Dirt Devil M084700DLR User manual

Please read these
instructions carefully before
using your cleaner
Let us help you put your
cleaner together or answer
any,questibns, call:
1-800-321-1134 (USA)
1-800-661-6200 (Canada)
web site: www.dirtdevil.com
For quick reference, please record your vacuum
information below.
Model
#:
Mfg. Code:
(This informationis located on the underside of cleaner)
@I 998 All rights reserved #1-480920-033
9/98
Espafiol - pagina El

You are now the proud owner of the Dirt evil cleaner with Power You Can See!
We trust your new purchase
will bring you many hours of satisfaction.
Ourcompany designed and developed this product with you in mind. The power-
fid system delivers superiorcleaning and has a clear dirt container for hksle-free
emptying, eliminating the need to buy bags. It
is a true all-surfacecleaner due to
the unique design that allows the brushroll to be deactivatedfor bare-floor clean-
ing then converts to a "canister style" vacuum for above-the-floor cleaning. A few
extrafeatureshave been added foryour convenienceincludingthe patented Swivel
Casters,Power Edger", and a Quick Cord Clip.
We are very proud of our products and hope that you are equally satisfied with
their qualityand performance.
Thankyou for your supportof Dirt Devil products.
Visit ourwebsite atwww.dirtdevil.com
TABLE OF CONTENTS
. .
Feature Descr~pt~ons .................................................................................... Page 4
Howto Assemble ......................................................................................... Page 4
Howto Operate ......................................................................................... Page 5
HoseAssembly and Tool Storage ................................................... Page 5
FloorICarpetCleaning ......................................................................... Page 5
......................................................................... Above FloorCleaning; Page 6
Hands Free Edge Clean,ing .................................................................. Page 6
Beltor Brush Roll RemovalIReplacement ....... :., ....................................... Page 6
Dirt Container Removaland Replacement ...................................................... Page 7
Filter Removal and Replacement ................................................................ Page 7
Cleaner Storage .................................................................. ..................... Page 8
Troubleshooting ................................................. ......................................... Page 8
LIMITED WARRANTY
To the consumer, RoyalAppliance Mfg. Co. warrants thii vacuum cleaner to be free of defectsin materialorworkmanshipcommencing upon the date of the original
purchase. Refertoyour vacuumcleanercartonforthe lengthof warranty and save your originalsales receipt to validate startof warranty period.
Ifthe vacuum cleaner should becomedefectivewithinthe warranty period, we will repair or replaceany defective parts free of charge. The complete machine must be
delivered
Dreoaid, to any ROYAL Authorized Sales & Warranty Service Station. Please include complete description of the problem, day of purchase, copy of original
salesreceiptandyour name, addressandtelephone number. Ifyou are not near a Warranty Station, callthe factoryfor assistanceat
USA: 1-800-321-1134 1 CANADA:
1-800-661 -6200. Use only genuine Royalreplacementparts.
The warranty does not includeunusualwear, damage resultingfrom accidentor unreasonable use of the vacuumcleaner. This warranty does not cover belts, brushes,
bags, bulbsorfandamage. Thiswarranty does notcover unauthorizedrepairs. This warrantygivesyouspecific legalrightsand youmay alsohave other rights. (Other
rightsmay vary fromstateto state inthe
USA).

