Discount Car Stereo A2DIY-CHRY02 Instruction Manual

Courtesy of: DiscountCarStereo.com
Serving the internet community since 1995
A2DIY-CHRY02
QUICK START INSTALLATION GUIDE FOR CHRYSLER CD CHANGER CONTROLLING RADIOS (MODE BUTTON)

PRODUCT SAFETY & DISCLAIMER
READ ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING, FAILURE TO DO SO MAY CAUSE
PERSONAL INJURY OR DAMAGE TO PRODUCT AND/OR PROPERTY
•This installation guide is provided as a GENERAL installation guide, some vehicles vary and
may require additional steps. We do not accept responsibility for third party labor charges
or modifications. Exercise due-diligence when installing this product.
•We do not accept any responsibility for vehicle damage or personal injury resulting from
the installation of this product.
•Careless installation and operation can result in equipment damage.
Requirements:
CD CHANGER CONTROLLING RADIO
Introduction –newest version 6.9
The A2DIY-CHRY02 wirelessly connects mobile devices to Chrysler radio system
allowing for Smartphone hands-free calls, music streaming, turn-by-turn
navigation, and more. A wireless connection means no wires, clutter or
complicated setup. The A2DIY-CHRY02 solution connects to the 10-pin CD
changer/Sat radio port which guarantees to best possible sound. In addition to
Bluetooth, users can also connect and play other devices through the module
AUX input jack and use included media remote to switch between sources, adjust
volume, change tracks, answer/end calls and more.
See Frequently Asked question at the end of this guide for details.
If installing module purchased prior to 6/9, click here.
Installation
Radio must be removed from dashboard to gain access to the connectors.
Vehicle specific radio removal is not part of this guide; however, they are
available upon request.
With radio out;
1. Connect harness 10-pin plug (See Fig. 1) to radio 10-pin connector, (See Fig.
2) Any factory option (satellite radio, CD changer etc.) plug already in place,
must be permanently disconnected.
Fig. 1
10-pin plug
Fig. 2
Radio 10-pin connector
2. Connect included 3.5mm male-male cable (See Fig. 5) to module “AUX”
input jack (See Fig. 6), and route audio cable to where audio device will
reside (within 3 ft.,)
Fig. 5

Fig. 6
3. Install microphone to visor or headliner using included visor clip (See
Fig. 8).
Fig. 7
Microphone
Fig. 8
Visor clip
4. Route microphone plug down pillar, under dashboard and into radio
cavity and connect to module “MIC” input (See Fig. 6)
Excursive caution when routing microphone so to not damage the
cable and ensure no ventilation duct is pointed towards
microphone.
Optional charging kit (not for thumb drives etc.)
Optional charging kit can be added to support BC1.2, QC2.0, QC3.0, PE1.1, PE2.0,
FCP, SFCP fast charge protocols (Samsung, Huawei etc.).
Features:
» Input voltage: 6-24V DC
» Working current: 30mA
» Default output voltage: 5V or 3V-12V (device dependent)
» Max output power: 24W
Should you decide to add it, we suggest one of 3 connecting options:
A. Flush to dash/panel requires drilling a ¾” hole
B. Flush with Support bracket (Mount USB terminal wherever your installation
demands without drilling)
C. USB port- (freestanding- default)
A. Flush to Dash or Panel (drilling required)
1. Drill a ¾” hole in the dash or panel using a step drill bit or equivalent (See
Fig. 9)
Fig. 9
Step drill bit

2. Insert supplied 3ft. USB male terminal (See Fig. 10) through hole created in
step 1 and connect to module USB port (See Fig. 11)
Fig. 10
Fig. 11
3. Snap USB header (See Fig. 12) in place and flush with mounting surface
(See Fig. 13)
Fig. 12
header
Fig. 13
Flush mounted to dash
B. Bracket Mount (No drilling)
1. Locate a flat surface at location of choice within 3.2 ft. of module and mount
USB support bracket (See Fig. 14) to surface using adhesive/tape or
screws (included).
Fig. 14
USB mounting bracket
2. Insert male terminal through hole in bracket (See Fig. 15) and connect to
USB port (See Fig. 13)
Fig. 15
3. Snap USB head (See Fig. 15) to bracket until flush (See Fig. 16)
Fig. 16
4. Connect BLACK wire to ground (radio chassis, radio ground wire etc.), and
RED or YELLOW to accessory or battery supply. Your choice!
Tuck away any extra wires and verify BLUE LED is lit.

