Kongsberg cNODE MiniS User manual

446008/C/2020–02–28
Chargingthebattery(on-deck)
Chargingthebatteryisconnectedwithsomerisk,
pleasereadtheinformationandfollowthecharge
procedurecarefully
Context
Thebatterymustbefullychargedbeforelong
termstorageanditisrecommendedtorecharge
thebatteryevery6monthstomakesurethe
batterydoesnotdischargecompletelyovertime.
Acompletelydischargedbatterywillnotcharge,
asalllithiumionbatteries.
Requiredbatterystateforairtransportationis
30%orlessremainingcapacitytocomplywith
regulations.
Thebatterychargerwillonlystarttochargeifthe
batterycapacityislowerthan96%.
Caution
EqualizethetemperatureofthecNODEMiniSto
between10°Cand40°Cbeforechargingit.
Foron-deckcharging,usethecNODEbattery
chargeronly.
Neverchargethebatteryunattended.
Procedure
1Switchoffthetransponder.
2Lettheunitwarmuporcooldowntoan
ambienttemperatureof10°Cto40°C
beforecharging.
3ConnectthecNODEbatterychargerplug
(B)totheconnectoronthecNODEMiniS
markedCHARGE(C).
4ConnectthecNODEbatterycharger(A)to
mains(110or220V AC).
Result
TheLEDindicatoronthechargerashesgreen
whencharging.Itnormallytakesabout30
secondsbeforethechargingstartsandtheLED
indicatorstartsashinggreenafterconnectingthe
cNODEbatterychargertothemains.Thebattery
willbechargedwithin1hour.TheLEDindicator
willstaygreenwhenfullycharged.
TurningonthecNODEMiniS
Thetransponderisdesignedforoperationin
wateronly.Thetranspondermaybeoperatedin
airfortestpurposesoverashortperiodoftime.
Prerequisites
Thetranspondermustbechargedbeforeuse.
KongsbergcNODEMiniS
QuickReferenceGuide

Procedure
1GreasetheconnectorwithMolykote44
Mediumorequivalentgrease.
2Connecttheon/offplugtotheendcap
connector.
3Tightenthelockingsleevetotheendcap
connector.
Result
Abuzzcanbeheardwithin25secondsasa
conrmationthatthetransponderisactivated.
Furtherrequirements
Itisrecommendedtotestthetransponderwith
theTestandCongurationunit(TTC)tomake
surethetransponderisworkingproperlybefore
operation.
Connectingthetransponderto
externalpowerandresponder
signals
Prerequisites
Thetranspondermustbechargedbeforeuse.
Thisisthepincongurationforamaleconnector,
asseentowardstheconnector(faceview).
1RS-232Tx
Conguration
2Ground
3RS-232Rx
Conguration
4Responder
trigger+
5Respondertrigger-
6On/Off
7Externalpower(24VDC)
8Ground
Procedure
1Usethecablewithpartnumber402462from
Kongsberg.
2Connectwire6and8inthepigtail(the
ON/OFFfunction).
When6-8arelinked,thetransponderisON.
Withnoconnectionbetween6-8,the
transponderisOFF.
3Makesurethattheexternalpowersupply24
VDCisbetween20and28VDC.
4Checktherespondertriggersignal.
5SwitchONtheunitbyinsertingtheexternal
power/respondercable.
Supportinformation
Shouldyouneedtechnicalsupportforyour
cNODEMiniSyoumustcontactaKongsberg
Maritimeofce.Alistofallourofcesis
providedonourwebsite.Youcanalsocontact
ourmainsupportofceinNorway.
Manualsandtechnicalinformationcanbe
downloadedfromoursupportwebsite.
CompanynameKongsberg
MaritimeAS
AddressStrandpromenaden
50,3183Horten,
Norway
Telephone[phone]
Telephone24hsupport+4733032407
Telefax+4733047619
Websitehttps://www.kongs-
berg.com/maritime/
SupportwebsiteProductsupportA
toZ
E-mailaddresskm.sup-
port.hpr@kongs-
berg.com
446008/C/2020–02–28
