sec. Then,
turn the key off and remove the key.
Illustration A Illustration B
Programming mode for coded key Chrysler with integrated remote
**As a reference: door should be left open during programming.
For key with integrated remote, see optional programming instructions.
PKU-CH2GX Transponder Override module is compatible with 2004 Dodge Durango. A manufactures issue exists with Durango vehicles built before May 17 2004 and
is covered under warranty. The WCM module is defective and does not permit ANY additional RFID codes to be added to the vehicle. This includes new ignition keys
(Sentry keys). Instead of recalling all Durango's for this module swap Chrysler is only changing the WCM when a Durango owner requests a new transponder key.
The WCM does not affect any other functions so is not a mandatory swap unless a new RFID is added. The PKU-CH2GX supplies the vehicles with a RFID and thus
must be programmed like a new key. The WCM will allow additional RFID codes to be programmed if the Mfg date is after May 17th otherwise the original WCM must
be changed under warranty in order to program the PKU-CH2GX to the Durango. The WCM replacement part number is 56038675AS.
For Durango 2004 built before 17/05/04:
Description: Chrysler 1st & 2nd Generation Sentry Key Override with 2nd Start Activation Output (
Functions:
No Key Required)
Installation
Manual (2\3 Pages)
PKUCH2GX
Transponder Bypass Kit for 1st & 2nd generation encrypted Chrysler Sentry key immobilizer systems. This transponder
bypass kit will override all Chrysler, Dodge & Jeep vehicles equipped with the 1st & 2nd generation type of Sentry
transponder key. PKUCH2GX designed with MUX (2nd starter & accessory wire) activation output
Bypass Method: RF override through induction using loop antenna.
which initiates the 2nd
Starter & 2nd accessory wire during start up.
t e e e i eelcot nThis Interface kit / Data Bus In erface part has been t sted on th listed vehicles. Other v hicles w ll badded to th se et vehicle list upon c mpletion of compa ibility testi g.
VwpDISCLAIMER b t eisit ebsite for latest vehicle a plication guide. : Under no circumstances shall the manufacturer or the distributors of the ypass kit / da a bus int rface part(s) be
eb ue y
held liable for any cons quential damages sustained in connection with the part(s) installation. The manufacturer and it’s distri utors will not, nor will they a thoriz an
i a i re
representative or any other indiv dual to assume obligation or li bility in relat on to the interface kit / data bus inte face part(s) other than its rplacement. N.B.:Under no
cs r s b l tsi
cir umstance shall the manufacture and di tributors of this product e liab e for consequen ial damages ustained in connection with th s product and neither assumes nor
o e s p
auth rizes any repr sentative or other per on to assume for it any obligation or liability other than the re lacement of this product only.

© 2007 Directed Electronics. All rights reserved.
LIMITED ONE-YEAR CONSUMER WARRANTY
For a period of ONE YEAR from the date of purchase of a Directed Electronics remote start or security product, Directed Electronics. (“DIRECTED”) promises to the original purchaser, to repair or
replace with a comparable reconditioned piece, the security or remote start accessory piece (hereinafter the “Part”), which proves to be defective in workmanship or material under normal
use, provided the following conditions are met: the Part was purchased from an authorized DIRECTED dealer; and the Part is returned to DIRECTED, postage prepaid, along with a clear,
legible copy of the receipt or bill of sale bearing the following information: consumer’s name, address, telephone number, the authorized licensed dealer’s name and complete product
and Part description.
This warranty is nontransferable and is automatically void if the Part has been modified or used in a manner contrary to its intended purpose or the Part has been damaged by accident,
unreasonable use, neglect, improper service, installation or other causes not arising out of defect in materials or construction.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR
PURPOSE AND WARRANTY OF NON INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME
FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED HEREBY DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES
INCLUDING DEALERS OR INSTALLERS. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF
CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY
LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE PRICE OF THE PART. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY
CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE.
NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR AT DIRECTED’S OPTION THE PART AS DESCRIBED ABOVE.
Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights
and you may also have other rights that vary from State to State. DIRECTED does not and has not authorized any person or entity to create for it any other obligation, promise, duty or obligation
in connection with this Part. 920-0007 07-06
PRODUCT DESCRIPTION
Overrides all generations of Chrysler Sentry key transponder immobilizer
systems. This bypasskit is compatible with both 1st and 2nd generation
Chrysler, Dodge & Jeep Sentry Key transponder immobilizer systems. This
transponder bypass includes a MUX activation output which initiates the 2nd
Starter&2ndaccessorywireduringstartup.NoKeyRequired(NKR).
PRODUCT FEATURES
!Two kits in one :
!compatible with any remote car starter
!compact design
!easy to mount
!simple 2-wire installation
!compatible with manufacturer's anti-theft system
!maintains integrity of factory vehicle anti-theft system
!easy programming
!no extra key required for operation
!activates 2nd start low circuit which saves having to wire in an additional
relay & a resistor value necessary to remote start most late model Dodge and
Chrysler vehicles
Overrides all generations of Chrysler Sentry key transponder
immobilizersystems
PKUCH2GX
CHRYSLER SENTRY KEY
TRANSPONDER RF BYPASS - ALL YEARS
00
9320757052
PROTECTED BY U.S. PATENTS:5,719,551;6,011,460B1*;6,243,004B1; 6,249,216 B1; 6,275,147 B1; 6,297,731 B1;
6,346,876B1; 6,392,534B1; 6,529,124B2; 6,696,927B2; 6,756,885 B1; 6,756,886B2; 6,771,167B1; 6 ,8 12 ,82 9 B1 ;
6,924,750B1; 7,010,402B1; 7,015,830B1; 7,031,826B1; 7,046,126 B1; 7,061,137B1; 7,068,153B1; 7,205,679 B1; CDN.
PATENT:2,320,248; 2,414,991; 2,415,011;2,415,023; 2,415,027; 2,415,038; 2,415,041; 2,420,947; 2,426,670; 2,454,089
EUROPEAN PATENT:1,053,128PAT. PENDING:2,291,306; MADE IN CANADA
Description: Chrysler 1st & 2nd Generation Sentry Key Override with 2nd Start Activation Output (
Functions:
No Key Required)
Installation
Manual (3\3 Pages)
Transponder Bypass Kit for 1st & 2nd generation encrypted Chrysler Sentry key immobilizer systems. This transponder
bypass kit will override all Chrysler, Dodge & Jeep vehicles equipped with the 1st & 2nd generation type of Sentry
transponder key. PKUCH2GX designed with MUX (2nd starter & accessory wire) activation output
Bypass Method: RF override through induction using loop antenna.
which initiates the 2nd
Starter & 2nd accessory wire during start up.
PKUCH2GX