CONSUMER INFORMATION
I q
THIS VACUUM ISINTENDEDFOR HOUSEHOLD USE ONLK
I'
IMPORTANT SAFETY INSTRUCTIONS -- SAVE THESE INSTRUCTIONS
When usingan electricalappliance, basic precautionsshouldalways be followed, includingthe following:
READ ALL INSTRUCTIONS BEFOREUSING THIS APPLIANCE
ALWAYS FOLLOW THESE SAWINSTRUCTIONS ,
WARNING - FULLY ASSEMBLE CLEANER BEFORE OPERATING.
WARNING: TO REDUCEnTHE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY
Do not leaveappliance when plugged in. Unplugfrom outlet when not inuse and before servicing.
Do not use outdoors or onwet surfaces.
Do not allow to be usedas a toy. Close attention isnecessarywhen used by or near children.
Use only as described inthis manual. Use only manufacturer's recommended attachments.
Do not use with damaged cord or plug. Ifappliance is not working as itshould, has been dropped, damaged, left outdoors,
ordropped intowater, return
it toa servicecenter.
Do not pull or carry bycord, use cord as a handle, close a door on cord, or pullcord around sharp edges or corners. Do not
runappliance over cord. Keep cord awayfrom heated surfaces.
Do not unplug by pulling oncord. To unplug, graspthe plug, not the cord.
Do not handleplug or appliance with wet hands.
Do not putany object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that
may reduceair flow.
Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
Turn off all controls beforeunplugging.
Use extra carewhen cleaning on stairs.
Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present.
Look onyour vacuum cleanerand follow all labeland marking instructions.
Do not use an extension cord with this cleaner.
Keep your hair, loose clothing, fingers, and all body parts away from moving parts; especially the revolvingbrush.
Do not use the vacuum cleaner without Dirt Containerand filter in place.
Store the vacuum cleaner indoors. Put the vacuum cleaneraway after use to preventtripping accidents.
When assembling the handle make sure all sections are securely fastened (or snapped) together before use.
Approved by the Vacuum Cleaner Manufacturer's Association ExecutiveCommittee, April
29, 1987.
WARNING: TO reduce the risk of electric shock, this appliance has apolarized plug (one blade is wider than the other). This plug
will
fit ina polarizedaoutletonly one way. If the plug does not fit fully inthe outlet, reversethe plug. If it stilldoes not fit, contact a qualified
electricianto installt6e proper outlet. Do not change the plug in any way.
Your cleaner contains
a Thermal Protector that turns off power to the motorto avoid overheating. If this happens, turn switch
off and unplug thecleaner. Inspectthe exhaust, inlet, hose, andfilters for any blockage. After approximately
30 minutes the motor
will have cooled and the vacuum will be ready to use.
NOTE: The cleanermust remain unplugged during the 30 minute coolingperiod.
NOTE: RETURN WARRANTY CARD TO REGISTER YOUR CLEANER
MAINTENANCE: Proper maintenance of your cleaner will assure continued effective cleaning performance.
1. Always use genuine Royalreplacement parts.
2. Clean-out DirtContainer frequently.
Q 1998 All rights reserved

Fia. 1
l-n -
Fiq. 2
Fia 1
1. Easy HangingHandle
2. Handle(Extension Wands)
3. CreviceTool
4. Power EdgerTM
5. 2 -in -1 Tool - Dust BrushIUpholsteryTool
6. DirtContainer
7. Wrap Around Bumper
8. Power EdgerTMSlots
9. Bare FloorlCarpetCleaningSelector
10. Exhaust Filter
11. RemovableTool Caddy
12. Tool Caddy Storage Hook
13. Quick Cord Clip
Fiq. 3
FEATURES
Fig 2
1. CreviceTool
2. Power Edger" Tool
3. 2-in-1 Tool- Dust BrushIUpholsteryTool
Fia. 3
1. Long Power Cord
2. OnlOff Pedal
3. Swivel Casters
4. HandleReleasePedal
5. HoseAttachment Rings
6. Stretch Hose
Hose handleclipsto back of wand
HOW TO ASSEMBLE
Removethe cleaner nozzle, two wands and handlegrip from the box.
Slide two wands together untilthey latch (they only fit together one way) (Diagram 1). Hose handleclips to back of wand.
Place handlegrip into the wand you just assembledand snap into place (Diagram
2).
Slide lower portionof handleassembly intothe handle pivoton top of the vacuum base and snap into place. (Diagram 3).
Warning:Make sure all handle pieces are securely fastenedprior to use.