Pairing and connection
Pairing varies among devices but basic steps are the same. This process is done
upon initial install and will not have to be repeated.
1. Turn ignition and radio “ON”
LED inside module peephole will flash rapidly (pairing mode)
2. Open device (e.g., Smartphone) Bluetooth Settings
3. Verify Bluetooth is enabled otherwise turn it on
4. Tap Scan or search for devices .
5. Wait for Bluetooth device name (See Fig. 17) to appear and tap it. Once
paired confirmation tone is heard on car speakers
Fig. 17
Warning: Caller ID and text are not shown on radio display. Operate
Bluetooth device via wireless remote control, VR (voice recognition) or
device built-in controls. Radio buttons can be used to adjust playback
level
Media remote control
Pairing:
Ensure Bluetooth is enabled on your device (e.g., Smartphone/Tablet etc.)
Press and hold pause/play until Blue LED begin flashing
Scan smartphone for available devices and select BT009 from list. (Blue LED
turns off).
Installation:
Attach the button to steering wheel (includes holder) or attach to dashboard
using included double sided tape –your choice.
Because the media button pairs with your Smart device, it can also be used at
home, in the park or wherever you decide to play your tunes.

Operation:
Once paired with smart device (e.g., Phone, Tablet, etc.), users may perform the
following functions on iOS with Bluetooth 3.0 and later or Android 4.0 or later.
Media remote control functions applies to smartphone NOT Chrysler radio.
Charging:
Media remote control built-in rechargeable 200mAH battery may last up to 10
days. Connect included USB cable to charge charging port at the back.
Red LED indicates charging; a full charge is reached after 2 hours at which time
LED turns off.
Bluetooth operation
1. Turn ignition and radio “ON”
2. Press “MODE” button on radio to enter Bluetooth mode (See Fig. 18)
Fig 18
3. Launch streaming application (e.g., Pandora, Apple music etc.)
4. Use device built-in control or Bluetooth media button to change tracks,
adjust device volume, pause/play etc.
5. Place test phone call or ask someone to call. Press media button
“Pause/Play” button to accept call and end call.
Use media button Pause/Play to switch between AUX playback
and Bluetooth.
6. If correct operation is confirmed go ahead and reinstall radio.
Warning: Use smartphone built-in controls to access applications
Notes:
1. If playback is distorted or low, adjust volume on Bluetooth device.
2. On incoming calls, ring tone plays on car speakers (radio must be in CD
mode)
3. Bluetooth range is approximately 30 ft. make sure device is within
range
4. Muting the car speakers is possible only if radio is in “CD” mode. If in
AM/FM mode, muting is not possible.
5. *Media remote does not control Chrysler radio/Aux functions. Use
radio buttons as customary and AUX device buttons for music selection
and controls.
If successful go ahead and reinstall radio

Frequently asked questions & troubleshooting
1. Does the A2DIY-CHRY02 work on all Chrysler 10-pin radios?
NO; Works on Chrysler CD changer ready radios with “MODE” button, DISC
up on Preset #1 (these buttons indicate radio has cd changer controls)
Not applicable to radios with MODE button without “DISC” markings
preset 1/5
Fig. 19
2. My “rounded face” has a CD-C button. Will the A2DIY-CHRY02 work?
NO, Radios with CD-C button and 8-pin socket requires our A2DIY-CH98.
3. My 2002 radio does not have a Mode button, will this adapter work?
NO; Radios without “MODE” button are NOT capable of connecting to this
device. The A2DIY-CHRY02 Works only on radios described in question 1.
4. Can I use the A2DIY-CHRY02 for hands-free calls?
YES; The A2DIY-CHRY02 supports hands-free calls.
5. Will I have to disconnect Satellite radio or remote CD changer?
YES, any factory option already in place must be disconnected.
6. Will I be able to play aux device without pairing smartphone?
YES, It is not necessary to pair smartphone in order to listen to an aux
device. Simply connect aux device, press Mode button on radio. To switch to
music streaming; press media Pause/play button.
Disclaimer
• This product has no affiliation with Chrysler
• We’re not liable for misuse of this product.
•We recommend professional installation
For support email [e-mail]