1. Slide one end of hose intothe handle and twist clockwise to lock (Diagram 1).
2. Slide other end of hose into the rear of the nonleon the right side and twistclockwise to lock. (Diagram 2).
3. Attach three hoseanchorsto handleclips on back of handle to hold hose inplace. (Diagram 3).
AJTACH TOOLS
1. Align bottomof Tool daddy to grooveson sides of handle. Snaptop of Caddy inplaceand slidedown on the handle pivot. Tool Caddy includes: Crevice tool,
poweredger, and 2-in-1 tool (Diagram
4).
2. The hookonthe Tool Caddy allows unitto hang incloset when not in use.
QUICK CORD RELEASE
1. Looselywrap cord inhand. Press Quick Cord Clip, locatedon the left side of upper handle, and inserttop portionof wrapped cord intoclip./Diagram5).
1. Cord
Retainel
2. Power
ONIOFF
Pedal
HOW TO OPERATE
1. Plugcord intoelectrical outlet and clipcord intocord retainer providedon upper handle. Your cord will stay up and out of your way while you vacuum.
lDiaaram
1).
2. turnclean& on by usingthe power switchfoot pedal, locatedonthe leftside of the nonle. Depressfoot pedalonce to turn "on". Depressfoot pedalagain to
turn the cleaner"off'. (Diagram
2).
3. To put handleinthe operating position, place foot on the handle releasefoot pedal, located on the right side of nonleand lower handle (Diagram 3)
BAREFLOORKARPET CLEANING
Theselector on the topof the cleaner is foradjusting toand from carpet and bare floor cleaning.
Impotiant: Turncleaner "ON" to select "Barefloor/Carpet" position.
5. Back position - Activates brush rollfor "Carpet" cleaning. (Diagram 5).
6. Middle position - Stops brush roll for "bare floor" cleaning. (Diagram 6).
7. Forwardposition - Closes nonlefor above floor cleaning. (when usingtools) (Diagram 7).
CAUTION: Do not use without Dirt Container and Filter in place.
5

ABOVE FLOOR CLEANING
Important: Turn cleaner "ON" to select "Barefloor/Carpet " posifion.
1. (Optional) Removethe tool caddy before usingthe power edger and extensiontools. (Diagram 1).
2. Forwardpositionclosesthe nozzle for above floor cleaning.(Oiagram 2).
3. Open Tool Caddy to retrievetools. Top: Crevice Tool, middle: Power Edger Toolw, bottom: 2-in-1 BrushTool (Diagram 3).
CREVICE TOOL AND 2-IN-1 TOOL
1. Unclipthe top hose clip from the hose anchor on the wand (Diagram4)
2. Remove upper handle by pressingthetab on the back side of the wand to unlatch; Pull up to remove. (Diagram
5).
3. Choose either of the handy accessories. Simply pushthe attachment firmly onto the end of the hose handle. To remove tool, twist and pull apart gently.
(Diagram
6 and 7). NOTE: Brush slides off 2-in-1 to use for upholsterycleaning.
EXTENSION WAND TOOL
I. Unclip the hose clip from the hose anchor on the wand (Diagram 1).
2. To use the extension wand, remove the handle at the desired length by pressingthe tab to unlatch the wand, either at the base of the vacuum or in th
middle of the handle (Diagram 2 and 3).
3. If you chooseto use an additional tool, pushthe attachmentfirmly onto the end of the wand (Diagram 4).
4. When the brush roll is deactivatedand the extension wand is used with the attachments-The vacuum functions as a canister style vacuum.
FOR HANDS FREE EDGE CLEANING:
1. Remove the toppfthe hose from the handle (Diagram 5), and the hose clip from the top hose anchor on the wand (Diagram 1).
2. Remove Power Edgerw from the Tool Caddy. Insert Power Edger intodesired power edger slot at front of nozzle. Slide hose end onto Power Edger". Glid
the cleaner against walls and baseboards for superioredge cleaning (Diagram
6).
CAUTION: Do not use without Dirt Container and Filter in place.

BELT OR BRUSH ROLL REMOVAL & REPLACEMENT
WARNING: TO REDUCE-THERISK OF INJURYFROM MOVING PARTS - UNPLUG BEFORE SERVICING.
Tool required: Phillipsscrewdriver
and flat headscrewdriver
TO REMtIVEBELT OR BRUSHROLL:
1. Turn cleaner over. Nozzle baseshouldlay flat and face up (Diagram 1). To remove nonle guard, use phillipsscrewdriverto remove two screws. Arrows
indiagram
1 show locationof screws. Gently pop nonleguard off withtip of flat head screwdriver(Diagram 2). Pullup and out on rear of nodeguard.
-. .
2. Lift and remove brush roll (Diagram 3).
BELT OR BRUSH ROLL REMOVAL & REPLACEMENT
NOTE: This cleaner uses 2 belts. One isconnected from the stop brush pulley to the brush, and the other is from the motor to the pul-
l....
TO REPLACE BELT OR BRUSH ROLL:
FRONT BELT:
. - . - . - -- - -
1. To replacethe front belt, loop beltaround pulley. Place belt onto brushroll.
2. Pulland insert brushroll into holder with flat brush endcap edge facing out. Rotate brush roll manually to make sure belt is nottwisted (Diagram
2).
REAR BELT:
3. To replacethe rear belt, removethe front beltfirst then remove rear belt. Place the new belt aroundthe middle pulley, use a flat head screwdriverto place
the beltaroundthe rear motor shaft (Diagram 3). (Do
NOT use a phillipsscrewdriverto do this) Replacefront belt.
4. Replace nozzle guard. Matchthe front tabs to the slots on the nozzle base. Push firmly on top end of nozzle guard to fit into place. Secure by replacing
screws.
CLEANING DlRT CONTAINER & FILTER
WARNING: TO REDUCE THE RISK OF INJURY FROM MOVING PARTS - UNPLUG BEFORE SERVICING.
REMOVE
& EMPTY DlRT CONTAINER: For best results empty dirt containerafler each use.
1. Removedirtcontainer by lifting from the back. Pull dirt containerstraight up and out of nozzle to empty and clean (Diagram 1).
2. Pullfilter out of dirt container (Diagram 2) and shake dirt from filter (Diagram 3).
CLEANING DlRT CONTAINER:
1. Use a sponge and lukewarmwater to wipe compartmentclean.
7

FILTER REMOVAL & REPLACEMENT
WARNING: TO REDUCE THE RISK OF INJURYFROMMOVING PARTS - UNPLUG BEFORESERVICING
REMOVE
& CLEAN OR REPLACE FILTER:
1. To replacefilter-remove filter frame from filter. Discardold filter. Reattach new filter tofilter frame b!&!~ placing back intodirt container (Diagram 1).
2. Filter replacements can be ordered by calling toll free 1-800-321-1134. Filterpart# 3-480230-001. Exhaust Filter part # 3-480480-001 .
3. With dirt container removed. (the SecondaryFilterinthe small opening inthe back can be removedand cleaned). (Diagram 2). The exhaust filter onthf
top of the cleaner can also be removedand cleanedwith the dirt container removed. (Diagram
3).
4. Place the tab onthe front of the dirt container inthe hole onthe front of the cleaner when returning the dirt container to its position. (Diagram 4).
TOOL AND VACUUM STORAGE
1. For easy storage release handle by depressingthe handle releasefoot pedal, on the rightside of nozzle. (Diagram 1).
2. The upper handlegrip allows this unit to hang flat ina vertical position (Diagram 2).
3. The hook onthe Tool Caddy allows unit to hang incloset when not in use. (Diagram 3).
--
IMPORTANT: UNPLUG CLEANER BEFORESERVICING
Cleanerwon? pick-upor low suction
Dust escaping from cleaner
CUSTOMER SERVICE: inthe event that further assistance is required, see your Yellow Pages for an authorized Royal Dealer. Costs of any transportationto and from a1
place of repairareto be paidby the owner. The service partsusedinthis unitare easily replacedandreadilyavailablefrom an authorized RoyalDealeror retailer. Always identifyyour cleal
er by the model numberand manufacturer code when requesting information or ordering replacementparts. (The model number
MFG code appears on the bottomof the cleaner.)
POSSIBLE SOLUTION
1. Motoroverheating - Pg. 3
2. Plug unitinfirmly.
3. Take to service center or call 1-800-321-1134.
4. Check fuse or breaker. Replacefuseheset breaker.
Or flipoutlet switch.
PROBLEM
Cleaner won't run .
POSSIBLE REASON
1. Motor Protectortripped
2. Powercord not firmly pluggedintooutlet.
3. Needs Service.
4. No power inwall plug.
1. Brushrollturned off.
2. DirtContainer full andlor filter clogged.
3. Brushroll worn.
4. Brokenor worn belt.
1. DirtContainer full andlor filter clogged.
2. DirtContainer not ~nstalledcorrectly.
3. DirtContainer cracked.
4. No DirtContainer in cleaner.
I. Turn Brush rollon. Pg. 5
2. Empty Dirt Containerandlor clean filter - Pg. 7
3. Replace brush roll - Pg. 7
4. Replace belt - Pg. 7
1. EmptyDirtContainerandlor clean filter - Pg. 7
2. Review Di? Containerinstallation - Pg. 7
3. Replace Dirt Contamer.
4. Install Dirt Container.
